Crestron C2-AUDIO-6PAK User manual

Crestron C2-AUDIO-6PAK
Six-Zone Audio Package
Reference Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
2003 Crestron Electronics, Inc.

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
Contents
Six-Zone Audio Package: C2-AUDIO-6PAK 1
Introduction ...............................................................................................................................1
Hardware Setup ......................................................................................................................... 2
Identity Code ...............................................................................................................2
Network Wiring........................................................................................................... 4
Audio Source Wiring...................................................................................................6
Advanced Wiring ........................................................................................................7
Software Setup........................................................................................................................... 8
Software System Requirements...................................................................................8
Installation via the Crestron Audio Six-Pack CD........................................................ 8
Installation of Crestron Application Builder ...............................................................9
Three Step Configuration ............................................................................................9
System Operation.....................................................................................................................18
On/Off Button............................................................................................................18
Volume and Mute Buttons......................................................................................... 18
Source Selection and Control ....................................................................................19
Priority Override........................................................................................................19
Audio Configuration................................................................................................................ 19
Setup Modes..............................................................................................................20
Room Setup Mode Operation.................................................................................... 20
Source Setup Mode Operation................................................................................... 21
Problem Solving ......................................................................................................................22
Troubleshooting......................................................................................................... 22
Firmware Upgrades ...................................................................................................22
Future Updates .......................................................................................................... 22
Appendix A: Swapping Control Systems ................................................................................23
Appendix B: Notice to CNX-AUDIO-6PAK Users ................................................................ 24
Software License Agreement................................................................................................... 25
Return and Warranty Policies ..................................................................................................27
Merchandise Returns / Repair Service ...................................................................... 27
CRESTRON Limited Warranty.................................................................................27
Reference Guide – DOC. 8188B Contents •i

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
Six-Zone Audio Package:
C2-AUDIO-6PAK
Introduction
The C2-AUDIO-6PAK, or Audio Six-Pack, is a complete package of 15 high-
performance components plus programming software, all specially designed to work
together. This packaged solution requires only minimal configuration and quick
setup for a 6-zone audio distribution system. It is also an excellent way to start a
basic system that is fully expandable for future upgrades. When enhanced with
additional Crestroncomponents and accessories, the package becomes the
foundation for a truly sophisticated home control and automation system.
Functional Summary
• 6-zone audio distribution system
• 15 component audio package provides six zones of audio control
• Minimal configuration and quick setup
• Simple Wizard-type programming
• Fully expandable to complete control and automation system
• Domestic and international models with user interfaces available in
three different colors
• Built-In 10/100 BaseT Ethernet port (CP2E option only)
• Built-In Web Server (CP2E option only)
The keypads packaged with the Audio Six-Pack are available in three different
colors: almond (A), black (B), and white (W). The exact color is denoted by the A,
B, or W suffix and the end of the sort name (e.g., the C2-AUDIO-6PAKA includes
almond-color keypads). Depending on which package is selected, the CP2 or CP2E
is the control system that contains the software program and provides connectivity
for communication and control of all devices within the package. The CP2E is
functionally identical to the CP2, with the exception that it also provides LAN and
Web access through its built-in 10/100 BaseT Ethernet port, which supports
dynamic/static IP addressing and full-duplex TCP/IP and UDP/IP protocols. The
type of control system is denoted in the first portion of the name; either ‘C2’ for the
CP2 or ‘C2E’ for the CP2E. Furthermore, the Audio Six-Pack is available as a
domestic or international system. All of the features are identical between the two
with the exceptions of the international AC power requirements and the unit
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •1

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
nomenclature of some components in the package. Throughout this guide, all
references to C2-AUDIO-6PAK apply to the different user interface colors, type of
control system, and their respective international versions as well, except where
noted.
The C2-AUDIO-6PAK is anchored by the Crestron 2-Series control system (CP2 or
CP2E) and the CNAMPX-12x60 Multi-Channel Power Amplifier. The CNAMPX-
12x60 provides 12 channels of amplification with power specifications of 60 Watts
per channel (WPC) at 8 ohms, 90 WPC into 4 ohms and 220 WPC bridged at 8
ohms. Use a bridged wiring configuration to provide over 200 watts of power to
each speaker. Bridging channels requires a Crestron CNXBRMO Mono Converter &
Bridge (not part of the Audio Six-Pack). For more information on bridging channels,
refer to “Advanced Wiring” on page 7.
NOTE: Cresnetcable is not included with the C2-AUDIO-6PAK. It must be
procured separately.
The complete list of hardware components includes:
• CP2 or CP2E, control system
• CNAMPX-12x60, multi-channel amplifier (domestic model) or
CNAMPXI-12x60, multi-channel amplifier (international model)
• CNPWS-75, external power supply (domestic model) or
CNPWSI-75, external power supply (international model)
• CNX-PAD8A, professional audio distribution processor
• C2N-DBF12, 12-button function keypad (quantity six keypads per pak)
• C2N-HBLOCK, multi-type network distribution block.
• IRP2, Cresnet Infrared Emitter (quantity four per pak)
Also included with the C2-AUDIO-6PAK is the Crestron Audio Six-Pack CD
(version 1.2), which contains among other software, the Audio Six-Pack Wizard.
This Wizard provides an easy-to-follow configuration of the entire six-zone audio
system.
NOTE: The Wizard in the Crestron Audio Six-Pack CD (version 1.2) allows a
system to be configured with either a CP2 or CP2E processor. If a different processor
is part of your system, use the Crestron Application Builder™ (AppBuilder) after
completing the steps in the Wizard to swap control systems. Refer to “Appendix A:
Swapping Control Systems” on page 23 for details.
NOTE: An earlier version of the CD is compatible with the CNX version of the
Audio Six-Pack. Only the software on the Crestron Audio Six-Pack CD (version 1.2
and later) works correctly with the C2-AUDIO-6PAK. Refer to “Appendix B: Notice
to CNX-AUDIO-6PAK Users” on page 24 for making changes to an existing CNX-
AUDIO-6PAK system.
Hardware Setup
Identity Code
Every equipment and user interface within the network requires a unique identity
code (Net ID). These codes are assigned a two-digit hexadecimal number from 03 to
2 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
FE. For your convenience, all hardware devices in the C2-AUDIO-6PAK have been
assigned unique Net IDs. However, the six keypads are zone specific. Be sure to
install the given user interface into the appropriate room as defined in the Crestron
Audio Six-Pack Wizard. Each keypad is physically labeled with the Net ID in the
barcode label. The room/Net ID key is as follows:
• Room 1 contains keypad with Net ID = 4C
• Room 2 contains keypad with Net ID = 52
• Room 3 contains keypad with Net ID = 53
• Room 4 contains keypad with Net ID = 54
• Room 5 contains keypad with Net ID = 55
• Room 6 contains keypad with Net ID = 56
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •3

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
Network Wiring
Refer to the network wiring diagram, shown below, when making all network
connections between the hardware devices of the C2-AUDIO-6PAK.
NOTE: Cresnet cable is not included with the C2-AUDIO-6PAK. It must be
procured separately.
43
ROOM INPUTS
ROOM OUTPUTS
8 OHM / 60 WATTS
4 OHM / 90 WATTS
MADE IN THE USA DATE:
3 4
+ - + -
+ -+ -
ATTENTION:
POUR LA PROTECTION CONTRE LES RISQUES D'INCENDIES
N'UTILISEZ SEULEMENTLE MEMES TYPE DE FUSIBLE.
DEBRANC HEZ LE CABLE D'ALI MENTATION AVANT DE
CHANGERLE F USIBLE.
CAUTION:
FOR CONTINUED PROTECTIONAGAINST FIRE
HAZARD USE ONLYSAME TYPE AND RATING FUSE.
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE.
OVERRIDE/SETUP
Z
NET
G
PWR
NET
24
Y
5
120V AC 60Hz
1440 WATTS MAX.
12A 125V
6
+ - + -
+ -+ -
65
21
LEFT
RIGHT
CRESTRON
USA07647N.J.ROCKLEIGH,INC.ELECTRONICS,
LEFT
RIGHT
1 2
+ - + -
+ -+ -
PRECAUCION:
PARA LA PROTECCION CONTINUADA CONTRA EL USO DEL
RIESGO DE INCENDIOSUSE SOLAMENTE ELMISMO TIPO Y
FUSIBLE DEL GRADO. DESCONECTE LA CUERDA DE LA
FUENTE ANTESDE CAMBIAR EL FUSIBLE.
AUSTAUSCHEN.
GERAT VOMNETZ BEVOR SIE DIE SICHERUNG
AUFGRUND BRANDSCHUTZRECHTLICHER BESTIMMUNGEN,
ACHTUNG:
BITTE NUR SICHERUNGEN DES SELBENTYPS UND MIT DER
SELBEN BELASTBRAKEIT VERWENDEN. TRENNEN SIE DAS
CNAMPX-12x60
ROCKLEIGH,
INFRARED - SERIAL OUTPUT
ATTACH IRP2 AS DESCRIBED IN
LATEST REVISION OF DOC. 8168.
4
CRESTRON
INC.ELECTRONICS,
1 2
1
RIGHT
LEFT
SOURCES
2 3
3
CNX-PAD8A
CP2 or CP2E
G
D
S
COMPUTER NET
G Z Y
24
24VDC 24W
A
S G S G
B
SG
C
07647N.J.
4 75 6
765
8
8
ROOMS
2
RIGHT
LEFT
1
G
RELAY OUTPUT
S GS GS GS G
E F G H
I/O
1 2 3 4 5 6 7 8 G
1 2 3 4 5 6 7 8
RISQUE DE CHO C ELECTRIQUE NEPASOUVRIR
RISK OF EL ECTRIC SHOC K
AVIS:
CAUTION
DO NOT OPEN
3 654
24 ZY G
NET
SETUP
7 8
Rockleigh, N .J. 07647 USA
COM A COM B
CRESTRON,
COM C
24VDC
2.0A
KEYPAD
NETWORK
WIRING
CONNECTOR
KEYPAD
NETWORK
WIRING
CONNECTOR
KEYPAD
NETWORK
WIRING
CONNECTOR
C2N-HBLOCK
ATTACH EXTER NAL
POWER SUPPLY
AS DESCRIBED IN
LATEST REVISION
OF DOC. 8091.
KEYPAD
NETWORK
WIRING
CONNECTOR
SIDE
VIEWS
OF
C2N-DBF12
(QUANTITY 6)
KEYPAD
NETWORK
WIRING
CONNECTOR
KEYPAD
NETWORK
WIRING
CONNECTOR
NOTE:
DEVICES ARE NOT DRAWN TO SCALE.
CONNECTORS
C2N-HBLOCK
ALL
1
A
CRESTRON
B
24
Y
Z
G
Y
24
Z
G
2
C D
24
Y
Z
G
Y
24
Z
G
43
PAR ALL ELINARE
a
POWER
E
24
Y
Z
G
Y
24
Z
G
65
cb
Y Z
8
Y
24
Z
G
7
4 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
Four-Wire Network Connector
The four-wire network cable is used to provide power and communications with
Crestron devices. Before making any four-wire network connections, refer to the
following network interconnection diagram and the cautions that follow.
Recommended Network Cable, Liberty Wire Reference: Cresnet
NETWORK DEVICE
BLACK
WHITE
NETWORK
TO OTHER
DEVICE
GROUND SHIELD AT CONTROL SYSTEM END ONLY.
RECOMMENDED COLOR CODE
BLACK
WHITE
BLUE
RED
GND =
24
=
=
=
Z
Y
PAIR B
(18 AWG
PARALLEL)
PAIR A
(22 AWG
TWISTED)
CONTROL SYSTEM
PARALLEL
G
TWISTED
PAIR A
PAIR B
Y
24
FRONT VIEW
Z
TO
WHITE 22 AWG
RED 18 AWG
BLUE 22 AWG
BLUE
SHIELD
BLACK RED
G
FRONT VIEW
24
Y
Z
24
Z
G
FRONT VIEW
Y
TO
CAUTION: Possible equipment damage if miswired.
NOTE: Do not power up system until all wiring is verified. Care should be taken to
ensure data (Y, Z) and power (24, G) connections are not crossed.
NOTE: A C2N-HBLOCK, multi-type network distribution block is provided as part
of the Audio Six-Pack for testing purposes and convenience of wiring.
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •5

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
CAT5 Wiring
CAT5 wiring can also be used to connect Crestron devices. Before making any
CAT5 connections, refer to the following network interconnection diagram and the
cautions that follow.
CAT5 Interconnect Drawing
PAIR D (NOT SHOWN)
PAIR A
PAIR B
PAIR C
TWISTED
ORANGE AND WHITE w/ORANGE STRIPE
BROWN AND WHITE w/BROWN STRIPE
GREEN AND WHITE w/GREEN STRIPE
RECOMMENDED CATEGORY 5 CABLE COLOR
WHITE w/BLUE STRIPE=
=
=
=
=
Z
SPARES
24
Y
GND
BLUE
TWISTED PAIR D
UNUSED (NOT SHOWN)
TWISTED
PAIR C
CODE
1 TO 1 PINOUT
REFERENCE
24
Y
Z
G
24
G
Z
Y
FRONT VIEW
TWISTED
PAIR B
G
Y
Z
24
TWISTED
CONTROL SYSTEM
PAIR A
TO
w/BLUE STRIPE
WHITE
BLUE
PAIR C
TWISTED
24
FRONT VIEW
TWISTED
PAIR A
Z
Y
G
NETWORK DEVICE
TWISTED
PAIR B
PAIR C
TO
24
FRONT VIEW
PAIR A
TWISTED
Y
G
Z
NETWORK DEVICE
TO
CAUTION: Possible equipment damage if miswired.
NOTE: Do not power up system until all wiring is verified. Care should be taken to
ensure data (Y, Z) and power (24, G) connections are not crossed.
NOTE: To calculate maximum CAT5 cable length, use the following equation:
L = 3000/PF
where L = maximum cable length (feet)
PF = total power factor for equipment on run (watts).
NOTE: For additional information on audio/video connections over CAT5, refer to
the latest version of the Crestron CAT5 Wiring Reference Guide (Doc. 6137), which
is available from the Downloads | Product Manuals section of the Crestron website
(www.crestron.com).
Audio Source Wiring
NOTE: Use good quality shielded interconnects between source equipment,
CNX-PAD8A, and CNAMPX-12x60 to minimize noise. The required wire gauge is
dependent on the length of the wire run.
6 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •7
Refer to the following audio wiring diagram when making audio connections
between the hardware devices of the C2-AUDIO-6PAK and the sources.
Advanced Wiring
If the intent is to use the C2-AUDIO-6PAK in a configuration other than its basic
design, refer to the individual device Operations Guides when making these
“advanced” wiring connections.
NOTE: Bridging channels requires a Crestron CNXBRMO Mono Converter &
Bridge (not part of the Six-Zone Audio Package). No more than two CNXBRMOs
should be connected to a single CNAMPX-12x60 when bridging. When
implementing a two-CNXBRMO bridge, Crestron recommends connecting one to
ROOM INPUTS 1 & 2 and connecting the other to ROOM INPUTS 5 & 6 on the
CNAMPX-12x60. Failure to make these connections in this particular application
may result in damage to the amplifier.
Audio Wiring
CNAMPX-12x60
43
ROOM INPUTS
ROOM OUTPUTS
8 OHM / 60 WATTS
4 OHM / 90 WATTS
MADE IN THE USA DATE:
34
+ - + -
+ -+ -
ATTENTION:
POUR LA PROTECTION CONTRE LES RISQUES D'INCENDIES
N'UTILISEZ SEULEMENT LE MEMES TYPE DE FUSIBLE.
DEBRANCHEZ LE CABLE D'ALIMENTATION AVANT DE
CHANGER LE FUSIBLE.
CAUTION:
FOR CONTINUED PROTECTION AGAINST FIRE
HAZARD USE ONLY SAME TYPE AND RATING FUSE.
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE.
21
LEFT
RIGHT
CRESTRON
USA07647N.J.ROCKLEIGH,INC.ELECTRONICS,
LEFT
RIGHT
12
+ - + -
+ -+ -
PRECAUCION:
PARA LA PROTECCION CONTINUADA CONTRA EL USO DEL
RIESGO DE INCENDIOS USE SOLAMENTE EL MISMO TIPO Y
FUSIBLE DEL GRADO. DESCONECTE LA CUERDA DE LA
FUENTE ANTES DE CAMBIAR EL FUSIBLE.
AUSTAUSCHEN.
GERAT VOM NETZ BEVOR SIE DIE SICHERUNG
AUFGRUND BRANDSCHUTZRECHTLICHER BESTIMMUNGEN,
ACHTUNG:
BITTE NUR SICHERUNGEN DES SELBEN TYPS UND MIT DER
SELBEN BELASTBRAKEIT VERWENDEN. TRENNEN SIE DAS
OVERRIDE/SETUP
Z
NET
G
PWR
NET
24
Y
5
120V AC 60Hz
1440 WATTS MAX.
12A 125V
6
+ - + -
+ -+ -
L2 R2
ROOM2
SPEAKERS
ROOM1
SPEAKERS
L1 R1
L5 R5
ROOM5
SPEAKERS
ROOM4
SPEAKERS
L3 R3 L4
ROOM3
SPEAKERS
R4
ROOM6
SPEAKERS
L6 R6
TAPE
DSS
CD CD 2
FM AUX
AUDIO
SOURCES
CORRESPONDING
AUDIO SOURCE
LOOP-THROUGH
ROCKLEIGH,
41 2
1
CRESTRON
RIGHT
LEFT
SOURCES
INC.ELECTRONICS,
23
3
4 7
07647N.J.
56
765
ROOMS
2
8
RIGHT
LEFT
1
G
8
65
AVIS:
RISKOF ELECTRIC SHOCK
CAUTION
RISQUEDE CHOC ELECTRIQUE NE PAS OUVRIR
DONOT OPEN
3 7654 8
24 ZYG
NET
SETUP
CNX-PAD8A
NOTE:
DEVICES ARE NOT DRAWN TO SCALE.

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
8 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B
Software Setup
NOTE: Have a question or comment about Crestron software?
Answers to frequently asked questions (FAQs) can be viewed in the Online Help
section of the Crestron website (www.crestron.com). To post your own question or
view questions you have submitted to Crestron’s True Blue Support, log in at
http://www.crestron.com/accounts/login.asp. First-time users will need to establish a
user account.
Software System Requirements
NOTE: The Audio Six-Pack Wizard is available from the Crestron Audio Six-Pack
CD and also as part of the Crestron Application Builder (AppBuilder) version 1.2.4
and later, which can be obtained from the Downloads | Software Updates section of
the Crestron website (www.crestron.com). Crestron software and any files on the
website are for Authorized Crestron dealers and Crestron Authorized Independent
Programmers (CAIP) only. New users may be required to register to obtain access to
certain areas of the site (including the FTP site).
The PC where the contents of the Crestron Audio Six-Pack CD or Crestron
AppBuilder (version 1.2.4 or later) are installed should meet these system
requirements.
Minimum Required PC Configuration
Windows 98/NT/2000/XP: 333MHz Pentium II with 256MB RAM
Display Setting of “256 Colors”
Recommended PC Configuration
Windows 98/NT/2000/XP: 1.3GHz Pentium 4 with 512MB RAM
Display Setting of “High Color (16 bit)” or higher
Installation via the Crestron Audio Six-Pack CD
Insert the Crestron Audio Six-Pack CD (version 1.2 or later) into the PC's CD-ROM
drive. If the CD does not start automatically, select Run from the Windows start
menu. Type the letter for the CD-ROM drive and :\Setup.
NOTE: The Wizard in the Crestron Audio Six-Pack CD (version 1.2) allows a
system to be configured with either a CP2 or CP2E processor. If a different processor
is part of your system, use the Crestron AppBuilder after completing the steps in the
Wizard to swap control systems. Refer to “Appendix A: Swapping Control Systems”
on page 23 for details.
NOTE: An earlier version of the CD is compatible with the CNX version of the
Audio Six-Pack. Only the software on the Crestron Audio Six-Pack CD (version 1.2
and later) works correctly with the C2-AUDIO-6PAK. Refer to “Appendix B: Notice
to CNX-AUDIO-6PAK Users” on page 24 for making changes to an existing CNX-
AUDIO-6PAK system.
There are certain versions of SIMPL Windows, Crestron VisionToolsPro-e
(VT Pro-e), and the Crestron Database required to successfully operate with the

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
Wizard. The minimum required versions are available from the Crestron Audio Six-
Pack CD.
The versions are:
• SIMPL Windows v2.04.14.05 or later. Requires SIMPL+Cross
Compiler version 1.1.
• VT Pro-e v3.1.2.0 or later.
• Crestron Database v16.0.4 or later.
• Crestron AppBuilder v1.2.4 with Audio Six-Pack Wizard.
The latest software versions can also be obtained from the Downloads | Software
Updates section of the Crestron website (www.crestron.com).
Installation of Crestron Application Builder
Download and double click the Crestron AppBuilder .EXE (version 1.2 or later) file
from the Crestron website. The InstallShield Wizard opens. Follow the steps to
complete the install.
There are certain versions of SIMPL Windows, VT Pro-e, and the Crestron Database
required to successfully operate with the Wizard. The minimum required versions
can be obtained from the Downloads | Software Updates section of the Crestron
website (www.crestron.com). The versions are:
• SIMPL Windows v2.04.14.05 or later. Requires SIMPL+Cross
Compiler version 1.1.
• VT Pro-e v3.1.2.0 or later.
• Crestron Database v16.0.4 or later.
• Crestron AppBuilder v1.2.4 with Audio Six-Pack Wizard.
Three Step Configuration
NOTE: The Wizard in the Crestron Audio Six-Pack CD (version 1.2) allows a
system to be configured with either a CP2 or CP2E processor. If a different processor
is part of your system, use the Crestron AppBuilder after completing the steps in the
Wizard to swap control systems. Refer to “Appendix A: Swapping Control Systems”
on page 23 for details.
Use the easy three-step configuration of the Crestron Audio Six-Pack Wizard
described on the following pages to complete the six-zone audio system. Refer to the
on-line and context-sensitive (F1) help, if assistance is needed.
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •9

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
Start Audio Six-Pack Wizard
Open the Audio Six-Pack Wizard and begin with the screen shown below.
Start Screen
To move onto the first step in the configuration of the audio system, click on the
Next> button or click on the square in the left column entitled “Name & Location”.
Advance through the Wizard steps using either of these methods. An alternative
method of initiating configuration is to click on the “Create New System” icon ( ).
Step 1: Name the System
From the next screen, shown below, specify the CP2 or CP2E as the processor to be
used and enter a name in the System Name: field. This name will be assigned to all
application files (Audio Six-Pack Wizard, SIMPL Windows, and VT Pro-e) for the
system. In the second field, enter a location to save all files that are created using the
Wizard. Defaults for each field are shown below.
Name the System
10 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
Step 2: Add Sources
The Crestron Database contains
information collected about devices
that have, at one time, been pro-
grammed into a Crestron system.
The User Database is a place to
store information about devices
that are not yet part of the Crestron
Database.
The Devices screen of the Audio Six-Pack Wizard allows the user to select all the
audio sources in the system that need to be controlled. The Wizard has access to
either the Crestron or User Database. Make a choice by selecting the correct
Database button, as shown in the screen below. A source can be added by first
selecting how to search for it. Decide how to sort the devices by selecting either the
Manufacturer or Type button from the Sort By area.
NOTE: It is possible to rebuild the User Database. Simply click on the folder icon
in the Database area of the Devices screen to open the “Preferences” window.
Add Sources
Use the pull-down arrows to select the Manufacturer, Type, and Model of each
source in the system. Once the three parameters are selected for a single source, click
the Add to System button to automatically enter the source into the list at the bottom
of the screen.
Notice that the Wizard keeps a running list of each source. The list includes the
device name, a description of the source, I/O assignment, and the Switcher Input.
Continue to add sources by repeating the procedure in the previous paragraph.
It is possible to assign properties to each source. Double click on an item from the
list of sources or alternatively, select the source and click on the Properties button, or
right click the source, then select Properties from the pull-down list. The “Device #
Properties” window appears with up to four tabs of its own: Audio, I/O Assignment,
Commands, and Properties. The pound symbol (#) in the title of the window
indicates the number assigned to the actual device.
Audio Properties
The Audio tab of the “Device # Properties” window, as shown after this paragraph,
identifies the name of the source device and assigns the predetermined input number
to the CNX-PAD8. The input number to the audio switcher can be changed.
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •11

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
“Device # Properties” Window – Audio Tab
I/O Assignment Properties
The I/O Assignment tab of the “Device # Properties” window, shown after this
paragraph, enables a change of the port assignment for the source as well as the
controlling device. Click the OK button to apply and save any changes made and
close the window. The Cancel button closes the window without saving any changes
that have been made.
“Device # Properties” Window – I/O Assignment Tab
The Device area displays all control information about the currently selected device,
specifically it reveals how this device is connected to the control system. Click on
the Configure button to modify how this device is connected to the control system.
For example, a CD might automatically be assigned to port C of an IR card. To place
12 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
this device on port D, simply click the Configure button, select the Port Assignment
tab from the “Device Settings” window, and choose a new port assignment.
The Controller area displays all control information about the device that controls
the currently selected device. For example, if the selected device is an IR controlled
CD, the controller may be an internal IR card such as the C2I-IR8. The top line of
text displays a description of this controlling device. The list box shows all
controllers to which the current device may be assigned. There are three buttons to
modify the contents of the list box.
• Click the Configure button to modify the controller location in the
control system.
• Click the New button to add a controller to the list assuming a valid
controller is available.
• Click the Remove button to remove the currently selected controller
from the list. Some controllers (i.e., built-in cards) cannot be removed.
NOTE: Expert users can always modify any of the device properties directly in
SIMPL Windows, after the program is generated.
Command Properties
This tab displays a list of possible commands, which are selectable. The four
commands, shown after this paragraph, are mapped to two fixed buttons on the
function keypad: left and right arrow. To execute the Next 1 command the user
presses the right arrow button; to execute the Next 2 command the user presses and
holds the right arrow button. Similarly, to execute the Prev 1 command the user
presses the left arrow button; for Prev 2, the user presses and holds the left arrow
button. Click the OK button to apply and save any changes made and close the
window. The Cancel button closes the window without saving any changes that have
been made.
“Device # Properties” Window – Command Tab
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •13

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
Properties
The Properties tab of the “Device # Properties” window, shown after this paragraph,
lists a set of values for specified functions. Crestron recommends that the default
values are used, but the programmer is free to alter them. Click the OK button to
apply and save any changes made and close the window. The Cancel button closes
the window without saving any changes that have been made.
NOTE: This tab is not available for all devices.
“Device # Properties” Window – Properties Tab
Step 3: Add Rooms
The C2-AUDIO-6PAK is designed
to permit control of up to eight
devices from up to six rooms. If the
intent is to control more than eight
devices or control seven or more
devices from a single room, the
designer should consider using
Crestron AppBuilder to supplement
the Audio Six-Pack Wizard or use
Crestron AppBuilder solely.
The top six buttons on the function keypad are pre-configured for source selection,
where by default the first button (on the top left of the panel) selects Device 1, the
second button (top right) selects Device 2, the third, Device 3 and so forth. In
applications with less than six devices, the extra source selection buttons will have
no function assignment. In those applications with seven or eight devices, the extra
devices will have no source selection buttons in certain rooms of the system. Use
this step to determine which of the available sources can be selected from a given
room.
The C2-AUDIO-6PAK is designed to provide control from up to six locations. The
Interfaces screen of the Wizard allows the user to assign source control from each of
the six rooms. From the pull-down above the user interface on the screen, as shown
after this paragraph, choose a room. The top six buttons of the keypad need to be
assigned to override the default settings. Move the cursor over one of the buttons and
notice that the perimeter of the button changes to a blue color. Selection of a button
changes the perimeter color to red and enables the Selected Source Button area of the
screen. Select an available source from the Source: field and assign a label for the
button on the keypad. Select another room and repeat the process.
NOTE: The keypad has standard source selector switch caps installed and a kit of
custom switch caps is supplied with the C2-AUDIO-6PAK. Instructions for
installing the custom switch caps or re-arranging the standard switch caps is
14 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B

Crestron C2-AUDIO-6PAK Six-Zone Audio Package
provided in the latest revision of the C2N-DBN12 and C2N-DBF12 Operations
Guide (Doc. 6200).
NOTE: The lower six buttons on the keypad are fixed.
NOTE: The Net ID of each user interface is room specific and shown beneath the
user interface on the screen.
Add Rooms
The switch caps on the lower six buttons on the keypad are fixed and cannot be
altered. These include the On/Off button, Volume Up and Down, and Mute. The left
and right arrow buttons are for the standard Next and Prev commands, as assigned in
the Command tab of the “Device # Properties” window, as described in "Step 2: Add
Sources" on page 11.
After configuring the buttons, click Next.
Upload the System
NOTE: The CP2E has a built-in Ethernet port and web-server. If a CP2E is part of
your audio system, use the features in SIMPL Windows and VT Pro-e after
compiling to take advantage of Crestron e-Controlcapabilities. Search each
application’s help file for Ethernet / e-Control details. Also, review the latest version
of the Crestron e-Control Reference Guide (Doc. 6052), which is available from the
Downloads | Product Manuals section of the Crestron website (www.crestron.com).
The Finish screen, shown after this paragraph, provides the final steps to building the
logic for the system. This involves creating and compiling the SIMPL Windows
program and uploading it to the control system. The completed SIMPL Windows
program is saved with the .smw extension in the system's program folder. It contains
all the logic that enables communication between the control system, button panels,
controlled devices and other C2-AUDIO-6PAK hardware.
Reference Guide – DOC. 8188B Six-Zone Audio Package: C2-AUDIO-6PAK •15

Six-Zone Audio Package Crestron C2-AUDIO-6PAK
Finish Screen
NOTE: The CP2E can use TCP/IP as the Connection Type when uploading system
programs. For uploading details, refer to the latest version of the Crestron e-Control
Reference Guide (Doc. 6052), which is available from the Downloads | Product
Manuals section of the Crestron website (www.crestron.com).
Before uploading the system, it is probably a good idea to verify the communication
preferences. The PC running the Wizard should be connected to the COMPUTER
port of the CP2 via a straight through 9-pin cable. Only then can all system programs
be uploaded. Select the Communication Settings button to open the “Port Settings”
window, shown after this paragraph.
Verify Port Settings
The Documentation button on the final screen of the Wizard displays an HTML
report of the entire system including devices and their respective locations. These
reports are a great troubleshooting tool.
16 •Six-Zone Audio Package: C2-AUDIO-6PAK Reference Guide – DOC. 8188B
