Supplemental Guide – DOC. 7728A DM-RMC-4K-SCALER-C/-DSP:4K DigitalMedia 8G+ Receivers
•
1
DM-RMC-4K-SCALER-C/-DSP:
4K DigitalMedia 8G+®Receivers and
Room Controllers with Scaler
Introduction
The DM-RMC-4K-SCALER-C and DM-RMC-4K-SCALER-C-DSP provide advanced
one-box interface solutions for a single display device as part of a complete Crestron®
DigitalMedia™ system. Each device functions as a DM 8G+®receiver, 4K/60 video scaler,
and control interface, providing a single HDMI®output. In addition, an analog audio output,
Ethernet, RS-232, IR, and relay control ports are provided. Built-in scaling enables the
connected display to handle virtually any video signal—including 4K and Ultra HD.
The DM-RMC-4K-SCALER-C-DSP also provides internal surround sound processing.
For additional information about the various features and capabilities of the
DM-RMC-4K-SCALER-C and DM-RMC-4K-SCALER-C-DSP, refer to the product
specification sheet on the corresponding product page of the Crestron website
(www.crestron.com). For installation information, refer to the DM-RMC-4K-SCALER-C/
DM-RMC-4K-SCALER-C-DSP DO Guide (Doc. 7708) at www.crestron.com/manuals.
NOTE:
Throughout the remainder of this guide, all references to the
DM-RMC-4K-SCALER-C apply to both the DM-RMC-4K-SCALER-C and the
DM-RMC-4K-SCALER-C-DSP unless otherwise noted.
This guide provides information about the following:
•Physical description of the top and side views of the DM-RMC-4K-SCALER-C
•Configuration of some of the capabilities of the DM-RMC-4K-SCALER-C, for
example, video processing
•HDCP 2.2. compliance
•Troubleshooting
•Pin assignments

2
•
DM-RMC-4K-SCALER-C/-DSP:4K DigitalMedia 8G+ Receivers Supplemental Guide – DOC. 7728A
Physical Description
This section provides information about the connectors, controls, and indicators on the top,
left side, and right side of the DM-RMC-4K-SCALER-C.
Top View
The following illustration shows the top of the DM-RMC-4K-SCALER-C.
Top View

ACT:
Green LED, indicates activity

SETUP:
(Applicable only to a configuration in which a DigitalMedia switcher is not
used)
Red LED and recessed push button for Ethernet setup of the default static IP
address of the device
NOTE:
The default static IP address of the DM-RMC-4K-SCALER-C is 192.168.1.221.
The default static IP address of the DM-RMC-4K-SCALER-C-DSP is 192.168.1.222.

RESET:
Recessed push button for reboot of the device




Supplemental Guide – DOC. 7728A DM-RMC-4K-SCALER-C/-DSP:4K DigitalMedia 8G+ Receivers
•
3
Side View, Left
The following illustration shows the left side of the DM-RMC-4K-SCALER-C.
Side View, Left

COM:
5-pin 3.5 mm detachable terminal block;
Bidirectional RS-232 port;
Up to 115.2k baud, hardware and software handshaking support

IR 1-2:
4-pin 3.5 mm detachable terminal block comprising 2 IR/serial ports;
IR output up to 1.1 MHz;
1-way serial TTL/RS-232 (0-5 volts) up to 19200 baud
NOTE:
The IR 1 and IR 2 commands can be sent in parallel but are processed serially.

AUDIO OUT L, R:
5-pin 3.5 mm detachable terminal block;
Balanced/unbalanced stereo line level audio output;
Output impedance: 200 ohm balanced or 100 ohm unbalanced;
Maximum output level: 4 Vrms balanced or 2 Vrms unbalanced
NOTE:
The analog stereo audio output is active only when the
DM-RMC-4K-SCALER-C is receiving a 2-channel stereo signal. For applications using a
multichannel surround sound source, use the DM-RMC-4K-SCALER-C-DSP, which
provides a stereo downmix of the multichannel signal.

RELAY 1-2:
4-pin 3.5 mm detachable terminal block comprising 2 normally open,
isolated relays;
Rated 1 amp, 30 Vac/Vdc;
MOV arc suppression across contacts

Ground ( ):
6-32 screw, chassis ground lug






4
•
DM-RMC-4K-SCALER-C/-DSP:4K DigitalMedia 8G+ Receivers Supplemental Guide – DOC. 7728A
Side View, Right
The following illustration shows the right side of the DM-RMC-4K-SCALER-C.
Side View, Right

LAN:
8-pin RJ-45 female, shielded, with two LEDs;
10BASE-T/100-BASETX Ethernet port;
Green LED indicates Ethernet link status;
Amber LED indicates Ethernet activity
NOTE:
Do not connect the LAN port to an Ethernet switch if the DM IN port connects
to a DigitalMedia switcher.

HDMI OUT:
19-pin Type A HDMI female;
HDMI digital video/audio output (DVI compatible)
NOTE:
HDMI OUT requires an appropriate adapter or interface cable to accommodate
a DVI signal. CBL-HD-DVI interface cable is available separately.

HDMI LED:
Green LED, indicates video signal presence at the HDMI output

DM IN:
8-pin RJ-45 female, shielded, with two LEDs;
DM 8G+ input, HDBaseT®standard compliant;
PoDM+ PD (Powered Device) port;
Connects to the DM 8G+ output of a DM®switcher, transmitter, or other DM device, or
to an HDBaseT device via CAT5e, Crestron DM-CBL-8G, or Crestron DM-CBL-ULTRA
cable;
Green LED indicates DM link status;
Solid amber LED indicates HDCP video;
Blinking amber LED indicates non-HDCP video
NOTE:
Receiving PODM+ requires connection to a switcher or other equipment that
has a PoDM+ PSE (Power Sourcing Equipment) port. Any wiring that is connected to a
PoDM+ PSE port is for intrabuilding use only and should not be connected to a line that
runs outside of the building in which the PSE is located.







Supplemental Guide – DOC. 7728A DM-RMC-4K-SCALER-C/-DSP:4K DigitalMedia 8G+ Receivers
•
5

24 VDC 1.25A MAX:
2.1 x 5.5 mm dc power connector;
24 Vdc power input;
Power pack included

Power LED:
Green LED, indicates operating power supplied via PoDM+ or 24 Vdc
local power pack
For pin assignment information, refer to the Appendix on page 15.
Configuration
This section provides configuration information about the following:
•Video wall processing
•Adjustable underscan and overscan
•User-selectable output resolution
•Standby timeout
•Display mode
•EDID
•Connection to a third-party HDBaseT transmitter
Video Wall Processing
Multiple DM-RMC-4K-SCALER-C units can be combined to configure a video wall
composed of up to 64 individual displays (up to eight columns of displays by eight rows of
displays). A separate DM-RMC-4K-SCALER-C is required for each display, and a
DigitalMedia switcher with sufficient DM 8G+ outputs is also required. Each
DM-RMC-4K-SCALER-C provides zoom capability and bezel compensation on its output to
display a portion of the source image.
To configure a video wall, use the Crestron Toolbox™ DMTool or use SIMPL Windows as
discussed in the following sections.
Configuration Using DMTool
An overview of the steps necessary to configure a video wall using DMTool follows.
NOTE:
For detailed information, refer to the Crestron Toolbox help file.
1. Connect to the DigitalMedia switcher.
2. Connect to the desired DM-RMC-4K-SCALER-C.
3. Open the Setup window of the HDMI output.
4. In the Video Settings dialog box, configure the video wall. In addition, configure
bezel compensation to compensate for image loss at the edges of the display.

6
•
DM-RMC-4K-SCALER-C/-DSP:4K DigitalMedia 8G+ Receivers Supplemental Guide – DOC. 7728A
Video Settings Dialog Box—Video Wall and Bezel Compensation Configuration
5. Repeat steps 2-4 for each DM-RMC-4K-SCALER-C that connects to a display for
inclusion in the video wall.
Configuration Using SIMPL Windows
An overview of the steps necessary to configure a video wall using SIMPL Windows follows.
NOTE:
For detailed information, refer to the SIMPL Windows help file.
1. Configure slot 3 for a DM-RMC-4K-SCALER-C Scaler by setting the
<Scaler_Out_Wall_Mode>
,
<Scaler_Out_Horizontal_Bezel_Compensation
>,
and
<Scaler_Out_Vertical_Bezel_Compensation>
analog input joins to the
desired values.
2. Repeat step 1 for each DM-RMC-4K-SCALER-C that connects to a display for
inclusion in the video wall.
Adjustable Underscan and Overscan
If content does not fit properly on a display, adjustments to underscan or overscan may be
desired. Adjustments can be made up to 7.5%. Adjusting the underscan reduces the image
size by the specified percentage so that the entire video frame is displayed. Adjusting the
overscan expands the image size by the specified percentage so that extra information
around the edges is not displayed.
To adjust underscan and overscan settings, use DMTool or SIMP Windows as discussed in
the following sections.
