Crestron TPS-IMW
Wall Mounted Interface Module
Operations Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
©2004 Crestron Electronics, Inc.

Crestron TPS-IMW Wall-Mounted Interface Module
Contents
Wall-Mounted Interface Module: TPS-IMW 1
Introduction......................................................................................1
Features & Functions.............................................................1
Specifications.........................................................................1
Physical Description ..............................................................2
Industry Compliance..............................................................6
Setup.................................................................................................6
Network Wiring.....................................................................6
Hardware Hookup..................................................................8
Problem Solving.............................................................................12
Troubleshooting...................................................................12
Further Inquiries ..................................................................14
Future Updates.....................................................................14
Return and Warranty Policies ........................................................15
Merchandise Returns / Repair Service ................................15
CRESTRON Limited Warranty ..........................................15
Operations Guide - DOC. 5857A Contents •i

Crestron TPS-IMW Wall-Mounted Interface Module
Wall-Mounted Interface Module:
TPS-IMW
Introduction
Features & Functions
The TPS-IMW is designed to serve as an optional interface module for
the Crestron TPS-3000, TPS-4000, TPS-5000 and TPS-6000 tilt
touchpanels. The module provides a clean, 2-gang mountable interface
for direct connection to the touchpanel. The TPS-IMW creatively hides
most of the connections behind a wall. The two visible telephone-type
jacks can be camouflaged with a Decora™ wallplate (not supplied) so
that the unit blends into any setting.
NOTE: For the TPS-4500 or TPS-4500V, use the TPS-4500IMW.
Specifications
The following table provides a summary of specifications for the
TPS-IMW.
Specifications of the TPS-IMW
SPECIFICATION DETAILS
Dimensions & Weight Height: 4.11 in (10.44 cm)
Width: 3.50 in (8.89 cm)
Depth: 1.51 in (3.82 cm)
Weight: 7.7 oz (0.22 kg)
Operations Guide – DOC. 5857A Wall-Mounted Interface Module: TPS-IMW •1

Wall-Mounted Interface Module Crestron TPS-IMW
Physical Description
The TPS-IMW, shown in the following diagram, mounts into a 2-gang
electrical box (recommended 2.5" depth). The back of the unit is labeled
and provides a network connector, video input connector, audio input,
and microphone output. Once installed, there are only two RJ-45
connectors (for audio/network/video) visible that provide connections to
the touchpanel via the cables supplied with the touchpanel.
Physical Views of the TPS-IMW
1.51 in
(3.82 cm)
4.11 in
(10.44 cm)
3.50 in
(8.89 cm)
2 •Wall-Mounted Interface Module: TPS-IMW Operations Guide – DOC. 5857A

Crestron TPS-IMW Wall-Mounted Interface Module
Ports
There are six ports that serve various functions on the TPS-IMW. Refer
to the following diagrams and descriptions of each port.
NTSC/PAL VIDEO
The NTSC/PAL video input uses a 6-position mini-terminal block
connector for twisted pair wiring of balanced or unbalanced video
signals. The video signal is connected to these ports and requires a
TPS-3000, TPS-4000, or installation of the TPS-VID-1 or TPS-VID-2
video card in a TPS-5000 or TPS-6000 touchpanel to display video.
Consult the latest revision of the TPS-3000 Operations Guide (Doc.
6076), TPS-4000 Operations Guide (Doc. 6268) or TPS-VID-1/2
Operations & Installation Guide (Doc. 6059) for details. A description of
the pinouts is shown in the following table.
NTSC/PAL Balanced Video Input Pinouts
PIN DESCRIPTION PIN DESCRIPTION
C(+) Chrominance (Positive) Y(+) Luminance (Positive)
C(-) Chrominance (Negative) Y(-) Luminance (Negative)
C(S) Chrominance (Shield) Y(S) Luminance (Shield)
To connect S-video signals, chrominance and luminance signals must be
connected to the “C” and “Y” terminals. To view composite signals, the
signal should be connected to the “Y” terminal.
NOTE: Except for differential input (balanced) video signal, the six-pin
video connector with jumpers (included) should be installed at all times.
Refer to “Hardware Hookup” on page 8 for details.
NET
This four-position terminal block connector is used to connect to other
Cresnet peripherals in a system and provide network power to the
touchpanel if an external power pack is not used. If making network
connections to a control system or Cresnet peripherals, refer to “Network
Wiring” on page 6.
Operations Guide – DOC. 5857A Wall-Mounted Interface Module: TPS-IMW •3

Wall-Mounted Interface Module Crestron TPS-IMW
AUDIO INPUT
The port mates with a six-position mini-terminal block connector
(supplied) and provides balanced and/or unbalanced audio input. A
description of the pinouts is shown in the following table.
AUDIO INPUT Pinouts
PIN DESCRIPTION PIN DESCRIPTION
S Shield L + Left Positive
R + Right Positive L- Left Negative
R - Right Negative S Shield
MIC OUT
The port mates with a three-position mini-terminal block connector
(supplied) and produces line level differential output. Description of the
pinouts is shown in the following table.
MIC OUT Pinouts
PIN DESCRIPTION
+ Positive
- Negative
S Shield
NET/VIDEO (To Panel)
VIDEO
NET/
1
This 10-pin RJ-45 connection mates with the TPS-3000, TPS-4000,
TPS-5000, or TPS-6000 touchpanel. Refer to the descriptions and pinout
table that follow this paragraph. The 10-pin net/video cable assembly to
connect the touchpanel to the TPS-IMW is supplied. Even though the
8-pin audio cable may fit into the port, do not use it.
This port provides the Cresnet connection to the touchpanel. This port
also provides composite or S-video input for the built-in video card (with
the purchase of a TPS-3000, TPS-4000, or installation of the
TPS-VID-1/2 in a TPS-5000 or TPS-6000 touchpanel). Consult the latest
revision of the TPS-3000 Operations Guide (Doc. 6076), TPS-4000
Operations Guide (Doc. 6268) or TPS-VID-1/2 Operations & Installation
Guide (Doc. 6059) for details.
4 •Wall-Mounted Interface Module: TPS-IMW Operations Guide – DOC. 5857A

Crestron TPS-IMW Wall-Mounted Interface Module
NET/VIDEO Pinouts
TYPE PIN DESIGNATION DESCRIPTION
1 +24V Power (Network)
2 GND Ground (Network)
3 C+ Chrominance (Positive)
/Composite 2
4 C- Chrominance (Negative)
/Composite 2
5 Y Data (Network)
6 Z Data (Network)
7 Y+ Luminance (Positive)
/Composite 1
8 Y- Luminance (Negative)
/Composite 1
9 GND Ground (Network)
10-pin RJ-45
Pin 1 Pin 1
10 +24V Power (Network)
To determine the location of pin 1, hold the cable so that the end of the
10-pin RJ-45 connector is facing away from you, with the clip side down
and the copper side up. The copper connector on the far left is pin 1.
CAUTION: The 10-pin RJ-45 net/video connector cable supplied by
Crestron is a custom cable and is the only one that should be used. The
end of the cable has a metal shield that is required to protect the
equipment. Using non-Crestron cables will result in damage to the
product.
AUDIO (To Panel)
AUDIO
1
This 8-pin RJ-45 mates with the TPS-3000, TPS-4000, TPS-5000, or
TPS-6000 touchpanel. The 8-pin audio cable assembly is supplied. Even
though the 10-pin net/video cable may fit into the port, do not use it. This
port provides audio input to the touchpanel and microphone output from
the touchpanel. A description of the pinouts is shown in the following
table.
Operations Guide – DOC. 5857A Wall-Mounted Interface Module: TPS-IMW •5

Wall-Mounted Interface Module Crestron TPS-IMW
AUDIO Pinouts
TYPE PIN DESIGNATION DESCRIPTION
1 L+ Left Input (Positive)
2 L- Left Input (Negative)
3 GND/Shield Audio Input Ground/Shield
4 R+ Right Input (Positive)
5 R- Right Input (Negative)
6 GND/Shield Mic Output Ground/Shield
7 M+ Mic Output (Positive)
18
18
Front
Top
8 M- Mic Output (Negative)
To determine the location of pin 1, hold the cable so that the end of the
8-pin RJ-45 connector is facing away from you, with the clip side down
and the copper side up. The copper connector on the far left is pin 1.
Industry Compliance
As of the date of manufacture, the TPS-IMW has been tested and found
to comply with specifications for CE marking and standards per EMC
and Radiocommunications Compliance Labelling.
Setup
Network Wiring
CAUTION: Use only Crestron power supplies for Crestron equipment.
Failure to do so could cause equipment damage or void the Crestron
warranty.
CAUTION: Provide sufficient power to the system. Insufficient power
can lead to unpredictable results or damage to the equipment. Please use
the Crestron Power Calculator (www.crestron.com/dealer-
tech_resources/power_calculator.asp) to help calculate how much power
is needed for the system.
CAUTION: Possible equipment damage if miswired.
