Crestron OD4-BRZ-T-EACH User manual

The Crestron® Reference Speaker REFERENCE OD4-BRZ-T-EACH made
by Origin Acoustics delivers the pinnacle of performance for demanding
residential installations. Select materials, top shelf components and a
high-end appearance underscore the design behind each speaker. The
result is a no-compromise outdoor speaker designed to be staked
directly into the ground or mounted to an exterior wall, fence post, or
tree.
In the Box
1 REFERENCE OD4-BRZ-T-EACH
 
Additional Items
1 Ground stake
2 Wire nuts
Installation
Prepare the Site
The Crestron Reference speaker REFERENCE OD4-BRZ-T-EACH can be
installed at ground level using the supplied stake. It can also be mounted
to outdoor hard surfaces, such as a trellis, under an eave, on a wall, on a
deck, or to a post using the surface/tree mount SPKA-SMK/TREEMK-
REFERENCE-OD4 (optional).
lFor in-ground level installation, choose a location that will not flood
and where the speaker will not be affected by an in-ground sprinkler
system.
lFor above-ground installation, the speaker is mounted with either the
surface or tree mounting bracket (not included).
REFERENCE OD4-BRZ-T-EACH QuickStart
Reference 4 in. 2-Way Outdoor Speaker, Bronze Textured, Single
1

Mount the Speaker
In-Ground Installation
For in-ground installation:
1. Pull the speaker cable through the top of the stake and out either
side on the bottom opening.
2. Drive the ground stake (included) into the ground.
lFor installation in soft soil: The stake can be installed without
excavating the soil. Push the stake down into the soil.
lFor installation in hard soil: Dig a hole for the stake. Place the
stake in the hole with the top cylinder of the stake above ground
level. Hold the stake straight while backfilling and compacting the
soil.
3. Attach the speaker to the stake by turning the speaker clockwise
until it is mounted properly.
2
REFERENCE OD4-BRZ-T-EACH QuickStart
Reference 4 in. 2-Way Outdoor Speaker, Bronze Textured, Single

Above-Ground Installation
Use the SPKA-SMK/TREEMK-REFERENCE-OD4 optional accessory to
install the speakers on a surface or a tree. This accessory must be
purchased separately.
For surface mount installation:
1. Route the speaker cable through all the components of the knuckle
adapter bracket.
2. Install the knuckle adapter bracket (not included) to the speaker as
shown in figure A.
NOTE: The knuckle adapter bracket comprises nut 1, mount base,
mount adapter, and nut 2.
a. Turn nut 1clockwise until it is secured to the speaker.
b. Fit the mount base onto the threaded end of the speaker, and
rotate it clockwise until it is secured.
c. Attach the mount adapter to the mount base using the Allen
screw.
d. Tighten nut 2 over the threaded end of the mount adapter.
3. Select a suitable location to mount the surface mount bracket.
4. Install the surface mount bracket as follows:
a. Place the surface mount bracket (not included) in the mounting
location.
b. Hold the surface mount bracket against the surface to mark the
screw holes.
c. Drill holes at the marked screw hole locations and install three
anchors (not included).
d. Route the speaker cable through the center hole and out of the
cable opening on the surface mount bracket.
e. Secure the surface mount bracket to the surface using drywall
screws (not included).
5. Attach the speaker to the surface mount bracket by hand threading
the assembled speaker to the surface mount bracket.
6. For optimal sound coverage, adjust the speaker left or right and up or
down.
a. Adjust the speaker left or right by adjusting the mounting base
threads and nut 2.
b. Adjust the speaker up or down by first loosening the allen screw
on the mount base. Adjust the angle to the desired position, then
retighten the screw.
3
REFERENCE OD4-BRZ-T-EACH QuickStart
Reference 4 in. 2-Way Outdoor Speaker, Bronze Textured, Single

For tree mount installation:
1. Route the speaker cable through all the components of the knuckle
adapter bracket.
2. Install the knuckle adapter bracket (not included) to the speaker as
shown in figure B.
NOTE: The knuckle adapter bracket comprises nut 1, mount base,
mount adapter, and nut 2.
a. Turn nut 1 clockwise until it is secured to the speaker.
b. Fit the mount base onto the threaded end of the speaker, and
rotate it clockwise until it is secured.
c. Attach the mount adapter to the mount base using the Allen
screw.
d. Tighten nut 2 over the threaded end of the mount adapter.
3. Install the tree mount bracket as follows:
a. Place the tree mount bracket (not included) in the mounting
location.
b. Hold the tree mount bracket against the surface to mark the
screw holes.
c. Drill holes at the marked screw hole locations and install three
anchors (not included).
d. Route the speaker cable through the center hole and out of the
cable opening on the tree mount bracket.
e. Secure the tree mount bracket (not included) to a tree using
drywall screws (not included).
4. Attach the speaker to the tree mount bracket by hand threading the
assembled speaker to the tree mount bracket.
5. For optimal sound coverage, adjust the speaker left or right and up or
down.
a. Adjust the speaker left or right by adjusting the mounting base
threads and nut 2.
b. Adjust the speaker up or down by first loosening the allen screw
on the mount base. Adjust the angle to the desired position, then
retighten the screw.
4
REFERENCE OD4-BRZ-T-EACH QuickStart
Reference 4 in. 2-Way Outdoor Speaker, Bronze Textured, Single

Connect the Speaker Cable
1. Run the speaker cable (not included) from theaudio source to the
wire nut, observing all appropriate local codes.
2. Run the speaker cable from the speaker location to the wire nut,
observing all appropriate local codes.
NOTES:
lThe speaker includes a hardwired direct-burial speaker cable.
lMake sure that the positive cable is attached to the red
connection, and the negative cable is attached to the black
connection.
lEach REFERENCE OD4-BRZ-T-EACH speaker presents a 16 ohm
load to the amplifier, and is designed to be wired in parallel
either with additional REFERENCE OD4-BRZ-T-EACH speakers
and/or with the subwoofer included in the REFERENCE OD4.1-4-
S10-BRZ-T KIT. These speakers are also suitable replacements
for the speakers in the REFERENCE OD4.1-4-S10-BRZ-T KIT.
3. Combine and twist the positive (+) cables together in a clockwise
motion. Repeat this step for the negative (-) cables.
4. Secure the two cables together using the wire nuts ensuring that NO
COPPER is exposed.
5
REFERENCE OD4-BRZ-T-EACH QuickStart
Reference 4 in. 2-Way Outdoor Speaker, Bronze Textured, Single

Visit the Product Page
Scan the QR code to visit the product page.
REFERENCE OD4-BRZ-T-EACH
https://www.crestron.com/model/6511866

Additional Information

Original Instructions
The U.S. English version of this document is the original instructions.
All other languages are a translation of the original instructions.
Crestron product development software is licensed to Crestron dealers and Crestron
Service Providers (CSPs) under a limited nonexclusive, nontransferable Software
Development Tools License Agreement. Crestron product operating system software is
licensed to Crestron dealers, CSPs, and end-users under a separate End-User License
Agreement. Both of these Agreements can be found on the Crestron website at
www.crestron.com/legal/software_license_agreement.
The product warranty can be found at www.crestron.com/warranty.
The specific patents that cover Crestron products are listed at
www.crestron.com/legal/patents.
Certain Crestron products contain open source software. For specific information, visit
www.crestron.com/opensource.
Crestron and the Crestron logo are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Origin Acoustics is
either a trademark or registered trademark of Origin Acoustics, Inc. in the United States
and/or other countries. Other trademarks, registered trademarks, and trade names may
be used in this document to refer to either the entities claiming the marks and names or
their products. Crestron disclaims any proprietary interest in the marks and names of
others. Crestron is not responsible for errors in typography or photography.

©2021 Crestron Electronics, Inc.
Doc. 9033B
09/09/21
6
REFERENCE OD4-BRZ-T-EACH QuickStart
Reference 4 in. 2-Way Outdoor Speaker, Bronze Textured, Single
