Saros®2-Way In-Ceiling Speakers
quickstart guide
SAROS_IC4T/IC6T/IC8T
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
SAROS_IC4T/IC6T/IC8T
Saros 2-way in-ceiling speakers are available in white or
black and may be painted to blend with the ceiling surface.
Set the Transformer Tap Selector Switch
The speakers are equipped with a 70V/100V matching transformer for distributed audio
systems. The transformer tap selector switch on the front panel is used to set the speaker
power level. Use a flat blade screwdriver to adjust the switch.
1. For SAROS_IC4T 70V systems, use the left side settings and select from 3.75, 7.5,
15, or 30 watts. The Xposition should not be used.
2. For SAROS_IC4T 100V systems, use the right side settings and select from 1.88,
3.75, 7.5, 15, or 30 watts.
3. For SAROS_IC6T and SAROS_IC8T 70V systems, use the left side settings and
select from 7.5, 15, 30, or 60 watts. The Xposition should not be used.
4. For SAROS_IC6T and SAROS_IC8T 100V systems, use the right side settings and
select from 3.75, 7.5, 15, 30, or 60 watts.
The switch may also be set to 8Ω operation, bypassing the transformer completely. This
setting should be used only for 8 Ω audio systems.
QUICKSTART DOC. 7387C (2034061) 08.13
1
1Installation
Saros®speakers by Crestron®deliver professional grade
performance and flexible installation in a range of popular
sizes for demanding commercial applications. Solid
construction and high end components are hallmarks of the
complete Saros speaker line.
Ideal for use in background or foreground music, paging,
and sound reinforcement systems, Saros speakers are
engineered to achieve smooth, even coverage, high output,
and clear, natural sound quality through the employment of
horn loaded titanium dome tweeters, high efficiency
damped cone woofers, ported enclosures, and precisely
tuned crossovers.
Prepare Mounting Hole
Front View - Grille Removed
Tighten Screws
70V 100V
IN
THRU
Terminal Block
Not Shown
Before finalizing the speaker location, check to make sure there are no fixtures, pipes, air ducts,
joists, or other possible obstructions. If applicable, use a good quality stud finder to locate joists.
If there are no obstructions, use the supplied template to trace an outline of the mounting hole.
For drop tile ceilings, remove the ceiling tile and place on a flat surface to trace the mounting
hole. For sheet rock or standard construction ceilings, use the template to trace the mounting
hole directly on the ceiling.
Install Cable
Run the cable from the audio source to the speaker location, observing all appropriate local
codes. Strip the ends of the speaker cables approximately 1/8” to 3/16” (~3 mm to ~5 mm) and
twist the strands.
Install Tile Bridge
The included tile bridge components provide proper support when the speaker is installed in a
typical drop tile ceiling. Refer to the illustration below.
1. Based on the location of the mounting hole determined in “Prepare Mounting Hole” above,
use the two supplied screws to attach the support ring to the fully extended rails so that
when installed, the ring is aligned with the mounting hole and the rails rest on the ceiling
grid frame.
2. The support ring position on the rails is adjustable to enable off-center speaker positioning.
The tile bridge assembly can be folded to fit through the speaker cutout in blind-mount
situations.
Connect Speaker Cable
Screw
Cable
Clamp
Speaker
Cable
Terminal
Block
Mounting
Clips
Rear
Cover
Panel
Mount/Remove Speaker
The in-ceiling speaker includes four toggle clamps that simplify the mounting process. If the grille is mounted
on the speaker, remove it before proceeding. (Refer to “Install/Remove Grille” above.)
1. Refering to the illustrations to the right, remove the screw securing the rear cover panel, and lift the cover
panel off to expose the supplied terminal block.
2. Route the speaker cable through the cover cable clamp and connect the wires to the terminal block,
using the outer IN terminals; red to +and black to –. Use the inner +and – THRU terminals to connect a
pass-through (parallel) speaker.
3. Allow some slack in the speaker cable(s) and position the cover panel on the back, making certain it
engages the mounting clips. Secure the cover panel using the screw removed in step 1 and tighten the
cable clamp to secure the cable(s). Do not overtighten. Use a safety tether attached to the rear enclosure
to prevent the speaker from accidentally falling.
4. The toggle clamps offer two positions to accommodate both standard and extra thick surfaces up to 2.4
inches (61 mm). For extra thick tiles, reset the toggle clamps to the upper position before continuing.
a. With the toggle clamps turned inward, insert the speaker into the opening.
b. Hold the speaker against the ceiling and begin tightening the four screws on the front of the speaker.
The toggle clamps first rotate into clamping position (as indicated in the front view illustration to the
right) and then begin holding the speaker to the ceiling.
c. Tighten the screws until the speaker is secure. Do not over tighten.
5. Speaker removal is accomplished by reversing steps 1 through 3 above.
a. Hold the speaker in position and loosen the front screws to unclamp the speaker. Continue to loosen
the screws until the toggle clamps rotate inward.
b. When the
speaker is loose, carefully lower the speaker from the opening and disconnect the wiring.
Tile Bridge Assembly
26.00 in
(661 mm)
Screws
(Supplied)
Adjustable
Rails
Support
Ring
Install/Remove Grille
The zero-bezel frameless grille is held in place by powerful magnets. A safety tether is included to prevent
any possibility of the grille falling from the ceiling. With the tether attached, place the grille in position on
the speaker. To remove the grille, grip the edges and pull away from the speaker.
Paint the Speaker Grille
Speaker grille painting should be done prior to mounting.
1. Carefully remove the material on the underside of the grille and set it aside for reinstallation. It may be
necessary to use a knife or other sharp instrument to free an edge of the material so it can be peeled
away. Use care to avoid cutting or tearing the material.
2. Dry brush or lightly spray the surface to be painted. Use care to avoid clogging the holes in the grille.
3. Once the paint is dry, reinstall the material to the underside.
Safety Tether
Rigging Points
For SAROS_IC4T
For SAROS_IC6T,
and SAROS_IC8T
100V
70V
100V
70V

QUICKSTART DOC. 7387C (2034061) 08.13
Saros®2-Way In-Ceiling Speakers
quickstart guide
SAROS_IC4T/IC6T/IC8T
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
SAROS_IC4T/IC6T/IC8T
The specific patents that cover crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo and Saros are either trademarks or registered trademarks of Crestron
Electronics, Inc. in the United States and/or other countries. Other trademarks, registered
trademarks, and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Crestron disclaims any proprietary interest in the marks
and names of others. Crestron is not responsible for errors in typography or photography.
This document was writtren by the Technical Publications department at Crestron.
©2013 Crestron Electronics, Inc.
3Specifications
2
SPECIFICATION
SAROS_IC4T, IC6T, IC8T
SAROS_IC4T SAROS_IC6T SAROS_IC8T The following table provides corrective action for possible trouble situations. If
further assistance is required, please contact a Crestron customer service
representative.
Further Inquiries
To locate specific information or resolve questions after reviewing this guide,
contact Crestron's True Blue Support at 1-888-CRESTRON [1-888-273-7876] or,
for assistance within a particular geographic region, refer to the listing of Crestron
worldwide offices at (www.crestron.com/offices).
To post a question about Crestron products, log onto Crestron’s Online Help at
www.crestron.com/onlinehelp. First-time users must establish a user account to
fully benefit from all available features.
Future Updates
As Crestron improves functions, adds new features and extends the capabilities of
the SAROS_IC4T/IC6T/IC8T, additional information may be made available as
manual updates. These updates are solely electronic and serve as intermediary
supplements prior to the release of a complete technical documentation revision.
Check the Crestron Web site periodically for manual update availability and its
relevance. Updates are identified as an “Addendum” in the Download column.
TROUBLE POSSIBLE CAUSE(S)
CORRECTIVE ACTION
No sound or
intermittent
sound from
speakers.
Cable connection error. Verify cable connections
between amplifier and
speakers.
Amplifier not receiving
input signal or amplifier
malfunction.
Verify amplifier is functioning
correctly, that it is receiving an
input signal and that correct
input source is selected.
Faulty device in system. Verify all devices in system are
functioning properly.
Constant
noise such as
buzz, hum, or
hiss from
speakers.
System grounding fault. Verify system grounding.
Poor low
frequency
output.
Incorrect connection
polarity at speaker or
amplifier.
Verify speaker connection
polarity (+on amplifier to +on
speaker).
4Problem Solving
Troubleshooting
2Physical Views
Minimum
Mounting Depth
Rear and Side View (Typical)
Construction
Enclosure Aluminum, plenum-rated, 1/2 in or 3/4 in conduit knockout top and side
Baffle ABS UL94V-0 plastic
Grille Steel with textured finish, paintable, magnetically-held “zero-bezel” frameless,
safety tether
Mounting Flush ceiling mount using 4 integral 2-step toggle clamps, 2.4 in (61 mm) maximum
surface thickness, tile bridge included. (2) rigging points for safety tether,
(SPKA-ST-15 sold separately)
IN
THRU
Recommended
Cutout Diameter
Diameter
Front View - Grille Removed (Typical)
Transformer
Tap Control
Settings
For SAROS-IC4T
For SAROS_IC6T,
and SAROS_IC8T
8.53 in (217 mm) not
including toggles
7.13 in (181 mm)
7.70 in (195 mm)
6.90 in (176 mm)
7.1 lb (3.2 kg)
10.57 in (269 mm) not
including toggles
8.31 in (211 mm)
9.70 in (245 mm)
8.10 in (206 mm)
10.4 lb (4.7 kg)
12.07 in (307 mm) not
including toggles
9.10 in (231 mm)
11.20 in (285 mm)
8.90 in (226 mm)
12.5 lb (5.7 kg)
Dimensions
Diameter
Depth
Recommended
cutout diameter
Minimum mounting
depth
Weight
Connections
Input (1) 4-pin 5 mm detachable terminal block with screw-down flanges;
Speaker input with parallel pass-through;
Maximum Wire Size: 12 AWG
Controls
Transformer Tap (1) Recessed 5-position screwdriver adjustable rotary switch on baffle;
Used to select 70/100V tap settings or 8Ω (bypass)
Environmental
Temperature -2° to 120° F (-19° to 49° C)
Humidity 5% to 95% RH (non-condensing)
100V70V
8.0 in (203 mm)
polypropylene with ring
mode decoupled cloth
surround and steel basket
0.98 in (25 mm) titanium
dome, 90° conical
horn-loaded
2.5 kHz
8 Ω nominal with
transformer set to 8Ω
7.5, 15, 30, 60 watts at
70 V; 3.75, 7.5, 15, 30, 60
watts at 100 V
50 Hz to 20 kHz (±3 dB)
40 Hz to 20 kHz (-10 dB)
150 watts program, (8 Ω)
90.5 dB @ (W/m)
95° conical (nominal)
6.5 in (165 mm)
polypropylene with ring
mode decoupled cloth
surround and steel basket
0.98 in (25 mm) titanium
dome, 90° conical
horn-loaded
2.5 kHz
8 Ω nominal with
transformer set to 8Ω
7.5, 15, 30, 60 watts at
70 V; 3.75, 7.5, 15, 30, 60
watts at 100 V
50 Hz to 20 kHz (±3 dB)
40 Hz to 20 kHz (-10 dB)
125 watts program (8 Ω)
88.5 dB @ (W/m)
100° conical (nominal)
4.0 in (102 mm)
polypropylene with ring
mode decoupled cloth
surround and steel basket
0.79 in (20 mm) titanium
dome, 90° conical
horn-loaded
2.0 kHz
8 Ω nominal with
transformer set to 8Ω
3.75, 7.5, 15, 30 watts at
70 V; 1.88, 3.75, 7.5, 15,
30 watts at 100 V
60 Hz to 20 kHz (±3 dB)
45 Hz to 20 kHz (-10 dB)
100 watts program, (8 Ω)
85.0 dB @ (W/m)
110° conical (nominal)
Woofer
Tweeter
Crossover Frequency
Impedance
Transformer Taps
Frequency Response
Frequency Range
Power Handling
Sensitivity
Coverage
