Crivit Z31222 User manual

Z31222
LCD SPORTS WATCH
Operation and Safety Notes
LCD-SPORTSUR
Brugs- og sikkerhedsanvisninger

GB Operation and Safety Notes Page 4
DK Brugs- og sikkerhedsanvisninger Side 26

3
4
3
1
2

4 GB
Intended use........................................................................ Page 5
Description of Parts....................................................... Page 5
General Safety Instructions .................................. Page 5
Safety Instructions for Batteries....................... Page 5
Watertightness.................................................................. Page 6
Preparations for use
Changing the battery.................................................................. Page 7
Operation
Time Mode .................................................................................. Page 7
Alarm ........................................................................................... Page 9
Stopwatch Mode........................................................................ Page 12
Compass Mode .......................................................................... Page 15
Altimeter Mode ........................................................................... Page 19
Background contrast lighting ..................................................... Page 24
Troubleshooting........................................................................... Page 24
Cleaning and Care.......................................................... Page 24
Disposal.................................................................................... Page 24

5GB
LCD Sports Watch
Intended use
The wrist watch shows the time and date and has alarm, stopwatch,
altitude measurement and compass functions. The product is not intended
for commercial use.
Description of Parts
1MODE button
2SELECT button (SPLIT) (selection)
3SET button (ST / SP) (setting)
4LIGHT button (light)
General Safety Instructions
PLEASE RETAIN ALL SAFETY INFORMATION AND INSTRUCTIONS
FOR FUTURE REFERENCE!
Safety Instructions for Batteries
DANGER TO LIFE! Batteries / rechargeable batteries
could be swallowed, which could pose a lethal hazard. Keep batteries/
rechargeable batteries away from small children If a battery / recharge-
able batteries has been swallowed, seek medical help immediately.

6 GB
CAUTION! EXPLOSION HAZARD! The batteries
must never be recharged!
Remove a spent battery immediately from the device. There is an
increased danger of leaks!
Batteries must not be disposed of in the normal domestic waste!
Every consumer is legally obliged to dispose of batteries in the proper
manner!
Keep batteries away from children. Do not throw batteries into a fire.
Never short-circuit them or take them apart.
If you do not observe these instructions, the battery could be discharged
beyond the cut-off voltage. There is then a danger of leaking. If the
battery has leaked inside your device, you should remove it immediately
in order to prevent damage to the device!
Avoid contact with the skin, eyes and mucous membranes. Any parts
of the body coming into contact with battery acid should be rinsed off
with copious amounts of water and/ or a doctor contacted if necessary!
Watertightness
1 bar

7GB
Preparations for use
Changing the battery
Note: Have batteries changed in a specialist shop.
Operation
Time Mode
Press the MODE button 1until the display „TIME“ appears to proceed
to the time mode.
By pressing the SELECT button in time mode, you can switch between
the following functions:
– Time (TIME)
– Alarm (ALARM)
– Countdown-Timer (TIMER)
Time (TIME)
Press the SELECT button 2in time mode until the display „TIME“
appears.
In time mode, the year is displayed in the top area and the weekday and
date are displayed in the bottom area.

8 GB
Setting the time (T1)
Press the SET button 3and hold for about 3 seconds. „HOLD TO
SET“ will appear in the display and the hour format „24H“ begins to
flash.
Press the SELECT button 2, to switch between the 12 and 24 hour
format.
Press the SET button to confirm your entry. The second display of the
time display will flash.
Press the SELECT button 2to set the second value to 0.
Press the SET button 3to confirm your entry.
Note: You can hold the SELECT button pressed down to change the
settings faster
.
Press the SELECT button to set the minute display.
Press the SET button to confirm your entry.
Set the hours, the year, the month and the day the same manner. The
measurement unit then starts to flash.
Press the SELECT button to set the desired measurement unit
(METRIC = metric system/ IMPERIAL = British system).
Press the MODE button 1. All settings will be saved.

9GB
Second time (T2)
Press the SELECT button 2in time mode and hold down for about
3 seconds. The second time (T2) appears in the bottom area of the
display.
To set the second time (T2), proceed in the same manner as for the
setting of the first time (T1) (see chapter „Setting the time (T1)“).
Press the SELECT button and hold down for about 3 seconds. The time
display switches back to normal time (T1).
Alarm
There are five individual alarm signals that can be individually activated
or deactivated according to your wishes. Each alarm can be set for four
different purposes.
a) Alarm on a specific date (alarm at 10 am on 19. June)
(A1)
b) Daily alarm in a specific month (alarm every day at
10 am in June) (A2)
c) Monthly alarm (alarm at 10 am on the 19. of every
month) (A3)
d) Daily alarm (alarm every day at 10 am) (A4)

10 GB
e) Hourly alarm (alarm every clock hour) (A5)
When the alarm is switched on, at the set time an alarm signal will buzz
for 30 seconds.
Note: Press the SELECT button 2, the SET button 3or the LIGHT button 4
to stop the alarm signal. Otherwise it will buzz for another four times at
intervals of 2minutes.
If the hourly alarm is switched on, there will be a beep tone every full hour.
Set the alarm as shown below:
1. Press the SELECT button 2in time mode until the display „ALARM“
appears.
2. Press the SET button 3to select between the alarm signals A1 to A5.
3. Hold the SET button pressed down to proceed to the setting of the
selected alarm.
4. Press the SET button again to make the alarm settings.
5. Press thee MODE button 1to save the settings.
To do this, follow Steps 1 to 6:

11GB
Alarm A1
Step 1
Alarm on
Step 2
month
Step 5
minute
Step 3
hour
Step 4
Date
Step 6
Hourly alarm on
Note: The set alarm is determined by the current time selected (T1 or T2).
Timer
The watch is equipped with a countdown timer and a countup timer.
Basic setting: 0.01.00 (1minute)
Press the SELECT button 2in time mode until the display „TIMER“
appears.
Press the SET button 3until the display „HOLD TO SET“ appears
and the countdown timer can be set.
Press the SELECT button to set the minutes. Press the SET button to
proceed to the next setting (hours).

12 GB
Press the SELECT button to set the hours. Press the SET button to
proceed to the next setting “Cd r”.
The countdown can be set at maximum 23 hours and 59 minutes.
Confirm your setting by pressing the MODE button 1.
Timer Types:
r: The timer begins to count down the previously set time until 0 is
reached.
U: The timer begins to count up the previously set time until 0 is reached.
S: The timer stops as soon as 0 is reached.
The following applies to all three timer types:
Press the SET button 3. The timer starts.
Press the SET button again. The timer stops.
Press the SET button again. The timer continues to count.
Press the SET button again and hold for about 3 seconds. In this way,
the timer is set back to the originally set time.
When the timer reaches 0, an alarm signal buzzes for 15 seconds.
Press the SELECT button 2, the SET button 3or the MODE button 1
to stop the alarm signal.
Stopwatch Mode
Press the MODE button 1until the display „CHRONO“ appears to
proceed to the stopwatch mode.

13GB
You can choose between the following sub-function in the stopwatch mode:
CHRONO (Stopwatch)
DATA RECALL (data recall)
Stopwatch
Press the SET button 3to start / stop the stopwatch..
Press the SELECT button 2to record a lap time in the lap memory
while the stopwatch is running.
Note: 99 laps can be saved. „MEMORY FULL“ will appear in the
display when the lap memory is full.
Note: You can only switch between „CHRONO“ and „DATA
RECALL“ if at least one lap has been recorded/stopped.
Press and hold down the SET button 3to reset the stopwatch display
and the lap counter to 0.
Stopwatch mode Total time Lap memory full
Lap memory
Lap
time
Stopwatch memory recall
Press the SET button 3to stop the stopwatch.
Press the SELECT button 2to proceed to the memory recall mode. In
the display „BEST LAP“ and the records of the BEST LAPS will appear.
Press the SET button to read the different lap memories.
Press the SELECT button to leave the memory recall mode.
Follow the diagrams to carry out a standard measurement, a lap time
measurement and a memory recall:

14 GB
Standard measurement: 3– 3– 3
START STOP
RESET
Press 3Press 3
Hold 3pressed
down
Measurement of lap time: 3– 2– 2– 3– 3
START
STOPRESET
Press 3
Press
3
Hold 3
pressed down
Press 2
Press 2
Lap 1 Lap 2
Lap 3
Recall of lap memory: 3– 2– 3– 3… 2– 3

15GB
Press 3to stop
the stopwatch
Press 2
Press
2
Hold
3pressed
down
Press 3
Press 3
RESET
(set to 0)
BACK TO STOP-
WATCH MODE
RECALL OF LAST
LAP
RECALL OF FIRST
LAP
STOPWATCH
MODE
Compass Mode
Press the MODE button 1until the display „COMP“ appears to
proceed to the compass mode.
Hold the compass in a horizontal position and mark the required
direction with .
There are two display formats: display with large digit and detailed display.
Display with large digits
There are two lines in this display format.
The compass appears in the first line.
The compass direction and the cardinal point appear in the second line

16 GB
Detail display
There are four lines in this display format.
R
– The compass appears in the first line.
– An arrow appears in the second line pointing the shortest route to the
north.
When „← N“ appears on the left side of the display, go left to reach
north faster.
When „N →“ appears on the right side of the display, go right to
reach north faster.
– The bearing appears in the third line.
– The compass with the direction and the cardinal point appear in the
fourth line.
Press the SET button 3to switch between the two display formats.
The compass switches off automatically to save energy:
in idle state after 3 minutes.
in continuous operation after 5 minutes
Note: To reactivate, press the SET button 3.

17GB
Ambient interference
– Digital compasses operate with the magnetic field of the earth. Hence
these devices react very sensitively to various ambient influences, that
distort the magnetic field of the earth, for example, when approaching
heavy metal, household devices, computers and power cables.
Never use the compass in the proximity of another compass or a
metal or magnetic object.
To obtain accurate information on the direction of movement, recali-
brate the compass (see chapter „Calibration of the device), if
1. „ERROR“ permanently appears in the display.
2. The direction details indicate an error of more than 10 degrees.
3. The device is used in a vehicle for the first time.
Calibration of the device
Press the MODE button 1to proceed to compass mode.
Press and hold down the SELECT button 2to proceed to calibration
mode. „CAL“ appears in the display.
Press the SELECT button once again to start the calibration. A rotating
ring appears in the display.
Rotate the device twice in a clockwise direction on a level surface that
is free from metal plates, household devices, computers, power cables
etc. Always rotate in the same direction. Ensure that you take at least
20 seconds for each rotation but not longer than one minute.
Then press the SET button 3to complete the calibration.
Note: If the calibration is not performed correctly, inaccurate informa-
tion could be the consequence. Perform the calibration once again if
any detail seems to be erroneous.

18 GB
R
Calibration mode
Press 2
Press 2
Press 3to
confirm
When the ring moves, turn the watch clockwise in two rotations
Entry of declination angle for the geographic north
(True North)
– The declination indicates the difference between the magnetic north
and the geometric north direction at your location.
– The local declination is marked at the edge of the map either as east
plus declination (E) or as west minus declination (W). During the orien-
tation, the direction on the map is corrected by subtraction of the plus
declination or addition of the minus declination.
Press and hold down the SET button 3to proceed to the setting
mode for the declination. The letter „E“ appears in the display and
begins to flash.
Press the SELECT button 2to select the direction east (E) or west (W).
Press the SET button again to confirm your entry The digit for the decli-
nation angle begins to flash.
Press the SELECT button to set the angle that should be adjusted . Press
the SET button to confirm your entry.
Press the SELECT button to switch the declination function on or off
“ON” or “OFF” appears in the bottom area of the display.

19GB
Press the MODE button 1to confirm the setting. You will now return
to compass mode.
Please read the following example to understand the declination
effect: The current direction is N 10 degrees. If the declination angle is
set at 30 degrees, the final direction is changed to NW 340 degrees.
Note: You will find information on the declination data for your location
positioning in the Internet.
Altimeter Mode
Press the MODE button 1to proceed to altimeter mode. „ALTI“
appears in the display.
Press the SELECT button 2in altimeter mode. You can choose
between the following sub-functions:
– Clock (ALTI)
– Memory of maximum altitude (HIGH)
– Memory of minimum altitude (LOW)
– Total height gain (UP)
– Total height loss (DOWN)
– Number of hills (HILL)
– Record (RECORD)

20 GB
Setting the altimeter
Press the SELECT button 2in altimeter mode until the display „ALTI“
appears.
Press the SET button 3and hold for about 3 seconds. “HOLD TO
SET” appears in the display The altitude display then starts to flash.
Press the SELECT button to set the altimeter.
Press the SET button to proceed to the next digit.
Press the MODE button 1to confirm the setting.
Note: Press the SELECT button 2to select the desired display in altime-
ter mode. If you then press the SET button 3, the following data appears
in the middle area of the display: temperature, time and graphic altitude
display.
Time
Note: You can have your current location displayed in different ways:
1. Simple display mode: current altitude and time,
2. Detailed display mode: temperature, time, current altitude and graphic
altitude display.
Press the SET button 3to proceed to simple display mode.
Press the SELECT button 2until the display „CLOCK“ appears. The
current time appears in the bottom area of the display, the current
altitude appears in the middle.
