Cruz Paddock Series User manual

1940-48x 940-49x Cruz Paddock
x x x1 1
Cruzber S.A., ES-A14018311
P.I. Las Salinas II, E-14960 Rute
www.cruzber.com
Peso
Weight
Poids
Gewicht
Código
Code
Code
Kode
Lote
Lot
Lot
Lot
Modelo
Model
Modèle
Modell
2º
1º
Cofre de techo
Roof box
Co󰀨re de toit
Dachbox
Mala de tejadilho
Boksy dachowe
Střešny boxy
Tetöboxok
Cutii-portagj
Krovne kutje
Αξεσουάρ: Μπαγαζιέρες
Portbagajlar
Бокс на крышу
Baule da tetto
Dakko󰀨er
Strešni kovček
1
Cruz Paddock
Código
Code Modelo
Model Medidas
Dimensions Volúmen
Capacity Color
Color
kg
Lote
Lot
940-480 Paddock 400GM 165x85x40cm 400 L gris mate
grey matt 12,50 kg 01/16
940-481 Paddock 400N 165x85x40cm 400 L negro brillo
black glossy 12,50 kg 01/16
940-484 Paddock 480GM 190x80x42cm 480 L gris mate
grey matt 18,00 kg 01/16
940-485 Paddock 480N 190x80x42cm 480 L negro brillo
black glossy 18,00 kg 01/16
940-490 Paddock 630N 210x90x42cm 630 L negro brillo
black glossy 17,50 kg 01/16
940-491 Paddock 630G 210x90x42cm 630 L gris brillo
grey glossy 17,50 kg 01/16
E
Instrucción de montaje
¡Leer primero!
GB
Assembly instructions
Read rst!
F
Instruction de montage
Lire en premier!
D
Montageanleitung
Zuerst lesen!
PT
Instruções de montagem
Ler primeiro!
PL
Instrukcja montażu
Najpierw przeczytaj!
CZ
Montážní návod
Čtěte pozorně!
HU
Szerelési Utasítás
Először olvasd el!
RO
Instructiuni de montaj
Intai cititi!
HR
Detaljne upute
Prvo procitati!
GR
Διαβάστε προσεκτικά τις
Οδηγίες Συναρμολόγησης!
TR
Öncelikle montaj:
Talimatlarını okuyunuz!
RU
Инструкции по монтажу
Сначала прочитайте!
IT
Istruzioni di montaggio
Leggere per primo!
NL
Montagehandleiding
Eerst lezen!
SLO
Navodila za sestavljanje
Preberite!
E
Contenido embalaje: ¡Vericar!
GB
Package content: Check!
F
Contenu d’emballage: Vérier!
D
Packungsinhalt: Überprüfen!
PT
Contéudo embalagem: Vericar!
PL
Zawartość opakowania: sprawdź!
CZ
Obsah balení: Zkontrolujte!
HU
Csomag tartalma: Ellenőrizd!
RO
Pachetul contine: Vericati!
HR
Sadrzaj paketa: Provjeri!
GR
Ελέγξτε το περιεχόμενο: του πακέτου!
TR
Paket içeriğini: Control ediniz!
RU
Содержание упаковки: Проверьте!
IT
Contenuto della confezione:
Controllare!
NL
Pakket inhoud: Controleer!
SLO
Vsebina paketa: Preverite!
940-
Lv 7 2016 - r
48x
1
940-49x
2
940-48x 940-49x Cruz Paddock
x4
x4
x2
x2
Código
Code
Code
Kode
• Anote el número de serie de llave
• Note down the key serial number
• Anoter le numéro de série du clé
• Notieren Sie die Schlüssel-Seriennummer
• Anotar o número de série da chave
• Впишите сюда серийный номер ключа
OUT
máx.
75 Kg
[1]
[1]
[4]
[5]
[6]
[7]
[3]
40Max mm
80Max mm
80Max mm
40Max mm
40Max mm
80Max mm
70
Max mm
40Max mm
40Max mm
80Max mm
80Max mm
40Max mm
40Max mm
80Max mm
70
Max mm
40Max mm
40Max mm
80Max mm
80Max mm
40Max mm
40Max mm
80Max mm
70
Max mm
40Max mm
940-
Lv 7 2016 - r
48x
1
940-49x
x2

CLACK
x1

CLACK

CLA
CK
û ü
û
1
2
3940-48x 940-49x Cruz Paddock











!
!
NO!
E
FIJAR EL COFRE A LAS BARRAS
A. Instale y je correctamente el sistema de ba-
rras. Coloque el cofre centrado entre las barras.
Fije el cofre a las barras mediante las jaciones,
introduciéndolos a través de las perforaciones
de la base del cofre, desde fuera hacía el inte-
rior (Figura 1). En el cofre, cierre las jaciones
según la (Figura 2). Revise cuidadosamente
que el sistema esté jado correctamente, y que
el cofre no se mueva sobre las barras.
B. La carga máxima permitida del cofre es de
75kg. No superar nunca la carga máxima del
techo del vehículo (ver el manual de fabricante
del vehículo). La carga del cofre debe repartir-
se uniformemente, distribuyendo el peso como
muestra el dibujo.
C.La carga se debe colocar sin que haya que for-
zar la tapa para encajar el cierre del cofre, y
sujetarse con las correas suministradas. Ase-
gure que el cofre esté cerrado con llave antes
de salir de viaje.
APERTURA Y CIERRE DEL COFRE
Para abrir el cofre, presionar y girar la llave a
la izquierda para desbloquear la cerradura. Le-
vantar la tapa hacia arriba. Para cerrar el cofre,
bajar la tapa y presionar y girar la llave hasta
encajar el cierre. Retirar siempre la llave antes
de salir de viaje.
GB
FIXING THE BOX TO THE BARS
A. Install and x correctly the bars system. Place
the box at the centre of the bars. Fix the box to
the bars using the U-bolts, put them through
the holes in the base of the box from the
outside to the inside part as Draw 1. In the box,
unblock the handle according Draw 2. Check
carefully that the system is appropriately xed
and that the roof box does not move onto the
roof bars.
B. The maximum permissible load of the box is
75 Kg. The maximum permissible load of the
roof must not be exceeded (see operating
instructions of the vehicle). Make sure the load
is well distributed inside the box (as shown).
C.The load must be placed in such way that the
upper lid does not have to be strained to lock
the box. The load must be hold with the straps
given. Make sure the box is locked before leav-
ing.
OPENING AND CLOSING THE BOX
For opening the box, push and turn the key to
the left to unlock the box. Lift the lid. To lock the
box, press the lid down until the key is pushed
and turned the right to block the lock. Make sure
you never leave the key in the lock.
D
DIE BOX AUF DEN DACHTRÄGERN
BEFESTIGEN
A Montieren sie die Dachträger gemäß der An-
leitung. Zentrieren sie die Dachbox auf den
Trägern. Befestigen sie die Box mit den [U-
Klemmen], und führen sie diese durch die vor-
gesehen Löcher im Boden der Box, von außen
nach innen. In der Dachbox, schließen Sie die
Befestigungen gemäß Bilder 2. Überprüfen Sie
sorgfältig , dass das System richtig eingestellt
ist , und dass die Dachbox auf den Dachträger
bewegt sich nicht.
B. Die erlaubte Höchstlast der Box sind 75kg.
Überschreiten sie nie die zulässige Dachlast
des Fahrzeugs (überprüfen sie diese in der Be-
triebsanleitung). Das Gepäck muss hinsichtlich
des Gewichts, gleichmäßig in der Box verteilt
werden, siehe Zeichnung.
C.Die Haube der Box darf nicht gewaltsam ge-
schlossen werden, verteilen sie die Ladung
dem entsprechend und sichern sie diese mit
den Gurten. Vergewissern sie sich, das die Box
gut verschlossen ist bevor sie losfahren.
ÖFFNEN UND SCHLIEßEN DER DACHBOX
Drehen sie den Schlüssel um die Dachbox zu
ö󰀨nen. Heben sie die Boxhaube nach oben.
Um die Dachbox zu schließen, drücken sie die
Haube nach unten bis sie im Schloss einrastet.
Drehen sie den Schlüssel um das Schloss zu
sichern. Ziehen sie immer den Schlüssel ab be-
vor sie losfahren.
4
940-48x 940-49x Cruz Paddock











!
!
NO!











!
!
NO!











!
!
NO!











!
!
NO!











!
!
NO!
Max. 130 Km/h
130 Km/h 


Max. 130 Km/h
130 Km/h 














!
!
NO!











!
!
NO!











!
!
NO!
Max. 130 Km/h
130 Km/h 


ü
