Directed Directechs DB3 User manual

Designed by Installers for Installers
INSTALLATION GUIDE
DB3
2015 Lincoln MKZ Hybrid (Smart Key). 403.FORD12 1.60
© 2022 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.

Introduction 3
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Installation 6
Wiring diagram without OEM Remote Start and with T-Harness (THFOD2) 6
Wiring diagram without OEM Remote Start 7
Wiring diagram with OEM Remote Start and with T-Harness (THFOD2) 8
Wiring diagram with OEM Remote Start 9
Locating components in the vehicle 10
Vehicle connections 11
Module programming 13
Push-to-Start (PTS) vehicles 13
Connecting the module 14
LED diagnostics and troubleshooting 15
Soft reset 17
Hard reset 17
Feature programming 18
Feature and option list 19
Limited one year consumer warranty 20
Quick reference guide 21
Contents

3403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.

4403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Parking Lights Control
Door Lock Control
Door Unlock
Control of aftermarket alarm with OEM remote
* Fuel Level
* Odometer
Immobilizer Bypass-Data No Key Req'd
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
Ignition Status

5403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
START HERE This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible THFOD2
AUX
Keys required for
programming 1Keys required for operation 0
Vehicle Takeover Refer to the Quick Reference Guide section for more details.
Firmware notes
Manual transmission: Not compatible with vehicles equipped with a manual transmission.
Factory hood pin: In vehicles not equipped with a Factory Hood Pin, must permanently ground the vehicles N.C. OEM Hood Pin
input for successful operation. See Directechs for hood pin location.
Note: Does not apply to vehicles with a (-) Hood pin such as the 2017+ F-250 - F-450.
Pit Stop: The vehicle pit stop/idle mode feature is not available in this firmware.
The optional Plug & Play THFOD2 T-Harness is sold separately
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
All T-Harness wires not listed in the diagram are not required for the installation.
All connectors are displayed from the wire side (unless specified otherwise).
Refer to the "Vehicle connections" following the installation diagram.
Conditions and Limitations
This installation enables the OEM remote starter and the remote start system will not work in the following conditions:
The ignition is on.
The alarm system is triggered.
The doors/hood are open.
The transmission is not in Park (P).
The vehicle battery voltage is too low.
The service engine light is on. Note: Any stored DTC code errors will prevent vehicle from remote starting (no visual lights on dash).
RS Features: The following remote starter features can be configured via the information display:
Climate control
Heated seats / steering wheel
Runtime (for best results, program the remote starter runtime to match the OEM setting)
Remote Starter enable/disable
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.

6403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
1412
10 42
Wiring diagram without OEM Remote Start and with T-Harness (THFOD2)
CUT
19
210
311
412
513
614
715
8
16
Headlight Switch
Type 1
4-pin
connectors
Type 2
NOT USED
(-) Parking Lights Output: Brown/Red
Parking Lights Interr. (conn. side): Orange/Red
Parking Lights Interr. (veh. side): Yellow/Red
(+) Ignition Status Output: Gray/Black: 7
Parking Light
Interrupt: Pin 4
(+) Ignition Status Input
(+) 12V(+) 12V Input
Gateway Module
(on OBDII Connector or right of steering column)
(-) Parking Lights: Gray
or Yellow, pin 11
(-) Ground
D2D
only
T-Harness THFOD2
(optional)
Remote Start Safety
Override Switch
White/Black N.C.
Do not
connect
D2D Port
XKD2D65
(-) Trunk Release Output: Black/White: 1
Refer to
‘Vehicle connections’
for wire and connector
details.
(-) Hood Input
Hood Pin

7403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
2
153
164
175
18
6
219
197
22
10
208
2311
12
13
1
14
24
1412
10 42
Wiring diagram without OEM Remote Start
CAN 3 High: Tan/Black: 3
CAN 1 High: Orange/Green: 5
CAN 3: Low: Tan: 4
CAN 1 Low: Orange/Brown: 6
(-) Ground
(+) 12V Input
(-) Parking Lights Output: Brown/Red:12
Parking Lights Interr. (conn. side): Orange/Red:10
Parking Lights Interr. (veh. side): Yellow/Red:11
Parking Light
Interrupt:
Pin 4
CUT
19
210
311
412
513
614
715
8
16
Headlight Switch
CAN 1 High:
White/Blue or Blue, pin 20
CAN 3 Low: Pin 17
CAN 3 High: Pin 18
CAN 1 Low:
White, pin 19
(+)12V: Pin 24
(-) Ground: Pin 14
(-) Parking Lights:
Gray or Yellow,
pin 11
Gateway Module
(on OBDII Connector or
right of steering column)
(+) Ignition Status Output: Gray/Black: 7
(+) Ignition Status Input
D2D Port
XKD2D65
(-) Trunk Release Output: Black/White: 1
Refer to
‘Vehicle connections’
for wire and connector
details.
(-) Hood Input
Hood Pin

8403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram with OEM Remote Starter and with T-Harness (THFOD2)
CUT
19
210
311
412
513
614
715
8
16
Headlight Switch
Type 2
4-pin
connectors
Type 1
NOT USED
(-) Parking Lights Output: Brown/Red
Parking Lights Interr. (conn. side): Orange/Red
Parking Lights Interr. (veh. side): Yellow/Red
T-Harness THFOD2
(optional)
(+) Ignition Status Output: Gray/Black: 7
(-) Trunk Release Output: Black/White: 1
Parking Light
Interrupt:
Pin 4
(-) Ground
(+) Ignition Status Input
(+) 12V(+) 12V Input
Remote Start Safety
Override Switch
White/Black N.C.
Gateway Module
(on OBDII Connector or right of steering column)
(-) Parking Lights:
Gray or Yellow, pin 11
D2D
only
Do not
connect
D2D Port
XKD2D65
Refer to
‘Vehicle connections’
for wire and connector
details.
(-) Hood Input
Hood Pin

9403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
2
153
16
4
175
186
21
9
19
7
2210
208
23
11
12
13
1
24
14
1412
10 42
Wiring diagram with OEM Remote Start
CAN 2 High: Tan/Black: 3
CAN 1 High: Orange/Green: 5
CAN 2 Low: Tan: 4
CAN 1 Low: Orange/Brown: 6
(-) Ground
(+) 12V Input
(-) Parking Lights Output: Brown/Red:12
Parking Lights Interr. (conn. side): Orange/Red:10
Parking Lights Interr. (veh. side): Yellow/Red:11
Parking Light
Interrupt:
Pin 4
CUT
19
210
311
412
513
614
715
8
16
Headlight Switch
CAN 1 High:
White/Blue or Blue, pin 20
CAN 2 Low: Pin 22
CAN 2 High: Pin 23
CAN 1 Low:
White, pin 19
(+)12V: Pin 24
(-) Ground: Pin 14
(-) Parking Lights:
Gray or Yellow,
pin 11
Gateway Module
(on OBDII Connector or
right of steering column)
(+) Ignition Status Output: Gray/Black: 7
(+) Ignition Status Input
D2D Port
XKD2D65
(-) Trunk Release Output: Black/White: 1
Refer to
‘Vehicle connections’
for wire and connector
details.
(-) Hood Input
Hood Pin

10 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Locating components in the vehicle

11 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2015 Lincoln MKZ Hybrid (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (Data) HS CAN 2 High (w/ OEM Remote Start) or
(Data) HS CAN 3 High (w/o OEM Remote Start)
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 23
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 18
data
data
gray (MS CAN)
green (HS2 CAN)
H1/4 Tan (Data) HS CAN 2 Low (w/ OEM Remote Start) or
(Data) HS CAN 3 Low (w/o OEM Remote Start)
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 22
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 17
data
data
violet (MS CAN)
gray (HS2 CAN)
H1/5 Orange/Green (DATA) HS CAN 1 High Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 20 data blue (HS CAN)
H1/6 Orange/Brown (DATA) HS CAN 1 Low Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 19 data white (HS CAN)
H1/7 Brown Relay N.O. No Connection No Connection
H1/8 Yellow Relay COM No Connection No Connection
H1/9 Orange/Yellow Relay N.C. No Connection No Connection
H1/10 Orange/Red Relay N.C. Parking Light Interrupt (conn. side) headlight switch, black 16 pin plug, pin 4 cut black/blue
H1/11 Yellow/Red Relay COM Pk Parking Light Interrupt (vehicle side) headlight switch, black 16 pin plug, pin 4 cut black/blue
H1/12 Brown/Red Relay N.O. (-) Parking Light Output headlight switch, black 16 pin plug, pin 11 - yellow
H1/13 Red (+) W2W Only - 12 Volt Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 24 + Gray/Red (7.5A)
H1/14 Black (-) W2W Only - Ground Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 14 - Black/Blue
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) Trunk Release Output release switch, black or brown 6 pin plug, pin 6
Not Applicable
- gray/yellow
H2/2 Green/Black No Connection No Connection
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black (-) W2W Only - Trunk Output Remote Starter
H2/5 Violet/White (AC) W2W Only - Tach Output Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black (+) Ignition Output Remote Starter
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown No Connection No Connection
H2/10 Yellow/Black No Connection No Connection
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter

12 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green (-) W2W Only - Lock Input Remote Starter
H3/2 Blue (-) W2W Only - Unlock Input Remote Starter
H3/3 Red/White (-) W2W Only - Trunk Input Remote Starter
H3/4 White/Violet No Connection No Connection
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black (-) Hood Input [1]
H3/7 Pink/White No Connection No Connection
H3/8 Violet (+) W2W Only - Starter Input Remote Starter
H3/9 Pink No Connection No Connection
H3/10 Blue/White (-) W2W Only - GWR Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Blue (Data) TX
H4/2 Black (-) Ground
H4/3 Green (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color
Ground 2 Gateway Module on OBD-Data Link Connector, black 24 pin plug,
pin 14
- Black/Blue
Hood Pin BCM/dash fuse box, black 40 pin plug (C), pin 14 - blue/orange
Ignition BCM/dash fuse box, black 22 pin plug (H), pin 6 + blue/gray (for ignition sense only)
Second 12 Volts Gateway Module on OBD-Data Link Connector, black 24 pin plug,
pin 24
+ Gray/Red (7.5A)

13 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
Push-to-Start (PTS) vehicles
1Wait until the LED turns ON solid red.
2Press on the Push-to-Start (PTS) button once to turn the ignition ON. The LED will remain ON
solid green for 3 seconds, and will then turn OFF.
3Press the PTS button once more to turn the ignition OFF once the module is successfully
programmed.
You have successfully completed the module programming sequence.

14 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Connecting the module
Important!
Make all the required connections to the vehicle, as described in this guide, and double check to ensure everything is correct prior
to moving onto programming.
Warning! To take advantage of advanced features, you must use DirectLink 4.5 (and higher) or the Directechs Mobile application.
Flashing a module using your computer:
1. Connect the interface module to your computer using the XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and select the Flash Module button.
3. Follow the instructions to select your vehicle, installation type, and configure your options.
4. Once you have configured the firmware options, click on the FLASH button.
Flashing a module using your smartphone or tablet:
1. Connect the interface module to your XKLoader3.
2. Launch the Directechs Mobile app on your smartphone or tablet.
3. Select FLASH YOUR MODULE and follow the on screen instructions.
When the flashing operation is successful, you can proceed with the instructions below.
D2D installation
Recommended: Connect the 10-pin, 12-pin and 14-pin harnesses to the module, then
connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
4th
(D2D)
2nd
(12-pin)
OR
W2W installation
If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin
harness to the module. 3rd
(14-pin)
1st
(10-pin)
2nd
(12-pin)

15 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
LED diagnostics and troubleshooting
This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation.
Module Programming
LED Description Troubleshooting
Off Module has no power. Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If
12 Volt is present, the module may be defective.
Solid red
Waiting to begin the programming
sequence. Ensure the correct programming procedure is being followed.
Flashes green & red Initialization failed. Reset the module and complete the programming again. If the issue persists, please contact Technical
Support.
Solid orange Transponder functions were skipped. (If compatible) when RXT mode is not desired or convenience features are needed, please reset the and
reprogram the module.
Flashes green
All required CAN networks has been
detected. Normal operation.
Flashes orange 1 of 2 CAN networks has been detected. Normal operation.
Flashes orange
slowly
Key2GO initiated. Please follow the steps indicated in “Module programming” to complete the Key2GO programming.
Solid green x 3 secs
Module was successfully programmed with
all functions. Normal operation.
Solid orange x 3 secs
Module was successfully programmed
without transponder functions. Normal operation.
Module Programming - Error codes
LED Description Troubleshooting
Flashes red x 1 CAN2 not detected.
Check the CAN2 Orange/Green and Orange/Brown wire connections. Wake up the data bus by
turning the ignition on and try again. If your installation does not require this connection, skip this step by
pressing the programming button 5 times.
Flashes red x 1 J1850 not detected. Check the J1850 wire connection. Wake up the data bus by turning the ignition on and try again.
Flashes red x 2 CAN1 not detected.
Check the CAN1 Tan and Tan/Black wire connections. Wake up the data bus by turning the ignition on
and try again. If your installation does not require this connection, skip this step by pressing the
programming button 5 times.
Flashes red x 3 Bypass data not detected. Check the bypass line connection. If more than one wire is used, make sure they are not inverted. Ensure
the vehicle still operates correctly using the factory key.
Flashes red x 4 Bypass processing error. The bypass calculation failed. Reset the module and try again. If the condition persists, please contact
Technical Support.
Flashes red x 5 ISO 1 not detected. The Yellow/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams &
vehicle wiring reference charts)” to check the connections.
Flashes red x 6 ISO 2 not detected. The Orange/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams &
vehicle wiring reference charts)” to check the connections.
Flashes red x 7 MUX not detected. The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to “Installation
(wiring diagrams & vehicle wiring reference charts)” to check the connections.
External Module Synchronization
LED Description Troubleshooting
(Flashes red, red,
then orange) x 10
OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited.

16 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.

Active Ground When Running (Status)
LED Description Troubleshooting
Flashes green
Ground When Running (Status) command
received. The module has initialized the remote start sequence.
Flashes red & orange Ignition ON command received. The module has received the Ignition ON command and is processing the remote start sequence.
Flashes green quickly Start ON command received. The module has received the Start ON command and is processing the remote start sequence.
Flashes red x 10 PTS shutdown error. The PTS output from the module was not activated due to safety protection.
Flashes red x 21 CAN bus incorrectly detected. Verify the CAN1 and CAN2 connections. Refer to “Installation (wiring diagrams & vehicle wiring
reference charts)” to check the connections.
Commands
LED Description Troubleshooting
Flashes orange x 1 LOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 2 UNLOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 3 TRUNK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 4 AUX1 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 5 AUX2 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 6 AUX3 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Shutdown Codes
LED Description Troubleshooting
Flashes green x 1 Takeover successful. Normal operation.
Flashes red x 1 Runsafe was not disabled. No UNLOCK command was received prior to opening the door, or the 45 second timer expired in
takeover mode.
Flashes red x 2 Brake was not detected. The brakes were not detected, which prevents the system from shutting down the vehicle.
Flashes red x 3 Smart key was not detected. The smart key was not detected, which prevents the system from shutting down the vehicle.
Flashes red x 4 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down.

17 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Soft reset
1
D2D installation
Connect the 10-pin, 12-pin & 14-pin harnesses to the module. Press and hold the
programming button, then connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
5th
(D2D)
2nd
(12-pin)
4th
(Button)
OR
W2W installation
Connect the 10-pin & 12-pin harnesses to the module. Press and hold the
programming button, then connect the 14-pin harness to the module. 4th
(14-pin)
3rd
(Button)
1st
(10-pin)
2nd
(12-pin)
2Wait 3 seconds until the LED turns ON solid orange then release the programming button.
The LED turns ON solid red. &&
Solid SolidRelease
A module reset will only erase the steps perfomed in “Module programming”. The firmware and settings flashed to the module
will not be affected.
Hard reset
Warning Against Executing a Hard Reset!
1
D2D installation
Connect the 10-pin, 12-pin & 14-pin harnesses to the module. Press and hold the
programming button, then connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
5th
(D2D)
2nd
(12-pin)
4th
(Button)
OR
W2W installation
Connect the 10-pin & 12-pin harnesses to the module. Press and hold the
programming button, then connect the 14-pin harness to the module. 4th
(14-pin)
3rd
(Button)
1st
(10-pin)
2nd
(12-pin)
2Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the
LED starts to flash orange and red. Solid Flashes
&
3Release the programming button. The LED turns ON solid red. &
Release Solid
A hard reset will revert the flashed firmware back to its default factory settings. Depending on the installation, some settings (such
as RFTD and D2D options) may have to be reconfigured. Refer to “Feature and option list”.

18 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Feature programming
To enter feature programming routine:
1. Turn the ignition ON, then OFF.
2. Within 5 seconds, press and hold the programming button until the LED turns ON orange (after 3 seconds).
3. Release the Programming button.
4. The LED will flash green once slowly to indicate the feature number is 1. After a short delay, the LED flashes red rapidly to
indicate the current option of feature 1 (e.g. 1 x green followed by 1 x red indicates feature 1 is set to option 1). The flashing
sequence will repeat until a new command is entered.
Changing feature options:
1. Press the lock/arm or unlock/disarm button on aftermarket transmitter to change the option of the selected feature.
2. The LED flashes red rapidly the number of times equal to the current option number. After a short delay, the LED flashes green
slowly the number of times to indicate the current feature. The flashing sequence will repeat until a new command is entered.
Accessing another feature:
1. Press and release the programming button a number of times to advance from the current feature to the next desired feature.
2. The LED flashes green slowly the number of times equal to the feature number. After a short delay, the LED flashes red rapidly
to indicate the current option of the current feature. The flashing sequence will repeat until a new command is entered.
When the maximum number of features or options is reached, the LED will start flashing again from the first feature or option.
Exiting feature programming:
To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface
for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence.

19 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Feature and option list
It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing page at
www.directechs.com. The web offers more options; however, manual configuration of the features is possible using the information on this
page.
* Default option
Feat
.Operation Flashes / Option Description
1 RFTD Output Type 1. No RF Output* Module is connected to a remote starter using a standard installation.
2. RFTD Output Module is connected to an XL202 using an RSR or RXT installation (when available).
3. SmartStart Module is connected to SmartStart using an RSR or RXT installation (when available).
2

20 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Limited 12 Months Consumer Warranty
VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part
thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date
of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s
option) without charge for parts or repair labor. A transmitter for a vehicle security or remote start system is warranted for
12 months from he date of original purchase.
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty
coverage (e.g. dated bill of sale), authorization number, specication of defect(s), transportation prepaid, to an approved
warranty station. This warranty is not transferable.
This Warranty does not cover damage to the vehicle’s electrical system or costs incurred for the installation, removal or
reinstallation of the product. This Warranty does not cover batteries, broken LCD transmitter display screens, nor apply
to any product or part thereof which, in the opinion of the Company, has su󰀨ered or been damaged through alteration,
improper installation, mishandling, misuse, abuse, neglect, accident, or by removal or defacement of the factory serial
number/bar code label(s).
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 24 MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY. No person or representative is
authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.
The company does not warrant that this product cannot be compromised or circumvented. THE EXTENT OF THE
COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY
PURCHASER FOR THE PRODUCT WITHOUT INSTALLATION LABOR.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitations or exclusions may not apply to you. This Warranty gives you specic legal
rights and you may also have other rights which vary from state to state.
VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824
