Dynojet Power Commander V 22-027 User manual

22-027 www.powercommander.com 2007-2013 Yamaha Grizzly 700 PCV - 1
PARTS LIST
1 Power Commander
1 USB Cable
1 CD-ROM
1 Installation Guide
2 Power Commander Decals
2 Dynojet Decals
2 Velcro
1 Alcohol swab
YOU CAN ALSO DOWNLOAD THE
POWER COMMANDER SOFTWARE AND
LATEST MAPS FROM OUR WEB SITE AT:
www.powercommander.com
2007-2013 Yamaha Grizzly 700
Installation Instructions
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com

22-027 www.powercommander.com 2007-2013 Yamaha Grizzly 700 PCV - 2
EXPANSION PORTS 1 & 2
Optional Accessories such as
Color LCD unit or Auto tune kit.
POWER COMMANDER V
INPUT ACCESSORY GUIDE
Map - (Input 1 or 2) The PCV has the ability to hold
2 different base maps. You can switch on the
fly between these two base maps when you
hook up a switch to the MAP inputs. You can
use any open/close type switch. The polarity
of the wires is not important. When using the
Autotune kit one position will hold a base map
and the other position will let you activate the
learning mode. When the switch is “CLOSED”
Autotune will be activated.
Shifter- (Input 1 or 2) These inputs are for use with the
Dynojet quickshifter. Insert the wires from the
Dynojet quickshifter into the SHIFTER inputs.
The polarity of the wires is not important.
Speed- If your application has a speed sensor then
you can tap into the signal side of the sensor
and run a wire into this input. This will allow
you to calculate gear position in the Control
Center Software. Once gear position is setup
you can alter your map based on gear position
and setup gear dependent kill times when
using a quickshifter.
Analog- This input is for a 0-5v signal such as
engine temp, boost, etc. Once this input
is established you can alter your fuel curve
based on this input in the control center
software.
Crank- Do NOT connect anything to this port unless
instructed to do so by Dynojet. It is used to
transfer crank trigger data from one module to
another.
ACCESSORY INPUTS
Wire connections:
To input wires into the PCV first remove the rubber
plug on the backside of the unit and loosen the
screw for the corresponding input. Using a 22-24
gauge wire strip about 10mm from its end. Push the
wire into the hole of the PCV until is stops and then
tighten the screw. Make sure to reinstall the rubber
plug.
NOTE: If you tin the wires with solder it will make
inserting them easier.
CRANK
ANALOG
SPEED
INPUT 1 (Grnd)
INPUT 1
INPUT 2 (Grnd)
INPUT 2
USB CONNECTION

22-027 www.powercommander.com 2007-2013 Yamaha Grizzly 700 PCV - 3
1 Remove the seat.
2 Remove the front cover (Fig. A).
3 Remove the right hand side cover (Fig. B) and the same cover on the left side.
4 Remove the intake tube for the CVT clutch on the right hand side of the quad
(Fig. C).
This allows access to the Throttle Position Sensor
FIG.A
Remove
Ground wire
FIG.B
Remove this cover
Remove
Remove
FIG.C

22-027 www.powercommander.com 2007-2013 Yamaha Grizzly 700 PCV - 4
5 Unplug the stock wiring harness from the injector (Fig. D).
Figure D was taken from the left hand side of the quad.
FIG.D
6 Place the PCV in the battery area temporarily.
7 Route the PCV harness down the left hand side of the Quad towards the
throttle body.
8 Plug the PCV in-line of the stock wiring harness and injector (Fig. E).
FIG.E
FIG.F
9 Locate the Throttle Position Sensor on the right hand side of the throttle body.
10 Unplug the stock wiring harness from the TPS (Fig. F).
Unplug
Unplug

22-027 www.powercommander.com 2007-2013 Yamaha Grizzly 700 PCV - 5
11 Plug the wiring harness from the PCV in-line of the stock wiring harness and
TPS (Fig. G).
FIG.G
12 Attach the ground wire from the PCV to the negative side of the battery
(Fig. H).
FIG.H
FIG.J
13 Install the included port covers onto your PCV.
14 Secure the PCV near the battery using the supplied Velcro (Fig. J).
Make sure to use the alcohol swab to clean both surfaces before attaching.
15 Reinstall bodywork.
Ground wire
