CTC Union FMC-1001S User manual

CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60, Zhouzi St., Neihu District, Taipei 114
Taiwan
T+886-2-26591021
F+886-2-26590237
E[email protected]
© 2017 CTC Union Technologies Co., Ltd.
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.
Introduction
FMC-1001S provides a cost-eff ective solution for Fast and
Gigabit Ethernet fiber media conversion. By utilizing industry
standard SFP modules, this converter can be utilized with multi-
mode or single mode fibers with LC connectors as well as single
fiber (WDM) transceivers. The fiber port provides 100/1000M
connection, while the copper UTP port provides 10/100/1000M
auto-negotiation to connect to a wide variety of Ethernet devices.
FMC-1001S gives you the freedom to extend your
10/100/1000M cabling distance by allowing connectivity up to
120KM over fiber. LED indicators signal the power status, UTP link
& speed and fiber link & speed.
Features
10/100/1000Base-T to 100/1000Base-X SFP Converter
Auto-Negotiation
Auto MDI/MDIX
Forward 2048K bytes (Max.) packets (Switch mode)
Support 9K bytes packets (Converter mode)
Supports Link Fault Pass Through (LFP)
Supports IEEE 802.1Q Tag VLAN pass thru
Supports Q in Q double tagged frame transparent
Provides DIP switch to set functions
Specifications
Electrical Interface
Standards: IEEE802.3 (10Base-T), 802.3u (100Base-TX), 802.3ab
(1000Base-T)
Speed: 10/100/1000Mbps
Connector Type: 1 x RJ-45 connector
Duplex Mode: Full duplex
Cable Type: Cat. 5, 5e or higher
Quick Installation Guide
FMC-1001S
FMC-1001S-AC
FMC-1001S-DC
10/100/1000Base-T to 100/1000Base-X Fiber Media Converters
Specifications (Cont.)
Optical Interface
Standards: IEEE802.3u (100Base-FX), 802.3z (1000Base-SX/LX)
Connector Type: SFP LC
Data Rate: 100/1000Mbps
Duplex Mode: Full duplex
Fiber: 50/125um (MM), 62.5/125um (MM); 9/125um (SM)
Distance: 2KM (MM), 15/30KM (SM), 20/40KM (WDM)
Wavelength: 1310nm (MM), 1310/1550nm (SM)
1310nm TX/1550nm RX Type A (WDM)
1550nm TX/1310nm RX Type B (WDM)
Power
Adapter Type: Adapter Output 12VDC 0.5A
Built-in AC Power: Input 100~240VAC
Built-in DC Power: Input 18~60VDC
Consumption: < 3W (SFP not included)
Mechanical
Dimensions: 73.4mm × 108mm × 23mm (Adapter type);
73.4mm × 135mm × 23mm (Power built-in type)
Mounting: Wall mounting (For wall mounting models only)
Weight: 120g (Adapter type); 140g (Power built-in type)
Environment
Operating Temperature: 0°C~50°C
Storage Temperature: -10°C~70°C
Humidity: 10%~90% (Non-condensing)
MTBF (MIL-HDBK-217)
65,000 Hours
Certifications
EMC: FCC Class A, CE
V1.0
- 2 -
- 1 -
[email protected]
www.ctcu.com

Panels
FMC-1001S (Adapter type)
FMC-1001S-AC (Built-in AC power type)
FMC-1001S-DC (Built-in DC power type)
LED Indicators
LED
Color
Status
Description
PWR
Green
ON
Lit if power is connected and active.
OFF
Power is not connected.
FX Link
Green
ON
Fiber link is connected and active.
OFF
No fiber link.
FX Speed
Amber
ON
The connected fiber speed is 1000M.
Green
ON
The connected fiber speed is 100M.
Amber/
Green
OFF
No fiber optic link.
TP Link
Green
ON
TP link is connected and active.
OFF
No TP link.
TP Speed
Amber
ON
The connected LAN speed is 1000M.
Green
ON
The connected LAN speed is 100M.
Amber/
Green
OFF
No Ethernet link or connected LAN
speed is 10M.
FDX
Green
ON
Full duplex.
OFF
Half duplex.
No.
Description
1
LAN connection
2
SFP Fiber slot
3
DIP Switch
4
LED indicators
5
Power input
Table 1: Index Reference
DIP Switch Function Descriptions
Pole
No.
Function
Setting
Function Description
1
FX Speed
FX 1G*
Set fiber optic speed to
1000Mbps (1Gbps).
FX
100M
Set fiber optic speed to
100Mbps.
2
FX-LFP
OFF*
Disable fiber link fault pass
through.
ON
Enable fiber link fault pass
through.
3
TP LFP
OFF*
Disable UTP link fault pass
through.
ON
Enable UTP link fault pass
through.
4
Flow
Control
OFF*
Disable flow control function.
ON
Enable flow control function.
NOTE 1: By default, all DIP switches are set to OFF position (marked with *).
NOTE 2: When LFP is enabled, the LAN port link down will force Fiber port
link down and vice versa.
Wall Mounting (For Wall Mounting Models Only)
FMC-1001S standalone converters have the option of adding wall
mount capability. One wall mount kit is required for installing a
single standalone unit on the wall. Each wall mount kit provides all
the necessary hardware for a complete installation.
- 5 -
www.ctcu.com
Converter (Adapter type) with Wall Mounting Bracket
5
1
4
2
5
2
- 4 -
- 6 -
- 3 -
Converter (Built-in power type) with Wall Mounting Bracket
2
4
1
3
5
3
3
1
4
