Bracket Installation (48-inch decks)
Note: Removing the cutting deck from beneath the tractor
as instructed in your tractor’s Operator’s Manual will ease
installation of this kit.
1. Locate and discard the three identical roller brackets used
for 54- and 60-inch decks.
2. Secure the two identical roller brackets for 48-inch decks
to the rear left and rear center of the cutting deck with self-
tapping screws. See Figure 1-2.
3. Secure the remaining roller bracket for 48-inch decks to the
rear right and of the cutting deck with self-tapping screws.
See Figure 1-2.
Figure 1-2
19A70019100 lawn striping kit is designed for use with three-
blade fabricated cutting decks found on select Cub Cadet
models. Refer to your machine’s Operator’s Manual or consult
your Cub Cadet dealer to assure compatibility.
Carton Contents
Before beginning installation, remove all parts from the carton to
make sure everything is present. Carton contents are listed below
and shown in Figure 1-1. Part numbers are shown in parentheses.
• One 25.75” Pin (711-05664)
• One Hex Lock Nut (712-3083)
• Six ⁄-inch Screws (710-0623)
• Four Rollers (731-3005)
• Three Roller Brackets (703-08454)
• Two Roller Brackets (703-09618)
• One Roller Bracket (703-08076)
48-inch decks 54- and 60-inch decks
Figure 1-1
WARNING: Before beginning installation, place
the tractor on a firm and level surface, set the
parking brake, place the PTO in the disengaged
(OFF) position, stop the tractor’s engine and remove
the ignition key to prevent unintended starting.
InstallatIon Manual
Lawn Striping Kit — 19A70019100
Form No. 769-06205
October 11, 2013
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA

Bracket Installation (54- and 60-inch decks)
Note: Removing the cutting deck from beneath the tractor
as instructed in your tractor’s Operator’s Manual will ease
installation of this kit.
4. Locate and discard the roller brackets used for 48-inch
decks.
5. Secure the three identical roller brackets for 54- and 60-
inch decks to the rear left, rear center and rear right of the
cutting deck with self-tapping screws. See Figure 1-3.
Figure 1-3
Roller Installation (all decks)
1. Position the rollers between the brackets as shown in
Figure 1-4.
2. Insert the pin through the brackets and rollers and secure it
in place with the hex lock nut. See Figure 1-4.
Figure 1-4
G
E
N
U
I
N
E
F
A
C
T
O
R
Y
P
A
R
T
S
To order replacement parts, call the Customer Dealer Referral Line at 1-877-282-8684
or visit www.cubcadet.com to find the nearest Cub Cadet dealer in your area.
