Cub cadet The tank tr20 User manual































APPLICATION

EQUIPMENT





TO MAkE yOU MOrE vALUAbLE TO yOUr CUsTOMErs.

How can you make your business more valuable to your customers and more protable to you? By using our

complete line of proven, reliable and highly successful application equipment. Our latest addition, the new XP

Stand-On Spreader/Sprayer, features an innovative design with the maneuverability and exibility you need

to be as efcient with your time as possible. Spreaders. Sprayers. Renovators. We’re talking rugged, durable

equipment that’s built to handle any of the toughest jobs and hold up over time. So no matter which piece

you’re using, you can be assured that you’re working with the best equipment available.















































































THE TANK™

SPREADER/SPRAYER

XP STAND-ON

SPREADER

XP STAND-ON

SPREADER/SPRAYER

TR20 TURF

RENOVATOR

80-LB. SPREADER

COMMERCIAL

SPRAYERS











as rated by engine manufacturer †See your local Cub Cadet Commercial Independent Dealer for warranty information.





WE MEAN BUSINESS.

™

80-lb. Rotary Spreader XP Stand-On Spreader XP Stand-On

Spreader/Sprayer TR20 Turf Renovator THE TANK™

Spreader/Sprayer

Engine – 6 HP* Kawasaki®6 HP* Kawasaki®8 HP* Kawasaki®17 HP* Kawasaki®

Engine series – Vertical OHV Vertical OHV Horizontal OHV Vertical OHV

Ignition – Recoil start Electric start/recoil Recoil start Electric start

Cylinder – Single Single Single Twin

Gear reduction 5:1 ratio – Electric motor – –

Oil ﬁlter – Yes – – Yes

Hopper/tank width – –

10 gal. total/fender mounted

20" dethatching/seeding –

Hopper size 80 lbs. 125 lbs. 125 lbs. 35 lbs. 125 lbs.

Tank size – – Dual 5-gal. tanks/independent – 40 gal.

Tank shape Rectangular hopper Rectangular hopper Rectangular hopper Rectangular Rectangular

Strainer Stainless mesh screen Stainless mesh screen Stainless mesh screen – –

Agitation Oscillating agitator Oscillating agitator Oscillating agitator – Triple jet &

oscillating agitator

Hopper/tank material Polyethylene Polyethylene Polyethylene Steel Polyethylene

Frame type Stainless steel Stainless/welded steel Stainless/welded steel Welded steel Welded steel

Frame material 1” SS tube 1" SS tube & 7-ga. steel 1" SS tube & 7-ga. steel 11-ga. painted steel Painted steel

Drive system Push Hydro-Gear™ transmission Hydro-Gear™ transmission Hydraulic with

chain-driven differential

Kanzaki DUP-10 pumps &

White®wheel motors

Speeds – Fwd: 5 mph, Rev: 3 mph Fwd: 5 mph, Rev: 3 mph Fwd: 2 mph, Rev: 1 mph Fwd: 10 mph, Rev: 4 mph,

lock-in application speed

Front wheels 13” x 5.0” – 6” 13" x 6.5" – 6" 13" x 6.5" – 6" 13" x 5.0" – 6" 13" x 6.5" – 6"

Rear wheels – 18" x 6.5" – 8" 18" x 8.5" – 8" 13" x 5.0" – 6" 24" x 12" – 12"

Pump output – – – – 4.8-GPM, 40 psi

Pump type – – 12 VDC Flojet™ pump – 12 VDC Flojet™ pump

Pump pressure – – – – –

Hose size – – 25-ft. coil hose w/spot

wand – 25-ft. coil hose

Hose material – – PVC – PVC

Pressure rating (hose) – – 100 psi – 100 psi

Length x width x height 48” x 25” x 35” 56" x 35" x 48" 56" x 35" x 48" 31" wide overall 99" x 57" x 48"

Effective spray/spread width – 120” 120"/108" boomless spray – 120"

Weight 32 lbs. dry 340 lbs. dry 365 lbs. dry 290 lbs. dry 1,134 lbs. dry

Spray wand/gun – – Spot spray wand &

3 boomless spray nozzles –Adj. spot spray wand &

3 section boom 5 nozzle

Warranty†1-year limited commercial 1-year limited commercial 1-year limited commercial 1-year limited commercial 1-year limited commercial

SPRAYERS 25 Spot 50 Poly 100 Poly 200 Poly 300 Poly 200 Compact

Engine 12 VDC 4 HP* Kawasaki®5.5 HP* Kawasaki®5.5 HP* Kawasaki®5.5 HP* Kawasaki®5.5 HP* Kawasaki®

Engine series – Horizontal OHV Horizontal OHV Horizontal OHV Horizontal OHV Horizontal OHV

Ignition – Recoil start Recoil start Recoil start Recoil start Recoil start

Cylinder – Single Single Single Single Single

Gear reduction – 6:1 direct-coupled 6:1 direct-coupled 6:1 direct-coupled 6:1 direct-coupled 6:1 direct-coupled

Tank size 25 gal. 50 gal. 100 gal. 200 gal. 300 gal. 200 gal.

Tank shape Rectangular

Strainer In-line SS on inlet

side of pump Stainless steel mesh Stainless steel mesh Stainless steel mesh Stainless steel mesh Stainless steel mesh

Agitation – Triple jet spray Triple jet spray Triple jet spray Triple jet spray Triple jet spray

Hopper/tank material Polyethylene

Frame type – Welded steel Welded steel Welded steel Welded steel Welded steel

Frame material – Painted steel Painted steel Painted steel Painted steel Painted steel

Pump output 4.8-GPM/40 psi Max. 6-GPM Max. 9.5-GPM Max. 9.5-GPM Max. 9.5-GPM Max. 9.5-GPM

Pump type Diaphragm Twin diaphragm Twin diaphragm Twin diaphragm Twin diaphragm 3-diaphragm

Pump pressure 60 psi Max. 275 psi Max. 550 psi Max. 550 psi Max. 550 psi Max. 550 psi

Hose reel – Hannay®electric Hannay®electric Hannay®electric Hannay®electric Hannay®electric

Hose size 1/4" i.d. x 25' 3/8" i.d. x 300' 1/2" i.d. x 300' 3/8" i.d. x 400' 1/2" i.d. x 300' 1/2" i.d. x 300'

Hose material Flexcoil – PVC PVC PVC urethane core PVC urethane core PVC urethane core PVC urethane core

Pressure rating (hose) 100 psi 300 psi 800 psi 800 psi 800 psi 800 psi

Length x width x height 30" x 20" x 19" 54" x 19" x 26" 48" x 38" x 34" 65" x 39" x 40" 88" x 38" x 47" 62" x 40" x 40"

Weight w/o hose & reel 22 lbs. dry 125 lbs. 237 lbs. 336 lbs. 422 lbs. 330 lbs.

Weight w/hose & reel – 200 lbs. 371 lbs. 470 lbs. 556 lbs. 454 lbs.

Spray wand/gun Trigger jet

w/conejet nozzle Order as needed Order as needed Order as needed Order as needed Order as needed

Warranty†1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

*as rated by engine manufacturer †See your local Cub Cadet Commercial Independent Dealer for warranty details. Commercial products are intended for professional use.

APPLICATION EQUIPMENT

This brochure is for advertisement purposes only. The product depictions are not meant to be used or relied upon as a substitute for the safety and use information that is published in the respective operator’s

manual. Before operating

the machine, read, understand and follow all instructions in the manual and on the machine. Speciﬁcations and programs are subject to change without notice. Images may not reﬂect dealer inventory and/or unit speciﬁcations.
