CUDA 2216 User manual

OPERATOR’S MANUAL
For technical assistance or the dealer nearest you,
consult our web page at www.CudaUSA.com
8.941-287.0-R07/01/16
2216
AUTOMATIC PARTS WASHER
89412870-1
9.801-125.0
ATTENTION
USE ONL
Y CUDAAPPROVED
DETERGENTSTO EXTEND
LABORWARRANTY TO 1-YEAR!
MIXDETERGENTS 1 LB (1/2 KG) PER
5-GALLONS(15 LITERS) OF WATER
ForCUDA Approved Detergents visit
http://www.cudausa.comor
call888-319-0882
9.807-513.0
90-DAYLABOR WARRANTY
EXTENDSTO 1-YEAR
WITHEXCLUSIVE USE OF
CUDADETERGENTS
LIMITED
■1.043-451.0 ■1.043-452.0 ■1.043-453.0
■ 1.043-454.0 ■1.043-455.0 ■1.043-456.0
■1.043-457.0 ■1.043-528.0 ■1.043-529.0
■1.043-530.0 ■1.043-531.0 ■1.043-532.0
■1.043-534.0 ■1.043-539.0

CONTENTS
2
2216 • 8.941-287.0-R
SECTION 1
Introduction and Safety
Introduction & General Safety 4-5
Component Identification 6-7
SECTION 2
Installation
Before you Begin 8
Step 1: Make Electrical Connections 9
Step 2: Connect a Compressed-Air Line and Accessories 0
Step 3: Connect a Water Line 0
Step 4: Fill the Machine with Water and Add Detergent 9
SECTION 3
Operation
Main Operating Components 10-13
Control Panel 10
Thermostat 10
Lid Safety Switch 11
Debris Screen 11
Air Flow Valve (Optional) 11
Power Brush (Optional) 11
Detail Brush and Flow Regulator (Optional) 12
Dual Oil Separator (DOS) System (Optional) 12
Detergent and Additives 13
Preparing the Machine for Use 13
Washing Parts 13
Shutting Down the Machine 13
SECTION 4
Troubleshooting
Overview 14-15
Troubleshooting the Electrical System 16-17
Testing Individual Components 18-19

3
CONTENTS
2216 • 8.941-287.0-R
Model Number ______________________________
Serial Number ______________________________
Date of Purchase ____________________________
The model and serial numbers will be found on a decal attached to
the parts washer. You should record both serial number and date
of purchase and keep in a safe place for future reference.
SECTION 5
Maintenance and Repair
Maintaining the Machine 20
Cleaning and Aligning the Spray Nozzles 20
Cleaning out the Sump 20
Using the Oil Skimmer 21-22
Repairing the Machine 22
Heating Element 22
Thermostat 22
Turntable Motor 23
Pump Seal 24-25
Timers and Switches on the Control Panel 25
EXPLODED VIEWS & PART LISTS
Front View Exploded View and Parts List 26-27
Rear View Exploded View and Parts List 28-29
Auto Fill & Brush Options Exploded View & Parts List 30-31
120 V Control Panel Exploded View and Parts List 32
230V, 460V Control Panel Exploded View and Parts List 33
120V Electrical Panel Exploded View and Parts List 34-35
208V, 230V, 1 pH Electrical Panel Exploded View and Parts List 36-37
208V, 230V, 460V, 575V 3 Ph Electrical Panel
Exploded View and Parts List 38-41
Oil Skimmer Exploded View and Parts List 42

2216 • 8.941-287.0-R
OPERATOR’S MANUAL PARTS WASHER
4
This manual is intended as a guide for safely installing,
operating and maintaining your automatic parts washer.
We reserve the right to make changes at any time
without incurring any obligation.
Owner/User Responsibility:
The owner and/or user must have an understand-
ing of the manufacturer’s operating instructions and
warnings before using this machine. Warning infor-
mation should be emphasized and understood. If the
operator is not fluent in English, the manufacturer’s
instructions and warnings shall be read to and discussed
with the operator in the operator’s native language by
the purchaser/owner, making sure that the operator
comprehends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’ instructions.
SAVE THESE INSTRUCTIONS
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and se-
rial number. Use only identical replacement parts.
This machine is to be used only by trained
operators.
GENERAL SAFETY
INFORMATION
CAUTION:To reduce the risk of
injury, read operating instruc-
tions carefully before using.
1. Read the owner’s manual
thoroughly. Failure to follow in-
structions could cause a mal-
function of the parts washer
and result in death, serious
bodily injury and/or property
damage.
2. Improper installation could cause serious injury
to the machine. All installations must comply with
local codes. Contact your electrician, plumber,
utility company or the selling distributor for specific
details.
3. The machine can only operate on the type of electri-
cal power indicated on the electrical specifications
tag. Operating the machine on any other power
supply will permanently damage the motors.
WARNING
READ OPERATOR’S
MANUAL
THOROUGHLY
PRIOR TO USE.
DANGER: Keep wand, hose, and
water spray away from electric
wiring or fatal electric shock
may result.
4. Install the machine in compli-
ance with the National Electric
Code, connect it to a properly
sized lockable disconnect and
ground the machine using
the grounding stud inside the
main electrical panel.
5. While operating the machine, keep all electrical
panels in place and securely fastened at all times.
6. Disconnect the machine completely from the
outside power source before servicing.
WARNING: Hot, high pressure
cleaning solution could cause
serious injury.
7. Do not operate the machine
with the lid or door open and
do not override the safety
switch.
8. After the machine stops, wait
10 seconds before opening
the lid or door.
WARNING: Always wear
approved eye protection and
protective clothing while operat-
ing machine.
9. Eye protection, gloves, foot
protection and other safety
devices must be worn when
loading and unloading parts
to be cleaned.
10. Always wear rubber gloves
when loading and unloading the machine or ser-
vicing components in the processing chambers or
sumps.
WARNING: Slips and falls from wet surfaces could
cause serious injury.
11. Maintain an unobstructed work area around the
machine and keep the floor free of water, oil, grease
or other foreign substances.
This automatic parts washer is designed to operate
safely and efficiently. Before you begin to install and
use the machine, please familiarize yourself with the
major components.
WARNING
HIGH PRESSURE
SPRAY CAN PIERCE
SKIN AND TISSUES.
WARNING
PROTECTIVE
EYEWEAR AND
CLOTHING MUST
BE WORN.
SECTION 1: INTRODUCTION & SAFETY
KEEP WATER
SPRAY AWAY FROM
ELECTRICAL WIRING.
DANGER

2216 • 8.941-287.0-R
5
PARTS WASHER OPERATOR’S MANUAL
WARNING
RISK OF EXPLOSION:
AVOID FLAMMABLE
LIQUIDS.
WARNING: Flammable liquids
can create fumes which can
ignite causing property dam-
age or severe injury.
12. Do not locate this machine in
the vicinity of any flammable
vapors, liquids or solids.
13. Before servicing the ma-
chine, refer to all MSDS’s on
the material identified in the waste stream. You
must comply with all warnings and wear all protec-
tive clothing stated on the MSDS.
14. When the machine is working, do not cover or
place in a closed space where ventilation is insuf-
ficient. Avoid installing machines in small confined
areas.
15. In cold climates, this parts washer will freeze if
not in operation and must be located in a heated
enclosure.
16. Running this machine without water will damage
the heating elements and will void the warranty.
WARNING: This is a heated parts cleaner. Use
only nonflammable, noncombustible, water-based
cleaning compounds in this machine. Do not fill or
contaminate with any flammable or combustible
material such as gasoline, alcohol, mineral spirits,
etc. Drain parts to be cleaned of any combustible
or flammable material before placing inside cabi-
net. Failure to observe this warning will create an
extremely hazardous condition.
17. All installations must comply with local codes.
Contact your electrician, plumber, utility company
or the selling distributor for specific details.
18. To protect the operator from electrical shock, the
machine must be electrically grounded. It is the
responsibility of the owner to connect this machine
to a grounded receptacle of proper voltage and
amperage ratings. Do not touch machine with wet
hands or while standing in water. Always discon-
nect the power before servicing.
19. Never make adjustments on machine while it is in
operation except those prescribed in this manual.
SECTION 1: INTRODUCTION & SAFETY
WARNING
EXTREMELY HOT:
USE CAUTION WHEN
OPENING LID.
WARNING: Use extreme
caution when opening the door
of this parts washer. Hot water/
detergent vapors will be emitted.
Stand Back!
20. Do not allow high concen-
trations of flammable flu-
ids, acids, or caustics to be
introduced into this machine.
This automatic parts washer is designed to operate
safely and efficiently. Before you begin to install and
use the machine, please familiarize yourself with the
major components.

2216 • 8.941-287.0-R
OPERATOR’S MANUAL PARTS WASHER
6
OPERATING INSTRUCTIONS
MAINTENANCE INSTRUCTIONS
89412870-2
9.801-125.0
ATTENTION
USE ONLYCUDA APPROVED
DETERGENTSTO EXTEND
LABORWARRANTY TO 1-YEAR!
MIXDETERGENTS 1 LB (1/2 KG) PER
5-GALLONS(15 LITERS) OF WATER
ForCUDA Approved Detergents visit
http://www.cudausa.comor
call888-319-0882
9.807-513.0
90-DAYLABOR WARRANTY
EXTENDSTO 1-YEAR
WITHEXCLUSIVE USE OF
CUDADETERGENTS
LIMITED
COMPONENT IDENTIFICATION - FRONT
Side Spray
Arm Assembly
Turntable
Assembly
Detail Brush
(Optional)
Tank Drain
Debris Screen
Power Brush
(Optional)
Pump
Flow
Regulator
Chain
Guard
Top Spray
Arm
Assembly
Control
Panel

2216 • 8.941-287.0-R
7
PARTS WASHER OPERATOR’S MANUAL
89412870-22
COMPONENT IDENTIFICATION - REAR
Exhaust Vent
Pump
Heating
Element
Assembly
Fresh
Water Inlet
Lid
Strut
Control Panel
Conduit
Autofill Valve
(optonal)

2216 • 8.941-287.0-R
OPERATOR’S MANUAL PARTS WASHER
8
SECTION 2: INSTALLATION
BEFORE YOU BEGIN
To prepare to install the machine, choose an unob-
structed, level site that allows convenient access for
operators and maintenance personnel. Sources for
water and electrical power should be located near the
installation site. If your machine is equipped with the
optional power brush and hand detail brush you must
also run a compressed air line to the installation site.
If you have any questions regarding the installation,
please contact your distributor
STEP 1: MAKE ELECTRICAL
CONNECTIONS
NOTE: The machine can only operate on the type of
electrical power indicated on the machine identification
tag. Read and understand the machine identification tag
to determine the electrical power requirements before
installing the machine.
All machines require a suitable user-supplied power
cord and a fused disconnect.
WARNING: Electrical shock could cause serious
injury or death. For 230V and 460V machines, all
electrical installation tasks must be performed by
a licensed, professional electrician to ensure safe
and proper operation.The installation must comply
with the National Electric Code and all applicable
state and local codes.
STEP 2: CONNECT A
COMPRESSED-AIR LINE AND
ACCESSORIES
This step is required for machines equipped with the
optional power brush and hand detail brush.
If your machine does not have these options, skip the
following procedure.
NOTE: To ensure proper operation and to minimize
the possibility of premature component failure, make
sure the compressed air is supplied at 75 to 90 psi.
We also recommends an in-line moisture trap and an
in-line lubricator on the main air supply line. Refer to
the documentation provided with the power brush for
more information.
Step 1:
Remove the power brush from the box, install the wire
brush in the chuck, and connect the air hose.
Step 2:
Familiarize yourself with the three-way air flow select
valve (See Figure Below), then install a fitting to accom-
modate a connection to your compressed-air supply.
Step 3:
Connect the shop compressed-air line to the machine.
Step 4:
Connect the hose from the power brush to the air flow
select valve.
Step 5:
Hang the power brush on the bracket mounted along
the right side of the machine.
STEP 3: CONNECT A
WATER LINE
A dedicated water line simplifies the filling process
and allows you to maintain the appropriate water level
much more easily. If you do not wish to connect the
machine to a dedicated water line, skip this step.
The APW is equipped with a water supply inlet valve
through which you can connect the machine to a dedi-
cated water line. The valve is located at the left rear
corner of the machine.
If you wish to connect the machine to a dedicated wa-
ter line, keep in mind that the machine is designed for
portability and some maintenance tasks require that
you move the machine. DO NOT make a permanent
connection from your shop water supply to the machine.
To connect the machine to your shop water supply,
install a 1/2"NPT (male) by 5/8" (female) connection to
the water supply inlet valve, then connect to a nearby
water spigot using a suitable burst-proof hose.
Power Brush
Connection
Flow
Regulator
To Detail Brush
Pump (Factory
Installed)
89412870-21

2216 • 8.941-287.0-R
9
PARTS WASHER OPERATOR’S MANUAL
SECTION 2: INSTALLATION
STEP 4: FILL THE MACHINE
WITH WATER AND ADD
DETERGENT
Step 1:
Fill the sump with water until the water indicator light
on the control panel turns off. The sump capacity is 30
gallons.
NOTE: Monitor the water level carefully.
Step 2:
120V Machines: Flip the heater switch to the ON
position.The sump water will reach operating tempera-
ture (160 – 180 °F) in approximately 2-3 hours.
230V and 460V Machines:Turn the heater timer to the
2 Hour position. The sump water will reach operating
temperature (160 – 180 °F) in approximately two hours.
Step 3:
While the sump water is heating, add the appropriate
quantity of factory approved detergent to the wash
chamber. We recommend mixing the detergent with
warm water in a separate bucket/container and then
pouring the dissolved detergent into the sump.
NOTE: Factory approved detergent is the only deter-
gent approved for use with this automatic parts washer.
It is specially formulated with rust inhibitors and anti-
foaming agents to optimize performance and minimize
maintenance. The use of any other detergent during
the warranty period will void the warranty. In addition,
using factory detergents will extend your 90 day labor
warranty to 1 year.
Step 4:
Close the lid.
Step 5:
Turn the wash cycle timer to 2 hours for the first time,
and allow the machine to complete the cycle to dissolve
the detergent into the water.
When the machine stops, and after the wash water
reaches operating temperature, it is ready for use. Refer
to Operation for complete operating instructions.

2216 • 8.941-287.0-R
OPERATOR’S MANUAL PARTS WASHER
10
SECTION 3: OPERATION
MAIN OPERATING
COMPONENTS
Familiarize yourself with the main operating
components before operating the machine.
Control Panel
The control panel is located on the front center of the
lid. It contains the heater, wash cycle skimmer and
turntable controls (See Figure Below).
Heater Control
Single Phase Machines:The heater control is a simple
illuminated rocker switch. It controls the heating element
in the sump chamber. The heater control illuminates
when the heating system is on. The heating system is
thermostatically set at the factory to reach a high tem-
perature of 180 °F.The temperature is adjustable using
the thermostat (See Thermostat Section).
NOTES: 120V machines contain an internal power re-
lay that automatically disconnects power to the heater
when the pump turns on; the heater and pump cannot
run simultaneously. After long wash cycles it may be
necessary to let the machine sit idle for a period of
time to allow the wash solution to reheat to operating
temperature.
The illuminated heater control is also a low-water indica-
tor; if the wash solution is low, the heater control will not
light up and the heating system will not operate (See
Low Water Shut-off System).
Three Phase Machines:The heater control is a 12-hour
timer switch. It controls the heating element in the sump
chamber. The heating system is thermostatically set at
the factory to reach a high temperature of 180°f. The
temperature is adjustable using the thermostat (See
Thermostat).
Wash Cycle Control
The wash cycle control is a 15 minute (120V - no hold)
or 60-minute (220V -with hold) timer switch with a hold
feature.When set between 1 and 60 minutes, the timer
automatically shuts off the pump and turntable when
the wash cycle is complete. When set to Hold (220V
Only), the pump and turntable run continuously until
manually shut off.
Turntable Switch
The turntable switch is a simple rocker switch that
enables you to disconnect power to the turntable mo-
tor. Set to ON, the turntable rotates during the wash
cycle. Set to OFF, the turntable does not rotate during
the wash cycle. The switch is useful for washing large
parts that would otherwise impede turntable rotation.
Low Water Indicator
The low water indicator light illuminates if the wash
solution in the sump is low. For more information refer
to Low Water Shut-off System.
Thermostat
The thermostat is located inside the heating element
and thermostat enclosure.The thermostat is factory-set
to heat the wash solution to a maximum temperature
of 180°f.
ADJUSTING THE THERMOSTAT
To adjust the thermostat, rotate the adjustment screw
or knob clockwise to increase the temperature, or
counter-clockwise to decrease the temperature
(See Figure Below).
89412870-4
Single Phase
Increase
Temperature
Decrease
Temperatures
Adjustment
Screw
Increase
Temperature
Decrease
Temperatures
Three Phase
89412870-3
Turntable
Switch
Oil
Skimmer
Wash Cycle
Control
Low Water
Indicator
Control Panel
Heater
Control

2216 • 8.941-287.0-R
11
PARTS WASHER OPERATOR’S MANUAL
SECTION 3: OPERATION
Lid Safety Switch
The lid safety switch is located on the front edge of the
cleaning chamber (See Figure Below). It ensures that
the water pump and turntable motor do not operate if the
lid is open or unsecured.The safety switch is adjustable.
ADJUSTING THE SAFETY SWITCH
To adjust the safety switch, loosen the two screws to
the left of the lid latch (See Figure Above), move the lid
latch strike plate up or down, then tighten the screws.
When properly adjusted, you should hear a slight “click"
as the lid latch closes and compresses the lid seal and
the lid closure safety switch. There is also a mercury
switch in the control panel that stops the machine from
running in case the lid switch is accidently pushed.
Debris Screen
The debris screen is located just below the wash cham-
ber, and is accessible from the front of the machine (See
Figure Below). The debris screen continuously filters
debris particles from the cleaning solution to ensure
blockage-free spray nozzle operation, and also provides
a safeguard against small parts that might accidentally
be washed through from the cleaning chamber.
The frequency at which you must clean the debris
screen depends on machine usage. In general, you
should clean the screen before operating the machine
each day.
NOTE: Never operate the machine without the debris
screen in place and never remove the screen while the
machine is operating.
The screen is specially sized to filter particles that could
clog the spray nozzles or damage the water pump.
Operating the machine without the debris screen in
place could cause spray nozzle clogging or water
pump failure.
Air Flow Valve (Optional)
The air flow valve is located on the right rear corner of
the machine. It is a three-way ball valve that controls
the flow of compressed air to the power brush and the
hand detail brush (See Figures Below).
Power Brush (Optional)
The power brush is located on the right front corner of
the machine.
Refer to Connect a Compressed-Air Line and Ac-
cessories detailed installation information.
NOTE: The power brush is a standard component on
the Deluxe Edition. It is available as an option on the
base model. For ordering information, contact your
distributor.
Using the Power Brush
WARNING: Particles dislodged by the power brush
could cause serious injury to your eyes. Always wear
approved eye protection when using the power brush.
With stiff stainless steel bristles turning at 1800 RPM,
the power brush easily removes carbon deposits, old
gasket material, or other tightly-adhered materials from
parts before washing.
To turn on the power brush, position the air flow select
valve appropriately, then push the power brush lever
lock forward with your thumb and squeeze the throttle
lever to control the speed of the brush.
89412870-6
Lid Safety
Switch
89412870-23
Position #1
for Power
Brush
Position #2
for Detail
Brush
89412870-24
Debris
Screen
Standard Screen: 10 Mesh
Optional Screen: 60 Mesh

2216 • 8.941-287.0-R
OPERATOR’S MANUAL PARTS WASHER
12
Detail Brush and Flow Regulator
(Optional)
The detail brush is located on the front inside wall of
the wash chamber. The flow regulator is located on the
right rear corner of the machine (See Figure Below).The
detail brush uses a continuous flow of hot cleaning solu-
tion through its nylon bristles to help you clean delicate
or lightly soiled parts. The flow regulator controls the
flow of cleaning solution through the detail brush.
WARNING: Hot, high-pressured cleaning solution
could cause serious injury. Always wear rubber
gloves and approved eye protection when handling
hot cleaning solution.
ADJUSTING THE FLOW OF CLEANING
SOLUTION
The flow of cleaning solution through the detail brush is
pre-set at the factory. If you need to adjust the flow, pull
out the flow regulator knob, then rotate it clockwise to
decrease the flow or counterclockwise to increase the
flow. After adjusting, push the knob back in to lock it.
NOTE: The detail brush is a standard component on
the Deluxe Edition. It is available as an option on the
base model. For ordering information, contact your
distributor or call your distributor.
SECTION 3: OPERATION
Automatic Oil Skimmer System
(Standard)
The automatic oil skimmer system consists of a skim-
mer assembly that includes an electric motor that ro-
tates a disk in the sump water. The oil adheres to the
disk and is wiped off by wiper blades and deposited in
a container. The gear motor is controlled by a rocker
switch on the control panel. See information in Section
5for detailed operation.
89412870-26
Oil
Skimmer
Assembly
Oil
Container
89412870-25
Flow
Regulator
Detail
Brush

2216 • 8.941-287.0-R
13
PARTS WASHER OPERATOR’S MANUAL
SECTION 3: OPERATION
DETERGENTS AND
ADDITIVES
Detergents
Manufacturer's detergents are the only detergents
approved for use with our Automatic Parts washers.
They are specially formulated with rust inhibitors and
anti-foaming agents to optimize performance and
minimize maintenance.The use of any other detergent
during the warranty period will void the warranty.
To monitor the relative concentration of the detergent
in the wash solution, periodically examine the wash
solution in the sump chamber for the following
indicators:
• Rust inside the machine: not enough
detergent
• Excessive foaming: not enough detergent
• Thick, white residue on parts after
washing: too much detergent
To maintain proper detergent concentration under typi-
cal operating conditions, add detergent each month af-
ter cleaning the sump chamber. Follow recommended
detergent quantities. Use pH kit to determine the proper
amount of detergent to use. If you need help interpret-
ing test results, contact customer service.
Rust Inhibitor Additive
Factory detergents protect the entire inside of your
machine against the degenerative effects of water
evaporation. A rust inhibitor additive actually evapo-
rates with the water and continously coats and protects
metal surfaces, even while your machine is sitting idle.
For more information, contact your distributor or call
customer service.
PREPARING THE MACHINE FOR USE
Before you begin to wash parts, it is important that you
properly prepare the machine. Before you begin to use
the machine each day:
• check the water level and add water to the sump
tank if necessary;
• heat the water to operating temperature
• verify that none of the spray nozzles are clogged;
and
• clean the debris screen.
WASHING PARTS
The following procedure assumes that the heater is
on and the sump water is at operating temperature.
To wash parts, perform the following procedure.
WARNING: Hot, high-pressured cleaning solution
could cause serious injury. Always wear rubber
gloves and approved eye protection when loading
and unloading the machine.
Step 1:
Load large, heavy parts directly onto the turntable. Load
small, light parts in the small parts basket, if available.
Make sure none of the parts extend beyond the edge
of the turntable and make sure large, light parts (valve
covers, for example) are secured to the turntable.
NOTE: For optimum cleaning performance, provide a
slight clearance between parts to allow adequate flow
of cleaning solution around and between them.
Step 2:
Close and latch the lid.
NOTE: If you are washing large parts that might impede
turntable rotation, flip the turntable switch OFF.
Step 3:
Set the wash cycle timer to between 1 and 60 minutes
for a timed wash cycle, or set it to Hold for a continu-
ous wash.
Step 4:
When the machine automatically stops (or after you
manually stop the wash cycle), lift the lid and wait a
few moments to allow the parts to cool and dry before
removing them. Most parts flash-dry in seconds.
SHUTTING DOWN THE
MACHINE
To shut down the machine at the end of the day:
• set the wash cycle control to OFF;
• 120V machines: set the heater control to ON
to enable automatic turn-on the following day;
230V and 460V machines: set the heater
control to OFF to prevent unattended heater
operation;
• shut off the water at the supply spigot (if a dedi-
cated water supply is installed); and
• shut off the compressed air at the supply line
(if installed).
WARNING: For 230V and 460V machines, if the
heater is left on unattended the water could evapo-
rate and the oil and grease in the wash chamber
could catch fire.
• For periods of extended shut-down (weekends
and holidays, for example), disconnect power
to the machine.
• If your machine is equipped with an optional
programmable heater timer, periodically verify
the settings to prevent inadvertent unattended
operation.

2216 • 8.941-287.0-R
PARTS WASHER Troubleshooting Guide
14
SECTION 4: TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
POOR
CLEANING
PERFORMANCE
Parts are obstructing each other Check the position of parts on turntable; position
parts to allow flow of cleaning solution around and
between them.
Low water level in sump Check sump water level; add water if necessary.
Clogged or improperly aligned
spray nozzles
Check spray nozzles for obstructions
and alignment; clean and align if necessary.
Low detergent concentration
10-11 ph
Add 1-2 scoops of detergent and observe cleaning
performance; add 1-2 scoops more if necessary.
Measure PH of sump solution.
Wash solution is not properly
heated
See wash solution is not heating.
Pump is not operating properly See pump does not operate properly.
WASH
SOLUTION
NOT HEATING
Blown fuse Refer to Troubleshooting the Electrical System.
Wash solution in sump chamber
is low, or the low water shut-off
system is not working properly
Check the level of the wash solution; add water
if necessary. Check the low water shut-off
float to ensure that it operates smoothly,
see Low Water Shut-Off System.
Thermostat is incorrectly set Check thermostat setting; set to 180°.
Excess debris is built up around
heating element
Check for debris buildup around
heating element; clean out if necessary.
Line voltage is too low Contact a licensed electrician to verify that
the incoming line voltage meets requirements.
Failed heater timer Test the heat timer; replace if necessary.
Failed thermostat Test the thermostat; replace if necessary
Failed heating element Test the heating element; replace if necessary.
WASH
SOLUTION
TOO HOT
Failed thermostat Replace the thermostat.
Thermostat is incorrectly
installed
Check the thermostat to ensure that it is
correctly installed into the mounting bracket.
FOAMING Machine operating with cold
water
Bring water up to correct temperature
Grease, high detergent motor
oils, transmission oil, gear lubes
Do not place oil or transmission pan into machine
without pouring oil out of it.
Not enough detergent Add more detergent, check pH level. Use defoamer.
WHITE
POWDER
ON PARTS
Solution is old Change sump water and recharge with
fresh detergent and vapor corrosion inhibitor.
Water hardness and TDS
(totally dissolved solids)
Use a water softener and/or change your sump
water more frequently.
Large parts can dry before
solution runs off, leaving
powdery residue
Turn heat down to approximately 140°

2216 • 8.941-287.0-R
15
PARTS WASHER Troubleshooting Guide
PROBLEM POSSIBLE CAUSE SOLUTION
MACHINE FAILS
TO START WHEN
“WASHING PARTS"
PROCEDURE IS
FOLLOWED
Main power disconnect is off Verify that no service is being performed on the
machine, then turn the main power disconnect on.
Failed lid closure safety switch Test the lid closure safety switch; replace if
necessary (See Adjusting the Lid Safety Switch).
Failed washer cycle timer Test the wash cycle timer; replace if necessary
(See Lid Safety Switch).
Pump is not operating properly See Pump does not operate properlysection.
TURNTABLE DOES
NOT OPERATE
PROPERLY
Failed turntable motor Contact a licensed electrician to test the motor;
replace if necessary.
Parts are obstructing turntable
rotation
Check for parts obstructing rotation of the turntable;
rearrange if necessary.
Drive chain is not on the drive
pulley
Check drive chain; realign on drive pulley if neces-
sary.
Turntable motor compression
springs are not installed
Check the turntable motor compression
springs; install if necessary
(See Turntable Motor Assembly).
Blown fuse Check electrical panel for blown fuse;
replace if necessary.
Failed wash cycle timer Test the electrical panel to eliminate the possibility
of a blown fuse then
contact a licensed electrician or a service
representative to test the turntable motor.
Failed start capacitor Test the start capacitor; replace if necessary.
PUMP DOES
NOT OPERATE
PROPERLY
Low water level in sump Check sump water level; add water if necessary.
Pump Intake is plugged Check pump intake for obstructions; clean out if
necessary.
Pump overload relay is tripped Reset the motor overload relay.
Blown fuse Check electrical panel for a blown fuse; replace if
necessary.
Line voltage is too low Contact a licensed electrician to verify that the line
voltage meets requirements.
Pump is failed Contact a licensed electrician to test the pump,
replace if necessary.
INTERIOR OF
MACHINE IS
RUSTING
Low detergent concentration
or improper detergent usage
Our detergents contain adequate rust inhibitors to
prevent rust. Verify that you are using manufacturer
detergents at the correct concentration.
Steam condensing on inside of
cabinet and lid
Leave lid open during long idle periods.
PUMP
LEAKS
Failed pump seal Replace the pump seal, see Pump Seal.
SECTION 4: TROUBLESHOOTING

2216 • 8.941-287.0-R
PARTS WASHER Troubleshooting Guide
16
SECTION 4: TROUBLESHOOTING
TROUBLESHOOTING THE
ELECTRICAL SYSTEM
To troubleshoot the electrical sys-
tem first eliminate the possibility of
a blown fuse or a bad connection,
then refer to Testing Individual
Components to determine which
component is causing the problem.
DANGER: Keep wand, hose,
and water spray away from
electric wiring or fatal
electric shock may result.
• Electrical troubleshooting should be performed
by qualified personnel only.
• Avoid contact with power leads, terminals, and
fuses when power is connected.
• Disconnect power to machine before removing
fuses or other electrical components.
120V Machines
To troubleshoot the electrical system on 120V machine,
use the exploded view on pages 34-35 to eliminate the
possibility of a blown relay or a bad connection, then
refer to Testing Individual Components to determine
which component is causing the problem.
Troubleshooting the 120V Electrical Panel
None
▲
▲
Power
ON
Measure Voltage Across
L1, and N Terminals on
Junction Box
Electrical Panel is OK, Check
Main Power Disconnect
Electrical Panel is
OK, Refer to Testing
Individual Components
110 to 120V
▲
OK
▲ ▲
▲
▲
Power
OFF
Power
OFF
Visibly Inspect Heater
Contacts
Heater Contacts is Blown;
Replace the Contacts
Visibly Inspect Pump
Contacts
Pump Contacts is Blown;Replace
the Contacts
OK
OK
Black
or
Deformed
Black
or
Deformed
▲▲
▲
Power
OFF
Power
OFF
Visibly Inspect Control
Fuse
Control Fuse is Blown; Replace
the Control Fuse
Visibly Inspect Low
Water Safety Relay
Low Water Safety Relay is Blown;
Replace the Relay
OK
Black
or
Deformed
Black
or
Deformed
▲
▲
Power
OFF
Check Blue and Grey
Terminal Blocks for
Loose Connections
Tighten Loose Connections
OK
Loose
KEEP WATER
SPRAY AWAY FROM
ELECTRICAL WIRING.
DANGER

2216 • 8.941-287.0-R
17
PARTS WASHER Troubleshooting Guide
230V and 460V Machines
To troubleshoot the electrical system on 230V and 460V
machines, use the exploded view on pages 36-37 to
eliminate the possibility of a blown fuse or a bad connec-
tion, then refer to Testing Individual Components to
determine which component is causing the problem.
Troubleshooting the 230V Electrical Panel




▲ ▲ ▲▲▲
▲
▲
▲
▲
▲
Power
ON
Power
OFF
Power
OFF
Power
OFF
Power
OFF
Measure Voltage Across
L1 and L2 Terminals on
Junction Box
Electrical Panel is OK,
Check Main Power
Disconnect
Remove Primary Fuses;
Measure the Resistance
of Each
One of the Primary
Fuses is Blown; Replace
the Blown Fuse
Remove Secondary
Fuse; Measure the
Resistance
Secondary Fuse is
Blown; Replace Fuse
Remove Pump Fuses;
Measure the Resistance
of Each
One of the Pump Fuses
is Blown; Replace the
Blown Fuse
Remove Heater Fuses;
Measure the Resistance
of Each
One of the Heater Fuses
is Blown; Replace the
Blown Fuse
Electrical Panel is
OK, Refer to Testing
Individual Components
approximately 0 Ohms
approximately 0 Ohms
approximately 0 Ohms
approximately 0 Ohms
None
SECTION 4: TROUBLESHOOTING

2216 • 8.941-287.0-R
PARTS WASHER Troubleshooting Guide
18
SECTION 4: TROUBLESHOOTING
TESTING INDIVIDUAL
COMPONENTS
NOTE: The following troubleshooting procedures re-
quire the use of a volt/ohm meter. If you are not familiar
with using a volt/ohm meter do not attempt to perform
the following troubleshooting procedures. If you need
assistance please contact your distributor.
Wash Cycle and Heater Timers
Step 1:
Disconnect power to the machine.
Step 2:
Remove the timer from the control panel and disconnect
all wires (See Timers and Switches on the Control
Panel).
Step 3:
With the timer in the OFF position, test for continuity
using an ohm meter.
If there is continuity the timer is no longer functional;
replace the timer.
Step 4:
With the timer in the ON position, test for continuity
using an ohm meter.
If there is not continuity the timer is no longer functional;
replace the timer.
89412870-5
Retaining
Nut
Timer
Unit
Lid Safety Switch
Step 1:
Disconnect power to the machine.
Step 2:
Remove the switch from the control panel and dis-
connect all wires (See Timers and Switches on the
Control Panel).
Step 3:
With the switch fully open (not depressed), test for
continuity. If there is continuity the switch is no longer
functional; replace the switch.
Step 4:
With the switch fully closed (depressed), test for con-
tinuity.
If there is not continuity the switch is no longer func-
tional; replace the switch.
Heating Element (Single Phase)
Step 1:
Disconnect power to the machine.
Step 2:
Remove the cover from the heating element and ther-
mostat enclosure (Two Screws; Use a 5/16" Wrench
or Socket).
89412870-6
Lid Safety
Switch
89412870-7

2216 • 8.941-287.0-R
19
PARTS WASHER Troubleshooting Guide
SECTION 4: TROUBLESHOOTING
Step 3:
Detach the two power leads from the heating element
(See Figures Below).
Step 4:
Use an ohm meter to measure the resistance of the
heating element. The resistance should be approxi-
mately 10 Ohms; if not, replace the heating element
(See Heating Element). For Three Phase Element
contact your distributor.
Thermostat
Step 1:
Disconnect power to the machine.
Step 2:
Remove the cover from the heating element and ther-
mostat enclosure (Two Screws; Use a 5/16" Wrench
or Socket).
Step 3:
Detach the two power leads from the thermostat (See
Figure Below).
Step 4:
Using a large flat-head screwdriver, pry the thermostat
out of the mounting bracket, then remove it from the
machine (See Figure Below).
Step 5:
Set the thermostat to 120 °F, warm it to just above
120 °F, then test for continuity.
If there is continuity the thermostat is no longer
functional; replace the thermostat.
Step 6:
Allow the thermostat to cool to room temperature, then
test for continuity.
If there is not continuity the thermostat is no longer
functional; replace the thermostat.
Start Capacitor
Step 1:
Disconnect power to the machine.
Step 2:
Remove the turntable motor cover (Two Screws; Use a
5/16" Wrench or Socket, See Figure Below).
Step 3:
Visually inspect the start capacitor (See Figure Below).
If it appears swollen or deformed, it is failed; replace
the start capacitor.
Step 4:
If the start capacitor is not visibly failed, remove it from
the motor bracket, disconnect the wires, and test it for
shorts using an ohm meter.
If the ohm meter reads approximately 1 ohm, the start
capacitor is no longer functional; replace the start
capacitor.
89412870-27
Power
Leads
Thermostat
89412870-29
Power
Leads
Thermostat
Mounting
Bracket
Thermostat
89412870-28
Motor
Cover
Screws

2216 • 8.941-287.0-R
PARTS WASHER Maintenance Guide
20
SECTION 5: MAINTENANCE
MAINTAINING THE MACHINE
To ensure optimum performance and trouble-free op-
eration, observe the following maintenance schedule
consistently.
Daily Maintenance
• Check the water level; add water if necessary.
• Clean the debris screen.
Weekly Maintenance
•Detergent Concentration Level: Check detergent
level weekly to maintain concentration level which
decreases when water is added.The pH level of this
detergent must be in accordance with the detergent
manufacturer's recommendation.
• Remove oil and grease from the wash solution by
using the oil skimmer.
• For oily or extremely soiled parts, it is recommended
the oil skimmer be operated on a more frequent
basis.
• Examine spray nozzles; clean and align if neces-
sary (See Cleaning and Aligning the Spray
Nozzles).
• Wipe down the exterior of the machine using spray
degreaser and a soft, damp cloth. TO PREVENT
ELECTRICAL COMPONENT FAILURE, DO NOT
SPRAY THE MACHINE WITH WATER.
NOTE: Degreaser spray and a damp cloth will usu-
ally remove all dirt and grime from the machine. For
particularly stubborn soap deposits, use a soft cloth
dampened with warm solution from the wash chamber.
Monthly Maintenance
• Drain and clean out the sump chamber (See Clean-
ing out the Sump).
Cleaning and Aligning the Spray Nozzles
To ensure optimum cleaning performance, it is important
that you examine the spray nozzles periodically and
clean and align them if necessary.
To clean a plugged nozzle, remove it from the spray
pipe and use a small wire brush to free the nozzle of
any obstructions. When you replace the nozzle on the
spray pipe, make sure you align it according to the figure
below to maintain a proper spray pattern.
NOTE: The spray nozzles are sized and positioned to
optimize the distribution of cleaning solution in the wash
chamber. If you remove the nozzles make sure you
replace them in the correct position on the appropriate
pipe. Spray nozzle specifications are stamped on the
face of each nozzle, as shown.
Cleaning out the Sump
Step 1:
Remove the turntable and the debris screen.To remove
the turntable:
a. Remove the turntable chain guard using a
5/16" wrench or socket (See Figure Below).
b. Disengage the chain from around the perimeter
of the turntable.
NOTE: When you disengage the chain from the turn-
table, be sure to maintain some chain tension to ensure
that the chain does not disengage from the drive pulley.
c. Pull up evenly on the turntable to remove it from
the center pin.
Step 2:
Drain the wash solution from the sump chamber. To
drain the solution either use the sump drain or a small
submersible pump.
Step 3:
Remove sand and other debris from the bottom of the
sump chamber. To remove the debris either flush it out
through the sump drain, or vacuum it out using a wet/dry
Vac. Dispose of the debris in accordance with applicable
local, state, and federal regulations.
89412870-31
Turntable
Chain Guard
89412870-30
Align The Notch In
Each Spray Nozzle
With The Center Of
The Turntable
TOP & BOTTOM
NOZZLES
SIDE NOZZLES
Rotate Each Nozzle
Approximately 3°
From The Center Line
Of The Pipe
3°
Turntable C
L
