Cuisinart CGWM-090 User manual

DO NOT RETURN YOUR TABLE TO THE STORE
Before visiting your local retailer, call our customer
service department at 1-866-994-6390 from 9:00 am
to 5:00 pm Eastern time, Monday through Friday.
Model NO: CGWM-090
DELUXE OUTDOOR
PREP TABLE
Customer Service Hotline
1-866-994-6390

SAFETY INFORMATION
CARE AND MAINTENANCE
2
WARNINGS AND USAGE
-----------------------------------------------------------------------------------
IMPORTANT: ALL INSTRUCTIONS AND SAFEGUARDS IN THIS SECTION MUST BE FOLLOWED TO
PREVENT DAMAGE AND/OR INJURY.
• Sink to be used for rinsing/washing of hands and non-food items ONLY.
• Not for permanent installation.
• For outdoor use only
• Designed only for connection to a garden hose as the water supply.
• Water supply from garden hose is not intended for human consumption.
• Waste water should only be routed to a bucket and disposed of according to local code.
• Keep use of water away from electrical connections and outlets.
• Use caution with all electric appliances, tools, extension cords and lights on and around table.
• When not in use, disconnect water supply then drain water from faucet by partially opening the faucet knob.
• Do not use in freezing temperatures.
• Disconnect, drain all water lines and cover if leaving in freezing temperatures (recommended cover, model
CGWM-095).
• Surface can become hot in direct sun or high temperatures.
• Maximum top weight load of 50 LBS
• Maximum shelf weight load of 30 LBS
• Use only on level surfaces.
• Before use ensure wheels are height adjusted so that the table does not rock when in use.
• Lock wheels when in use.
• Before use insure drain and faucet function properly and are free of obstructions.
• Do not pour boiling water in the drain and avoid food waste entering the drain.
• Do not allow children to climb the product.
CALIFORNIA PROPOSITION 65 WARNING:
• WARNING: This product can expose you to lead, which is known to the State of California
to cause cancer and birth defects or other reproductive harm. For more information go to
CLEANING
-----------------------------------------------------------------------------------
Painted and Plastic surfaces
Wash with mild detergent or non-abrasive cleaner and warm water.
Stainless steel surfaces
Wash with mild detergent and warm soapy water or use a stainless steel cleaner. Wipe dry with a soft cloth
after each use. Wash only in the direction of the stainless brushed finish to avoid damage.
Stainless steel can rust under certain conditions. This can be caused by acidic marinades, chlorine, saltwater,
exposure to coastal climates, other natural elements, or improper cleaning tools such as wire or steel wool.
Faucet
If faucet ever becomes clogged, turn off the water supply, unscrew the faucet tip, clean the screen and reinstall.

WHAT’S IN THE BOX
2(x1)
(x1)
(x1)
(x1)
(x1)
(x2)
(x1)
(x2)
(x1)
(x4)
(x1)
(x1)
(x2)
(x1)
(x1)
(x1)
(x1)
(x2)
(x40) (x1)
(x1)
(x1)
1
3
4
5
6
7
8
9
13
12
11
10
14
15
16
17
18
19
20
AA
(x40)
BB
CC
PART PARTDESCRIPTION DESCRIPTIONQTY QTY
3
Counter Top
Assembly
Non-Locking
Caster
Garbage Bag
Ring
Garbage Bag
Support
Side Panel
Rear
Support
Water Supply
Hose
Name Plate
Left Back
Leg (LB)
Upper
Shelf
Left Front
Leg (LF)
Right Back
Leg (RB)
Paper Towel
Bar
Right Front
Leg (RF)
Towel Bar End
Lower
Shelf
Drain
Assembly
Screw
Lock Washer
Locking
Caster
Wrench
Faucet
Assembly
Utensil
Hanger
COMPONENTS
-----------------------------------------------------------------------------------
HARDWARE AND TOOLS
-----------------------------------------------------------------------------------

EXPLODED VIEW
4

Assembly Tip: To avoid scratching prep table and to protect floor/patio surfaces, reuse cardboard packaging
and lay parts on top while assembling.
STEP 1
-----------------------------------------------------------------------------------
To create “screw assemblies” for future steps, install all 40 of the lock washers (BB) onto all 40 screws (AA).
Install locking casters (20) and non locking casters (10) on opposing ends as shown. Use the double-ended
open wrench (CC) to attach the 4 casters (20, 10) onto the bottom of the lower shelf (16).
ASSEMBLY INSTRUCTIONS
Please be careful when handling components. Always wear work gloves during assembly and set up. Read
and follow all safety statements, warnings, assembly instructions and use and care instructions before
attempting to assemble and use. Before beginning assembly of product, make sure all parts are present.
Compare parts with package contents list and hardware contents list. If any part is missing or damaged, DO
NOT attempt to assemble the product.
Estimated Assembly Time: 1 hour
Tools required for assembly: (included) Wrench, (not included) Phillips Head Screwdriver (magnetic tip will be
helpful), Gloves
Screw Assembly
AA BB
ASSEMBLY PREPARATION
5
Included Not Included

ASSEMBLY INSTRUCTIONS
STEP 2
-----------------------------------------------------------------------------------
Use screw assemblies to attach the middle portion of left back leg (5) (LB) and the right back leg (17) (RB) to the
upper shelf (16) as shown below.
• Note: it is important to not fully tighten the screws during initial assembly of the parts. Wait until
the end of step 13 to complete assembly by fully tightening all of the screws.
• Note: Legs are punched with markings to indicate position for assembly, (LB, RB, LF, RF).
• Note: Assembly for the next 4 steps is done with the unit laying on its’ back.
STEP 3
-----------------------------------------------------------------------------------
Use screw assemblies to attach the lower shelf (19) assembly to the lower portion of the left back leg (5) (LB)
and the right back leg (17) (RB). Note that the locking casters (20) are to the right and only side screws are
installed into the legs for this step.
6
2
2
2
x 2
x 2

STEP 4
-----------------------------------------------------------------------------------
Use screw assemblies to attach the left front leg (6) (LF) and the right front leg (18) (RF) to the lower shelf (19)
and the upper shelf (16). Note that only side screws are installed into the legs for this step.
STEP 5
-----------------------------------------------------------------------------------
Use screw assemblies to complete attachment of all four legs as shown.
Tip upright to install rear screws.
ASSEMBLY INSTRUCTIONS
7
2
2
x 4
x 8

STEP 6
-----------------------------------------------------------------------------------
Use screw assemblies to attach name plate (15) to the left front leg (6) (LF) and the right front leg (18) (RF). Next
use screw assemblies to attach the rear support to the left back leg (5) (LB) and the right back leg (17) (RB).
STEP 7
-----------------------------------------------------------------------------------
Use screw assemblies to attach the side panel (3) to the left leg assembly using four screws.
ASSEMBLY INSTRUCTIONS
8
2
2
2
2
x 4
x 8

STEP 8
-----------------------------------------------------------------------------------
Use screw assemblies to attach the side panel (3) to the right leg assembly using just the top two screws.
Install these screws only half way in to allow for parts to be assembled in the next step.
STEP 9
-----------------------------------------------------------------------------------
Use screw assemblies to attach the garbage bag support (12) to the right leg assembly using the two
previously installed screws and the slotted upper holes. Then install two screws in the lower holes to secure in
place.
ASSEMBLY INSTRUCTIONS
9
2
2
x 2
x 2

STEP 11
-----------------------------------------------------------------------------------
Install the paper towel bar (7) between the two towel bar ends (8) by flexing them slightly outward inserting bar
and releasing.
STEP 10
-----------------------------------------------------------------------------------
Use screw assemblies to attach both of the towel bar ends (8) to the left leg assembly.
ASSEMBLY INSTRUCTIONS
10
2
2
x 4

STEP 12
-----------------------------------------------------------------------------------
Install the faucet assembly (2) into the counter top assembly (1) by inserting the faucet and small rubber
washer in from the top and then securing from the bottom with the large rubber washer and nut. Complete by
screwing the supply hose (4) onto the bottom of the faucet and tightening. Hand tightening is all that is required
for these components.
Install the drain assembly (9) into the sink portion of the counter top assembly (1) by inserting the upper
metal drain and large rubber washer from the top. Next, from the bottom, install the large foam washer and
lower plastic drain followed by the small rubber washer and threading on the threaded adaptor. Complete by
pressing the drain hose on until it bottoms out on the threaded adaptor. Hand tightening is all that is required
for these components.
ASSEMBLY INSTRUCTIONS
11
Expanding Drain Hose
Threaded Adapter
Lower Plastic Drain
Upper Metal Drain
Strainer
Faucet
Small Rubber
Large Rubber
Washer
Nut
Water Supply Hose
Large Foam Washer
Large Rubber Washer
Small Rubber Washer

STEP 13
-----------------------------------------------------------------------------------
Use screw assemblies to attach the counter top assembly (1) to the prep station base. Now tighten all
screw assemblies that have been installed throughout the unit.
ASSEMBLY INSTRUCTIONS
12
2
2
2
2
x 2
x 2

STEP 14
-----------------------------------------------------------------------------------
Install the utensil hangers by screwing them into the front edge of the counter top assembly (1). Place the
garbage bag ring (11) into the garbage bag support (12).
STEP 15
-----------------------------------------------------------------------------------
Once the completed prep table is in its’ desired location use the threaded posts of the casters (10, 20) to level
the table and lock nuts with the double-ended open wrench (CC) to hold the adjusted position.
ASSEMBLY INSTRUCTIONS
13

STEP 16
-----------------------------------------------------------------------------------
Increase the length of the expanding drain hose by pulling the lower open end of the tube while holding firm
the top end that is pressed onto the threaded adaptor. Next position a bucket (not included) close by and
place the end of the expanded hose into the bucket. This bucket will serve to catch the waste water.
STEP 17
-----------------------------------------------------------------------------------
Screw the end of the water supply hose onto a garden hose that is attached to a water supply source. Make
sure the faucet is off and turn on the garden hose and check for leaks. If there are leaks turn off the garden
hose, tighten the leaking fittings and repeat this step until are seals are tight and not leaking.
CONNECTION INSTRUCTIONS
14

STEP 18
-----------------------------------------------------------------------------------
Install a garbage bag by inserting the bag through the garbage bag ring (11) and then wrapping the open end of
the bag around the ring. Feed the bottom of the bag through the garbage bag support (12) and then place the
garbage bag ring (11), with the opening of the bag wrapped around it, into the garbage bag support (12).
STEP 19
-----------------------------------------------------------------------------------
Pull the bag from its’ bottom to ensure it is fully secured by the garbage bag ring (11) and garbage bag
support (12).
GARBAGE BAG INSTRUCTIONS
15

To register your Cuisinart product, please visit https://cuisinart.registria.com.
For FAQ’s and replacement parts, please contact us at [email protected].
For our consumer care department, please contact us at [e-mail]
or call 1-866-994-6390.
Model # CGWM-090
North American Distributor:
The Fulham Group
Newton, MA 02466
WARRANTY AND REPLACEMENT PARTS
1 Year Limited Warranty
PROOF OF PURCHASE is required to access this warranty program, which is in effect from the date of purchase.
Customers will be subject to parts, and shipping and handling fees if unable to provide proof of the purchase or after
the warranty has expired.
If you have any questions or problems, you can call our customer service department at 1-866-994-6390 from 9:00am
to 5:00pm EST, Monday through Friday for assistance.
This limited warranty applies to the functionality of the product ONLY. It does not cover cosmetic issues such as
scratches and dents, damage from abrasive or chemical cleaners or any tools used in the assembly or installation of
the table, surface rust, or the discoloration of stainless steel surfaces. Paint is not warranted and will require touch up.
RUST is not considered a manufacturing or materials defect.
This limited warranty will not reimburse you for the cost of any inconvenience, food, personal injury or property damage.
WARRANTY PROVISIONS
This warranty is non-transferable and does not cover failures due to misuse, improper installation or maintenance.
This warranty is for replacement of defective parts only. We are not responsible for incidental or consequential damages
or labor costs.
This warranty does not cover corrosion or discoloration after the prep table is used, or lack of maintenance, hostile
environment, accidents, alterations, abuse or neglect.
This warranty does not cover damage caused by abrasive or chemical cleaners, or any damage to other components
used in the installation or operation of the prep table.
Paint is not warranted and may require touch-up.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
Repair or replacement of defective parts is your exclusive remedy under the terms of this limited warranty.
Manufacturer will not be responsible for any consequential or incidental damages arising from the breach of either
this limited warranty or any applicable implied warranty, or for failure or damage resulting from acts of God,
improper care and maintenance, accident, alteration, replacement of parts by anyone other than
manufacturer, misuse, transportation, commercial use, abuse, hostile environments (inclement weather, acts of
nature, animal tampering), improper installation or installation not in accordance with printed manufacturer instructions.
For replacement parts, call our customer service department at 1-866-994-6390 from 9:00am to 5:00pm EST, Monday
through Friday for assistance.
16
