Cuisinart SmartStick CSB-100 Service manual

INSTRUCTION AND
RECIPE BOOKLET
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.
SmartStick®700-Watt Hand Blender CSB-100

2
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should
always be followed, including the following:
1. READ ALL INSTRUCTIONS.
2. Unplug from outlet when not in use, before putting on or
taking off parts and before cleaning. To unplug, grasp plug
and pull from electrical outlet. Never pull cord.
3. To protect against electrical shock, do not put the motor body,
cord or electrical plug of this hand blender in water or other
liquids. Only the detachable blending shaft and other certain
parts of this appliance have been designed for immersion into
water or other liquids. Never submerge any other portion of this
unit. If hand blender falls into liquid, immediately unplug it.
Carefully remove the blending shaft, clean and dry unit thoroughly
before continuing.
4. This appliance should not be used by children and care should
be taken when used near children.
5. Avoid contact with moving parts.
6. During operation keep hands, hair and clothing, as well as
spatulas and other utensils, away from attachments and any
mixing container to reduce risk of injury to persons and/or
damage to the appliance. A spatula may be used, but must be
used only when the unit is not operating.
7. Do not operate any appliance with a damaged cord or plug,
or after the appliance has malfunctioned or has been dropped
or damaged in any way or is not operating properly. Return the
appliance to the nearest Cuisinart Repair Center for examination,
repair or mechanical or electrical adjustment.
8. Remove detachable shaft from the blender before washing the
blades or shaft.
9. Blades are SHARP. Handle carefully when removing,
inserting or cleaning. Exercise the same care when
removing, inserting the cutting blade for the chopper/grinder
attachment.
10. When mixing liquids, especially hot liquids, use a tall container
or make small quantities at a time to reduce spillage, splattering
and possibility of injury from burning.
11. To reduce the risk of injury, never place chopper/grinder
attachment cutting blade on base without first putting work bowl
properly in place.
12. Be certain the chopper/grinder attachment cover is securely
locked in place before operating appliance. Do not attempt to
remove cover until blade has stopped rotating.
13. Check work bowl for presence of foreign objects before using.

3
14. The use of attachments or accessories not recommended by
Cuisinart may cause fire, electrical shock, or risk of injury.
15. Do not use outdoors or for purposes other than intended use.
16. Do not let any cord hang over the edge of the table or counter.
Do not let cord contact hot surfaces, including stovetop.
17. Make sure the appliance is off, the motor has stopped
completely and the appliance is unplugged from outlet before
putting on or taking off attachments, and before cleaning.
18. Maximum rating is based on the optional CSB-100BFC baby
food chopper attachment that draws the greatest power. And
that other recommended attachments may draw significantly
less power.
19.
Do not operate your appliance in an appliance garage or
under a wall cabinet. When storing in an appliance garage
always unplug the unit from the electrical outlet. Not doing
so could create a risk of fire, especially if the appliance
touches the walls of the garage or the door touches the unit
as it closes.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
NOTICE
This appliance has a polarized plug (one blade is wider than the
other). As a safety feature, this plug will fit in a polarized outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Do not attempt
to defeat this safety feature.

4
CONTENTS
Important Safeguards ....................................2
Unpacking Instructions ...................................4
Introduction ............................................4
Features and Components ................................5
Assembly..............................................6
Blending Attachment................................6
Chopper/Grinder Attachment .........................6
Reversible Blade ...................................6
Whisk Attachment ..................................7
Potato Masher Attachment ..........................7
Operation..............................................8
Blending..........................................8
Pulse ............................................8
Chopping/Grinding .................................8
Whisking .........................................9
Mashing Potatoes ..................................9
Cleaning and Maintenance ................................9
Tips and Hints .........................................10
Frequent Uses for Chopper and Grinder ....................13
Recipes ..............................................14
Warranty .............................................32
UNPACKING INSTRUCTIONS
Place the package containing the Cuisinart
®
Smart Stick
®
Variable
Speed Hand Blender on a sturdy surface. Unpack the components from
the box by removing the upper protective insert. Gently slide the unit
from the box. Remove all support materials from the box and replace
the upper insert. Save packaging for possible repacking of the unit.
NOTE: The blending and chopper/grinder blades are extremely
sharp.
Before using the Cuisinart®Smart Stick®Variable Speed Hand Blender
for the first time, we recommend that you wipe the unit with a clean,
damp cloth to remove any dirt or dust. Dry it thoroughly with a soft
absorbent cloth. To clean all parts see instructions on page 9 and 10.
Read all instructions completely for detailed operating procedures.
INTRODUCTION
Get ready to experience a whole new level of blender versatility. Your
SmartStick® 700-Watt Hand Blender is a Potato Masher, too. A unique new
attachment slips onto the power handle so you don’t have to pull out your
hand or stand mixer to make perfect mashed potatoes – in only takes sec-
onds! This very powerful hand blender is also supremely multifunctional, with
a chopper/grinder and chef’s whisk that attach to the 700-watt motor body
housing. Take a look at our recipes to find out even more you can do with this
SmartStick!

5
FEATURES AND
COMPONENTS
1. Variable Speed Control Dial
Allows you to select speed and
gradually adjust during blending if
desired.
2. Lock/Unlock Button
Must be pressed to unlock before
power handle will operate.
3. On/Off Power Button:
Allows you to activate the hand
blender at the touch of a button
after unlocking. Simply unlock, then
press and hold down to blend or
pulse. Once the button is released,
blending will stop.
4. Comfort Grip Handle:
The handle allows you to control the
hand blender with ease.
5. Motor Body Housing:
Houses the powerful 700-watt motor.
6. Blending Attachment:
This attachment easily snaps into
the motor body housing. The fixed
stainless blade is partially covered
by a stainless housing steel blade
guard that keeps splashing to a
minimum. Press the release button
on the back of the unit to detach for
easy cleaning.
7. Potato Masher:
Attaches to motor housing to mash
potatoes in bowl or pot.
8. Whisk Attachment:
Whisk attachment snaps into the
motor body housing; this attachment
is great for whipping cream, egg
whites and other delectable treats.
9. Chopper/Grinder Attachment with
Reversible Blade:
Attaches to motor housing to chop,
mince and grind.
10. Mixing/Measuring Beaker:
4-cup blending cup beaker is dishwasher safe.
Use this container it to blend drinks, shakes,
salad dressings and more. Designed for easy
gripping and drip-free pouring.
1. 2.
4.
3.
5.
6.
8.
9.
7.
10.

6
ASSEMBLY
BLENDING ATTACHMENT
1. Align the motor body housing with the blending
shaft and push the pieces together until you
hear and feel them click. It may be helpful to
press the release button when assembling.
2. Plug the motor housing into a electrical outlet.
CHOPPER/GRINDER ATTACHMENT
(WITH REVERSIBLE BLADE)
1. Place the chopping/grinding blade into center of
the work bowl over metal blade shaft
(See REVERSIBLE BLADE, following).
2. Place cover on top of the work bowl. Align notches
on cover and bowl, and turn clockwise to lock into
place.
3. When ready to process food, press power handle
onto cover.
Assemble the parts.
1. Place the chopping cup on a flat, dry, stable surface.
2.
The metal blade assembly shaft (A) is attached to the
bottom of the chopping cup. If not already in
place, slide the fully assembled blade assembly
(B) over the top of the metal blade assembly shaft.
2a. Put together the blade assembly if not
assembled: Very carefully connect the blade
ring (C) to the plastic blade sheath (D). Line up
the blade ring opening with the plastic sheath.
There are notches (E) on opposite sides of the interior of the
hub. These fit over ridges on the sides of the plastic blade
sheath (G). Let the blade ring slide to the
bottom of the plastic sheath. HOLD THE
BLADE RING BY THE CENTRAL HUB
HOLDING RIBS (grips) (F) ONLY. DO NOT
TOUCH THE RAZOR-SHARP BLADES.
Pick up the blade ring by its hub holding
ribs (grips) and turn it very slightly
B
A
C
D
GF
E

7
clockwise. This locks it in place on the plastic blade sheath and
prevents it from sliding up during processing. Note these
important features of the blade ring. The blade ring can be
placed over the plastic blade sheath in two different ways: If you
hold it this way (A), you will see the word “Sharp” on the blade.
Assemble the blade this side up to use the sharp edge. If you
hold it this way (B), you will see no writing on the blade.
Assemble the blade this side up to use the blunt edge.
B. BLUNT SIDE UP
SHARP SIDE
A.
WHISK ATTACHMENT
1. Align the motor body housing with the assembled whisk
attachment and push the gearbox and motor housing
together until you hear and feel them click. It may be
helpful to press the release button when assembling.
Note: Whisk and whisk gearbox are detachable from one
another.
POTATO MASHER ATTACHMENT
Your potato masher attachment comes fully assembled.
1. Align the gear box at the end of the potato masher
with the motor body housing and push gearbox and
housing together until you hear and feel them click.
2. Plug the motor housing into an electrical outlet.
NOTE: Gearbox detaches from potato masher shaft
for cleaning and storage
To reassemble potato masher after cleaning
(see Cleaning Potato Masher Attachment, pg.10)
1. Align the triangle mark on the gear box with the
unlock symbol on the potato masher shaft.
2. Rotate the gear box clockwise until you hear it click
and lock into place on the shaft.
3. Place blade onto hub at the wide end of shaft,
push down, and twist counterclockwise to secure.
NOTE: blade cannot be put on or taken off unless
gear box is firmly attached to the shaft.

8
OPERATION
BLENDING
The specially designed blade is for mixing and puréeing all kinds of
foods, including salad dressings, powdered drink products, soups and
sauces and blended drinks like milkshakes or smoothies.
This blade mixes and stirs while adding only a minimum of air to your
mixture. A gentle up-and-down motion is all you need to make the
most flavorful, full-bodied recipes. Be careful never to remove the
blending shaft from the liquid while in operation, for it will splatter.
Tilt the pan or bowl away from you if needed to ensure the protective
blade guard on the blending shaft is fully submerged.
1. Plug in motor housing.
2. Put blending shaft into mixture to be blended.
3.
Select Speed. Press and hold the Lock/Unlock button on top of the
motor housing and press the power button to turn motor on. Once
motor is on, you can release the Lock/Unlock button but continue to
hold in the power button. You can also press the power button first,
holding it down as you press the Lock/Unlock button to turn motor
on. Speed can be gradually adjusted at any time during blending.
Do not hold power button down for more than 60 seconds at a time.
4. To turn the blender motor off, release the power button.
5. Unplug immediately after use.
CAUTION: DO NOT PUT FINGERS NEAR BLADE. TO DISLODGE
FOOD, UNPLUG HAND BLENDER FROM THE OUTLET FIRST.
PULSE
To Pulse, press and hold the Lock/Unlock button while pressing and
releasing the power button as desired.
CHOPPING AND GRINDING
Do not operate the chopper/grinder attachment without food in the
work bowl.
1. Put the work bowl on a flat, sturdy surface like a countertop.
2. Be sure the blade is assembled to use the edge that is appropriate
for the food to be processed, then place over metal blade shaft in
work bowl.
3. Put food into the work bowl. Food should be cut into small even
pieces, and the bowl not overloaded.
4. Put the chopper/grinder cover on top of the prep bowl, making
sure the cover is properly seated.
5. Place motor housing over the center gear hub in the work bowl
cover and push down to lock into place.
6. Plug unit in.

9
7. Select Speed, unlock, then press on the power button. Note: Due
to the powerful motor provided with this unit, Cuisinart
recommends using one hand to support the work bowl during
operation.
8. WHEN THE BLADE STOPS MOVING, unplug the unit, remove the
motor body from the chopper/grinder cover, and remove the
cover.
9. Carefully remove the chopping blade, holding it by the gripping
ridges on the plastic sheath. NEVER TOUCH THE BLADE
ITSELF.
10. Remove food with a spatula.
WHISKING
1. Insert the whisk attachment into the motor body. (See Assembly
for Whisk Attachment, page 7.)
2. Plug electrical cord into a wall socket.
3. Put the whisk into mixture to be blended.
4. Select Speed, unlock and press power button. The hand blender
will continue to run as long as the power button is pressed in.
To turn off, release the power button and the motor will stop.
MASHING POTATOES
1. Be sure potato masher is securely assembled.
2. Put potatoes or other food to be mashed in large bowl or pot.
3. Plug in unit and place head of potato masher into food.
4. Unlock and push power switch to turn masher on.
5. Slightly raise and lower masher as you move it through food until it
reaches texture you want.
6. Release power button to turn off masher before you lift it away
from the food.
7. Unplug unit.
CLEANING AND MAINTENANCE
HAND BLENDER
Always clean the motor body and blending shaft thoroughly after
using. Remove the blending shaft from the motor body. Clean the
motor body only with a sponge or damp cloth. Do not use abrasive
cleaners that could scratch the surface. To clean the blending shaft,
wash by hand in hot water using mild detergent or on top shelf of
dishwasher. Be mindful of the fixed razor-sharp blade edges.

10
CHOPPER/GRINDER ATTACHMENT
To simplify cleaning, rinse the work bowl and blade and wipe the
underside of the cover immediately after use so food does not dry
on them. Do not submerge the work bowl cover in water or put in the
dishwasher. Wash blade and work bowl in warm, soapy water – avoid
leaving the blade submerged in water where it may disappear from
sight. Rinse and dry. Blade and work bowl can also be cleaned on
the top shelf of dishwasher. Unload the dishwasher carefully to avoid
contact with the sharp blade. Wipe the underside of the cover with
a sponge or damp cloth to remove any food. Wipe the power handle
and top of the cover with a damp sponge or cloth. Dry it immediately.
Never submerge the power handle or the chopper cover in water
or other liquids. The chopper/grinder attachment is intended for
HOUSEHOLD USE ONLY.
WHISK ATTACHMENT
To clean your whisk attachment, simply release the attachment
from the motor body housing. Once the whisk is removed, detach
the metal whisk from the gearbox by pulling the pieces apart.
To clean the gearbox, simply wipe with a damp cloth. To clean the
metal whisk, wash with warm soapy water or clean on top shelf of
the dishwasher. Do not submerge the gearbox in water or any other
liquid.
POTATO MASHER ATTACHMENT
Release the potato masher attachment from the housing body. To simplify
cleaning, rinse the potato masher attachment immediately after use so
food does not dry on it. Press the inner blade back into the unit and turn
clockwise to release inner blade. Wash with warm, soapy water and a soft
bristle brush if necessary, or clean on top rack of dishwasher. Do not use
any sharp, metal objects. Dry thoroughly. To reassemble, see the
assembly instructions on page 7.
Any other servicing should be performed by an authorized service
representative.
TIPS AND HINTS
FOR HAND BLENDER
• Be sure that the blending blade guard is fully submerged before
blending ingredients to prevent splatter.
• To purée a soup, use the hand blender to blend the soup ingredients
to the desired consistency, using a gentle up-and-down motion right
in the saucepan or pot.
• When blending ingredients right in a pot or pan tilt the pan away
from you to create a deeper area for blending to prevent splatter.
• When using a nonstick cooking surface, be careful not to scratch
the coating with the hand blender.
