Cuppone Tiziano User manual

1
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
TZ 420
TZ 425
TZ 230
TZ 430
TZ 435
Tiziano
OVEN
Pre-installation and installation manual
Original instructions

2
The company cannot be held liable for any print or transcription errors, reserving the right to
make changes where deemed suitable without prior notice.
Partial reproduction without the Manufacturer's consent is prohibited. Measurements are
purely indicative and not binding.
The original language used to prepare this manual is English: the Manufacturer is not
responsible for any translation/interpretation or print errors.
Contents
This oven has been designed with the utmost care and
undergone rigorous tests in our laboratories and for this reason
we guarantee its absolute safety and functionality.
The installation must be carried out by professionally
qualied sta, that can take responsibility for the installation
and guarantee the best safe operating conditions.
Before the installation, read the content of this manual
carefully: it contains important information regarding product
assembly and safety regulations.
Technical service
The Dealer can solve any technical problem regarding
installation.
Do not hesitate to contact him in case of doubt.
Introduction
1CHECKS BEFORE PURCHASING.................3
2OVEN TECHNICAL DATA.............................6
Tiziano TZ 420 oven technical data.................................................................8
Tiziano TZ 425 oven technical data.................................................................17
Tiziano TZ 230 oven technical data.................................................................26
Tiziano TZ 430 oven technical data.................................................................35
Tiziano TZ 435 oven technical data.................................................................44
3INSTALLATION ............................................53
Transport..........................................................................................................................54
Preliminary operations............................................................................................54
Packaging disposal....................................................................................................54
Positioning......................................................................................................................55
Serial number plate reading................................................................................55
Smoke extraction .......................................................................................................55
Electrical connection................................................................................................57
Pre-testing and nal inspection ........................................................................63
Checking the operation and rst start-up..................................................63
4MAINTENANCE AND CLEANING ...............65
Warnings..........................................................................................................................65
Oven cleaning..............................................................................................................65
Replacing components..........................................................................................67
CUPPONE since 1963
CUPPONE S.R.L.
Via Sile, 36
31057 Silea (TV) - ITALY
T [phone]
F [phone]
[e-mail] - www.cuppone.com

3
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
Fig.1
1CHECKS BEFORE PURCHASING
ACheck with the owner if in the place of installation there are the tools to handle the oven easily Fig.1
√To handle the oven correctly, it is necessary to:
• have personal protection equipment available (e.g. safety shoes, gloves, etc.)
• have lifting equipment available that can handle the appliance safely (check weight and dimensions in the following pages), together with sta qualied to carry out this operation.
B Check the dimensions of the selected oven and accessories
√
• check that the dimensions of the selected oven are suitable to the available space in the installation room.
• check that the cooking chamber capacity is adequate to the owner's needs. The “Technical data” section from page 6contains the weights and dimensions of the ovens and cooking
chambers.
Before purchasing the oven and before its installation, check and agree with the owner that, on installation, all the following conditions are met; they are indispensable for the correct and safe
installation, operation and maintenance of the oven.

4
Checks before purchasing
• it is possible to maintain a minimum distance between the oven
and the walls, other appliances, objects and combustible
materials Fig.3 In case of hot or cold appliances, keep a
distance of 500 mm [19.7in.].
It is absolutely necessary to comply with the min-
imum stated safety distances. The distances must
be increased in case of objects in heat-sensitive
materials.
• Fig.4 there is an evacuation ue for the exclusive use of
the appliance, which complies with the regulations in force
and which has a diameter which allows the passage of an
evacuation tube of Ø150 mm [Ø5.91 in.].
The oven is equipped with a smoke outlet located at the top
for the evacuation of the vapours from the cooking chamber
(you can nd its exact position in the "Technical data" section
starting on page 6). This steam, together with the one
from the door during the work phases, must be conveyed
outside in one of the following ways:
A
through a hood belonging to the user, of suitable
capacity, placed at a minimum of 300 mm [11.81 in.]
from the oven;
B
through an adequate extraction system supplied by
the user connected to the oven ue: in this case a
draught switch must be installed between the extractor
and the oven ue (the extractor, switch and relative
connection tube are not supplied by the Manufacturer).
In this type of installation, the fumes resulting from the
opening of the door will not be extracted.
Cthrough a tube measuring Ø80mm
[Ø3.1 in.] (not
supplied) connected to the oven discharge. In this type
of installation, the fumes resulting from the opening of
the door will not be extracted;
D
through a hood supplied by the Manufacturer that en-
sures perfect compatibility with the oven. For correct assem-
bly and xing to the oven, see the sheet attached to it; the
evacuation ue must be for the exclusive use of the appli-
ance, comply with current regulations and have a diameter
that allows the passage of an evacuation pipe measuring
Ø150 mm [Ø5.91 in.] which corresponds to the diameter
of the tube to be mounted on the hood (not supplied).
E
through an adequate suction system supplied by
theuserconnectedtothefumeueoftheManufacturer's
hood: in this case, it is mandatory to place a fume damper
between the extractor and the oven hood (the extractor,
the connection pipe between the two and the damper
are not supplied by the Manufacturer).
C
Survey the installation room to make sure it is adequate.
√Make sure that Fig.2
• the oor of the installation room is reproof, perfectly
level and capable of withstanding the weight of the
appliance.
Model single double Model single double
TZ420 51kg / 112.4lb 90kg / 198.4lb TZ430 85kg / 187.3lb 148kg / 326.2lb
TZ425 65kg / 143.3lb 114kg / 251.3lb TZ435 105kg / 231.4lb 178kg / 392.4lb
TZ230 71kg / 156.5lb 122kg / 268.9lb
• The oven must be placed on a base, built by the Manufactur-
er or by yourself that:
• is ame and heat resistant;
• is perfectly stable and level;
• withstands the weight of the appliance.
• the installation room:
• is dedicated and suitable to cooking food;
• has adequate air ventilation;
• contains no ammable or explosive elements;
• complies with the current regulations on health and safe-
ty and systems in the workplace;
• is protected from the weather;
• has a maximum temperature of between +5° (41 °F) and
+35 °C (104 °F);
• has a maximum humidity of 70%.
• the appliance passes through the doorways easily.
When choosing the positioning room, take into ac-
count that the appliance must be easy to move for
any extraordinary maintenance: be careful that any
brickwork after installation (e.g.: wall construction,
replacement of a door with a narrower one, renova-
tions, etc.) do not hamper movements.
• there are NO other sources of heat (i.e. grills, fryers, etc.), high-
ly ammable substances or fuels (i.e. gasoline, petrol, bottles
of alcohol, etc...) in the vicinity of the appliance.
• there is adequate ventilation according to the reg-
ulations in force in the Country of installation. If this is
not the case, a ø140 mm [5.51 in.] air intake is man-
datory, communicating with the outside or a ventilat-
ed room (i.e. storeroom, attic, garage, basement).
D
Inform the owner about the necessary electrical ar-
rangements (activities to be carried out by a qualied
electrician)
√For a correct connection Fig.2:
• Provide a socket connecting to the electrical network near
the oven. If the oven has a double chamber, there must be
one connecting socket.
The “Technical data” section from page 6 contains all the
electrical data as well as the positions of the supply cable and
equipotential terminal.
• provide a connection cable A and a plug
B:
appliances are supplied without either power cable or plug:
they must both be tted by qualied personnel. The cable
must be only of the type stated and the plug tted to it
must be suitable for the consumption and connection of
the oven to the electrical mains.
• check that the systems in the room comply with the
legal provisions in force in the country of use and meet
the specications on the serial number plate. For a correct
electrical connection, the appliance must:
• be included in an equipotential system in compli-
ance with the legislation in force. This connection must
be made between the various devices with the terminal
marked with the equipotential symbol . The cable
must have a maximum cross-section of 10 mm2(in com-
pliance with IEC EN 60335-2-42:2003-09) and must be
yellow-green;
• must be grounded to the mains (green-yellow wire);
• must be connected to a thermal dierential switch in
compliance with the regulations in force (0.03A A type);
• must be connected to an omnipolar circuit breaker
allowing complete disconnection in overvoltage III cate-
gory conditions.

5
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
Max 35°C
Max 70% Min 5°C
Max 95°F
Min 41°F
Kg
lb
A
B
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
Fig.2
Fig.4
min 300mm
[
11,81
in.]
Ø150mm
[
Ø5,91
in.]
Ø150mm
[
Ø5,91
in.]
Ø80mm
[
Ø3,15
in.]
D
C
A
B E
in.]
50 mm
[ 1,97 in.]
min.
500 mm
[ 19,7 in.]
min.
50 mm
[ 1,97 in.]
min.
1000mm
[ 39,37 in.]
50 mm
[ 1,97 in.]
min.
50 mm
[ 1,97 in.]
min.
50 mm
[ 1,97 in.]
Fig.3
Evacuation tube, Ø150 mm [Ø5.91 in.] (NOT supplied)
Checks before purchasing
extraction system extraction system
damper
draught switch
The minimum side distance is 50 mm
[1.97 in.], however we recommend
you leave a gap of 500 mm [19.7 in.]
on the right side to make access to the
electrical system easier. If this is not
possible, in case of intervention, it will
be necessary to move the oven from
its housing with suitable systems.

6
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
G
G
E
F
CD
B
A
SINGLE STANDARD OVEN
Oven model
Power
supply
(V)
Power
(kW)
Average
consumption
(kWh)
Absorption
(A)
Cable type
(Nxmm2)
Customer
panel prot.
(NxA)
420
TZ420/1M-C5-CP 3Nx400V
2,1 1,3
3,0 5x0,75 4x16
TZ420/1M-B5-CP 3x230V 5,3 4x0,75 3x16
TZ420/1M-A5-CP 230V 9,1 3x1 2x16
TZ420/1M-B6-US 3x208V 5,8 4xAWG18 3x16
TZ420/1M-A6-US 208V 10,1 3xAWG15 2x16
TZ420/1M-E6-US 240V 8,8 3xAWG17 2x16
425
TZ425/1M-C5-CP 3Nx400V
3,8 2,3
5,5 5x0,75 4x16
TZ425/1M-B5-CP 3x230V 9,5 4x1 3x16
TZ425/1M-A5-CP 230V 16,5 3x2,5 2x20
TZ425/1M-B6-US 3x208V 10,5 4xAWG15 3x16
TZ425/1M-A6-US 208V 18,3 3xAWG13 2x20
TZ425/1M-E6-US 240V 15,8 3xAWG15 2x16
430
TZ430/1M-C5-CP 3Nx400V
4,6 2,8
6,6 5x1 4x16
TZ430/1M-B5-CP 3x230V 11,5 4x1,5 3x16
TZ430/1M-A5-CP 230V 20,0 3x2,5 2x25
TZ430/1M-B6-US 3x208V 12,8 4xAWG15 3x16
TZ430/1M-A6-US 208V 22,1 3xAWG13 2x25
TZ430/1M-E6-US 240V 19,2 3xAWG13 2x20
435
TZ435/1M-C5-CP 3Nx400V
5,2 3,1
7,5 5x1 4x16
TZ435/1M-B5-CP 3x230V 13,1 4x1,5 3x16
TZ435/1M-A5-CP 230V 22,6 3x2,5 2x25
TZ435/1M-B6-US 3x208V 14,4 4xAWG15 3x16
TZ435/1M-A6-US 208V 25,0 3xAWG11 2x32
TZ435/1M-E6-US 240V 21,7 3xAWG13 2x25
230
TZ230/1M-C5-CP 3Nx400V
3,1 1,9
4,5 5x0,75 4x16
TZ230/1M-B5-CP 3x230V 7,8 4x1 3x16
TZ230/1M-A5-CP 230V 13,5 3x1,5 2x16
TZ230/1M-B6-US 3x208V 8,6 4xAWG17 3x16
TZ230/1M-A6-US 208V 14,9 3xAWG15 2x16
TZ230/1M-E6-US 240V 12,9 3xAWG15 2x16
DOUBLE STANDARD OVEN
Oven model
Power
supply
(V)
Power
(kW)
Average
consumption
(kWh)
Absorption
(A)
Cable type
(Nxmm2)
Customer
panel prot.
(NxA)
420
TZ420/2M-C5-CP 3Nx400V
4,2 2,5
6,1 5x1 4x16
TZ420/2M-B5-CP 3x230V 10,5 4x1,5 3x16
TZ420/2M-A5-CP 230V 18,3 3x2,5 2x20
TZ420/2M-B6-US 3x208V 11,7 4xAWG15 3x16
TZ420/2M-A6-US 208V 20,2 3xAWG13 2x25
TZ420/2M-E6-US 240V 17,5 3xAWG13 2x20
425
TZ425/2M-C5-CP 3Nx400V
7,6 4,6
11,0 5x1,5 4x16
TZ425/2M-B5-CP 3x230V 19,1 4x2,5 3x20
TZ425/2M-A5-CP 230V 33,0 3x6 2x40
TZ425/2M-B6-US 3x208V 21,1 4xAWG13 3x25
TZ425/2M-A6-US 208V 36,5 3xAWG9 2x40
TZ425/2M-E6-US 240V 31,7 3xAWG11 2x32
430
TZ430/2M-C5-CP 3Nx400V
9,2 5,5
13,3 5x1,5 4x16
TZ430/2M-B5-CP 3x230V 23,1 4x2,5 3x25
TZ430/2M-A5-CP 230V 40,0 3x10 2x50
TZ430/2M-B6-US 3x208V 25,5 4xAWG11 3x32
TZ430/2M-A6-US 208V 44,2 3xAWG7 2x50
TZ430/2M-E6-US 240V 38,3 3xAWG9 2x40
435
TZ435/2M-C5-CP 3Nx400V
10,4 6,2
15,0 5x1,5 4x16
TZ435/2M-B5-CP 3x230V 26,1 4x4 3x32
TZ435/2M-A5-CP 230V 45,2 3x10 2x50
TZ435/2M-B6-US 3x208V 28,9 4xAWG11 3x32
TZ435/2M-A6-US 208V 50,0 3xAWG7 2x63
TZ435/2M-E6-US 240V 43,3 3xAWG7 2x50
230
TZ230/2M-C5-CP 3Nx400V
6,2 3,7
8,9 5x1 4x16
TZ230/2M-B5-CP 3x230V 15,6 4x1,5 3x16
TZ230/2M-A5-CP 230V 27,0 3x4 2x32
TZ230/2M-B6-US 3x208V 17,2 4xAWG13 3x20
TZ230/2M-A6-US 208V 29,8 3xAWG11 2x32
TZ230/2M-E6-US 240V 25,8 3xAWG11 2x32
Electrical data | STANDARD OVENS
2OVEN TECHNICAL DATA
Key
(only USA models)
AOven smoke exhaust
BOven door
CControl panel
DPanel to access electrical components
EOven supply input
FEquipotential
GCircuit breaker (only USA models)

7
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
SINGLE ENHANCED OVEN
Oven model
Power
supply
(V)
Power
(kW)
Average
consumption
(kWh)
Absorption
(A)
Cable type
(Nxmm2)
Customer
panel prot.
(NxA)
420
TZ420/1M-C5P-CP 3Nx400V
2,6 1,6
3,8 5x0,75 4x16
TZ420/1M-B5P-CP 3x230V 6,5 4x1 3x16
TZ420/1M-A5P-CP 230V 11,3 3x1,5 2x16
TZ420/1M-B6P-US 3x208V 7,2 4xAWG17 3x16
TZ420/1M-A6P-US 208V 12,5 3xAWG15 2x16
TZ420/1M-E6P-US 240V 10,8 3xAWG15 2x16
425
TZ425/1M-C5P-CP 3Nx400V
4,6 2,8
6,6 5x1 4x16
TZ425/1M-B5P-CP 3x230V 11,5 4x1,5 3x16
TZ425/1M-A5P-CP 230V 20,0 3x2,5 2x25
TZ425/1M-B6P-US 3x208V 12,8 4xAWG15 3x16
TZ425/1M-A6P-US 208V 22,1 3xAWG13 2x25
TZ425/1M-E6P-US 240V 19,2 3xAWG13 2x20
430
TZ430/1M-C5P-CP 3Nx400V
5,6 3,4
8,1 5x1 4x16
TZ430/1M-B5P-CP 3x230V 14,1 4x1,5 3x16
TZ430/1M-A5P-CP 230V 24,3 3x2,5 2x25
TZ430/1M-B6P-US 3x208V 15,5 4xAWG15 3x16
TZ430/1M-A6P-US 208V 26,9 3xAWG11 2x32
TZ430/1M-E6P-US 240V 23,3 3xAWG13 2x25
435
TZ435/1M-C5P-CP 3Nx400V
6,4 3,8
9,2 5x1 4x16
TZ435/1M-B5P-CP 3x230V 16,1 4x2,5 3x20
TZ435/1M-A5P-CP 230V 27,8 3x4 2x32
TZ435/1M-B6P-US 3x208V 17,8 4xAWG13 3x20
TZ435/1M-A6P-US 208V 30,8 3xAWG11 2x32
TZ435/1M-E6P-US 240V 26,7 3xAWG11 2x32
230
TZ230/1M-C5P-CP 3Nx400V
3,8 2,3
5,5 5x0,75 4x16
TZ230/1M-B5P-CP 3x230V 9,5 4x1 3x16
TZ230/1M-A5P-CP 230V 16,5 3x2,5 2x20
TZ230/1M-B6P-US 3x208V 10,5 4xAWG15 3x16
TZ230/1M-A6P-US 208V 18,3 3xAWG13 2x20
TZ230/1M-E6P-US 240V 15,8 3XAWG15 2x16
DOUBLE ENHANCED OVEN
Oven model
Power
supply
(V)
Power
(kW)
Average
consumption
(kWh)
Absorption
(A)
Cable type
(Nxmm2)
Customer
panel prot.
(NxA)
420
TZ420/2M-C5P-CP 3Nx400V
5,2 3,1
7,5 5x1 4x16
TZ420/2M-B5P-CP 3x230V 13,1 4x1,5 3x16
TZ420/2M-A5P-CP 230V 22,6 3x2,5 2x25
TZ420/2M-2MP-US 3x208V 14,4 4xAWG15 3x16
TZ420/2M-A6P-US 208V 25,0 3xAWG11 2x32
TZ420/2M-E6P-US 240V 21,7 3xAWG13 2x25
425
TZ425/2M-C5P-CP 3Nx400V
9,2 5,5
13,3 5x1 4x16
TZ425/2M-B5P-CP 3x230V 23,1 4x1,5 3x16
TZ425/2M-A5P-CP 230V 40,0 3x2,5 2x25
TZ425/2M-2MP-US 3x208V 25,5 4xAWG15 3x16
TZ425/2M-A6P-US 208V 44,2 3xAWG11 2x32
TZ425/2M-E6P-US 240V 38,3 3xAWG9 2x40
430
TZ430/2M-C5P-CP 3Nx400V
11,2 6,7
16,2 5x2,5 4x20
TZ430/2M-B5P-CP 3x230V 28,1 4x4 3x32
TZ430/2M-A5P-CP 230V 48,7 3x10 2x50
TZ430/2M-2MP-US 3x208V 31,1 4xAWG11 3x32
TZ430/2M-A6P-US 208V 53,8 3xAWG7 2x63
TZ430/2M-E6P-US 240V 46,7 3xAWG7 2x50
435
TZ435/2M-C5P-CP 3Nx400V
12,8 7,7
18,5 5x2,5 4x20
TZ435/2M-B5P-CP 3x230V 32,1 4x6 3x40
TZ435/2M-A5P-CP 230V 55,7 3x10 2x63
TZ435/2M-2 MP-US 3x208V 35,5 4xAWG9 3x40
TZ435/2M-A6P-US 208V 61,5 3xAWG7 2x63
TZ435/2M-E6P-US 240V 53,3 3xAWG7 2x63
230
TZ230/2M-C5P-CP 3Nx400V
7,6 4,6
11,0 5x1,5 4x16
TZ230/2M-B5P-CP 3x230V 19,1 4x2,5 3x20
TZ230/2M-A5P-CP 230V 33,0 3x6 2x40
TZ230/2M-2MP-US 3x208V 21,1 4xAWG13 3x25
TZ230/2M-A6P-US 208V 36,5 3xAWG9 2x40
TZ230/2M-E6P-US 240V 31,7 3xAWG11 2x32
Electrical data | ENHANCED OVENS

8
700 [27,559]
700 [27,559]
632 [24,882]
ø85 [ø3,346]
68 [2,677]
110 [4,331]
450 [17,717]
50 [1,969]
61 [2,402]
630 [24,803]
45 [1,772]
560 [22,047]
390 [15,354]
140 [5,512]
560 [22,047]
630 [24,803]
units of measurement: mm [inch]
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
TZ 420 single oven weight
51 kg [112.4 lb]
weight of packaging +
TZ 420 single complete oven
64 kg [141 lb]
TZ 420 single oven packaging dimensions
730x650x540 [28.74x25.59x21.26 in.]
Tiziano TZ 420 oven technical data | single oven

9
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
705 [27,756] 715 [28,150]
433 [17,047]
153 [6,024]
282 [11,102]
172 [6,772]
562 [22,126]
390 [15,354]
172 [6,772]
20 [0,787]
542 [21,339]
390 [15,354]
152 [5,984]
352 [13,878] 352 [13,878]
units of measurement: mm [inch]
Tiziano TZ 420 oven + KTZ 420 hood technical data | hood + single oven

10
700 [27,559] 630 [24,803]
140 [5,512]
445 [17,520]
50 [1,969]61 [2,402]
45 [1,772]
560 [22,047]
690 [27,165]
700 [27,559]
632 [24,882]
ø85 [ø3,346]
68 [2,677]
110 [4,331]
450 [17,717]
560 [22,047]
630 [24,803]
units of measurement: mm [inch]
Tiziano TZ 420 oven technical data | double oven
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
TZ 420 double oven weight
90 kg [198.4 lb]
weight of packaging +
TZ 420 double complete oven
105 kg [231.4 lb]
TZ 420 double oven packaging dimen-
sions
730x650x840 [28.74x25.59x33.07 in.]

11
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
172 [6,772]
862 [33,937]
690 [27,165]
172 [6,772]
690 [27,165]
842 [33,150] 20 [0,787]
152 [5,984]
705 [27,756] 715 [28,150]
433 [17,047]
282 [11,102]
352 [13,878] 352 [13,878]
153 [6,024]
units of measurement: mm [inch]
Tiziano TZ 420 oven + KTZ 420 hood technical data | hood + double oven

12
700 [27,559] 630 [24,803]
140 [5,512]
445 [17,520]
830 [32,677]
50 [1,969] 50 [1,969]
61 [2,402] 640 [25,197]
45 [1,772]
560 [22,047]
690 [27,165] 390 [15,354]
1080 [42,520]
700 [27,559]
632 [24,882]
ø85 [ø3,346]
68 [2,677]
110 [4,331]
450 [17,717]
560 [22,047]
630 [24,803]
units of measurement: mm [inch]
Tiziano TZ 420 oven technical data | triple oven

13
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
172 [6,772]
1252 [49,291]
1080 [42,520]
172 [6,772]
20 [0,787]
152 [5,984]
1080 [42,5201]
1232 [48,504]
715 [28,150]
433 [17,047]
282 [11,102]
705 [27,756]
352 [13,878] 352 [13,878]
153 [6,024]
units of measurement: mm [inch]
Tiziano TZ 420 oven + KTZ 420 hood technical data | hood + triple oven

14
700 [27,559]
630 [24,803]
50 [1,969] 50 [1,969]
61 [2,402] 640 [25,197]
1135 [44,685]
830 [32,677]
445 [17,520]
140 [5,512]
45 [1,772]
560 [22,047]
690 [27,165]
1380 [54,331]
690 [27,165]
700 [27,559]
632 [24,882]
ø85 [ø3,346]
68 [2,677]
110 [4,331]
450 [17,717]
560 [22,047]
630 [24,803]
units of measurement: mm [inch]
Tiziano TZ 420 oven technical data | quadruple oven

15
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
172 [6,772]
1552 [61,102]
1380 [54,331]
172 [6,772]
20 [0,787]
152 [5,984]
1380 [54,331]
1352 [60,351]
715 [28,150]
433 [17,047]
282 [11,102]
705 [27,756]
352 [13,878] 352 [13,878]
153 [6,024]
units of measurement: mm [inch]
Tiziano TZ 420 oven + KTZ 420 hood technical data | hood + quadruple oven

16
ECO
ECO
420 mm [16,54 in.]
420 mm [16,54 in.]
chamber height: 140 mm [ 5.51 in. ]
Tiziano TZ 420 oven technical data | capacity
ALIGNMENT OF THE OVEN WITH THE SUPPORT
If the oven is to be placed on a support, make the oven rear corners match the rear corners of the support.
PIZZA Ø 30 cm [Ø 11.81 in.]
PIZZA Ø 35 cm [Ø 13.78 in.]
Ø PIZZAS HOURLY PRODUCTIVITY
Ø 20 cm [Ø 7.87 in.]
36 PIZZAS
Ø 30 cm [Ø 11.81 in.]
9 PIZZAS
Ø 40 cm [Ø 15.75 in.]
9 PIZZAS
Ø 35 cm [Ø 13.78 in.]
9 PIZZAS
Ø 50 cm [Ø 19.69 in.]
-
60x40 cm [23.62x15.75 in.]
-

17
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
800 [31,496]
1560 [661,417]
798 [31,417]
1310 [51,575]
1231 [48,465] 50 [1,969]
292 [11,496]
1170 [461,063]
212 [8,346]
550 [21,654]
110 [4,331]
660 [25,984]
730 [28,740]
390 [15,354]
730 [28,740]
660 [25,984] 45 [1,772]
800 [31,496]
800 [31,496]
732 [28,819]
68 [2,677]
Ø85 [Ø3,346]
800 [31,496]
638 [25,118] 22 [0,866]
438 [17,244]
units of measurement: mm [inch]
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
TZ 425 single oven weight
65 kg [143.3 lb]
weight of packaging +
TZ 425 single complete oven
78 kg [171.9 lb]
TZ 425 single oven packaging dimen-
sions
830x750x540 [32.68x29.53x21.26 in.]
Tiziano TZ 425 oven technical data | single oven

18
1730 [68,189] 1560 [61,417] 172 [6,772]
20 [0,787]
172 [6,772]
152 [5,584]
1560 [61,417]
1712 [67,402]
805 [31,693] 815 [32,087]
533 [20,984] 282 [11,102]
153 [6,024]
402,5 [15,864]402,5 [15,864]
units of measurement: mm [inch]
Tiziano TZ 425 oven + KTZ 425 hood technical data | hood + single oven

19
Ed. 0423 - 70702500 REV03 TIZIANO - Pre-installation
800 [31,496]
1660 [65,354]
598 [23,543]
1110 [43,701]
1415 [55,709]
1031 [40,591] 50 [1,969]
292 [11,496]
970 [38,189]
212 [8,346]
690 [27,165]
730 [28,740]
660 [25,984] 45 [1,772]
800 [31,496]
800 [31,496]
638 [25,118] 22 [0,866]
438 [17,244]
550 [21,654]
110 [4,331]
660 [25,984]
730 [28,740]
800 [31,496]
732 [28,819]
68 [2,677]
Ø85 [Ø3,346]
units of measurement: mm [inch]
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
0
200
100
300
°C400
600
500
TZ 425 double oven weight
114 kg [251.3 lb]
packaging +TZ 425 double
complete oven weight
128 kg [282.1 lb]
TZ 425 double
oven packaging dimensions
830x750x840 [32.68x29.53x33.07 in.]
Tiziano TZ 425 oven technical data | double oven

20
805 31,693 815 32,087
533 20,984 282 11,102
1812 71,339
1660 65,354
402,5 15,846 402,5 15,846
172 6,772
152 5,984
153 6,024
20 0,787
172 6,772
1660 65,354
1832 72,126
units of measurement: mm [inch]
Tiziano TZ 425 oven + KTZ 425 hood technical data | hood + double oven
