Current Solutions TENS 7000 To Go User manual

SO
L
U
TI
O
N
S
TM
A Roscoe Medical Company
CURRENT
The purpose of this guide is to assist you in correctly operating your TENS 7000 To Go™ unit.
Do not use this device for undiagnosed pain symptoms until consulting a physician. This guide
is not intended to replace or substitute the TENS 7000 To Go™ Instruction Manual. PLEASE READ
THE INSTRUCTION MANUAL COMPLETELY BEFORE USING THIS DEVICE. Read, understand and
practice the contraindications, warnings, cautions and operating instructions found on pages 4 –5 of your
instruction manual. Always follow the operating instructions prescribed by your healthcare provider.
QUICK REFERENCE GUIDE PAGE 1
1
2
Top
Side
Front
3
4
5
6
7
8
9
10
Lead connector sockets - 2 channels
On / o / intensity dial - 2 channels
Panel cover with reference guide
Liquid crystal display (LCD)
Mode selection button
Set selection button
Increment control / increase button
Increment control / decrease button
Protective cover
Belt clip
1
2
3
4
5
6
7
8
9
10
TENS 7000 T0 G0™
UNIT
LEAD WIRES
For more information about your TENS 7000 To Go™ unit, visit us online at currentsolutionsnow.com or call 1-800-871-7858.
The belt feature of the TENS 7000To Go™ allows
patients to comfortably apply stimulation to the lower
back without having to contort or twist into positions
commonly associated with the placement of self-
adhesive electrodes.The belt ts comfortably under
clothes and the belt clip ensures continued mobility.
TheTENS 7000 To Go™ features two protective covers
that prevent unintentional changes to settings.
Turn on device by rotating the dial clockwise and
select the desired intensity level. Turn o
device by turning dial counterclockwise to O.
Low battery indicator signals when battery is
low. Replace battery when stimulation feels weaker.
SPECIAL FEATURES
BELT INSERT BATTERY
Press arrow and slide
battery compartment
cover open. Insert 9V
battery, matching the
+ and – ends to
those in unit.
The battery should
be place on top of the
compartment ribbon
to allow easy battery
removal.
RUBBER ELECTRODE PADS
SNAP WIRES
TENS 7000 to Go DT6070
replacement parts :
GB7000 – Conductive Back Belt
WS3147 – Snap Wires
WW3005 – LeadWires
TA9050 – Battery
LS2177 - Conductive Spray, 2 oz
SPRAY

2 3 APPLY CONDUCTIVE
SPRAY TO RUBBER
ELECTRODES
5TURN DEVICE ON AND
SELECT INTENSITY
7SELECT PULSE WIDTH
The pulse width is adjusted from 50us to 300us. Press
the SET button to enter this menu, then press the s
and tbuttons to adjust the setting. Unless other-
wise instructed, a setting of 70-120us is suggested.
8SELECT PULSE RATE 9SET THE TIMER
The treatment time is adjustable from 1 to 60 minutes,
or Continuous (C). Press the sand tbuttons to adjust
the setting. Your settings will be stored permanently
unless they are adjusted again.
6SELECT
THERAPY MODE
Please see page 22 of your TENS 7000 To Go™ Instruction Manual for troubleshooting tips.
PROBLEMS WITH YOUR DEVICE?
Steps 1–4 should be performed with the device turned OFF.
Once the unit has been turned ON, do not remove the belt
without rst turning OFF the device.
IMPORTANT!
SO
L
U
TI
O
N
S
TM
A Roscoe Medical Company
CURRENT
QUICK REFERENCE GUIDE PAGE 2
There are 5 modes available: Burst, Normal,
Modulation, SD1 and SD2. Press the MODE button
and continue to press until you have reached your
desired setting.
1CONNECT LEAD WIRES
TO BELT WIRE SNAPS
The stimulation output will increase as the dial is
turned clockwise or to a higher number.
1 = Weaker 8 = Stronger
By turning the
controls clockwise,
the appropriate
channel is switched
on and the indicator
of power (CH1 and
CH2) is revealed in
the LCD.
The pulse rate is adjusted from 2Hz to 150Hz. Press the
SET button to enter this menu, then press the sand
tbuttons to adjust the setting. Unless otherwise
instructed, a setting of 70-120Hz is suggested.
ON/
Increase
Continuous
Connect snap wires to metal snaps located on the back
of the belt. Securely connect the lead wires to the snap
wires. Make certain no bare metal of pins is exposed.
Select one of
the two available
channels and
insert the lead
wire rmly into
the socket.
CONNECT LEAD WIRES
TO DEVICE
Apply two pumps of conductive spray to each rubber
electrode pad before placing belt around waist.
4PLACE BELT
AROUND WAIST
With the electrode
pads facing toward
your body, position
the belt on your
lower back. After
a comfortable t
has been achieved,
fasten belt by
overlapping the
Velcro® closure
in front.
