Curtis iMode IP1500 User manual

IPOD RADIO CD MICRO SYSTEM
MODEL NO. IP1500
OWNER'S MANUAL
PLEASE READ BEFORE OPERATING THIS EQUIPMENT

1
C AUTION: TO R E DUC E THE R IS K OF E LE C TR IC
S HOC K, DO NOT R E MOV E C OV E R (OR B AC K ). NO
US E R -S E R VIC E ABLE PAR TS INS IDE . R E F E R S E R VIC -
ING TO QUALIF IE D S E R VIC E P E R S ONNE L.
C AUTION
R IS K OF E LE C T R IC S HOC K
DO NO T OP E N
DA NG E R OUS V OLTA G E :
The lightning ßash with arrowhead
symbol, within an equilateral trian-
gle is intended to alert the user to
the presence of uninsulated dan-
gerous voltage within the productÕs
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
ATTE NTION:
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and mainte-
nance (servicing) instructions in
the literature accompanying the
appliance.
DA NG E R :
Invisible and hazardous laser
radiation when open and inter-
lock failed or defeated. Avoid
direct exposure to beam.
F C C WAR NING :
This equipment may generate or use
radio frequency energy. C hanges or
modiÞcations to this equipment may
cause harmful interference unless the
modiÞcations are expressly approved in
the instruction manual. The user could
lose the authority to operate this
equipment if an unauthorized change or
modiÞcation is made.
S UR G E P R OT E C TOR S :
It is recommended to use a surge
protector for AC connection. Lightning
and power surges AR E NOT covered
under warranty for this product.
L AS E R S AFE T Y: This unit
employs a laser. Only qualified
service personnel should attempt
to service this device due to
possible eye injury.
C AUTION: US E OF
C ONTR OLS , ADJ US TME NTS
OR P E R F OR MANC E
P R OC E DUR E HE R E IN MAY
R E S ULT IN HAZAR DOUS
R ADIATION E XP OS UR E .
INF OR MATION:
This equipment has been tested and
found to comply with the limits for a
C lass B digital device, pursuant to P art
15 of the F C C R ules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
¥R eorient or relocate the receiving
antenna.
¥Increase the separation between the
equipment and receiver.
¥C onnect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
¥C onsult the dealer or an experienced
radio/TV technician for help.
S AF E TY INS TR UC TIONS

PREPARATION FOR USE
Unpacking and Setup
AC Operation
Unwind the AC cord and extend it to its full length. Insert the AC cord into any
convenient AC 120V~60Hz household outlet.
Please note that this unit is equipped with a polarized AC plug which has one
blade wider than the other. This is a safety feature to reduce the likelihood of
electric shock. This polarized AC plug will only fit in a polarized AC outlet. If you
find that you cannot insert this plug into your outlet, you may have an obsolete
non-polarized outlet.
Please do not try to defeat this safety feature by using a non-polarized adapter
or by filing the wider blade to make it fit into your outlet. If this plug does not fit
into your outlet, you should contact a qualified licensed electrician to replace
your obsolete outlet.
Carefully remove the unit from the display carton and remove all packing
material from the unit itself.
2

L OC AT ION OF C ONTR OL S
1. POWER BUTTON
2. MEM/CLK ADJ BUTTON
3. REPEAT/M-DN BUTTON
4. TIMER BUTTON
5. SLEEP BUTTON
6. FUNCTION BUTTON
7. IPOD BUTTON
8. SKIP/TUNE DN BUTTON
9. PRESET EQ BUTTON
10.SKIP/TUNE UP BUTTON
11. VOLUME DN BUTTON
12. VOLUME UP BUTTON
13. STOP/BAND BUTTON
14. OPEN/CLOSE BUTTON
15. HEADPHONE JACK
16. PLAY/PAUSE MEM-UP BUTTON
3
1 2 3 4 5 6 7
8 9 10 11 12 13 14 15 16

L OC AT ION OF R E MOT E C ONTR OL S
1. POWER BUTTON
2. FUNCTION BUTTON
3. DISPLAY BUTTONS
4. FM ST BUTTON
5. SKIP/TUNE DN BUTTON
6. SLEEP BUTTON
7. SKIP/TUNE UP BUTTON
8. TIMER BUTTON
9. MEM/CLK SET BUTTON
10.STOP/BAND BUTTON
11.REPEAT/MEM DN BUTTON
12. PLAY/PAUSE/MEM UP BUTTON
13. VOLUME DN BUTTON
14. MUTE BUTTON
15. EQ BUTTON
16. VOLUME UP BUTTON
17. IPOD BUTTON
18.OPEN/CLOSE BUTTON
4
1
2
3
4
5
11
12
POWEREJECT
FM ST
EQ
MUTE
CLK SET MEM DN
TUNE/SKIP BAND MEM-UP
VOL
VOL
iPOD
REPEAT
6
7 8 9 10
13
14
15
16
17
18

P OWE R S OUR C E S
BATTERIES
NOTE:
The button cell battery contains mercury, don't put in the trash. Recycle or
dispose as hazardous waste.
NOTE:
You may need to remove a protective covering from the remote's battery
compartment before using the remote control.
5
(FOR R E MOTE C ONT R OL)

OP E R AT ING INS TR UC T IONS
6
Setting up your radio
Checking AM Radio reception
Your clock radio has a built-in antenna for AM radio. To improve reception,
you need to rotate your unit.
Unpacking And Set Up
• Remove the main unit, the speakers, and the remote control unit from the
display carton. Remove all packing materials from the components.
• Unwind the AC power cord and extend it to its full length.
• Unwind the external FM wire antenna and extend it to its full length.
• Remove the twist-ties from the speaker wires.
Placement of the System
The system should be placed on a stable, level surface such as a table, desk, or
shelf, convenient to an AC outlet, away from direct sunlight, and sources of excess
heat, dust, moisture, humidity, vibration, or strong magnetic fields.
The speakers may be placed next to the main unit or as far apart as the speaker
wires allow. We recommend that you leave a gap of approximately 1/2 inch between
the main unit and the speakers so that any vibration from the speakers will not
interfere with the CD player in the main unit

OP E R AT ING INS TR UC TIONS
7

1. Plug the AC Power cord into a power outlet.
2. Press the POWER button on the main unit or remote control to turn the
 system ‘On’.
3. If necessary, press the FUNCTION button to select the Radio mode and
 the display shows: FM 87.5 MHz.
4. To switch between FM and AM bands press the STOP/BAND button on
 the front panel or remote.
5. Automatic Tuning - Depress and hold the or buttons until the display
 begins to move, then release the buttons. The tuner will scan up or down
 the band until it finds the first strong station, and then stop on that station.
 Repeat this process until the tuner stops on your desired station.
6. If you tune to an FM Stereo station the “(ST)” indicator appears in the
 display.
7. Manual Tuning - Press the or buttons repeatedly until the display is
 showing the frequency of your desired station. Use the manual tuning
 method to tune to weaker stations that are bypassed during Automatic
 Tuning.
Setting the time
To set the time on your radio:
1. With the power off.
2. Press and hold the MEM/CLK ADJ Button; "12Hr" will blink.
3. Press the SKIP/TUNING Button to set the unit to the 24 hour (24Hr) mode
 or 12 hour (12Hr) mode.
4. Press the MEM/CLK ADJ Button and the hours will blink.
5. Press the SKIP/TUNING Button to set the current hour, then press the
 MEM/CLK ADJ again; the minute digits will blink. Press the SKIP/TUNING
 to set the current minutes.
6. Press the MEM/CLK ADJ Button to confirm the time.
Using your radio

OP E R AT ING INS TR UC TIONS
8
Programming radio station presets:
You can program as many as 10 FM and 10 AM radio station presets. After you
program a station, you can tune to the station by pressing one of the SKIP/TUNE
Buttons.
To program a radio station:
1. Press the POWER Button to turn on your radio.
2. Press the FUNCTION Button one or more times until TUNER appears
 on the display.
3. Press the BAND Button to select AM or FM.
4. Press and hold one of the SKIP/TUNE Buttons to select a radio station.
5. Press and hold the MEM/CLK ARJ Button to activate the programming
 mode.
6. Press one of the SKIP/TUNING Buttons to select the preset number you
 want to assign the station to.
7. Press the MEM/CLK ARJ Button to store the station with the preset number
 you selected.
8. Repeat Steps 4 through 7 to program additional presets.

OP E R AT ING INS TR UC TIONS
9
To tune to a radio station preset:
1. Press the POWER Button to turn on your radio.
2. Press the FUNCTION button one or more times until TUNER appears on
 the display.
3. Press the STOP Button to select AM or FM.
4. Press the MEM DN or MEM UP Button one or more times until the preset
 number you want appears on the display.
To select an equalizer mode:
Press the EQ Button one ore more times to select the mode you want
You can select:
 * Classic
 * Jazz
 * Rock
 * Pop
Listening to a CD
Your radio can play audio CDs, CD-Rs and CD-RWs. CD-Rs and CD-RWs
must be finalized before you can play them on your unit.
To listening to a CD:
1. Press the POWER Button to turn on your radio.
2.  Press the FUNCTION Button one or more times until CD track "--" appears
 on the display.
3. Press the OPEN/CLOSE Button to open the CD tray.
4. Place a CD with the label side up into the CD tray.
5. Press the OPEN/CLOSE Button to close the CD tray.
6. Press the PLAY/PAUSE Button to start playback.
7. To control the CD during playback:
 * Press the PLAY/PAUSE Button to pause playback. Press the button
 again to resume playback.
 * Press one of the SKIP/TUNING Buttons to go to the next or previous
 track on the CD.
 * Press and hold one of the SKIP/TUNING Buttons to search for a track
 on the CD.
8. Press the STOP Button to stop playback.


OP E R AT ING INS TR UC TIONS
10
To set up a CD playlist:
1. Press the POWER Button to turn on your unit, then Press the FUNCTION
 Button one or more times until CD track "--" appears on the display.
2. Insert a CD into the CD tray. If the CD starts playing, press the STOP Button.
3.  Press the MEM/CLK ARJ Button. "PROG 0" appears on the display.
4. Press one of the SKIP/TUNING Buttons one or more times to select the first
 track you want to program.
5. Press the MEM/CLK ARJ Button to confirm your selection.
6. Repeat Step 4 and 5 to add more tracks to your playlist.
7. When you have finished creating your playlist, press the PLAY/PAUSE
 Button to start playing your playlist.
To edit a CD playlist:
1. While the CD is playing, press the STOP Button to stop playback.
2. Press the MEM/CLK ARJ Button to select one of the programmed tracks.
3. Press one of the SKIP/TUNING Buttons one or more times to select a new
 track you want to program.
4. Repeat Steps 2 and 3 to edit aditional track selections.
To cancel a playlist:
While the CD is playing, do one of the following:
 * Press the STOP Button twice.
 * Press the FUNCTION Button.
 * Press the OPEN/CLOSE Button to open the CD tray.
 * Press the POWER Button to turn off your radio.
To repeat a track or an entire CD:
1. Press the POWER Button to turn on your radio.
2. Press the FUNCTION Button one or more times until CD track appears on
 the display.
3. Press the OPEN/CLOSE Button to open the CD tray.
4. Place a CD with the label side up in the tracy, then press the OPEN/CLOSE
 button to close the tray.
5. Press the PLAY/PAUSE Button to start playback.

OP E R AT ING INS TR UC TIONS
11
iPod®Inserts
Your unit comes with removable inserts* to ensure your iPod®fits properly in the dock on
the top of the unit.
* Due to new iPod ®models, new inserts subject to availability.
To Place an Insert
Select the insert for your iPod®(see chart above). Using the correct insert ensures the
proper fit for your iPod®.
Gently press the iPod®insert into the dock.
Carefully place your iPod®into the dock.
To remove/replace an insert, first remove your iPod®, then grip the insert and pull gently
upwards.
Mini Insert
Use with iPod®
Mini
Thin iPod®s Insert
iPod® 3Gen 10-15 GB
iPod®3Gen 20 GB
iPod®4Gen 20 GB
iPod®Photo 30 GB
Thick iPod®s Insert
iPod®3Gen 30 GB
iPod®3Gen 40 GB
iPod®4Gen 40 GB
iPod®Photo 40 GB
iPod®Photo 60 GB
Nano Insert
iPod®Nano 2 GB
iPod®Nano 4 GB
Listening to your iPod®
When the iPod®is docked and in standby mode, press the IPOD Button on the unit to
play it. The iPod®icon will appear on the display.
Charging your iPod®
When you docked your iPod®and it recharges (until fully charged).
Note: iPod®Shuffles will NOT charge.

OP E R AT ING INS TR UC TIONS
12
Video Out
You will need a television or other video device that has a composite video input.
Securely dock the iPod®.
Connect the yellow RCA cable (Not Included) into the rear video out jack on the unit.
Connect the other end of the yellow RCA cable to the video device.
For Movie Output
Press the IPOD Button on the unit.
Switch on the iPod®Movie.
On the Main Menu choose Video then select Video Setting.
At the TV Out section set it to “ON”.
Switch back to movie library and play the movie of your choice.
For Photo View
Press the IPOD Button on the unit.
Switch on the iPod®Photo.
On the Main Menu choose Photo then select Slide Show Settings.
At TV Out section set it to “ON”.
Go to Photo Library and then press play. The slideshow will play on your device.
Note: The RCA Video input connector on a television is usually color coded yellow to
match the color on the AV cable.
Note: When playing movies, the audio will only playback on the unit speakers.
Note: RCA Cable is not included.

OP E R AT ING INS TR UC TIONS
13
Maintenance
To clean the exterior
 * Use a soft cloth dampened with luke warm water only to clean the exterior
 of your radio.
 * Make sure that you do not drip water into your radio.
 * Do not use solvents, such as benzene, because they may damage the
 finish.
Caring for discs
 * A dirty, scratched, or warped CD may cause skipping or noise.
To clean the lens
 * If the lens get dirty, your player may skip or may not play a CD
1. Open the CD tray.
2. Use a camera lens blower/brush to blow on the lens once or twice, brush
 the dust or particles off the lens, then blow again.
3. To remove fingerprints, use a dry cotton swab to wipe from the middle to
 outer edge of the lens.
Stereo Headphone Jack
You may connect stereo headphones (not included) to the Headphone jack on
the front panel of this system for private listening without disturbing others.
When headphones are connected the speakers are automatically shut off.
IMPORTANT: Before you connect your headphones, set the VOLUME control
of this system to a low level. Then connect your headphones, put them on and
gradually increase the volume to a comfortable listening level.
Remember that prolonged listening to loud music at high volume levels through
headphones or the in-ear type ‘ear-buds’ can result in hearing loss.

TROUBLESHOOTING GUIDE
14
PROBLEM SOLUTION POSSIBLE CAUSE
GENERAL
No sound is heard. Power is not on.
VOLUME Control is set
to minimum.
Mute is on.
Press the POWER button.
Adjust the VOLUME
Control.
Press Mute on remote.
RADIO
Station has not been
tuned properly.
FM reception is weak.
Wrong function is
selected.
Press the FUNCTION
button to the radio
position.
No sound is heard. Tune station properly.
Extend the FM cord.
CD
All or part of the CD
will not play.
CD is inserted
incorrectly.
Make sure that the CD is
placed in the tray with the
label side up.
CD is scratched. Try another CD.
CD is dirty Clean the CD with
soft cloth
CD is warped Try another CD.
Condensation has formed
inside your CD player.
Remove the CD and leave
the CD tray open for about
one hour to let the CD player
dry out.
Function swtich is not
set to CD. Set Function switch to CD
CD compartment not
closed
Close CD compartment
door.

TROUBLESHOOTING GUIDE
15
PROBLEM SOLUTION POSSIBLE CAUSE
iPod®does not
dock properly
Using no or wrong iPod®insert. Make sure the dock insert is the
proper fit for your iPod®.
iPod®didn’t install properly. Remove your iPod®from the dock
and check for obstruction on the
connectors in the dock and on your
iPod®. Then reseat it in the dock.
iPod®does not
respond to the
unit
iPod®is not installed properly. Remove your iPod®from the dock
and check for obstruction on the
connectors in the dock and on your
iPod®. Then reseat it in the dock.
iPod®is locked up. Please make sure your iPod®is
working properly before docking into
the unit. Please refer to your iPod®
manual for details.
Using 1st or 2nd generation iPod®,
iPod®Shuffle or other devices.
Unit cannot control those iPod®s or
other devices.
iPod®didn’t
charge up
iPod®is not installed properly. Remove your iPod®from the dock
and check for obstruction on the
connectors in the dock and on your
iPod®. Then reseat it in the dock.
