Cutech 40180H User manual
2
TABLE OF CONTENTS
INTRODUCTION
SECTION 1 Warranty ..............................................................................................3
SECTION 2 Product Specifications .........................................................................4
SECTION 3 Feature Identification ...........................................................................4
SECTION 4 General Safety......................................................................................5
SECTION 5 Product Safety .....................................................................................8
SECTION 6 Grounding Instructions........................................................................10
SECTION 7 Unpacking & Inventory........................................................................12
SECTION 8 Assembly & Adjustments …………………….......................................13
SECTION 9 Cleaning Spiral Cutterhead & Tips……………....................................24
SECTION 10 Operations …………………………………………………………………26
SECTION 11 Maintenance........................................................................................30
SECTION 12 Troubleshooting...................................................................................35
SECTION 13 Parts Diagram & Lists .........................................................................37
INTRODUCTION
This user manual is intended for use by anyone working with this machine. It should be
kept available for immediate reference so that all operations can be performed with
maximum efficiency and safety. Do not attempt to perform maintenance or operate this
machine until you have read and understand the information contained in this manual.
The drawings, illustrations, photographs, and specifications in this user manual represent
your machine at time of print. However, changes may be made to your machine or this
manual at any time with no obligation to CUTECH.
3
WARRANTY
2 YEAR LIMITED WARRANTY
CUTECH warrants its machinery to be free of defects in workmanship and materials for a period of two (2) years from the date of the
original purchase by the original owner. This warranty applies to products sold in United States only. The warranty does not apply to
any product used for professional or commercial production purposes nor for industrial or educational applications. Such cases are
covered by our 1 year Limited Warranty with the Conditions and Exceptions.
Warranty does not include failures, breakage or defects deemed after inspection by anAuthorized Service Center or our agent to have
been directly or indirectly caused by or resulting from improper use, lack of or improper maintenance, misuse or abuse, negligence,
accidents, damage in handling or transport, or normal wear and tear of any part or component. Examples are consumables such as
inserts and knives or wear items like drive belts, bearings or brushes.Additionally, warranty is void if repairs or alterations are made to
the machine by an unauthorized service center without the direct consent of CUTECH.
To file a claim of warranty, call toll free 877-568-8879 or email techservices@cutechtool.com . Warranty applies to the original buyer
only and cannot be transferred. Your machines date of purchase and serial number have already been registered with Cutech when
shipped. If you purchased your machine from one of our authorized dealers, please go online at www.cutechtool.com and register your
machine online. Thus, you will only need to provide your full name when contacting Cutech.
The defective units should be returned Freight prepaid to CUTECH’s Authorized Service Center for inspection. If the warranty claim is
considered to be invalid due to exclusions listed above CUTECH will at your direction dispose of or return the product. In the event you
choose to have the product returned you will be responsible for the handling and shipping cost of the return.
CUTECH furnishes the above warranties in lieu of all other warranties, express or implied. CUTECH shall not be liable for any special,
indirect, incidental, punitive or consequential damages, including without limitation to loss of profits arising from or related to the
warranty, the breach of any agreement or warranty, or the operation or use of its machinery, including without limitation damages
arising from damage to fixtures, tools, equipment, parts or materials, direct or indirect loss caused by any other part, loss of revenue or
profits, financing or interest charges, and claims by and third person, whether or not notice of such possible damages has been given
to CUTECH. Not Responsible for damages of any kind for any delay by or failure of CUTECH to perform its obligations under this
agreement or claims made a subject of a legal proceeding against CUTECH more than one (1) year after such cause of action first
arose.
The validity, construction and performance of this Warranty and any sale of machinery by CUTECH shall be governed by the law of the
State of Tennessee, without regard to conflicts of law’s provisions of any jurisdiction. Any action related in any way to any alleged or
actual offer, acceptance or sale by CUTECH or any claim related to the performance of and agreement including without limitation this
Warranty, shall take place in the federal or state courts in Shelby County, Tennessee.
CUTECH reserves the right to change the specifications of its machines without prior notice.
4
PRODUCT SPECIFICATIONS
Cutterhead speed RPM 12,000
Motor RPM 19000+/-10% (No Load)
Cutterhead diameter 2”
Max capacity 8” x 1/8"
Cutter inserts qty 16
Motor power input 120 V, 60 Hz, AC Only, 10 Amp
Fence Size Overall 4-3/8” x 19-5/8”
Tables (Overall measurements) 8” x 33.5”
Tables (Overall with extension support) 8” x 51”
Shipping Weight 59lbs
Net Weight 49lbs
Shipping Dimensions 37” L x 16” W x 12” H
Machine Length 51”
Machine Depth with Fence 20”
Machine Height with Fence 13 ¼”
FEATURE IDENTIFICATION
5
GENERAL SAFETY
NOTE: The WARNING! and CAUTION! symbols indicate a potentially hazardous
situation which, if not avoided, COULD result in death or serious injury. READ THIS
MANUAL completely before assembling and operating this machine.
WARNING! TO AVOID serious injury, death, or damage to the machine, please read,
understand, and follow, all Safety and Operating Instructions before assembling and operating
this machine. This manual is not totally comprehensive. It does not and cannot convey every
possible safety and operational problem which may arise while using this machine. The manual
will cover many of the basic and specific safety procedures needed in an industrial environment.
All federal and state laws, and any regulations having jurisdiction covering the safety
requirements for use of this machine, take precedence over the statements in this manual. Users
of this machine must adhere to all such regulations.
WARNING! Exposure to the dust created by power sanding, sawing, grinding, drilling and
other construction activities may cause serious and permanent respiratory or other injury,
including silicosis (a serious lung disease), cancer, and death. Avoid breathing the dust, and avoid
prolonged contact with dust. The dust may contain chemicals known to the State of California to
cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Always operate tool in well ventilated area and provide for proper dust removal. Use a dust
collection system along with an air filtration system whenever possible. Always use properly
fitting NIOSH/OSHA approved respiratory protection appropriate for the dust exposure, and wash
exposed areas with soap and water.
WARNING! ALWAYS wear eye protection. Any machine can throw debris into the eyes during
operations, which could cause severe and permanent eye damage. Everyday eyeglasses are
NOT safety glasses. ALWAYS wear Safety Goggles (that comply with ANSI standard Z87.1) when
operating power tools.
WARNING! ALWAYS wear hearing protection. Plain cotton is not an acceptable protective
device. Hearing equipment should comply with ANSI S3.19 Standards.
WARNING! ALWAYS wear a NIOSH/OSHAapproved dust mask to prevent inhaling dangerous
dust or airborne particles.
