CWT 1630 User manual

Assembly Guide
CWT Lamination Table
Preassembled Version
CWT 1630
CWT 1640
CWT 1647
CWT 1840
CWT 1847
CWT 2140
CWT 2147

Parts included in Regular series
Roll and holder for
Glide beam
Rubber strip
Installation kit
End plate x2
Cutting mat
Legs
Table top
Glide beam
Glass sheet x2
100x40mm Girder x2
U-brackets
Assistance legs
Diffuser pack for LED
Center profiles

Parts included in Premium upgrade kit
LED kit
Power cable
Extra lower roll holder
Table top roll holder

Tools needed for assembly
Metric wrenches –size 8, 13, 17 and 19
Based on DIN standard
Metric allen keys –4, 5, 6, 8 and 10
Based on ISO4762/DIN 912
Spirit-level for leveling the table

Step 1
Open from the marked side by removing screws
Plastic folder including a sticker with
the serial number, to be placed on the
leg and bits for opening the packing.

Step 2
Mount Roller holder to the Glide beam.

Step 3
When placing the legs on the floor, make sure that the
smaller holes are pointing towards each other.
Mount the air regulator and the wire brackets
(from the Installation kit) to the legs.
Using M6x16, 4 pcs.
Allen key 5

Step 4
Mount the 100x40 Girder to the legs using M10x30, 4x2 pcs
Do not tighten to hard. (maximum 20Nm)
Allen key 8

776
888
944
832
Step 5
Mount two of the U-brackets on the table top using M12x30 and nuts, 2x6
pcs. and the Assistance legs, M10x20 and nut 2x1 pcs.
Note: The mounting of the U-brackets and
assistance legs should be done with the table
top placed in the package.
Allen keys 8 and 10
Wrenches 17 and 19
Note: The hole pattern on the U-bracket
and the assistance leg correspond.
Final table surface
height, approx. mm.

Step 6
Assemble the table top by mounting the two U-brackets to the legs using
M12x30, 2x2 pcs with nuts and place the assistance legs to the Girder.
Allen key 10
Wrench 19

Step 7
Cross measure the table top

Step 8
Place the center profiles on the center of table top

Step 9
Push the LED kit plates into the table top.
The stickers on the plates, marked A, B
and C, shall be towards each other in the
middle of the table.
C
B
A
B
A
C
Included in Premium upgrade kit
For Regular series, go to step 12.

Step 10
When the LED plates are pushed in to final position,
connect the 12V cables.
Make sure that the cables are not squeezed
between the plates
Secure the outer plates by tightening the M8 screws
towards the crossbeam, two screws on each plate.
Included in Premium upgrade kit
For Regular model, go to step 12.

Step 11
Mount the plate with switch and cable to the leg
using M6x16, 2 pcs.
Allen key 5
The cable should be attached to the leg in such a
way that it can´t be damaged by the Glide beam.
View from opposite direction
Recommended fastening points
of cable on U-bracket
Included in Premium upgrade kit.
For Regular model, go to step 12
For
Connect the power cable to electrical switch

Step 12
Place the Diffuser plates [1] and Glass plates [2] on the table top.
1
2
DIFFUSER PACK
Model Acrylic sheet size Position
1630 1492x1580 mm -
1640/1840 1085x1580/1780 mm Middle
1450x1580/1780 mm Right/left
1647/1847 1805x1580/1780 Middle
1450x1580/1780 Right/left
Place rubber band all
around the glass plates.
A small amount of lubricant like,
kitchen dish soap, applied on the
rubber makes the assembly easier.

Step 13
Slide the Glide beam onto the table top.
Make sure that the spiral hose and the
brackets are on the same side.
Bracket

Step 14
Assemble the two remaining U-brackets to the table
top, using M12x30 and nuts, 2x6 pcs and to the leg
using M12x30 and nuts 2x2 pcs.
Allen keys 6 and 10
Wrenches 13 and 19

Step 15
Remove the assistance legs
Allen key 8
Wrench 17
Level the table using a spirit-level and if
necessary adjust with the threaded rod

Step 16
Place the cutting mat on the table top.
The outer side of the mat, when it is in
rolled-up condition, shall be upwards
when placing it on the glass.
Trim the cutting mat to fit the table top.
About a quarter inch or 6mm into the
glass surface-
