CYBELEC DNC 60 GS User manual

DNC 60 GS
User Guide
CYBELEC SA Tel. ++ 41 24 447 02 00
RUE DES UTTINS 27 Fax ++ 41 24 447 02 01
CH - 1400 YVERDON-LES-BAINS E-Mail: [e-mail]
SWITZERLAND
V-DOC-60GS-EN

Information in this document is subject to change without notice, and does not represent
a commitment on the part of CYBELEC SA.
The software described in this document is furnished under a license agreement or nondisclosure
agreement. The software may be used or copied only in accordance with the terms of the agreement. It is
against the law to copy the software on any medium except as specifically allowed in the license or
nondisclosure agreement.
Copyright CYBELEC SA. 1991
All rights reserved.
Important:
This notice explains normal and standard programming operations for the numerical control.
In view of the fact that numerical controls can be equipped with configurable functions by the press
manufacturer for his own specific purposes, please refer to the manufacturer-supplied complementary
instructions regarding the programming of these functions.
Autocad is a registered trade mark of Autodesk Inc..
CYBELEC is a registred trademark of CYBELEC SA.
Ethernet is a registered trade mark of Xerox Corporation.
IBM , PC/AT , PC Network , Token Ring Network
are registered trade marks of the International Business Machines Corporation.
MS-DOS is a registered trade mark of Microsoft Corporation.
MS-Windows is a registered trade mark of Microsoft Corporation.
Novell Netware is a registered trade mark of Novell, Incorporated.
Windows NT is a registered trade mark of Microsoft Corporation.

SAFETY AND MAINTENANCE INSTRUCTIONS PAGE I
SAFETY AND MAINTENANCE INSTRUCTIONS
!The operator must be trained for working with the
machine on which the numerical control is installed.
!Improper use of the numerical control can cause
heavy damage on equipment and/or injuries to
people.
!Modification of machine parameters can cause
important material damage or lead to irregular
product quality.
!The rear panel may only be removed by a qualified
technician (danger of electrocution).
!Do not expose the numerical control to excessive
humidity so as to avoid any risk of electrocution and
any deterioration of the equipment.
!Make sure the numerical control is disconnected
from the mains power before carrying out any
cleaning. Do not use liquids based on alcohol or
ammoniac.
!In case of malfunction of the numerical control, call a
technician.
!Do not expose the numerical control to direct sun
rays or any other heat source.
!Do not place the numerical control in the
neighbourhood of magnetic equipment such as
transformers, motors or devices which generate
interference (welding machines, etc.)
! Replace fan filters at regular intervals so as to avoid
overheating.

PAGE II USER GUIDE DNC 60 GS
This page has been left blank intentionally.

LICENSE AGREEMENT PAGE III
LICENSE AGREEMENT FOR CYBELEC
SOFTWARE
GENERAL COPYRIGHT
The CYBELEC software is protected by Copyright, and all the copying rights are reserved.
The CYBELEC software may only be installed and used in authorized equipments (PC or DNC).
The user manuals are also covered by copyright, and all rights to use and to copy are reserved.
This document may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced
without prior consent, in writing, from CYBELEC.
SPECIAL DISKETTE COPYRIGHT
The legal users of this software product are authorized only to copy the contents of the diskette into the
memory of the computer to run the program, and to make one backup copy of the original diskette for
safety purposes in case of loss of the original program.
Unauthorized copying, duplicating, selling or otherwise distributing this product is a violation of the law.
SPECIAL EPROM COPYRIGHT
The CYBELEC DNC and CNC units in which the original software made by CYBELEC has been
replaced by a copy not made by CYBELEC, and without written authorization of CYBELEC, will
immediately lose their warranty.
WARRANTY
CYBELEC does not warrant that its software products will function properly in every computer and
programming environment.
The limitations of use of a software product and its technical specifications are decided by CYBELEC
only; CYBELEC solely is entitled to decide upon conformity and performance of a given software.
The CYBELEC software does not compensate for incompatibilities in operating system revisions or
versions.
Running the CYBELEC software under various revisions or versions, or switching between different
versions or revisions may result in loss or alteration of data.

PAGE IV LICENSE AGREEMENT
SOFTWARE UPDATE SERVICE
Purchase of the CYBELEC software entitles the user, during one year, to delivery of software updates of
the "correction" type.
During the use of a revised or corrected version of the software it may occur that data (program,
parameters, etc.) is lost, or that the equipment or its connections need to be modified; these effects are not
always foreseeable and do not engage CYBELEC's responsibility.
TERMINATION
This agreement shall automatically terminate upon any act of bankruptcy by or against licensee, upon any
assignment for the benefit of creditors of the licensee, upon any attachment execution of judgement or
process against licensee or its assets that substantially inhibits its ability to do business, or upon
dissolution of licensee.
CYBELEC has the right to terminate this agreement immediately, should the licensee violate the
aforementioned conditions.
Within 30 days of termination of this agreement for any reason, licensee shall at his option, either:
!return to CYBELEC or authorized dealer all existent copies of such software and related materials, or
!furnish to CYBELEC evidence satisfactory that the original and all copies of the software, in whole
and in any form, have been destroyed.
LIMITATION OF LIABILITY
The foregoing warranty is instead of all other warranties, expressed or implied.
Licensee further agrees that CYBELEC shall not be liable for any lost profits, lost savings, loss of use, or
other incidental or consequential damages arising from the use or inability to use the software, or for any
claim or demand against licensee by any other party.
In no event shall CYBELEC be liable for consequential damages, even if CYBELEC has been advised of
the possibility of such damages.
CYBELEC does not warrant that the functions contained in the software will meet the licensee's
requirement or that the operation of the software will be totally error free.
Should the software prove defective, the licensee (and not CYBELEC or an authorized dealer or
representative) will assume the entire cost of all necessary service, repair or correction.
CYBELEC warrants the diskettes, EPROMS or other magnetic support or cassettes on which the
programs are supplied to be free of defects in material and workmanship under normal use for a period of
90 days from the date of shipment to the licensee as evidenced by a copy of the packing slip.

LICENSE AGREEMENT PAGE V
LIMITATION OF REMEDIES
CYBELEC's entire liability and the licensee's exclusive remedy shall be as follows:
The replacement of any diskettes or EPROMS or magnetic support media or cassettes not meeting
CYBELEC's limited warranty and which materials are returned to CYBELEC or an authorized
CYBELEC representative with a copy of the packing slip, or
If CYBELEC or its representative is unable to deliver replacement diskettes, magnetic support media,
EPROM or cassettes which are free of defects in materials or workmanship, the licensee may terminate
this agreement under the terms and conditions herein mentioned, and the purchaser's money will be
refunded.
GENERAL
The licensee acknowledges that he has read this agreement, understands it and agrees to be bound by its
terms and conditions.
The licensee agrees to hold CYBELEC harmless on all liability associated with licensee's breach of this
agreement including, but not limited to, all reasonable attorney's fees and court costs, if any.
This license agreement shall be governed by Swiss law; place of jurisdiction is Lausanne, Switzerland.
MAINTENANCE
CYBELEC will provide one year of software maintenance.The extent of maintenance, and response time
for furnishing same, shall be at the sole discretion of CYBELEC.Maintenance shall normally include
correction of errors in code, correction of errors in supporting documentation, update versions of the
covered software which may be released by CYBELEC during the maintenance period.
In no event shall CYBELEC be obliged to provide technical support in attempting to resolve problems or
difficulties resulting from licensee's modification of the licensed software; any such modification by
licensee is entirely at licensee's own risk.

PAGE VI LICENSE AGREEMENT
This page has been left blank intentionally.

25.01.2001 V. 2.2
60GS_10EN.DOC TABLE OF CONTENTS PAGE 1
TABLE OF CONTENTS
SAFETY AND MAINTENANCE INSTRUCTIONS............................................................................I
LICENSE AGREEMENT FOR CYBELEC SOFTWARE..................................................................III
FOREWORD....................................................................................................................................3
DESCRIPTION OF THE NUMERICAL CONTROL DNC 60 GS.....................................................5
General information.............................................................................................................5
Physical and logical organization.........................................................................................7
The memories .....................................................................................................................8
Work memory (buffer memory) 8
DNC internal memory 8
The user interface................................................................................................................9
The screen 9
The keyboard 9
Presentation of the screen pages........................................................................................13
Cursor accessible fields 13
THE SCREEN PAGES.....................................................................................................................15
The MENU page..................................................................................................................15
List of products in the internal memory................................................................................16
List of products according criteria........................................................................................17
Production page...................................................................................................................18
Consulting the production page 18
PRODUCTION page : Explication of the fields 19
Working time 20
Loading and saving an order 20
Consulting the orders 20
Deleting an order 21
Introduction of alphanumerical characters in the fields 21
Transfer RS232 page..........................................................................................................22
DNC <–> PC TRANSFER page 22
PRODUCT page (AF Information).......................................................................................23
PRODUCT page..................................................................................................................24
Sequences list page ............................................................................................................26
SEQUENCE page (small characters)..................................................................................28
Definition of the work cycle 31
SEQUENCE page (large characters), Programming ..........................................................32
SEQUENCE page (large characters), Operating ................................................................33
Correction page...................................................................................................................34
Origin of axes ......................................................................................................................35
Machine parameters............................................................................................................36

PAGE 2 TABLE OF CONTENTS
PROGRAMMING.............................................................................................................................37
Operating procedure...........................................................................................................37
Clearing the buffer ..............................................................................................................37
Programming a sequence...................................................................................................37
Creation of a second (or nth) sequence ............................................................................. 38
Searching for a sequence...................................................................................................38
Deleting a sequence...........................................................................................................38
Insertion of a sequence ......................................................................................................39
Jumping a sequence...........................................................................................................39
Sequence repetition............................................................................................................39
Repeating a group of sequences........................................................................................39
Storage and recall of programs in the internal memory...................................................... 40
Storing a product.................................................................................................................40
Recall of a product from the internal memory..................................................................... 40
Deletion of a product from the internal memory..................................................................41
Complete clearance of the internal memory.......................................................................41
Modification of a product in the internal memory................................................................41
THE INITIALIZATION PAGE........................................................................................................... 43
TRANSMISSION .............................................................................................................................45
Tests of the serial ports ......................................................................................................46
CYBACK.............................................................................................................................47
PROTECTION OF THE ACCESS LEVELS .................................................................................... 49
General Information............................................................................................................49
The users............................................................................................................................50
Access by password........................................................................................................... 51
Access to levels superior to 3............................................................................................. 52
Change password............................................................................................................... 53
Management of the access levels by external key.............................................................54
MAINTENANCE...............................................................................................................................55
In case of failure .................................................................................................................55
Initial checks to carry out 55
Possible memory pollution 55
Before calling for technical help 56
SAFETY AND INTERACTIVE MESSAGES....................................................................................57
The interactive messages................................................................................................... 57
PRINT SCREEN TO THE PRINTER (OR ASCII FILE)...................................................................61
INDEX..............................................................................................................................................63

FOREWORD PAGE 3
FOREWORD
This manual will familiarize you with the programming of the DNC 60. It
supplies the necessary information to allow you to program products and
tools.
You will also learn how to search for, copy, modify and save these data.

PAGE 4 USER GUIDE DNC 60 GS
This page has been left blank intentionally.

DESCRIPTION OF THE DNC 60 PAGE 5
DESCRIPTION OF THE NUMERICAL CONTROL
DNC 60 GS
GENERAL INFORMATION
Numerical control for 1 axis.
!X3 Backgauge axis
Black and white high resolution LCD screen.
Two character sizes.
Multi-page display by menu or direct access.
Multilingual conversational programming. In each DNC, 8 languages are
permanently available for the operator.
Automatic calculation for:
!Blade gap
!Rake angle
!Cutting length
! Material length
Alphanumerical programming of the code number and production pages.
"Printscreen" function for printing the contents of each screen page (via serial
line).
Automatic conversion:
! Inch / mm
Internal non-volatile memory which allows to store in the DNC:
!approx. 800 sequences
!36 sequences per product
!Product N° : 3 numbers
!Code N° : 24 numbers or letters
!Sequence N° : 2 numbers
!Sequence repetitions : 2 numbers

PAGE 6 USER GUIDE DNC 60 GS
For each digital axis:
!High performance closed loop regulation with or without insensibility
zone.
!Counting frequency: 250 KHz
!Displacement speed, acceleration, deceleration, regulation gain, PID,
safeties and limit switches programmable numerically in the machine
parameters.
!Automatic initialization procedure.
Memorization of the axes positions in the case of a power failure.
Corrections per product and per sequence.
RS232 series interface integrated in the DNC for "ON LINE" link with IBM-
PC / AT / PS2.

DESCRIPTION OF THE DNC 60 PAGE 7
PHYSICAL AND LOGICAL ORGANIZATION
The following diagram is a schematic representation of the physical and logical organization of the
DNC 60:
Screen Keyboard RS232
interface
Microprocessors, memory
PCBs
Auxiliairy
functions
Axes command and
surveillance
Motors
encoders

PAGE 8 USER GUIDE DNC 60 GS
THE MEMORIES
The different memories of the DNC 70 may be represented schematically as
follows:
RAM
+
battery
ROM
Program
Work memory
Internal non volatile memory
Products, production,
machineparameters,
axes position
The DNC 60 is equipped as standard with a ROM memory containing the
DNC 60 program and a RAM memory which allows the programming and
storing of products and machine parameters. The RAM is divided into several
zones each having a different use.
WORK MEMORY (BUFFER MEMORY)
This is a static RAM used for programming, modifying and executing
products.
It is a temporary memory whose contents are deleted whenever another
product is called for.
The contents of this memory is conserved if the DNC power supply is cut,
even if it has not been previously stored in the internal memory.
DNC INTERNAL MEMORY
This fixed internal memory, of the static RAM type maintained by a lithium
battery, contains the products, axes positions, numbers concerning the
production and machine parameters.
No programming or modification are done directly in this memory.

DESCRIPTION OF THE DNC 60 PAGE 9
THE USER INTERFACE
THE SCREEN
The screen displays the products, and machine parameters as well as all other
useful information for programming and machine work.
The keys situated on the front of the DNC 60, are used for selecting the
screen pages and introducing data.
A cursor indicates where the user can intervene.
THE KEYBOARD
The keyboard is divided into several zones:
a) Numerical keyboard
b) Screen page selection keys
c) Working mode selection keys
d) The commands
e) The cursor keys
f) Other keys
a) Numerical keyboard:
The numerical keys as well as the and keys are used to introduce
numbers or values into the different fields.
b) The screen page selection keys:
MENU key
Gives access to the MAIN MENU page.
PRODUCT LIST key
Pressing this key displays the list of products in
the DNC memory.
PRODUCT key
Visualization of the product data (sequence 0)
and shear functions.
SEQUENCE key
Triple function key.
Pressing the key once displays all the values of
the current sequence.
Pressing a second time displays the main values
of the sequences and axes in large characters.
Pressing a third time displays the main values
of the sequence with the secondary values of
the axes in large characters.

PAGE 10 USER GUIDE DNC 60 GS
CORRECTION key
This key displays the correction page which
allows to make corrections to the current
sequence, as well as to the entire product.
c) The working modes
PROGRAMMING mode
Allows to introduce, modify and read data as
well as to store, search for and transfer
programs.
MANUAL mode
Authorizes axis movement and auxiliary
functions using the
keys.
SEMI-AUTOMATIC mode
Allows a machine cycle with the current
sequence values without automatic sequence
change.
This mode is used for adjustments when
realizing the first product, as well as for
products with only one cut.
The sequence change is made using the
keys.
NB: The product counter Q does not function
in this mode.
AUTOMATIC mode
Normal mode for product production.
The DNC automatically changes sequence after
each cut.
Changing directly from "programming" mode
automatically forces the first sequence of the
program.
Changing from "programming" mode to "semi-
automatic" mode and then to "automatic"
mode, conserves the current sequence for
execution.
This allows to take up again a product in
production without having to make "empty"
cycles.

DESCRIPTION OF THE DNC 60 PAGE 11
d) The commands
DELETE key
Allows to delete a sequence or a program when
the cursor is placed on the PRODUCT or N
fields.
Only functions in PROGRAMMING mode.
CLEAR key
This key allows to delete data indicated by the
cursor.
Pressing this key twice, on most pages, deletes
all the data on the page.
SEARCH key
According to the cursor position allows:
- to search for a product
- to search for a sequence
- to search for a screen page
- to execute a transfer
Only functions in PROGRAMMING mode.
STORE (memorization) key
Depending on the cursor position, allows to
store the current program in the DNC internal
memory, or create (insert) a new sequence in
the middle of an existing program, or copy
(teach) the value of an axis positioned manually
in the current sequence.
This key is only valid in programming
(memorization and insertion) mode and in
manual (teach) mode.

PAGE 12 USER GUIDE DNC 60 GS
e) The cursor keys
SEQUENCE FORWARDS / PAGE
FORWARDS key
This key allows to scroll pages of the same type.
Also allows to pass to the next page when a
series of information occupies several pages.
Eg.: !program sequence
!production pages
!parameter pages
In PROGRAMMING mode also allows to
create an identical sequence (copy function) to
the previous one as long as this is the last
sequence of the program.
The incorporated LED indicates whether the
sequence is the last of the program.
PAGE BACKWARDS key
Allows to scroll backwards through pages of
the same type.
Functions in all modes except automatic mode.
Cursor upwards, to the next accessible field.
Cursor downwards, to next accessible field.
f) Other keys
START key
Commands:
!The displacement of the axis and auxiliary
functions.
During movement the LED lights up.
!An indexation (on option depending on the
configuration) on digital axes when this key
is first pressed after switching on the DNC.
To indicate that an index is being taken the
LED remains constantly alight, until the
indexes are received. Indexes can only be taken
in or modes.
STOP key
This key stops, depending on the working
mode chosen, the axes or auxiliary functions in
movement
The "Stop" LED will remain alight until we
press it a second time.
NB: No axes (or auxiliary function) movement
will be authorized unless the stop LED is off.
In this group, you will find as well all the dis-
placement keys connected to the "MANUAL"
mode.
