1 CYB-KLED CyberSuite Installation Manual
INTRODUCTION
This document details the wiring configuration of the CyberSuite
condominium control keypad and installer programming functions.
Hardware Compatibility
This manual is written for hardware verison 208-4125-020 or
higher and covers firmware application 1.00. This firmware
communicates with a CyberSuite enabled Protégé System
Controller firmware version 1.06 or above.

2
CYB-KLED CyberSuite Installation Manual
WIRING CONFIGURATION
Introduction
The wiring structure of the CyberSuite keypad uses an encrypted
RS485 communication interface. Connections should be made in a
daisy chain configuration, avoiding star and stub connections.
Figure 1 - Condominium Keypad Communication
Keypad Wire Loom Colour Coding
The condominium keypads are supplied with a wire loom attachment
and are connected using a keyed 10 position snap lock connector.
The 10 way wiring loom connection uses the following colour coding.
Figure 2 - Wire Loom Colour Coding and Function

3 CYB-KLED CyberSuite Installation Manual
Communication Connection
Support for up to 250 keypads per condominium controller is
provided, connection to the system controller uses the network
communication RS-485 interface. This interface is an isolated
interface and requires power to be supplied to the N+ and N-
terminals.
Figure 3 - Wire Loom Colour Coding and Function
When using more than one PSU to supply multiple wiring runs
of condominium keypads only connect the +12 output of ONE
power supply unit to the N+ and N- terminals of the
controller. Each PSU unit should have the common (0V or -)
connected together to ensure a common 0V.

4
CYB-KLED CyberSuite Installation Manual
Zone Input Wiring
The CyberSuite LED Keypad is capable of connecting to 4 zone
inputs, each zone input can then be programmed to perform the
required function in the system.
The following diagrams show each of the zone wiring configuration
settings that are possible. The programmed zone configuration for
the CyberSuite LED Keypad is made in the option settings. Refer to
the General Options Section on Page 17 for the programming of the
zone configuration.
When using a tamper input on a device the tamper contacts
must be normally closed and wired in series.
All resistors required to wire the zone configurations are
provided with the CyberSuite LED Keypad in the accessory
bag.
Figure 4 - 2 Zone Input (No Resistors)
Figure 5 - 2 Zone Input (1K and 1K)

5 CYB-KLED CyberSuite Installation Manual
Figure 6 - 4 Zone Input Duplex Mode (1K and 2K4)
Fire Zone Input Wiring
When wiring a zone to be a fire zone input the current programmed
zone options will determine what resistors and configuration is
required, refer to the General Options Section on Page 17 and the
zone configuration diagrams in the Zone Input Wiring Configuration
on Page 4.
Figure 7 - Fire/Smoke Detection Input
When a fire zone is connected to a zone input that is used in
the duplex zone configuration a fire zone fault will NOT BE
shown when the fire zone has a shorted condition as this is
shown as all zones closed. A Fire Loop trouble will be shown
when the zone is tampered.
Fire zones that are installed in duplex mode operation are not
recommended. Fire zones should ALWAYS be connected using
the EOL resistor method (2R) as this provides both open and
short circuit monitoring.

6
CYB-KLED CyberSuite Installation Manual
Slave Keypad Zone Wiring
With one or more slave keypads connected, extra zones beyond the
normal 4 are available on the suite system.
There are 2 options for wiring the zones:
-Duplex mode enabled, 8 zones in total available. This setup
is shown in Error! Reference source not found..
-Standard wiring mode, 6 zones in total available. This setup
is shown in Figure 9.
The choice between the two wiring options will be dependent on the
physical configuration of the sensors and wiring in each installation.
See General Options on page 17 for enabling duplex zones.
Figure 8 - Slave Keypad Duplex Zone Wiring

7 CYB-KLED CyberSuite Installation Manual
Figure 9 - Slave Keypad Standard Zone Wiring
PGM (Programmable Output)
The CyberSuite LED Keypad uses a programmable output (PGM) that
will activate during an alarm condition. This output can be
programmed to either:
-Follow the status of the alarm siren time or the fire alarm setting
-Follow the armed / disarmed status of the keypad.
Connect a relay or other interface device to this open collector output
for activation of ancillary devices. The behaviour of this output can
also be inverted in the programming, see the General Options section
0 for details on PGM programming.
Figure 10 - LED Indicator Output

8
CYB-KLED CyberSuite Installation Manual
Slave Reader Network
The CyberSuite LED Keypad is capable of controlling a slave network of
up to 8 proximity card reader devices from the following range:
-PRX-NANO Nano Prox Small Form Factor Proximity Card Reader
-PRX-VARIO Vario Prox Flush Mount Proximity Card Reader
Each slave reader device communicates with the keypad via a PRX-SAM
Standalone Module Board. This module also allows control of an
electronic lock device with the onboard relay.
Figure 11 - Slave Reader Network Wiring To SAM
Module
For further information regarding wiring of the Reader device and the
Stand Alone Modules, please refer to the PRX-SAM Stand Alone
Module Installation Manual, provided with your SAM board or from
www.integratedcontroltechnology.com.

9 CYB-KLED CyberSuite Installation Manual
Slave Keypad Network
The CyberSuite LED Keypad is capable of controlling a slave network
of up to 4 other CyberSuite Keypads in Slave Mode (see Device
Options for configuration).
Each slave reader device communicates with the keypad via
connection of their primary network lines to the secondary network
lines of the master keypad, as shown below. Note that the Slave
Reader Network Enabled option must be OFF to allow use of the
slave keypad network.
Figure 12 – Slave Keypad Wiring to Master Keypad

10
CYB-KLED CyberSuite Installation Manual
Indicator Lights
The CyberSuite™ LED keypad features three status indicator lights showing
the condition of the CyberSuite™ Security System.
Bypass Power/Trouble
Install Ready Indicator
Message Armed/Alarm
Figure 13 - Indicator Lights
Binary Number Display
The CyberSuite™ LED keypad displays programming information such as
timers and addresses using the 8 Zone LED’s. The Zone LED’s will be lit in
binary mode, meaning that you must add the place value of each LED
together to obtain the programmed value. The place values are shown in
the table below:
ZONE LED VALUE
Zone 1 128
Zone 2 64
Zone 3 32
Zone 4 16
Zone 5 8
Zone 6 4
Zone 7 2
Zone 8 1
Binary Number Display Example
64 + 2 + 1 = 67

11 CYB-KLED CyberSuite Installation Manual
DEVICE CONFIGURATION
Device Configuration Mode Access
Before the CyberSuite LED Keypad module will communicate it must
be assigned an address and programmed with specific options as to
how it will operate. This is achieved by accessing the device
configuration menu.
The device configuration menu can only be accessed in the
FIRST 2 SECONDS when the device powers up. It is not able
to be accessed when the system is operational.
To gain access to the device configuration menu, apply power to the
device, and within the first 2 seconds after the four beep tone is
heard, press the [CLEAR] key, followed by the [ENTER] key.
The INSTALL LED will then be lit to notify that device configuration
mode has been entered. You can then press the key corresponding to
the menu required from the following list.
Address Selection ([MENU] , [1])
The address selection sets the address of the CyberSuite LED
Keypad, this address must be a unique address on the system from 1
to 250.
Enter the address with the following keypress sequence:
[MENU] , [1] , [ADDRESS 1] , [ADDRESS 2], [ADDRESS 3], [ENTER]
The address will now be displayed on the zone LED’s in binary form once
all 3 digits have been entered.
ALL 3 Digits MUST be entered when programming an address.
This means that for addresses below 100, you must enter [0]
then the 2 digits of the address. For addresses below 10, you
must enter [0] , [0] followed by the address digit.

12
CYB-KLED CyberSuite Installation Manual
Device Options ([MENU] , [2])
The device options set options that relate to the mode of operation of
the CyberSuite keypad.
To enter the Device Options Menu, press
[MENU] , [2]
To toggle options press the keys [1] to [8] , and the corresponding
Zone LED will be lit when that option is ENABLED.
Pressing the [ENTER] key will save the options.
Option 1 – Slave Keypad
If this option is used, be sure to address the keypad as
slave 1,2,3 or 4.
5Enabled Slave mode is entered on start up
6Disabled Master mode is entered on start up
Option 2 to 8 – Reserved
Device Default ([MENU] , [3])
To default all the Device Options, press
[MENU] , [3]
The ARMED LED will now flash, and you must press [ENTER] to
confirm or [MENU] to cancel.
Exiting Device Configuration Mode
Once Device configuration is complete, press the [CLEAR] key to restart
the keypad.
If you do not press any key for 45 seconds while in Device
Configuration mode, the keypad will automatically restart.

13 CYB-KLED CyberSuite Installation Manual
LOCAL INSTALLER LOGIN
Introduction
The default local installer code is [0000]. To access the local
installation menu, press:
[ENTER] , [0000]
The INSTALL LED will then be lit to notify that Installer mode has
been entered.
One Zone LED will be lit to show you which selection from the
current menu you are currently at. You can change your selection
with the [Ï] and [Ð] keys and then press [ENTER] to access that
menu item, or just press the number key corresponding to the
menu item you wish to select.
The following pages will outline the menu selections available, along
with their shortcut keys.
Notes on Installer Access
If a module update has been performed on the system controller and
the user code at system controller user location 3 (UN00003) has
been changed. The code that is entered in this setting is now the
local installer code. This code is programmed system wide when an
update is performed.
To disable the Installer Code on ALL CyberSuite keypads
(Recommended) delete the code for User UN00003 by following the
instructions in the CyberSuite System Reference Manual for deleting
a user pin code.
You can not access the installer menu if the CyberSuite system is
armed. Disarm the CyberSuite system before attempting to login
with the installer code.
It is recommended that all installer modifications are completed and
downloaded using the Protege System Management Suite (PRT-
SMGT). Ensure a module update command is executed when
modifications are being made.

14
CYB-KLED CyberSuite Installation Manual
TIMING (MENU 1)
ALL 3 Digits of the timer value MUST be entered when
programming a timer. This means that for addresses below
100, you must enter [0] then the 2 digits of the address. For
addresses below 10, you must enter [0] , [0] followed by the
address digit.
Entry Delay Timer ([MENU] [1], [1])
The entry delay timer is programmable from 000 to 255 seconds
(Default 30 Seconds).
To program the timer value, press
[MENU] , [1] , [1] , [TIM 1], [TIM 2] , [TIM 3] , [ENTER]
Where TIM 1 ~ 3 are the timer value digits, entered using the 0 to 9
number keys.
Programming the entry delay timer to 0 will result in no entry delay
operation for any zone that has been assigned the entry delay zone
type.
Exit Delay Timer ([MENU] , [1] , [2])
The exit timer is programmable from 000 to 255 seconds (Default 30
Seconds).
To program the timer value, press
[MENU] , [1] , [2] , [TIM 1], [TIM 2] , [TIM 3] , [ENTER]
Where TIM 1 ~ 3 are the timer value digits, entered using the 0 to 9
number keys.
Programming the exit delay timer to 0 will result in no exit delay, the
system will immediately arm the CyberSuite System.

15 CYB-KLED CyberSuite Installation Manual
Alarm/Siren ([MENU] , [1] , [3])
The siren/alarm timer is programmed from 000 to 250 minutes
(Default 4 minutes).
To program the timer value, press
[MENU] , [1] , [3] , [TIM 1], [TIM 2] , [TIM 3] , [ENTER]
Where TIM 1 ~ 3 are the timer value digits, entered using the 0 to 9
number keys.

16
CYB-KLED CyberSuite Installation Manual
Reader Pre-Alarm Timer ([MENU] , [1] , [4])
The Reader Pre-Alarm Timer is programmable from 0 to 255 seconds
(Default 30 Seconds). This is only used when the Reader Slave
Network is enabled.
To program the timer value, press
[MENU] , [1] , [4] , [TIM 1], [TIM 2] , [TIM 3] , [ENTER]
Where TIM 1 ~ 3 are the timer value digits, entered using the 0 to 9
number keys.
The minimum Pre-Alarm Time is 5 seconds, any number lower than 5
seconds entered will be automatically increased to 5 seconds to
ensure correct reader operation.
Reader Left Open Timer ([MENU] , [1] , [5])
The Reader Left Open Timer is programmable from 0 to 255 seconds
(Default 45 Seconds). This is only used when the Reader Slave
Network is enabled.
To program the timer value, press
[MENU] , [1] , [5] , [TIM 1], [TIM 2] , [TIM 3] , [ENTER]
Where TIM 1 ~ 3 are the timer value digits, entered using the 0 to 9
number keys.
The minimum Left Open Time is 5 seconds, any number lower than 5
seconds entered will be automatically increased to 5 seconds to
ensure correct reader operation.

17 CYB-KLED CyberSuite Installation Manual
OPTIONS (MENU 2)
General Options ([MENU] , [2] , [1])
The general options set options that relate to the general operation
of the CyberSuite keypad.
To enter the General Options Menu, press
[MENU] , [2] , [1]
To toggle options press the keys [1] to [8] , and the corresponding
Zone LED will be lit when that option is ENABLED.
Pressing the [ENTER] key will save the options.
Option 1 - Zone Type Option 1
If duplex zone (Option 2) is not enabled then Option 1
will set the zone input configuration (EOL or NO EOL).
EOL requires the use of 2 X 1K resistors to provide,
Short, Alarm, Closed and Tamper Monitoring. NO EOL
provides Alarm and Closed monitoring.
5Enabled EOL resistors are used (2R Mode) (2 Zones).
6Disabled NO EOL resistors are used (2 Zones).
Option 2 - Duplex Zone Operation
If Option 2 is set Option 1 does not have any function.
When option 2 is set the zones will use a 1K and 2K4
resistor and provide monitoring for 2 zones.
5Enabled Duplex Zone Mode (4 Zones).
6Disabled Option 1 sets the zone configuration.
Option 3 - Beep On Trouble Condition
5Enabled the beeper will emit 4 beeps every 5 minutes
if a trouble condition is present, to silence the trouble
beep, view the trouble condition.
