CyberData 011211 series Manual

Quick Reference 930502E © 2013, CyberData Corporation, ALL RIGHTS RESERVED© 2013, CyberData Corporation, ALL RIGHTS RESERVED 930502E Quick Reference
Wall Mounting Options
Gang Box Mounting Options
Screw Wall Cutout
on Wall
Pre Drill Holes
121001A
Backplate
Accessory
Kit
to J1
Cable
Network
Rotate Backplate 180°
to use Top Cable Entry
Entry
Cable
Top
Slot
Entry
Cable
Top
Gang Box Mounting Screw (4x)
Wall Cutout
Wall Cutout
or Two Gang Box
Backplate accepts
Single Gang Box
Single Gang Box use two
Backplate 121002B
Kit
Accessory
Screw
Slot
Entry
Entry
Cable
Cable
Top
Top
Getting Started
• Download the VoIP V3 Indoor Intercom Operations Guide PDF file from the following web page:
http://www.cyberdata.net/products/voip/digitalanalog/intercomindoorv3/docs.html
• Create a plan for the locations of your Intercoms.
• Prior to installation, consult local building and electrical code requirements.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
Contacting CyberData
Parameter Factory Default Setting
IP Addressing DHCP
IP Addressa10.10.10.10
Web Access Username admin
Web Access Password admin
Subnet Maska255.0.0.0
Default Gatewaya10.0.0.1
a. Default if there is not a DHCP server present.
(4) Plastic Ribbed Anchor (4) #6-32 FlatHead Countersunk
Machine Screw
(1) Wall Mounting Kit(1) Intercom Assembly (1) Gang Box Mounting Kit
(4) Sheet Metal Screw
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Web: http://www.cyberdata.net/support/contactsupportvoip.php
RMA Dept: [phone] ext. 136
Email: [email protected]
RMA Status: http://www.cyberdata.net/support/rmastatus.html
Warranty information is available at:
Web: http://www.cyberdata.net/support/warranty/index.html
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
www.CyberData.net
The IP Endpoint Company
Installation Quick Reference
VoIP V3 Indoor Intercom
SIP Compliant
011211*, RAL 9003, Signal White
*Replaces the 011111 number.

© 2013, CyberData Corporation, ALL RIGHTS RESERVED 930502E Quick Reference Quick Reference 930502E © 2013, CyberData Corporation, ALL RIGHTS RESERVED
RTFM Button
Dimensions
Maximum Recommended Wall Cutout Dimensions
SW1
When the device is operational and linked to a network, you can
use the Reset Test Function Management (RTFM) button (SW1
[see picture]) to announce the device’s IP address or restore the
device to the factory
default settings.
To announce the device’s current IP address:
• Press and release the RTFM button within a five second
window.
Note The device will use DHCP to obtain the new IP
address (DHCP-assigned address or default to
10.10.10.10 if a DHCP server is not present).
To restore the device to factory default settings:
• Press and hold the RTFM button for longer than five
seconds until you hear the device announce that it is
restoring the factory default settings.
4.53 [115.0]
4.53 [115.0]
2.22 [56.3]
DIMENSIONS ARE IN INCHES [MILLIMETER]
Dimensions are in Inches [Millimeter]
Wall Cutout
0.25[6.4]
0.25[6.4]
0.25[6.4]
0.25[6.4]
Top Cable Entry Closed
Top Cable Entry Opening
Cable Connections
Terminal Block Connections
to J2
021078D
Speaker to J7
Back Plate
Push-Button
to J6
Microphone
PCBA
Mounting
Screws
Mounting
Screws
PCBA
J7
J6
J2
J3 Terminal Block
Wire (IN)
Terminal Block
can accept
16 AWG wire
Relay Contact:
(1A at 30 VDC for continuous loads)
3 = Normally Open Common
4 = Normally Open Contact
5 = Door Sense Input
6 = Door Sense Ground Reference
2 = Power Ground*
1 = +12 to 24 VDC at 1000 mA (500 mA minimum)*
34
Alternate Power Input:
*Contacts 1 and 2 on the J3 terminal block are only for
powering the Intercom from a non-PoE +12VDC power
source as an alternative to Network PoE power. Use of
these contacts for any other purpose will damage the
Intercom and void the product warranty.
1
6
