Installation Quick Reference
VoIP Remote Call Button
011184, RAL 9002, Gray White, Standard
011185, RAL 9003, Signal White, Optional
Mounting Options—Metal Bracket
Mounting Options—Plastic Bracket
Contacting CyberData
Wall Plate Mounting Bracket (Metal)
Tools Required: Wall board saw, Pliers
Instructions:
1. Use the inside area of the bracket to trace the hole
cut onto the wall.
2. Using a wall board saw or matt knife, cut along the
stencil line.
3. Place bracket against the wall opening.
4. Bend tabs up and down against the inside wall to
secure the bracket.
5. Place the optional gasket over the metal bracket.
6. Mount the flush mount wall plate to the bracket.
To be installed and or used in accordance with the
appropriate electrical codes and regulations.
Optional
Gasket
Mounting
Screw (2x)
Remote Call
Button Assembly
One-Gang
Low Voltage
Mounting Bracket
(Metal)
Wall Opening
Bend tabs up and
down against
inside wall to
secure bracket.
To be installed and or used in accordance with the
appropriate electrical codes and regulations.
Wall Plate Mounting Bracket (Plastic)
Tools Required: Wall board saw, Philips screwdriver
Instructions:
1. Use the inside area of the bracket to trace the hole
cut onto the wall.
2. Using a wall board saw or matt knife, cut along the
stencil line.
3. Place bracket through the wall opening.
4. Tighten screws to pull Flagnuts against the inside
wall to secure the bracket.
5. Place the optional gasket over the plastic bracket.
6. Mount the flush mount wall plate to the bracket.
Optional
Gasket
Mounting
Screw (2x)
Remote Call
Button Assembly
One-Gang
Low Voltage
Mounting Bracket
(Plastic)
Wall Opening
Tighten screws to
pull Flagnuts against
inside wall to secure
bracket.
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Web: http://www.cyberdata.net/support/contactsupportvoip.html
RMA Dept: [phone] ext. 136
Email: [e-mail]
RMA Status: http://www.cyberdata.net/support/rmastatus.html
Warranty information is available at:
Web: http://www.cyberdata.net/support/warranty/index.html
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
www.CyberData.net
Typical Call Button System Installation
Getting Started
• Create a plan for the locations of your Call Buttons.
• Prior to installation, consult local building and electrical code requirements.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
As an option to the CyberData V2 speaker, the V2 Remote Call Button enables calls to the V2 Speaker that
can be initiated or answered from a remotely-mounted switch.
When enabled through the Web interface, if the Remote Call Button is pressed, the speaker would initiate a
SIP call to a predetermined extension.
When the V2 Speaker is called from a remote phone and Auto-Answer is not enabled within the unit’s Web
interface, the LED on the Remote Button will blink. The call will be answered when the button is pressed.
802.3af Compliant Ethernet Hub
IP Phone IP PBX Server
12 34 56
Remote Call Button Speaker
(1) Call Button Assembly
(1) Optional Gasket
(1) Optional One-Gang, Low Voltage,
Mounting Bracket (Metal)
(1) Optional One-Gang, Low Voltage,
Mounting Bracket (Plastic)
(1) Wall Mounting Kit
(2) Mounting screws
Optional Parts (Not Included) (1) Optional One-Gang
Box (Metal)
(1) Optional One-Gang
Box (Plastic)
