CyberData 011490 Manual

Quick Reference 931658C © 2021, CyberData Corporation, ALL RIGHTS RESERVED© 2021, CyberData Corporation, ALL RIGHTS RESERVED 931658C Quick Reference
Parts List • (1) Outdoor Auxiliary RGB (Multi-Color) Strobe Kit
• (1) 3.28 feet [1 meter] cable
Features • Meets ADA requirements for telephony signaling and notification
• Activates from a CyberData IP endpoint
• Mailbox Message Waiting Indication
• Multicast activation
Getting Started
• Download the Operations Guide PDF file, from the Downloads tab at the following
webpage:
https://www.cyberdata.net/products/011490
• Create a plan for the locations of your Outdoor Auxiliary RGB (Multi-Color) Strobe Kits.
• WARNING: This product should be installed by a licensed electrician according to all local
electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
Contacting CyberData
Optional Accessories
(for gooseneck mounting)
(4) Carriage bolts
(4) Carriage bolt nuts
(4) Carriage bolt washers
(1) Hole plug assembly
Accessory Kit
(4) Security Torx Screws
(1) T-15H Torx Key
(4) Phillips Screws
Sales: 831-373-2601 ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department Contact and Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
http://www.cyberdata.net/
The IP Endpoint Company
Installation Quick Reference
Outdoor Auxiliary RGB
(Multi-Color) Strobe Kit
011490
Dimensions and Rear View with Mounting Holes
5.122 [130]
2.76 [70]
5.2 [132]
Ø0.280 [Ø7.11]
Mounting Hole
(4 Places)
1/2" Conduit Hole
Ø0.854 [Ø21.69]
Dimensions are in Inches [Millimeter]
1.690 [42.93]
3.380 [85.85]
1.690 [42.93]
All manuals and user guides at all-guides.com

© 2021, CyberData Corporation, ALL RIGHTS RESERVED 931658C Quick Reference Quick Reference 931658C © 2021, CyberData Corporation, ALL RIGHTS RESERVED
Loudspeaker Amplifier Connections
Strobe Cable Connection
Remove Hole Plug
and Grommet
Cover
Plate
Slide I2C Cable Grommet
into Cover Plate Slot
Cover
Screw
to
STROBE IN
Keep Washer that
Came with the
1/2" EMT Compression Connector
Remove Hole Plug Assembly then
Install It onto Rear Conduit Hole
1/2" EMT Compression Connector
Remove Cord Grip Assembly
then Replace with
1/2" EMT Compression Connector 1/2" EMT Compression Connector
Lock
Washer
1/2" EMT Conduit
Lock
Washer
to J1 J1
Cable & Wire
Create Service Loop
Backbox Ground
(Optional)
(Faceplate Ground)
Gasket
with IP66 Rating Enclosure
RGB Strobe
Outdoor Auxiliary
Optional Conduit Wall Mounting (Outdoor Intercom or Outdoor Call Button)
Faceplate
Assembly
Torx Security Screw
Faceplate Mounting
Wall Anchor & Screw
1/4" Concrete
Hole Plug
Assembly
Conduit
Backbox
Auxiliary
Outdoor
to Ground Stud
Ground Wires
Through Rear Conduit Hole
Network and Ground Wires in
Spacer
Compression
Connector
Backbox
Torx Key
Outdoor
Call Button
Torx Security Screw
Faceplate Mounting
Ground Wire
I2C Cable
Network Cable
Spacer
1/2" EMT 1/2" EMT
Compression
Connector
1/2" EMT
on Faceplate
to Ground Stud
RGB Strobe
on Faceplate
to Ground Stud
Outdoor
Intercom
OR
to Remove Hex Nut:
11/32" or 9mm
Open-End Wrench
or Socket
to J1
Network Cable
to JX
I2C
to JX
I2C
Speaker Stud
Ground Wire to
I2C
to JX
Network Cable
to J1
Ground Wire
Apply RTV
Silicone Sealant
Around Mounting Holes
Apply RTV
Silicone Sealant
Around Backside Perimeter
Note: All parts shown are not provided
other than the 011490 Strobe Kit.
All manuals and user guides at all-guides.com
