CyberPower AVR Series User manual

DETERMINE THE POWER
REQUIREMENTS OF YOUR EQUIPMENT
1. Ensure that the equipment plugged into the
UPS does not exceed the UPS unit’s rated
capacity (750VA/450W for AVRG750U
and 900VA/480W for AVRG900U). If the
rated capacities of the unit are exceeded,
an overload condition may occur and cause
the UPS unit to shut down or the circuit
breaker to trip.
2. There are many factors that can aect
the amount of power that your electronic
equipment will require. For optimal system
performance keep the load below 80% of
the unit’s rated capacity.
HARDWARE INSTALLATION GUIDE
1. Your new UPS may be used immediately
upon receipt. However, after receiving a
new UPS, to ensure the battery’s maximum
charge capacity, it is recommended that
you charge the battery for at least 8 hours.
Your UPS is equipped with an auto charge
feature. When the UPS is plugged into an
AC outlet, the battery will automatically
charge whether the UPS is turned on or
turned o.
2. With the UPS unit turned o and un-
plugged, connect your computer, monitor,
and any other peripherals requiring battery
backup into the battery power supplied
outlets. Plug the other peripheral equip-
ment (e.g., printer, scanner, speakers, etc.)
into the full time surge protection outlets.
DO NOT plug a laser printer, paper shred-
der, copier, space heater, vacuum cleaner,
sump pump or other large electrical device
into the “Battery and Surge Protected Out-
lets”. The power demands of these devices
will overload and possibly damage the unit.
3. To protect a fax, phone, or modem line,
connect a telephone cable from the wall
jack outlet to the IN jack
of the UPS. Connect a
telephone cable from one
of the UPS OUT jacks to
the modem port on the
computer. The other UPS
OUT jack can be used to
protect a telephone or fax
machine.
4. Plug the UPS into a 2-pole, 3-wire ground-
ed receptacle (wall outlet). Make sure the
wall branch outlet is protected by a fuse or
circuit breaker and does not service equip-
ment with large electrical demands (e.g.
air conditioner, refrigerator, copier, etc.).
The warranty prohibits the use of extension
cords, outlet strips, and surge strips in con-
junction with the UPS unit.
5. Press the power switch to turn the unit on.
The Power On indicator light will illuminate
green and the unit will emit one long and
one short “beep”.
6. If an overload is detected, an audible alarm
will sound and the unit will emit one long
beep. To correct this, turn the UPS o and
unplug at least one piece of equipment
from the battery power supplied outlets.
Make sure the circuit breaker is depressed
and then turn the UPS on.
7. To maintain optimal battery charge, leave the
UPS plugged into an AC outlet at all times.
8. To store the UPS for an extended period
of time, cover it and store with the battery
fully charged. While in storage, recharge
the battery every three months to ensure
optimal battery life.
9. Ensure the wall outlet and UPS are locat-
ed near the equipment being attached for
proper accessibility.
YOUR ULTIMATE ALLY IN POWER
Cyber Power Systems (USA), Inc.
4241 12th Avenue East, Suite 400 | Shakopee, MN 55379 | CyberPowerSystems.com
AVR UPS SERIES
AVRG750U / AVRG900U
USER MANUAL
FEATURES
1. Battery and Surge Protected Outlets
2. Full-Time Surge Protection Outlets
3. Power Switch
4. Power On Indicator
5. Mute Button
6. Fault Indicator
7. USB Port
8. Communication Protection Ports
9. Circuit Breaker
10. Ground Screw
11. Widely-Spaced Outlets
Thank you for purchasing a CyberPower product. This UPS is designed to provide unsurpassed
power protection, operation, and performance during the lifetime of the product. Please take a
few minutes to register your product at: www.CyberPowerSystems.com/registration.
Registration certifies your product’s warranty, confirms your ownership in the event of a product
loss or theft, and entitles you to free technical support. Register your product now to receive the
benefits of CyberPower ownership.
CAUTION! To prevent the risk of fire or
electric shock, install in a temperature and
humidity controlled indoor area free of
conductive contaminants. (Please see
specifications for acceptable temperature
and humidity range).
CAUTION! To reduce the risk of electric shock,
do not remove the cover except to service the
battery. Turn o and unplug the unit before
servicing the batteries. There are no user-ser-
viceable parts inside except for the battery.
CAUTION! Hazardous live parts inside can be
energized by the battery even when the AC
input power is disconnected.
CAUTION! The UPS must be connected to an
AC power outlet with fuse or circuit breaker
protection. Do not plug into an outlet that is
not grounded. If you need to de-energize this
equipment, turn o and unplug the unit.
CAUTION! To avoid electric shock, turn o the
unit and unplug it from the AC power source
before installing a computer component.
CAUTION! To reduce the risk of fire, connect
only to a circuit provided with 20 amperes
maximum branch circuit over current protec-
tion in accordance with the National Electric
Code, ANSI/NFPA 70.
CAUTION! Not for use in a computer room as
defined in the Standard for the Protection of
Electronic Computer / Data Processing Equip-
ment, ANSI/NFPA 75.
CAUTION! Do not dispose of batteries in a fire.
The batteries may explode.
CAUTION! Do not open or mutilate batteries.
Released electrolyte is harmful to the skin and
eyes. It may be toxic.
DO NOT USE FOR MEDICAL
OR LIFE SUPPORT EQUIPMENT!
CyberPower Systems does not sell products
for life support or medical applications. DO
NOT use in any circumstance that would aect
operation and safety of life support equip-
ment, any medical applications or patient care.
DO NOT USE WITH OR NEAR AQUARIUMS!
To reduce the risk of fire or electric shock, do
not use with or near an aquarium. Condensa-
tion from the aquarium can cause the unit to
short out.
DO NOT USE THE UPS
ON ANY TRANSPORTATION!
To reduce the risk of fire or electric shock, do
not use the unit on any transportation such
as airplanes or ships. The eect of shock or
vibration caused during transit and the damp
environment can cause the unit to short out.
PRODUCT REGISTRATION
IMPORTANT SAFETY WARNINGS (SAVE THESE INSTRUCTIONS)
This manual contains important safety instructions. Please read and follow all instructions carefully
during installation and operation of the unit. Read this manual thoroughly before attempting to
unpack, install, or operate your UPS.
INSTALLING YOUR UPS SYSTEM - continued
UNPACKING
Inspect the UPS upon receipt.
The box should contain the following:
(a) UPS unit
(b) User’s manual
(c) USB device cable
PowerPanel® Personal software is
available on our website. Please visit
www.cyberpowersystems.com and go
to the Software Section for a free download.
AUTOMATIC VOLTAGE REGULATOR
The AVRG750U/AVRG900U stabilizes incon-
sistent utility power to nominal levels that are
safe for equipment. Unstable utility power can
be damaging to important data and hardware.
With Automatic Voltage Regulation (AVR),
damaging voltage levels
are corrected to safe
levels. AVR automatical-
ly increases low utility
power or decreases
high utility power to
a consistent and safe
110/120 volts.
BASIC OPERATION
INSTALLING YOUR UPS SYSTEM
1. Battery and Surge Protected Outlets -
The unit has six battery powered and surge
protected outlets to ensure temporary
uninterrupted operation of your equipment
during a power failure. DO NOT plug a laser
printer, paper shredder, copier, space
heater, vacuum cleaner, sump pump or
other large electrical device into the
Battery and Surge Protected Outlets.
The power demands of these devices will
overload and possibly damage the unit.
2. Full-Time Surge Protection Outlets -
The unit has six surge suppression outlets
3. Power Switch - Used as the master on/
o switch for equipment connected to the
battery power supplied outlets.
To turn the UPS ON, press the power
button for approximately 2 seconds - you
will hear a constant tone (1 second) - and
release after a short beep.
To turn the UPS OFF, press the power
button for approximately 2 seconds - you
will hear a constant tone (1 second) - and
release after two short beeps.
4. Power On Indicator - This LED is illuminat-
ed when the utility power is normal and the
UPS outlets are providing power, free of
surges and spikes.
5. Mute Button - Press the button for 2
seconds to enable (beeps once) or disable
(beeps twice) the audible alarm.
6. Fault Indicator - This LED is illuminated if
there is a problem with the UPS.
7. USB Port - The USB port allows connection
and communication between the USB port
on the computer and the UPS unit.
8. Communication Protection Ports -
Communication protection ports will
protect any standard modem, fax , or
telephone line (RJ11)
9. Circuit Breaker - Located on the side of the
UPS, the circuit breaker serves to provide
overload and fault protection.
10. Ground Screw - The ground screw is used
for any equipment that needs a chassis
ground connection.
11. Widely-Spaced Outlets - The UPS unit
has four widely-spaced outlets. AC power
adapters can be plugged into the UPS
without overlapping or blocking adjacent
outlets.
Replacement of batteries located
in an OPERATOR ACCESS AREA
1. When replacing batteries, replace with
the same number of the following battery:
CyberPower / RB1270B for AVRG750U;
RB1290A for AVRG900U
2. CAUTION! Risk of Energy Hazard, 12V,
maximum 9 Ampere hour battery. Before
replacing batteries, remove conductive
jewelry such as chains, wrist watches, and
rings. High energy through conductive
materials could cause severe burns.
3. CAUTION! Do not dispose of batteries in a
fire. The batteries may explode.
4. CAUTION! Do not open or mutilate batter-
ies. Released material is harmful to the skin
and eyes. It may be toxic.
CAUTION - RISK OF EXPLOSION IF BATTERY
IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO LOCAL REGULATIONS
TO REPLACE THE BATTERY
1. Turn o and unplug all connected
equipment.
2. Unplug it from the AC power source.
3. Turn the UPS upside down.
4. Remove the 1 retaining screw.
5. Slide the battery compartment cover
completely o of the unit.
6. Remove the battery from the compartment.
7. Disconnect the battery wires from the battery.
continued next page
REPLACING THE BATTERY
2
3 4
12
3 5
46
11
7810
9
11
11
11

8. Install the replacement battery by
connecting the red wire and black wire to
the positive (+) and negative (-) terminal of
the battery.
9. Put the battery back into the compartment.
10. Slide back the battery compartment cover
and tighten the retaining screw.
11. Charge the unit for 8 hours to fully charge
the battery.
REMINDER:
Batteries are considered HAZARDOUS
WASTE and must be disposed of properly.
Most retailers that sell lead acid batteries
collect used batteries for recycling, as
required by local regulations
SYSTEM FUNCTION BLOCK DIAGRAM
TROUBLESHOOTING - continued
Problem Possible Cause Solution
Full-time surge protection
outlets stop providing power
to equipment. Circuit breaker
button is projecting from the side
of the unit.
Circuit breaker has been tripped
due to an overload.
Turn the UPS o and unplug at
least one piece of equipment.
Wait 10 seconds, reset the circuit
breaker by pressing the button,
and then turn the UPS on.
The UPS does not perform
expected runtime.
Battery not fully charged. Recharge the battery by leaving
the UPS plugged in.
Battery is worn out.
Contact CyberPower Systems
about replacement batteries at:
cyberpowersystems.com/support.
The UPS will not turn on.
The on/o switch is designed
to prevent damage from rapidly
turning it o and on.
Turn the UPS o. Wait 10 seconds
and then turn the UPS on.
The unit is not connected to an
AC outlet.
The unit must be connected to a
120V 60Hz outlet.
The battery is worn out.
Contact CyberPower Systems
about replacement batteries at:
cyberpowersystems.com/support.
Mechanical problem. Contact CyberPower Systems at:
cyberpowersystems.com/support.
The frequency is outside of the
operating range of 57-63Hz.
Turn the UPS o. Make sure the
frequency range is within 57-63Hz.
Or you can turn the UPS on in
battery mode.
Additional troubleshooting information can be found at “Support” at www.CyberPowerSystems.com
* The Power On LED will flash when UPS alarm is beeping.
POWER
i
FAULT ALARM
CONDITION
On O O Normal
On* O Beep twice
every 30 seconds
Utility Failure - The UPS is providing power to
battery power-supplied outlets from its battery.
On* O Rapid beeping
every 1/2 second
Utility Failure - The UPS is providing battery power. Rapid
beeping indicates the unit will run out of power soon
On/O
Flash once
every 5
seconds
Constant tone
Battery Mode or AC/Utility Power Mode Overload Fault -
Occurs when connected equipment exceeds the rating of
battery outlets of the unit. Please unplug at least one piece
of equipment from battery outlets.
O
Flash once
every 5
seconds
Constant tone
Battery Output Short Fault - Please unplug at least one
piece of equipment from battery outlets and turn on the
UPS again. If the fault still exists, please contact
CyberPower Systems for support.
On
Flash 3
times
every 5
seconds
Constant tone Charger Fault - Contact CyberPower Systems for support.
DEFINITIONS FOR LED INDICATORS & AUDIBLE ALARMS
REPLACING THE BATTERY - continued
TROUBLESHOOTING
Problem Possible Cause Solution
PowerPanel® Personal is inactive
(all icons are gray).
The USB cable is not connected.
Connect the USB cable to the UPS
unit and an open USB port on the
back of the computer.
The USB cable is connected to a
bad USB port.
Check for a dierent USB port and
plug the cable in.
The unit is not providing battery
power.
Shutdown your computer and turn
the UPS o. Wait 10 seconds and
turn the UPS back on. This should
reset the unit.
TECHNICAL SPECIFICATIONS
Model AVRG750U AVRG900U
Capacity 750VA / 450W 900VA / 480W
Nominal Input Voltage 120Vac
Input Frequency 60 Hz ± 3 Hz
On-Battery Output Voltage 120Vac ± 5%
Automatic Voltage Regulator
(AVR) Yes
On-Battery Output Frequency 60Hz +/- 1%
Max. Load for UPS Outlets 750VA / 450W 900VA / 480W
Max. Load for Full-Time Surge
Protection Outlets 12 Amps
On-Battery Output Wave Form Simulated Sine Wave
Operating Temperature + 32°F to 104°F / 0°C to 40°C
Operating Relative Humidity 0 to 90% non-condensing
Size (W x H x D) 12.2” x 7” x 3.5”
Net Weight 13.44 lbs 14.04 lbs
Typical Battery Recharge Time 8 hours typical from total discharge
Typical Battery Life 3 to 6 years, depending on number of discharge/recharge cycles
Recommended Battery Sealed Maintenance-Free Lead Acid Battery
Safety Approvals UL1778(UPS), cUL107., FCC/DoC Class B
Advanced Energy-Saving Patented Bypass Technology
CyberPower’s patented GreenPower UPS™ with Bypass Technology reduces UPS energy costs by up to 75% compared to conventional
UPS models. Even when utility power is normal, conventional UPS models constantly pass power through a transformer. By contrast,
under normal conditions the advanced circuitry of a GreenPower UPS™ bypasses the transformer. As a result, the power eciency is
significantly increased while decreasing waste heat, using less energy, and reducing energy costs. When an abnormal power condition
occurs, the GreenPower UPS™ automatically runs power through its transformer to regulate voltage and provide “safe” power.
Since utility power is normal over 88% of the time, the GreenPower UPS™ operates primarily in its ecient bypass mode. The GreenPower
UPS™ is also manufactured in accordance with the Restriction on Hazardous Substances (RoHS) directive making it one of the most
environmentally-friendly on the market today.
CYBERPOWER GREENPOWER UPS™ TECHNOLOGY
GREEN P
OWER
UPS
™
Energy-Saving Technology
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Canadian Compliance Statement
CAN ICES-3 (B)/NMB-3(B)
FCC COMPLIANCE STATEMENT
Please visit www.CyberPowerSystems.com for a copy of the Limited Warranty and Connected Equipment Guarantee.
Where Can I Get More Information?
The application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded.
CyberPower is the warrantor under this Limited Warranty. For further information please feel free to contact CyberPower at:
Cyber Power Systems (USA), Inc. 4241 12th Ave E., STE 400, Shakopee, MN 55379;
call us at [phone]; or submit a web ticket online at cyberpowersystems.com/support.
Cyber Power Systems (USA), Inc. encourages environmentally sound methods for disposal and recycling of its UPS products.
Please dispose and/or recycle your UPS and batteries in accordance to the local regulations of your state.
WARNING: This product can expose you to chemicals including bisphenol A (BPA) and styrene, which is known to the State of California
to cause reproductive harm and cancer. For more information, go to www.P65Warnings.ca.gov.
LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARANTEE
© 2021 CyberPower Systems (USA), Inc. PowerPanel® Personal is a trademark of Cyber Power Systems(USA) Inc.
All rights reserved. All other trademarks are the property of their respective owners.
6
7 8
5
Input Output
Battery Mode
Normal Mode
EMI
Filter
Surge
Suppressor
Inverter
Charger
AC / DC
Battery
AVR
