CYP CVW-9000W User manual

DRAFT
CVW-9000W
HDMI Multi-Digital Signage TV Wall
Control System
Operation Manual
Operation Manual

DRAFT

DRAFT
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version VR1.0 January 2012
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

DRAFT
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 15/11/12 Preliminary Release
RDV2 24/10/13 Cancel 8x8

DRAFT
CONTENTS
1. Introduction.......................................................... 1
2. Applications......................................................... 1
3. Package Contents .............................................. 1
4. System Requirements.......................................... 1
5. Features................................................................ 2
6. Operation Controls and Functions..................... 3
6.1 UART Controller’s Front Panel........................ 3
6.2 UART Controller’s Rear Panel ........................ 3
6.3 Remote Control.............................................. 4
6.4 Software Installation....................................... 5
6.5 UART Controller’s RS-232 Pin Assignment..... 9
6.6 UART Controller’s RS-232 Commands ........ 10
7. Connection and Installation............................. 11
8. Specications .................................................... 12

DRAFT
1
1. INTRODUCTION
To capture the public’s attention, the HDMI Multi-Digital Signage TV
Wall Control System is ideal for advertising, entertaining and displaying
information. The devices allow users to display HDMI sources to
multiple TV/monitors with multi-screen, while using RS-232 to control
and fully utilized the display screens over a TV wall. This device is
designed to work with an HDMI matrix/splitter which allows sources
to be select and display, video wall control systems that provides
signal arrangement on the display and a mutil-RS-232 control system
to organize and control over all the signal display formats. The HDMI
Multi-Digital Signage TV Wall Control System is the idealist system for
your multi-format digital signage display.
2. APPLICATIONS
• Digital Signage display and control
• Commercial advertising and control
• Show room Display and control
• Public information display and control
• Gaming competition display and control
3. PACKAGE CONTENTS
• 1 x UART Controller
• 1 x 5V/1A Power Adaptor
• HDMI Matrix/Splitter (Optional)
• Video Wall Control Systems CVW-11HS (Optional)
• Remote Control
• Operation Manual
4. SYSTEM REQUIREMENTS
• Input HDMI source equipments such as PS3/DVD/Blu-ray players
(connect from HDMI device)
• D-Sub 9pin RS-232 cables (connected to HDMI device and Video
Wall Control System)
• Output display TV/monitors (connect from HDMI device)

DRAFT
2
5. FEATURES
• Support video wall combinations of HxV: 3x2 and any customized
combination.
• Supports both HDMI and PC input sources from Video Wall Control
System
• Use RS-232 cables to cascade over every connected Video Control
System box to remotely control each monitors with one setting only
• Use RS-232 cables to control over all output image display format
• Supports IR remote control

DRAFT
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 UART Controller’s Front Panel
1 2 3
12345678910 11 12 13 14 15 16 3X3
4X4
IR
UART CONTROLER CVW-9000W
2X2
1
IR:
IR receiver window (accepts the remote control signal of this
device only)
2
1~16 Input LED:
The LED will illuminate accordingly to which port is selected.
3
2x2/3x3/4x4:
This function is not available.
6.2 UART Controller’s Rear Panel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 RS-232 In DC 5V
RS-232 Out
1 2 3
11~16 RS-232 Out:
Connect to RS-232 equipped devices for RS-232 controls. Here it is
to connect to HDMI device (Out 1) and Video Wall Control System
(Out 2).
2RS-232 In:
Connect to a PC/NB with D-Sub 9-pin cable for the transmission of
RS-232 commands with different display mode control.
3DC 5V:
Plug the 5V DC power supply into the unit and connect the
adaptor to an AC outlet.

DRAFT
4
6.3 Remote Control
1POWER:
Press this button to switch ON UART
Controller then the device will also
switch on the connected HDMI
device and VideoWall Control
System.
2POWER OFF:
Press this button to switch OFF UART
Controller and the connected
HDMI device.
3Video Wall Setting:
Press any of these hot keys to
switch the video display format.
4 ▲▼◄►OK:
Press these key inside the menu
function to select the desire
function or adjustment and press
OK to conrm the selection.
5RETURN:
Press this button to exit or return from the OSD menu functions.
6MENU:
Press this button to bring up the OSD menu of Video Wall Control
Systems.
7HDMI:
Press this button to switch input from HDMI source with Video Wall
Control Systems.
8U/OVER:
Press this button to display the image overscan/underscan on the
TV/monitor.
9VGA:
Press this button to switch input from VGA source with Video Wall
Control Systems.
POWER
RETURN MENU
HDMI VGA U/OVER
POWER OFF
CR-82*A1
OK
ABC
DEFAB
ABC
B
C
A
B
CA
A
1
3
5
7
9
2
4
6
8

DRAFT
5
6.4 Software Installation
Insert the software into the PC/NB that is going to connect to CVW-
9000W and click on Setup le.
Click “OK” to begin the installation.
Set the specied destination directory and click on the icon.

DRAFT
6
Set the group name in the Program Group box and click Continue.
Click OK to nish the Setup.
Open the application program “CVW-9000W” where it had been
saved.

DRAFT
7
Connect the RS-232 COM port rst.
Choose the video wall mode or power on/off after the RS-232 COM
port connects
(The “Connect” button will turn to green color).

DRAFT
8
Click on any one of the video wall modes and enter into the next
page, then click the “Set” button to conrm the video wall setting.
The “Set” button will disappear after conrmed, click on “Return” to
go back to the main page.

DRAFT
9
6.5 UART Controller’s RS-232 Pin Assignment
RS-232 IN
►
◄
RS-232 OUT
Pin Assignment Pin Assignment
1 NC 1 NC
2 TXD 2 RXD
3 RXD 3 TXD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 Connect to Pin 8 7 Connect to Pin 8
8 Connect to Pin 7 8 Connect to Pin 7
9 NC 9 NC
Baud Rate: 19200bps
Data bit: 8bits
Parity: None
Stop Bit: 1bit
Flow Control: None

DRAFT
10
6.6 UART Controller’s RS-232 Commands
Commands Description
0xEF 0x04 0xE3 0xC2 0x33 0xEE Mode 1
0xEF 0x04 0xE4 0xC2 0x34 0xEE Mode 2
0xEF 0x04 0xE5 0xC2 0x35 0xEE Mode 3
0xEF 0x04 0xE6 0xC2 0x36 0xEE Mode 4
0xEF 0x04 0xE7 0xC2 0x37 0xEE Mode 5
0xEF 0x04 0xE8 0xC2 0x38 0xEE Mode 6
0xEF 0x04 0xE9 0xC2 0x39 0xEE Power Off
0xEF 0x04 0xEA 0xC2 0x3A 0xEE Power On
Note: All the RS-232 command will be not executed unless followed
with a carriage return. Commands are Case-Sensitive.

DRAFT
11
7. CONNECTION AND INSTALLATION
DC 24V
IR-In
RS-232 Service
A
HDMI Out
1
HDMI In
B
HDMI Out
2
HDMI In
C
HDMI Out
3
HDMI In
D
HDMI Out
4
HDMI In
E
HDMI Out
5
HDMI In
F
HDMI Out
6
HDMI In
G
HDMI Out
7
HDMI In
H
HDMI Out
8
HDMI In
12
34
V+
GND
GND
GND
V+
CONTROL
1
2
3
4
V+
GND
GND GND
V+
1234567
䡾
䢃
䡿
䢂
䢀
䢁
䢃
䢃
䢂
䢂
䢂
䢂
䢂
䢁
䢁
䢁
CMSI-8H8HS
CVW-11HS
3
4
5
6
7
8
9
10
11
12
13
14
15
16 RS-232 In DC 5V
RS-232 Out
䡾
HDMI
䡿
HDMI
䢀
HDMI
䢁
HDMI
䢂
HDMI
䢃
HDMI
Media ServerCD Player CD Player
Notebook
Media Player Media PlayerSet-top Box
Video Wall
Control
System
UART Controller
HDMI Device

DRAFT
12
8. SPECIFICATIONS
Input Port 1xRS-232 (Female Jack)
Output Port 16xRS-232(Male Jack)
Power Supply 5V DC/ 1A (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Dimensions (mm) 320(W) x 95(D) x 45(H)
Weight(g) 978
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C ~ 40˚C / 32 ˚F ~ 104 ˚F
Storage Temperature -20˚C ~ 60˚C / -4 ˚F ~ 140 ˚F
Relative Humidity 20 ~ 90% RH (non-condensing)
Power Consumption 1W

DRAFT

DRAFT

DRAFT
