CYP PU-8H8HBTE User manual

38++%7(38++%7(
[[+'0,+'%DVH70DWUL[
3OD\LQFOXGLQ /$1VHUYLQ 
23(5$7,210$18$/

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
 
electrical shock and injury to persons.
 
moisture or install this product near water.
 Never spill liquid of any kind on or into this product.
 Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
 Do not attach the power supply cabling to building surfaces.
 Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
 Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
 To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for

REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 11/06/11 Preliminary Release
RDV2 13/06/11 Add CMSI-4H8CVE

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 2
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Side Panel .........................................5
6.4 Remote Control................................6
6.5 IR Cable Pin Assignment..................6
6.6 RS-232 Protocols ...............................7
6.7 RS-232 & Telnet Commands............8
6.8 Telnet Control ...................................9
6.9 Web GUI Control ............................11
7. Connection Diagram .......................... 13
 ...................................... 15
9. Acronyms ............................................. 16

1
1. INTRODUCTION



outputs. It supports digital audio formats such as LPCM 7.1CH, Dolby
TrueHD, Dolby Digital Plus and DTS-HD Master Audio. Also, 3D content

allows the connection of source equipment to output displays, over
distances of up to 100 meters along with IR and RS-232(includes telnet)
control and PoE features. Further, it allows all outputs with access of
ethernetfunction through the single LAN port's active connection on
the device.
2. APPLICATIONS
 HDMI System control
 Video/TV wall display and control
 Security surveillance and control
 Commercial advertising, displaying and control
 Lecture room display and control
 Hyper market demonstration and control
3. PACKAGE CONTENTS
 
 HDMI over CAT5e/6/7 Receiver (Optional)
 
 2×IR Blaster
 2×24 V/6.25 A DC Power Adaptor (1 for PoE)
 1×IR Remote Control
 Operation Manual

2
4. SYSTEM REQUIREMENTS
 HDMI equipped input source devices with HDMI cables
 HDMI equipped output displays (TVs or monitors) or HDMI equipped
AV receivers with HDMI cables
 Industry CAT5e/6/7 cables
5. FEATURES
 HDMI, HDCP1.1 and DVI compliant
 Supports HDMI 3D features
 Supports resolutions VGA~WUXGA and 480i~1080p dependent upon
the output display’s EDID settings
 Supports distances up to 100 meters through CAT5e/6/7 cables
 Supports 3D signal display dependent upon the output display EDID
settings
 Supports PoE (Power over Ethernet) on compatible receivers only
 Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters
at 12-bit resolution
 Supports IR in/out from input and output locations
 Supports RS-232(include Telnet), remote control and on-panel
control
 Supports IP function through the single LAN port
 
 
 Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
Note: 1.The PoE function is designed for powering compatible
receiver units onlynon-PoE receivers will need their own
power supply.Receivers of another brand may not be
compatible.
2.LAN/CONTROL port must not miss connected with CAT
outputs, doing so will destroy the device.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER LOCK
MENU OUTA 1B2C3D4
IN
E5F6G7H8
8X8 HDMI MATRIX over CAT5e/6 CMSI-8H8CVE
2 3 4 5 61
1LCM : Displays the setting information of each input and output
setting.
2POWER: Press this button to power the device on/off. The LED will
illuminate green when the power is on, red when it is in 'Standby'
mode.
3LOCK: Press this button to lock all the buttons on the panel; press
again to unlock. The LED will illuminate green when locked.
4IR: IR Receiver window (accepts the remote control signal of this
device only).
5MENU: Press this button to change the EDID setting from STD

selection.
61~8/A~H and In/Out: Press the Out or In button to select the output
or input mode and then press the required number button to make
the selection accordingly.
 
E~H need to be set to input 2, then the following sequence of
button presses need to be performed:
 

Note: If the menu button is not pressed the selection will not be
changed.

4
6.2 Rear Panel
LAN
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUTCAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
1
2
3
4
V+
GND
GND GND
V+
2 4
3
510 111
6
8
7
9
1LAN: Connect an active Ethernet port for network signal sharing
with receivers with LAN function for a data transmission rate of
100Mbps or when anyone of the receivers connected to this
device is connect with an active Ethernet port all receivers with
LAN function and this device will also access the Ethernet function.
This port is also the link for Telnet system and web GUI controls,
further details please referes to section 6.8 & 6.9.
2RS-232: Connect to a PC or laptop with D-Sub 9-pin cable for the
transmission of RS-232 commands.
3ALL IR OUT: Connect to the IR blaster (included in the package) for IR
signal transmission of the source or display equipment. Place the IR
blaster in direct line-of-sight of the equipment to be controlled.
4ALL IR IN:
IR signal reception of the remote control of this device or the source
and display equipment. Ensure that remote being used is within the

5SERVICE: Manufacturer use only.
6IR OUT 1~8: Connect the supplied IR blasters (included in the
package) for IR signal transmission. Place the IR blaster in direct line-
of-sight of the equipment to be controlled.
7IR IN 1~8:
package) for IR signal reception. Ensure that remote being used is


5
8CAT5e/6/7 OUT 1~8: Connect to the CAT input port of receiver units
with a single CAT5e/6/7 cable for HDMI Audio/Video and IR/RS-232
control signal sending.
Warning: Please do not miss connect CAT5e/6/7 ports with receiver
device's LAN port doing so will destroy the device.
9HDMI IN 1~8: Connect to the HDMI input source devices such as a

10 DC 24V MAIN POWER: Plug the 24 V DC power supply into the unit
and connect the adaptor to an AC outlet.
11 PoE 24V: Plug the 24 V PoE power supply into the unit and connect
the adaptor to an AC outlet. This unit will mainly power PoE (Power
over Ethernet) capaable receiver units.
6.3 Side Panel
1
1Fan Ventilator: These are air ventilation areas, DO NOT block these
areas or cover it with any object. Please allow adequate space
around the unit for air circulation.

6
6.4 Remote Control
1POWER: Press this button to
switch on the device or set it to
standby mode.
2IN: Input ports selection 1~8.
3OUT: Output ports selection A~H.
6.5 IR Cable Pin Assignment
3
1
3
1
2
2
Power 5 V
IR Blaster Signal
NC
IR Signal
Power 5 V
Grounding
IR Receiver
IR Blaster
1
23

7
6.6 RS-232 Protocols
Pin Assignment
CMSI-8H8CVE/CMSI-4H8CVE Remote Control Console
PIN Assignment PIN Assignment
1NC 1NC
2 2
3 3
4NC 4NC
5 GND 5 GND
6NC 6NC
7NC 7NC
8NC 8NC
9NC 9NC
Baud Rate: 19200 bps
Data bit: 8 bits
Parity: None
Stop Bit: 1
Flow Control: None

8
6.7 RS-232 & Telnet Commands
Command Description
A1~A8 Switch Output A to 1~8
B1~B8 Switch Output B to 1~8
C1~C8 Switch Output C to 1~8
D1~D8 Switch Output D to 1~8
E1~E8 Switch Output E to 1~8
F1~F8 Switch Output F to 1~8
G1~G8 Switch Output G to 1~8
H1~H8 Switch Output H to 1~8
ABCD...1~ABCD...8 Switch Output A B C D... to 1~8 at the
same time
SETIP <IP> <SubNet> <GW> Setting IP. SubNet. GateWay (Static IP)
RSTIP 
Defaults <DHCP>
IPCONFIG 
P0 Power OFF
P1 Power ON
I1~I8 Switch all the Output to 1~8
ST 
W version
RS System Reset to A1, B2, C3, D4, E5, F6,
G7, H8
?Display all the available commands
Quit 
Note: All the commands will not be executed unless followed with a
carriage return. All letters are not case-sensitive.

9
6.8 Telnet Control
Before starting the telnet control, please connect both the device
(LAN /CONTROL p ort) and the PC/NB to an active Ethernet link and
power on the device. Please do not connect both the device and
the PC/NB with single CAT5e/6 cable together as it will not access the
telnet function.
To Enter into telnet control under Windows 7, click on start and type

Under Windows XP go to start and click on "Run", type "cmd"with enter
key hit.

See below for reference.

10
After entering into the cmd/terminal key in “telnet ” to enter into the
telnet system.
Once entered type "telnet" " " with "IP address" "" and "23" then hit
enter. IP address can be found from the device's LCM monitor by
press the Menu button twice.
This will bring us into the device which we wish to control. Type "help"
to bring out the available commends.

“RSTIP” and to use a set static IP type ”SETIP”
Note: All the commands will not be executed unless followed with a
carriage return. All letters are not case-sensitive.

11
6.9 Web GUI Control
Enter into the web page and type device's IP address on the web
address column. The system will bring out the control device's status,
control and User setting pages.
Click on Control to control power, input/output ports, EDID and reset
mode.

12


changed. IP address also need to be changed accordingly on the
web address column order for continuing control.

13
7. CONNECTION DIAGRAM
ZONE A
LAN
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
I
R
I
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
123456
RX
ZONE B
Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE C
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE D
RX Power
Extender Blaster
IR 2
IR 1
ZO
N
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
IR Out (All)
IR In (ALL)
RS-232 Equipped
PC or Notebook
with Ethernet
connection

14
G H
R
OUT
R IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
7
HDMI IN
8
HDMI IN
12
34
V+
GND
GND
GND
V+
87
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
N
EEZONE FZONE GZONE H
Main Power Supply
Power Supply for
Power-over-Ethernet
Receiver Units
Single
CAT 5e/6
Cable
HDMI Inputs
IR Out/In
HDMI Outputs
IR Out/In
Source
Equipment
Displays

15
8. SPECIFICATIONS
Video Bandwidth 
Input Ports 


Output Ports 8×CAT5e/6/7, 9×IR Blaster
ESD Protection Human-body Model:
± 8kV (Air-gap discharge)
± 4kV (Contact discharge)
Power Supply 24 V/6.25 A DC (US/EU standards, CE/

Dimensions 438 mm (W)×255 mm (D)×92 mm (H)
Weight 4268g/8H8CVE, 4402g/4H8CVE
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0 ºC~40 ºC/32 ºF~104 ºF
Storage Temperature C~60 ºCF~140 ºF
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 

16
9. ACRONYMS
ACRONYM COMPLETE TERM
DTS Digital Theater System
DVI Digital Visual Interface
EDID 
HDCP High-bandwidth Digital Content Protection
HDMI 
HDTV 
LCM Liquid Crystal Module
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA 

ZZZF\SHXURSHFRP
