Cypress Hills AXCCMAR20 User manual

MARANA 8 CUBE STORAGE
ASSEMBLY INSTRUCTIONS
MODEL # AXCCMAR20

DO NOT RETURN
FOR REPLACEMENT PARTS OR OTHER INQUIRIES
PLEASE CONTACT US AT:
1-800-667-8992
PLEASE ENSURE TO HAVE THE COLLECTION
NAME AND DESCRIPTION FROM THE
PACKAGING OR INSTRUCTION BOOKLET

IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
SAFETY INFORMATION

Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger, but lose moisture more
slowly than other finishes.
To help protect your wood furniture, take these steps:
Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly. Don't over-humidify; that can damage wood
by causing it to expand and contract.
Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3
to 4 inches away from the wall, giving the heat and air space to circulate.
Dust with soft dry cloth.
Do not use liquid or aerosol products.
CARE and MAINTENANCE
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

TOP
QTY 1 LEFT SIDE QTY 1
TOP DIVIDER (L&R Same)
QTY 3
BOTTOM SHELF
QTY 1 LEFT BACK PANEL
QTY 1
BOTTOM DIVIDER (L&R Same)
QTY 3 TOP SHELF
QTY 1
BOTTOM SUPPORT LEG
QTY 1
PART DESCRIPTION
A BL
CD E
FG
RIGHT SIDE
QTY 1
BR
HL
HRH
RIGHT BACK PANEL
QTY 1
MIDDLE BACK PANEL
(L&R Same)
QTY 2
PRE-ASSEMBLY INFORMATION MODEL # AXCCMAR20
Warning Label
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-800-667-8992.

ALLEN KEY
QTY 1
ALLEN KEY SCREW
M6 X 30mm
QTY 27
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 34
CAM LOCK PIN
CAM LOCK
QTY 18 SETS
WOOD DOWEL
QTY 17
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
PHILLIPS SCREW
M4 X 30mm
QTY 4
HARDWARE DESCRIPTION
12 3 4
5 6 7
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
PRE-ASSEMBLY INFORMATION MODEL # AXCCMAR20
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-800-667-8992.

A
CCC
E
DDD
F
G
HH
BL
BR
HR
HL
COMPONENTS-KEY DIAGRAM MODEL # AXCCMAR20

STEP-1
C
E
4
1
3
C
C
1. Insert 1 Dowel 3 into guidehole on each Top Divider C .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 3 Top Dividers C to Top Shelf E using 6 Allen Key Screws 1
(2 Screws on each Divider).
4. Use Allen Key 4 to tighten screws. Do not over-tighten.
ASSEMBLY MODEL # AXCCMAR20

STEP-2
C
C
C
E
D
D
D
3
2
1. Insert 1 Dowel 3 into guide hole on each Bottom Divider D .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 6 Cam Lock Pins 2 to Top Shelf E using pre-drilled holes.
4. Align Cam Lock Pins with guide holes on Dividers D .
5. Insert 2 Cam Locks 2 into guide holes on each Divider D .
6. Use flathead screwdriver to secure Cam Locks.
ASSEMBLY MODEL # AXCCMAR20

STEP-3
C
C
C
ED
F
D
D
31
4
1. Insert 1 Dowel 3 into guide holes on each Bottom Divider D .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 3 Bottom Dividers D to Bottom Shelf F using 6 Allen Key Screws 1
(2 Screws on each Divider).
4. Use Allen Key 4 to tighten screws. Do not over-tighten.
ASSEMBLY MODEL # AXCCMAR20

STEP-4
2
3
F
D
CE
3
2
D
D
C
C
1. Insert 8 Dowels 3 into guide holes on each Top Shelf E and Bottom Shelf F
( 4 dowels on each shelf ).
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 6 Cam Lock Pins 2 to each Side BL , BR using pre-drilled holes.
4. Align Cam Lock Pins with guide holes on Top Shelf E and Bottom Shelf F .
5. Insert 6 Cam Locks 2 into guide holes on each Top Shelf E and
Bottom Shelf F ( 3 Cam Locks on each side of shelf ).
6. Use flathead screwdriver to secure Cam Locks.
BL
BR
ASSEMBLY MODEL # AXCCMAR20

STEP-5
1
4
4
1
F
D
ED
D
C
C
C
A
G
1. Attach Top A to Sides BL , BR and 3 Top Dividers C using 15 Allen Key Screws 1
(3 screws on each Side and Divider).
2. Use Allen Key 4 to tighten Screws. Do not over-tighten.
3. Attach Bottom Support Leg G to Bottom Shelf F using 4 Phillips Screws 6 .
4. Use Phillips screwdriver to snugly tighten screw.
BL
BR
ASSEMBLY MODEL # AXCCMAR20
6

STEP-6
H
A
5
1. Attach Back Panels H , HL , HR to back frame of cube storage using 34 Phillips
Screws Round Head 5 through guide holes.
2. Use Phillips Screwdriver to tighten screws.
H
HL
HR
ASSEMBLY MODEL # AXCCMAR20
Warning Label
Note:
Note: Levelers on bottom of legs can be adjusted if floor is uneven.

7
7
STEP-7
NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
FURNITURE TIP OVER RESTRAINT ASSEMBLY

Furniture Tip Over Restraint Instructions:
1. Attach one of the mounting brackets securely to the back edge of
the furniture. Use the shorter screw.
2. Determine where furniture is to be placed and mark location on
the wall for mounting bracket screw hole approximately 2 inches
below the bracket mounted to the furniture.
3. Drill a 3/16 inch hole in the wall. Press the plastic anchor into the
hole and gently tap until the flange on the anchor is against the
wall surface.
4. Position the bracket over the anchor and use the longer screw to
securely attach the bracket to the wall.
5. Place the furniture so the back edge is in line with the bracket on
the wall.
6. Lace an end of the nylon zip-tie strap down through each bracket.
Bring both ends together and slide the smooth side upright
through the square-shaped end and pull through to create the
7. Check to make sure the strap is securely laced and locked to the
brackets.
DO NOT put a TV or other heavy objects on top of a 8 Cube Storage /
Sofa Table or any other furniture not intended for use with a TV
DO NOT place heavy objects in top drawers
DO NOT let children climb or hang on drawers, doors or shelves
x
x
x
FURNITURE TIP OVER RESTRAINT ASSEMBLY
