Cypress Hills MARANA AXCCMAR17 User manual

1/24
MARANA TALL TV STAND
MODEL # AXCCMAR17
ASSEMBLY INSTRUCTIONS

2/24
DO NOT RETURN
FOR REPLACEMENT PARTS OR OTHER INQUIRIES
PLEASE CONTACT US AT:
1-800-667-8992
PLEASE ENSURE TO HAVE THE COLLECTION
NAME AND DESCRIPTION FROM THE
PACKAGING OR INSTRUCTION BOOKLET

3/24
WARNING Do not place toys, food, etc. on the top shelves or upper drawers.
Serious injury or death may occur when children climb on furniture. A remote
control or items placed on the furniture may encourage a child to climb on the
furniture and as a result make it top-heavy and cause it to tip over on the child.
WARNING Do not place a TV that exceeds the weight limits or size guidelines
shown in the instructions specified for the furniture. Do not overload shelves or
place heavy items on top shelves or drawers.
Improper use of furniture to support TVs may result in serious injury or death.
WARNING Do not relocate audio and/or video equipment to furniture not
specifically designed to support audio and/or video equipment. Do not move
furniture without shelves or drawers unloaded. Furniture can collapse or tip over
onto a child and cause physical injury or death.
This TV Stand does not come with legible instructions pertaining to the risk of fire
and electric shock that is associated with the use of electrical components such as
operation, user-maintenance, loading, storage and as applicable electrical issues
including grounding or double-insulation.
Any use of this item other than that recommended by the manufacturer in this
manual may cause fire, burns, electric shock and/or serious injuries or death.
MAXIMUM LOAD 200 LBS
MAXIMUM LOAD 25 LBS
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
WARNING
The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to 68.58
cm). For use with televisions weighing 200 lbs or less. Using larger or heavier televisions
may cause instability or tip over which can lead to serious injury or even death.
The recommended maximum width of the television intended for use is 60 inch (152.4 cm).

4/24
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
CAUTION: Injuries and damage can occur from furniture tip over if product is not
properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided
with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.

5/24
CARE and MAINTENANCE
Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative
humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls,
and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally
along different grain directions. As humidity changes, the components of wooden objects are
continually pushing and pulling against each other. This pressure often results in parts of furniture
no longer fitting together closely or becoming distorted or breaking from their own internal
stresses.
The response to relative humidity changes begins with determining the annual average RH for
your particular space. Then try to keep the RH in the space where your furniture is as close to that
average as possible, generally within about 10% up or down. De-humidify in the summer and
humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern heating
systems, which can drive down interior RH in the winter, almost invariably cause problems for
furniture. To counteract their effect, you can either modify the RH by keeping furniture containing
spaces cooler in the winter or most importantly, have a good working humidifier for your home. A
humidistat automatically works to balance the humidity in your home so it is constant. Dry indoor
air can suck enough moisture from its surroundings to do permanent damage to wood, causing it
to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how rapidly a
wood will lose moisture are pore size and surface hardness. A piece made from a dense and hard
wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished piece
while pieces with veneer finishes are not only stronger, but lose moisture more slowly than other
finishes.
To help protect your wood furniture, take these steps:
• Use a humidifier, preferably one with an automatic control system that can sense the humidity
level and adjust itself accordingly. Don't over-humidify; that can damage wood by causing it to
expand and contract.
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
• If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3 to 4
inches away from the wall, giving the heat and air space to circulate.
• Dust with soft dry cloth.
• Do not use liquid or aerosol products.
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• For soil build-up, wipe with damp cloth & dry.
• Do not use abrasive cleaners.
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

PRE-ASSEMBLY INFORMATION
MODEL # AXCCMAR17
PARTS DESCRIPTION
6/24
A
TOP
QTY 1
BL
LEFT SIDE
QTY 1
BR
RIGHT SIDE
QTY 1
C
CENTRE SHELF
QTY 1
D
BOTTOM SHELF
QTY 1
EL
LEFT DIVIDER
QTY 1
ER
RIGHT DIVIDER
QTY 1
F
DOOR (L&R Same)
QTY 2
G
SHELF PART
QTY 4
Front / Avant
Front
/ Avant
Front
/ Avant
Front / Avant
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-800-667-8992.
Front
/
Avant
Front
/ Avant

PRE-ASSEMBLY INFORMATION
MODEL # AXCCMAR17
PARTS DESCRIPTION
7/24
H
SHELF PART
QTY 1
I
BACK PANEL
QTY 1
J
BACK PANEL
QTY 1
KL
LEFT BACK PANEL
QTY 1
L
DRAWER FRONT
QTY 2
ML
LEFT DRAWER SIDE
QTY 2
O
N
DRAWER BACK
QTY 2
DRAWER BOTTOM
QTY 2
MR
RIGHT DRAWER SIDE
QTY 2
KR
RIGHT BACK PANEL
QTY 1
Warning Label
P
BOTTOM SUPPORT LEG
QTY 1
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-800-667-8992.

1
PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
23
4 5 6
7
10
8 9
ALLEN KEY SCREW
M6 X 30 mm
QTY 26
PHILLIPS SCREW
M4 X 15 mm
QTY 24
HANDLE
M4 X 30 mm
QTY 4 SETS
CAM LOCK PIN
CAM LOCK
QTY 20 SETS
PHILLIPS SCREW
M3 X 15 mm
QTY 8
MAGNET AND PLATE
QTY 2 SETS
ALLEN KEY
QTY 1
PHILLIPS SCREW ROUND HEAD
M4 X 15 mm
QTY 25
SHELF SUPPORT
QTY 30
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
8/24
MODEL # AXCCMAR17
12
a. M4 X 25 - QTY 2
( )1 is extra
b. M4 X 15 - QTY 1
c. M4 X 25 - QTY 1
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
PHILLIPS SCREW
M4 X 30 mm
QTY 4
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-800-667-8992.
11
ADJUSTABLE HINGE
QTY 4

COMPONENTS – KEY DIAGRAM
9/24
MODEL # AXCCMAR17
EL
ER
A
BL
KR
I
KL
J
H
C
G
G
BR
F
F
Front / Avant
Front / Avant
Front /
Avant
Front / Avant
Front / Avant
G
G
D
P
MR
N
L
ML
O

ASSEMBLY
STEP 1
STEP 2
1. Slide Drawer Bottom O firmly into slots on Drawer Sides ML , MR and
Drawer Front L .
MODEL # AXCCMAR17
10/24
1. Attach 4 Cam Lock Pins 2 to back of Left Drawer Front L .
2. Align Cam Lock Pins with guide holes and attach Drawer Sides ML , MR .
3. Insert 2 Cam Locks 2 into guide holes on each Drawer Side ML , MR .
4. Use flathead screwdriver to secure Cam Locks.
L
MR
ML
2
2
O
L
MR
ML

STEP 3
STEP 4
1. Align Drawer Back N with Drawer Bottom O and press firmly into slot.
2. Attach back using 2 Allen Key Screws 1 through guide holes on each side.
3. Use Allen Key 3 to tighten screws. Do not over tighten.
1. Use Phillips screwdriver to attach Handle 7 to Drawer Front L .
Repeat Step 1-4 for the second drawer .
MODEL # AXCCMAR17
11/24
1
3
1
N
O
L
MR
ML
L
7
ASSEMBLY

STEP 5
1. Attach 3 Cam Lock Pins 2 to each Divider EL , ER .
2. Align Cam Lock Pins with guide holes and attach Center Shelf C .
3. Insert 6 Cam Locks 2 into guide holes on Center Shelf C .
4. Use flathead screwdriver to secure Cam Locks.
12/24
MODEL # AXCCMAR17
Front
/ Avant
Front
/
Avant
C
EL
ER
2
Front
/ Avant
Front
/
Avant
C
EL
ER
ASSEMBLY

STEP 6
1. Attach Dividers EL , ER to Bottom Shelf D using 6 Allen Key Screws 1 through
guide holes.
13/24
MODEL # AXCCMAR17
D
EL
ER
1
3
Front /
Avant
Front / Avant
Front
/
Avant
ASSEMBLY

STEP 7
1. Attach 6 Cam Lock Pins 2 to Sides BL , BR using pre-drilled holes.
2. Align Cam Lock Pins with guide holes on Bottom Shelf D and attach
Bottom Shelf D .
3. Insert 6 Cam Lock 2 into guide holes on Bottom Shelf D .
4. Use a flathead screwdriver to tighten Cam Locks into Pins.
14/24
MODEL # AXCCMAR17
Front
/ Avant
Front /
Avant
Front
/ Avant
Front
/ Avant
Front
/ Avant
D
BR
BL
Right
Left
22
ASSEMBLY

STEP 8
1. Attach Bottom Support Leg P to Bottom Shelf D using 4 Phillips Screws 10 .
2. Use Phillips screwdriver to tighten screws. Do not over-tighten.
15/24
MODEL # AXCCMAR17
Front / Avant
Front
/
Avant
Front
/
Avant
Front
/
Avant
Front
/ Avant
BL
EL
BR
P
P
10
D
ER
ASSEMBLY

STEP 9
1. Attach Top A to 2 Sides BL , BR and 2 Dividers EL , ER using Allen Key Screws 1
through guide holes.
2. Use Allen Key 3 to tighten screws. Do not over-tighten.
16/24
MODEL # AXCCMAR17
Front / Avant
Front /
Avant
Front
/
Avant
Front /
Avant
Front
/ Avant
Front
/
Avant
BL
EL
ER
BR
A
1
3
1
3
ASSEMBLY

STEP 10
17/24
MODEL # AXCCMAR17
KL
KR
I
J
Front
/ Avant
Front
/ Avant
Front
/
Avant
Front
/ Avant
Front
/ Avant
Front / Avant
Warning Label
KR
KL
I
J
1. Use Phillips screws Round Head 6 to attach Back Panels I , J , KL , KR through
guild holes.
2. Use Phillips screwdriver to tighten screws.
6
Note:
The back of the tv frame does not have
pre-drilled holes to aach the back panels.
ASSEMBLY

STEP 11
18/24
MODEL # AXCCMAR17
11
4
11
4
2. Attach Adjustable Hinges on Doors F to Sides BL , BR using Phillips Screws 4
into pre-drilled holes on Side BL , BR .
3. Use a Phillips screwdriver to tighten screws.
F
1. Attach Adjustable Hinges 11 to Doors F using Phillips Screws 4
into pre-drilled holes on Doors F .
F
F
BL
BR
ASSEMBLY

STEP 12
19/24
MODEL # AXCCMAR17
IMPORTANT NOTE:
II
I
4
Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so
that all the spaces between the door and the unit sides are equal. To adjust, follow
instructions:
1. Side adjustment 4 mm
To move the door towards the side panel, loosen screw I and tighten screw II .
To move the door away from the side panel, loosen screw II and tighten screw I .
2. Depth adjustment 4 mm
Loosen screw II ( just one turn ), adjust door to desired position, re-tighten screw .
3. Height adjustment
Loosen screw 4 , adjust door to desired position, re-tighten screw .
ASSEMBLY

STEP 13
1. Attach Magnet Plates 8 to bottom corners of Doors F using Phillips Screws 5 into
pre-drill holes on Doors F .
2. Attach Magnets 8 using Phillips Screws 5 into pre-drill holes on Bottom Shelf D .
3. Use Phillips screwdriver to attach Handles 7 to Doors F .
20/24
MODEL # AXCCMAR17
5
8
7NOTE: The screwdriver is not
included in the hardware pack.
7
8
5
F
F
D
ASSEMBLY
