CY8CKIT-146 PSOC®4200DS PROTOTYPING KIT QUICK START GUIDE
© 2017 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks
referenced herein are the properties of their respective owners. 002-18477 Rev.**
Pinout Description
Block Diagram
KitProg2 Mode Switching
Example Project Operation
KitProg2 Programming Modes*
KitProg2 program/debug mode
(PPCOM mode) (default) ON
CMIS-DAP & Mass Storage
Programming Mode
*Note: Toggling between the Programming modes can be done by pressing Mode switch SW3
Breathing
Status LED (LED3)
For more information, please visit: www.cypress.com/CY8CKIT-146
KitProg2
(PSoC 5LP)
Pullup
4.7K
P1.3 P0.1
I2C
SWD
UART
KitProg2 PSoC 4200DS
PSoC 4200DS
(Target Device)
User Switch (SW1)
Not Pressed Breathing
Pressed OFF
User LED (LED1) Status
P0_1
P0_2
P3_6
P3_5
P3_4
P3_0
GND
VTARG
GND
P1_0/RX
P1_1/TX
P1_2
P1_3/SW1
P3_0/SCL
P3_1/SDA
P3_4
P3_2/SWDIO
P3_3/SWDCLK
RESET
GND
VTARG
VTARG
GND
P0_6
P0_5
P0_4
P0_2
P0_1/LED1
P0_0
P2_2
P2_3
P2_4
P2_5
P2_6
P2_7
P12_6/UART TX
P12_7/UART RX
P12_1/12C SDA
P12_0/12C SCL
P12_5
GND
VBUS
Pullup
4.7K
Mode
Switch
User
Button
User
LED
USB
I/O Headers
(No Load)
Status
LED
Power
LED
Reset
Switch
External
Prog/Debug
(No Load)
I/O Headers
(No Load)
KitProg2
Programmer and Debugger
PSoC 4200DS

Design the way you think!

Contents under the label
Cypress Semiconductor
CY8CKIT-146 PSOC®4200DS Prototyping Kit
