Cypress CLUX-42S User manual

CLUX-42S
4x2 HDMI v1.3
Switcher
Operation Manual
CLUX-42S

TABLE OF CONTENTS
1. Introduction 1
2. Features 1
3. Operation Controls and Functions 2
3.1 Front Panel 2
3.2 Rear Panel 2
4. Remote Control 3
5. RS-232 Remote Control Protocol 3
5.1 RS-232 transmission format 3
5.2 RS-232 command 4
6. Specifications 4
7. Connection and Installation 5
8. Cypress HDMI v1.3 Series 6

1. Introduction
This is a high performance HDMI v1.3 Switcher with remote control. It allows
various HDMI sources to share two HDTV display. Simply pressing button to select
your desired HDMI source for display on the HDTV.
Each product in this series is compatible to HDMI v1.3 specifications, a cutting
edge technology which defines the support to transfer Deep Color (10-bit and
12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and
DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz.
2. Features
* HDMI 1.3, HDCP1.1 and DVI1.0 compliant.
* Deep color video up to 12bit, 1080p@60Hz.
* Four HDMI sources to connect up to two HDMI displays simultaneously.
* Supports DVI source and DVI display by using HDMI to/from DVI adaptor
cable.
* Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master
Audio transmission (32-192kHz Fs sample rate).
* Supports a wide range of PC and HDTV resolutions from VGA to UXGA and
480i to 1080p.
* HDMI cable distance test with 1080p resolution: Input/Output source can run
up to 30M/5.1CH.
* Full HDCP Compliant.
1

2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote Control Sensor.
2 HDMI input Select/Indicator: Press the "Input" button sequentially to switch to
your desired input (HDMI 1 to HDMI 4), the LED will illuminate to indicate
which input source is selected
3 POWER Switch/Indicator: Press the "POWER" button to turn on/off the power,
the power LED illuminate in red color means the power is turned on, when
the LED not illuminate power is turned off.
3.2 Rear Panel
1 HDMI Outputs 1 and 2: Connect each of the output ports to the HDMI
display. When more than one output connected, the HDMI outputs play
identical video signal simultaneously.
2 RS232: 9-pin D-Sub connector for connecting to your PC or other control
console for remote control.
3 HDMI Inputs 1 to 4: Connect each of the input ports to the HDMI or DVI
output of your source equipment such as DVD player or set-top-box.
4 Power: Plug the 5V DC power supply into this unit and connect the adaptor
to AC wall outlet.
POWERINPUT
4321
SPLITTER
4x2
HDMI 1.3/2.25G
HDMI
1 2 3
RS-232
HDMI OUT HDMI OUT
2 1
HDMI IN
4
HDMI IN
3
HDMI IN
2
HDMI IN
DC 5V
1
1 2 3 4

4. Remote Control
1 Power: Press the button to turn on/off the unit.
2 Direct input selector:
Press 1, 2, 3 or 4 to select the desired input source.
5. RS-232 Remote Control Protocol
The connection between splitter and remote controller with RS-232 modem cable.
5.1 RS-232 transmission format:
Baud Rate: 9600 bps
Data bit: 8 Bits
Parity: None
Stop Bit: 1 bit
1
2
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
TxD
RxD
NC
GND
NC
NC
NC
NC
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
Rx
Tx
NC
GND
NC
NC
NC
NC
Splitter Remote Controller


CR-23
3

4
5. RS-232 Remote Control Protocol
5.1 RS-232 transmission format:
Frequency bandwidth
Input port
Output port
Power Supply
Remote Control
Dimensions (mm)
Weight(g)
Chassis Material
Silk Skin Color
Operating Temperature
2.25Gbps (single link)
4x HDMI female ports
2 x HDMI female ports
5VDC/2.6A (US/EU standards, CE/FCC/UL certified)
Discrete IR remote
240(W) x 104(D) x 44(H)
800
Metal
Black
Operating from 0°C ~ 40°C
6. Specifications
RS-232 command Operation
POWER 00
POWER 01
PORT 01
PORT 02
PORT 03
PORT 04
Select power OFF
Select power ON
Select port 1
Select port 2
Select port 3
Select port 4

STB
LCD TV
LCD TV
DVD 1 DVD 3
DVD 2
7. Connection and Installation
5
