DFE-670TXD
Plug & Play Fast Ethernet
Access for Notebooks
The D-Link DFE-670TXD is a 10/100Mbps
Fast Ethernet 16-bit PC Card adapter for
notebooks. With the built-in connector, a RJ-45
LAN cable can be directly plugged into a
notebook computer. The DFE-670TXD
provides instant connectivity for mobile users.
Enabling easy access to a network - users can
access databases and resources in diverse
environments.
The DFE-670TXD adheres to IEEE 802.3
and IEEE 802.3u standards, which specify
existing 10BASE-T and 100BASE-TX
Ethernet technology supporting both half
and full duplex modes with data rates up
to 10/100Mbps and 20/200Mbps. The
DFE-670TXD also utilizes auto-negotiation
Built-in Ethernet Port
Compatible with 10Mbps or
100Mbps Networks
WHQL Certified for Windows
Compatibility
Enhanced Power Management
Extends Battery Life
to adjust the speed to any 10BASE-T or
100BASE-TX network automatically.
With the DFE-670TXD’s RAM data buffer,
all incoming data is processed and stored
into temporary memory and eventually
filtered out, resulting in smooth data flow.
The DFE-670TXD s extensive diagnostic
LED s show link connectivity for both
10Link/Activity and 100Link/Activity.
Designed with a plug-and-play feature,
the DFE-670TXD is simple to install
and operate. With built-in hot swapping
capabilites, the DFE-670TXD can be removed
while the computer is still in operation.

SPECIFICATIONS
Drivers Supported
.Windows XP/Me/2000/98SE/98/95, NT 3.51 and NT 4.0
.NDIS 2.0 for Microsoft LAN Manager for DOS
.NDIS 2.0 for Microsoft Network Client 3.0 for Workgroup 3.11
.Packet Driver for NCSA
.Packet Driver for WinSock
.Novell Netware DOS ODI Driver
.Novell Netware Server v3.12, v4.x and v5.0
.Linux 2.2
D-Link Systems, Inc. 53 Discovery Drive Irvine CA 92618 www.dlink.com
©Copyright D-Link Systems, Inc. 2002. All rights reserved. D-Link® is a registered trademark of D-Link Systems, Inc.
Other trademarks or registered trademarks are the property of their respective manufacturers or owners. Price and
specifications are subject to changes without notice. See inside package for warranty details.
* 24/7 Tech Support is available only in USA.
DFE-670TXD
Product Information
Part No: DFE-670TXD
Description: 16-bit Fast
Ethernet PC Card Adapter
D-Link Systems, Inc.
TEL: [phone]
www.dlink.com
Package Contents
.DFE-670TXD Fast Ethernet
PC Card Adapter
.Drivers & Software on CD-ROM
.Installation Guide
Standards
.IEEE 802.3 10Base-T Ethernet
.IEEE 802.3u 100Base-TX Fast
Ethernet
.ANSI/IEEE 802.3 NWay Auto-
Negotiation
.PCMCIA 2.x
.Type II 16-bit Cardbus
Network Media
.Ethernet: UTP Cat3, 4, 5 EIA/
TIA-568 100-ohm screened
twisted-pair (STP)
.Fast Ethernet: UTP Cat5, EIA/
TIA-568 100-ohm screened
twisted-pair (STP)
Diagnostic LEDs
.10M Link/Activity
.100M Link/ Activity
Host Interface
PCMCIA Type II 16-bit Cardbus
Power Requirements
.Normal Operation+3.3V DC, 380mA max.
.Sleep Mode+3.3V DC, 80mA max.
Network Data Transfer Rate
.Ethernet: 10Mbps (Half-duplex)
.Ethernet: 20 Mbps (Full-duplex)
.Fast Ethernet: 100Mbps (Half-duplex)
.Fast Ethernet: 200Mbps (Full-duplex)
Temperature
.Operating: -10~50°C
.Storage: -10~70°C
Humidity
.Operating: 10%~90%
.Storage: 5%~90%
Compliances
CE Class B, FCC Class B, VCCI-B
Warranty
1 Year
