D-Link MYDLINK DNR-322L User manual

Version 1.1 | 29/12/2011

iD-Link DNR-322L User Manual
Table of Contents
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any
person or organization of such revisions or changes. Information in this document may become obsolete as our services and
websites develop and change. Please refer to the www.mydlink.com website for the most current information.
Manual Revisions
Revision Date Description
1.0 August 02, 2011 DNR-322L Revision A1 with rmware version 1.00
1.1 December 29, 2011 DNR-322L Revision A1 with rmware version 1.10
Manual Overview
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United
States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of
their respective companies.
Copyright © 2012 by D-Link Corporation.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission
from D-Link Corporation.

iiD-Link DNR-322L User Manual
Table of Contents
Features............................................................................................ 4
Hardware Overview..................................................................... 7
Front View................................................................................ 7
Rear Panel (Connections)...................................................8
Getting Started ..........................................................................9
NVR Software CD.......................................................................... 9
Installation............................................................................... 10
Setup Wizard ........................................................................... 10
Install the Hard Drives.......................................................11
Power and Device Selection ...........................................13
Admin password .................................................................14
RAID Conguration and Drive Mapping ....................15
Search Camera.....................................................................16
Set up Internet connection.............................................18
D-Link NVR Search Utility ........................................................25
Web UI Login ........................................................................27
Congure Hard Drive.........................................................28
Auto Search Camera..........................................................29
Web UI ............................................................................................31
Conguring the NVR..........................................................32
Network Setup.....................................................................33
Camera Search.....................................................................34
Camera Setup.......................................................................35
Audio and Video..................................................................36
Live and Playback Setup ..................................................37
Recording Schedule...........................................................38
Event Setup...........................................................................41
Auto Backup .........................................................................42
E-mail Setup..........................................................................44
Time and Date Setup.........................................................45
Maintenance............................................................................ 46
User Management..............................................................46
System ....................................................................................48
RAID.........................................................................................49
Dynamic DNS .......................................................................51
Firmware Update ................................................................52
Status ........................................................................................ 53
Camera Status......................................................................53
System Info ...........................................................................54
System Log............................................................................55
NVR Log..................................................................................56
Support ..................................................................................57
Live Video................................................................................. 58
General Setting....................................................................... 61
Multiple view........................................................................... 64
Playback ................................................................................... 65
Open Record and Setting ................................................68
Table of Contents

iiiD-Link DNR-322L User Manual
Table of Contents
Search the Recorded Video to Playback.....................70
Recorded Video Enhancement ......................................72
Save Video .............................................................................73
Save Image............................................................................74
Print Image............................................................................75
Page Setting .........................................................................75
Backup the Recorded Video............................................76
Playback Manager Application............................................ 77
Set Connections to the Units..........................................78
Backup and File Manager Application ............................... 79
Verication Tool ...................................................................... 81
Verify Image / Video...........................................................82
Troubleshooting ..................................................................... 83
Choose a RAID Level .............................................................. 85
Replacing or Adding a New Hard Drive.............................. 86
Technical Specications ........................................................ 87
Firmware Specication.......................................................... 87
Hardware Specication ......................................................... 88

1D-Link DNR-322L User Manual
Section 1 - Product Overview
• D-LinkDNR-322LmydlinkNetworkVideoRecorder(NVR)
• CAT5EthernetCable
• PowerAdapter
• CableHolder
• Keys
• ManualandSoftwareonCD
• QuickInstallGuide
Note:Using a power supply with a dierent voltage than the one included with your product
will cause damage and void the warranty for this product.
If any of the above items are missing, please contact your reseller.
Package Contents

2D-Link DNR-322L User Manual
Section 1 - Product Overview
*Hard disk drives should be from the same manufacturer. To ensure maximum performance, identical drives are recommended for RAID 1
congurations.
System Requirements
Hardware Requirements •Oneortwo3.5”SATAharddiskdrive(s)*
Network Requirements
•BroadbandInternetconnection(forremoteaccess)
•Networkcamera(s)(refertotheD-Linkwebsiteforalistofsupportedcameras)
•10/100/1000MbitGigabitEthernetswitchorrouter
Web-based Conguration
Utility Requirements/Remote
PC Minimum Requirements
Computer with the following:
•MicrosoftWindows®7,Vista®,orXP(32bits)
•Pentium4-2.4GHzorhigher
•512MBorhigher
Browser Requirements:
•InternetExplorer7.0orhigher
Make sure you have the latest version of Java installed.Visit www.java.com to download
the latest version.
Optional UPS with USB interface

3D-Link DNR-322L User Manual
Section 1 - Product Overview
Introduction
Congratulations on your purchase of the DNR-322L 2-bay mydlink NVR.
DNR-322LisastandalonewiredNetworkVideoRecorder(NVR)whichsupportsmulti-channelnetworkcameraswithM-JPEG,
MPEG4orH.264recordingwith2high-speed3.5-inchSATAharddisksforlongtimerecording.Thankstothepowerfulembedded
system, the NVR can record video from network cameras located in local or remote sites into a dedicated HDD storage without
turn on PC.
Empowered by Mydlink technology, DNR-322L can be easily setup for internet access. It supports real-time monitoring and
playback from everywhere via IE browser. The triplex function can keep recording while user live viewing or searching playback
at the same time. With complete video management, display and playback ability makes it as a convenient and stable video
recorder.

4D-Link DNR-322L User Manual
Section 1 - Product Overview
Features
Comprehensive IP Surveillance Solution
• Total Solution: The D-Link NVR is a standalone SATA RAID network video recorder capable of 24/7 recording without
a PC. The NVR can manage multiple network cameras, providing direct access to view live video and play recorded
data through the Internet from anywhere anytime. The device itself is compact in size and incorporates a physical
security lock.
• Easy to Use:Auser-friendlyGUIsimpliesnetworkandcamerasetup,allowinguserstoeasilyaccessmultiplecameras
for viewing, recording, playback, and conguration.
• Centralized Interface for Conguration: NVR provides a exible and economic alternative to manage and congure
multiple Network cameras on a centralized web interface.
• Megapixel Resolution Support: The major advantage of digital over analog video is its higher resolution support.
The NVR supports high resolution megapixel recording for vivid video with high clarity.
• Empowered by Mydlink technology: DNR-322L can be easily setup for internet access. It supports real-time monitoring
and playback from everywhere via IE browser.The recording store in your own HDD with high privacy, not in the cloud.
Complete Network Functionality
• PPPoE Support:The D-Link NVR utilizes ADSL services. It can connect to the Internet via an ADSL modem over Ethernet.
• DDNS Support: Dynamic DNS is a solution for users without a xed IP address. With DDNS service, users can connect
to the NVR from the Internet using an easy-to-remember domain name.
• NTP Support: Maintaining an accurate record of time is essential if recorded data is to be used as evidence. To ensure
that the time recording is always accurate, the NVR can update the system clock from an Internet server using the
Network Time Protocol (NTP).
• DHCP Server: The NVR can act as a DHCP server for easy deployment when the network environment is very simple
and there is no existing DHCP server.

5D-Link DNR-322L User Manual
Section 1 - Product Overview
Fully Functional Recording
1. Flexible Recording Schedule: Once cameras have been set up, a highly congurable scheduling system allows
for continuous recording or recording during specically allotted time frames. Each camera can be set to record
independently at preset intervals. It also provides event recording based on specic triggers.
2. Recording Automatic Overwrite: The NVR can be congured to overwrite the oldest data automatically when Hard
Disk space runs out, allowing for continuous and uninterrupted recording. Users can specify the number of days the
recording should be kept (within the limits of the Hard Disk capacity). For example, if the NVR has the capacity to store
7 days of recording, using the overwrite option, the NVR will record the 8th day and delete the 1st day.
3. Recording Stop Alert: The NVR also provides the option to stop recording when the Hard Disk is full. When the disk
reach capacity, a notication can be sent via E-mail or to an external device such as an audible alarm or LED display.
Comprehensive Data and Hardware Security
1. Secure Data: RAID 1 duplicates the recordings database onto two separate drives. In the event of an Hard Disk failure,
data integrity is maintained on the secondary Hard Disk.
2. Auto Boot after Power Recovery:The NVR will boot up automatically once the power is recovered after a power outage.
3. Access List Control: User can specify safe and blocked IP addresses to lter the external connections; this feature
increases data security.
4. Multiple User Privilege Control: Administrators may also choose access privileges for users by specifying the cameras
they may have access to live view, playback, audio, and PTZ functions.
5. UPS Status Monitor: A UPS can be used as emergency power supply for the NVR. The UPS uses a USB interface to notify
the NVR to perform a proper shutdown before battery power runs out.
6. Backup Recording Data: Recorded data is stored in a secure database.This recorded data can be backed up to additional
storage locations periodically or whenever needed.
Powerful Event Management
1. Camera Status: The camera status page will show connection, recording, frame rate and bit rate information of each
camera. Meanwhile, the estimated available recording time is also displayed for quick reference.
2. Flexible Event Management: Event setup is another key conguration of the NVR. The NVR can monitor all of the
camera triggers from motion detection. One of the most powerful functions is notication application. The NVR
centrally controls the E-mail and recording of all the connected cameras.

6D-Link DNR-322L User Manual
Section 1 - Product Overview
Instant Live View
1. Full Screen: Enlarge the display to full screen of live view and recorded video.
2. Drag and Drop GUI: With multiple channels enabled, users can change channel by drag and drop.
3. Camera Name and Status on OSD: Camera name and recording status are displayed via OSD to aid in identication.
4. PTZ/Audio Support: Users can control pan/tilt/zoom (PTZ) functions from within the interface using the provided
interface buttons or by directly clicking on the video. A single camera may be viewed full-screen with optional two-
way audio.
5. Preset Point: Presets from within the interface can be set to instantly restore a previously saved view.
6. Digital Zoom: Videos can be enlarged by digital zoom.
Intelligent Playback
1. AVI/ASF Outputs: During playback, if a user uncovers video that needs to be exported, two formats are available. The
AVI format will export raw video. The ASF le format will transpose a timestamp on the exported video.
2. Playback Speed Control: Playback speed control allows for up to 16x speed fast forward or fast backward play. The
step playback option displays one frame at a time.
3.Video Enhancement: Users can enhance the recorded video with controls such as brightness, contrast, and sharpness.
4. Print Picture: If a printer is connected to the user’s PC, the NVR can also print the selected still image.

7D-Link DNR-322L User Manual
Section 1 - Product Overview
Hardware Overview
Front View
USB Port
Drive LED Power LED
COMPONENT DESCRIPTION
Power Button Press once to power on the NVR. Press and hold the button until the LED begins to blink to power down the NVR.
Power LED Power LED will blink when boot, turn steady when working normal.
Drive LED These LEDs will be solid BLUE when the drives are connected but inactive. The LEDs will blink when the drives
are being accessed, formatted or synchronized. They will illuminate AMBER if a drive has failed.
USB Port USB port for UPS status update.
Power Button

8D-Link DNR-322L User Manual
Section 1 - Product Overview
Rear Panel (Connections)
COMPONENT DESCRIPTION
Cover Lock This lock is used to remove the cover when unlocked. Locking it will restrict the removal of the top cover.
Cooling Fan The cooling fan is used to cool the hard drives and features speed control. When the unit is rst powered on the
fans rotate at a low speed and rotate at a high speed when the temperature rises above 49 °C.
Reset Button Press this button for more than 5 seconds to reset the unit to factory defaults.
Power Receptacle Connect the supplied power cord to the receptacle.
GigabitEthernetPort UsetheGigabitEthernetPorttoconnectthedevicetothelocalnetwork.TheportisequippedwithbothaLAN
LINK(R)andTracLED(L)toindicateconnectivityandtracrespectivelytothelocalLAN
Security Lock This lock can be used to tie the DNR-322L to the desk to prevent theft. Cables are sold separately.
Cover Lock
Cooling Fan
Security Lock
Reset Button
Cable Hook
Power Receptacle
GigabitEthernetPort

9D-Link DNR-322L User Manual
Section 2 - Getting Started
To get started with the NVR Setup Wizard, insert the supplied CD into your CD-ROM drive:
Getting Started
NVR Software CD
Click the Install button to start the NVR Setup
Wizard.

10D-Link DNR-322L User Manual
Section 3 - Installation
Insert the Installation CD-ROM into your computer’s optical drive to start the autorun program.
The CD-ROM will open the NVR Setup Wizard. Simply click Start to go through the Setup Wizard, which will guide you through
the installation process from connecting your hardware to conguring your NVR.
Installation
Setup Wizard
Note: The computer used to access the NVR web-based conguration manager must be on the same subnet as the NVR. If your network is using a DHCP
server, the
NVR will automatically be in the same subnet.

11D-Link DNR-322L User Manual
Section 3 - Installation
Install the Hard Drives
This step shows you how to open your NVR so that you can install one or two hard drives.
Click Next to continue.
Slide either one or two hard drives into the open hard drive bays of your device. Click
Next to continue.

12D-Link DNR-322L User Manual
Section 3 - Installation
Once the hard drives are installed, you can attach the top cover. Click Next to continue.
A standard CAT5E Ethernet cable with a RJ-45 connector is needed to connect your NVR
to your network. Click Next to continue.

13D-Link DNR-322L User Manual
Section 3 - Installation
Power and Device Selection
Connect the power adapter to the power receptor on the back of the device. Press the
power button located under the faceplate LEDs to turn on the device. Click Next to
continue.
With the power on check that the Power LED is solid. If it is solid, answer Yes to the
conrmation window otherwise select No and wait for the power connection to the NVR.
If the connection is good then check that the hard drives are installed correctly and have
no other issues. Click Next to continue.
Note: When you select your device from the list, it will cause the LEDs to blink to conrm
the device selection.

14D-Link DNR-322L User Manual
Section 3 - Installation
Admin password
This window requests the Admin (administrator) password. If this is the rst installation
of this device then the password will be blank. Click Next to continue.
In this step you can create a new password for the Admin username. It is recommended
you set a password however you may also leave the elds blank. Click Next to continue.

15D-Link DNR-322L User Manual
Section 3 - Installation
RAID Conguration and Drive Mapping
Select one of theVolume File Systems type. Clicking on each le system type radio button
will give a description below.
This step allows you to map the volume created as a network drive on your computer.
Click Next to continue.
Note:
1. Only Volume 2 is able to format as a File Server and mount to your Windows system
as a Network Drive.
2.Youcanalsouse“NVRSearch”utilitytosetuptheNetworkDrivemapping.
Click Next to continue.

16D-Link DNR-322L User Manual
Section 3 - Installation
Search Camera
Please connect your network camera(s) to the network and power on.
The NVR will search for your available camera(s) in the local network (LAN) and add it to
the camera list in the NVR.
NVR will use default login ID: admin and blank password to add new camera(s).
If you have an existing camera(s) with a dierent password, you can change the password
in the Password eld in the camera list.
