D-Link DWR-910 User manual

LED STATUS
QUICK INSTALLATION GUIDE
DWR-910 LTE DONGLE ROUTER
ENGLISH
A GLANCE AT DWR-910 LTE DONGLE ROUTER
INSERT SIM AND MICRO SD CARDS
CONNECT THE USB
Push the SIM/Micro SD card into the card slots with the gold contact points facing
upwards.
NOTE! Please insert the SIM/Micro SD card according to the orientation of the
SIM/Micro SD card icon on the device.
The USB on the dongle can be rotated 90° or 180° according to your needs.
1. Rotate the USB to the desired angle.
2. Connect the USB plug on the dongle to the USB input port on your computer.
Ensure the plug is connected rmly.
NOTE! Rotate the antennas 90° for best signal reception.
WEB UI ACCESS
APN SETTINGS
The Web UI allows you to congure advanced settings. To access the Web UI:
1. Connect the DWR-910 LTE Dongle Router to your computer.
2. Enter “192.168.0.1” or “http://dlink.DWR-910” as the URL in your Web
browser to access the Web UI; the Web UI login screen will then appear.
ESTABLISH A NETWORK CONNECTION
The device supports USB Connection and Wi-Fi Connection methods to
access the Internet.
Modem Mode (USB Connection)
Plugging the dongle into your computer’s USB port will allow you to access the
Internet or the Web UI. The device will automatically install driver on rst time
usage.
1. Log in to Web UI.
2. Click the Setup Wizard icon on the main page of the Web UI. The default
APN Prole setting for DWR-910 is set to Auto. The device will match the
APN Prole with your SIM card automatically.
However, if APN Prole cannot be matched, you can enter the related
information manually. For detailed information please refer to your service
provider.
SIM Card Slot
Micro SD Card Slot
MicroSD
LED Indicators
Wi-Fi/ 4G/Signal
Antenna
USB
Antenna
TMTM
WPSButton
Micro SD
MicroSD
90
180
90
180
TMTM
Wi-Fi LTE Signal
Solid Idle Red No data connection
Green Connected with 3G
Purple Connected with 2G
Blue Connected with LTE
Orange Roaming in another
operator’s network
Blinking Number
of clients
currently
connected
to the device
Data traffic Blink once Signal weak
Blink twice Signal fair
Blink three
times
Signal
strong
Router Mode (Wi-Fi connection)
Wi-Fi
1. Search for the Wi-Fi signal broadcast by the device on other client devices
such as a computer, mobile phone, tablet PC, or game console.
2. Establish a connection by selecting the device’s network name (SSID) and
password. The default SSIDs are:
SSID1: dlink_DWR-910_xxxx (Password: 10 digits), user can nd the
default SSID and Wi-Fi key on the label of this device.
SSID2: dlink_DWR-910.1 (This is a hidden SSID. Security method: WPA2;
password: 1234567890).
3. The default settings will allow the device to automatically connect to the
Internet.
Note! If you encounter a WAN connection failure, please login to the Web UI
and congure the APN manually.
