D-Link DMS-3130 Series Manual

Hardware Installation Guide
Product Model: DMS-3130 Series
Layer 3 Stackable Managed Switch
Release 1.00

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
ii
Information in this document is subject to change without notice. Reproduction in any manner whatsoever, without the written
permission of D-Link Corporation, is strictly forbidden.
Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation; Microsoft and Windows are
registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or
their products. D-Link Corporation disclaims any proprietary interest in trademarks and trade names other than its own.
© 2022 D-Link Corporation. All rights reserved.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with this manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at his expense.
CE Mark Warning
This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference.
VCCI Warning
この装置は、クラス A情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こすことがあります。この場合には
使用者が適切な対策を講ずるよう要求されることがあります。VCCI-A.
BSMI Notice
此為甲類資訊技術設備，於居住環境中使用時，可能會造成射頻擾動，在此種情況下，使用者會被要求採取某些適當的對策。
Safety Compliance
Warning: Class 1 Laser Product:
Product shall be used with Class 1 laser device modules certified by CDRH.
Le produit peut être utilisé avec des modules de dispositifs laser de classe 1 certifiés par le CDRH.
•EN: When using a fiber optic media expansion module, never look at the transmit laser while it is powered on. Also, never
look directly at the fiber TX port and fiber cable ends when they are powered on.
•FR: Ne regardez jamais le laser tant qu’il est sous tension. Ne regardez jamais directement le port TX (Tramsmission) à
fibres optiques et les embouts de câbles à fibres optiques tant qu’ils sont sous tension.
SFP (Mini-GBIC), XENPAK, and XFP Regulatory Compliance
Networks pluggable optical modules should meet the following regulatory requirements:
•Class 1.
•IEC/EN60825-1:2007 2nd Edition or later, European Standard
•FCC 21 CFR Chapter 1, Subchapter J in accordance with FDA and CDRH requirements.
•Application of CE Mark in accordance with 2004/108/EEC EMC Directive and the 2006/95/EC Low Voltage Directives.
•UL and/or CSA registered component for North America.
•47 CFR Part 15, Class A when installed into products.
Warning
Class I Equipment. This equipment must be earthed. The power plug must be connected to a properly wired earth ground socket
outlet. An improperly wired socket outlet could place hazardous voltages on accessible metal parts.
Avertissement
Équipement de classe I. Ce matériel doit être relié à la terre. La fiche d'alimentation doit être raccordée à une prise de terre
correctement câblée. Une prise de courant mal câblée pourrait induire des tensions dangereuses sur des parties métalliques
accessibles.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
iii
The machine can only be used in a restricted access location and has installation instructions by a skilled person.
Les matériels sont destinés à être installés dans des EMPLACEMENTS À ACCÈS RESTREINT.
Product shall be used with Class 1 laser device modules certified by CDRH.
Le produit peut être utilisé avec des modules de dispositifs laser de classe 1 certifiés par le CDRH.
62368-1 Clause equipment for installation:
“Suitable for installation in Information Technology Rooms in accordance with Article 645 of the National Electrical Code and NFPA
75.”
Équipement conforme à la clause 62368-1 pour l'installation :
« Convient pour une installation dans les salles informatiques conformément à l'article 645 du National Electrical Code et à la
norme NFPA 75 ».
The device can only be used in a fixed location such as a lab or a machine room. When you install the device, ensure that the
protective earthing connection of the socket-outlet is verified by a skilled person.
Lithium battery Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with same or equivalent type of battery.
Dispose of the batteries according to the instructions of the manufacturer.
PoE Load Condition:
- For AC or DC input: 30W/60W per each PoE port, total: 740W (960W when two PSU are connected) maximum (for DMS-
3130-30PS)
To reduce potential safety issues, only the AC adapter purchased as an accessory from “D-Link”, or “agency” should be used with
the product for further information.
Pour réduire les problèmes de sécurité potentiels, seul l'adaptateur secteur acheté comme accessoire chez « D-Link », ou
« agency », doit être utilisé avec le produit pour plus d'informations.
Intended Readers
The DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide contains detailed information
about the hardware specifications of the switches in this series. It also contains brief information on how to configure
and manage a switch in this series. This manual is intended for advanced level users that are familiar with network
management concepts and terminology. For all practical reasons, all the switches in this series will simply be referred
to as the Switch throughout this manual.
Typographical Conventions
Convention Description
Boldface Font This convention is used to place emphasis on keywords. It also indicates a
button, toolbar icon, menu, menu item, system message, or a prompt
appearing on the screen. For example, click the Apply button.
Initial capital letter This convention is used to indicate a window name or keyboard key. For
example, press the Enter key.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
iv
Convention Description
Blue Courier Font
This convention is used to represent a Command Line Interface (CLI)
example.
Notes and Cautions
NOTE: A note indicates important information that helps you make better use of your device.
CAUTION: A caution indicates a potential for property damage, personal injury, or death.
Safety/Sécurité
Safety Instructions
Please pay careful attention to the following safety guidelines to ensure your own personal safety and to help protect
your system from potential damage.
Safety Cautions
To greatly reduce the risk of physical injury, electrical shock, fire, and damage to equipment, observe the following
precautions.
Observe and follow service markings.
•Do not attempt to service any product, except when it is explained in the system’s documentation.
•Opening or removing covers, marked with a high voltage sign, may expose the user to electrical shock.
•Only a trained service technician should service components inside these compartments.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or contact
your trained service provider:
•Damage to the power cable, extension cable, or plug.
•An object has fallen into the product.
•The product has been exposed to water.
•The product has been dropped or damaged.
•The product does not operate correctly when the operating instructions are correctly followed.
General safety cautions:
•Keep the system away from radiators and heat sources. Also, do not block cooling vents.
•Do not spill food or liquids on system components, and never operate the product in a wet environment. If the
system gets wet contact your trained service provider.
•Do not push any objects into the openings of the system. Doing so can cause fire or electric shock by shorting
out interior components.
•Only use this product with approved equipment.
•Allow the product to cool before removing the cover or touching internal components.
•Operate the product only from the type of external power source indicated on the electrical ratings label. If
unsure of the type of power source required, consult your service provider or local power company.
•Be sure that attached devices are electrically rated to operate with the power available in your location.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
v
•Use only approved power cable(s). If you have not been provided with a power cable for your system or for
any AC-powered option intended for your system, purchase a power cable that is approved for use in your
country. The power cable must be rated for the product and for the voltage and current marked on the
product's electrical ratings label. The voltage and current rating of the cable should be greater than the ratings
marked on the product.
•To help prevent electric shock, plug the system and peripheral power cables into properly grounded electrical
outlets. These cables are equipped with three-prong plugs to help ensure proper grounding. Do not use
adapter plugs or remove the grounding prong from a cable. If using an extension cable is necessary, use a 3-
wire cable with properly grounded plugs.
•Observe the extension cable and power strip ratings. Make sure that the total ampere rating of all products
plugged into the extension cable or power strip does not exceed 80 percent of the ampere ratings limit for the
extension cable or power strip.
•To help protect the system from sudden, transient increases and decreases in electrical power, use a surge
suppressor, line conditioner, or uninterruptible power supply (UPS).
•Position system cables and power cables carefully. Route cables so that they cannot be stepped on or tripped
over. Be sure that nothing rests on any cables.
•Do not modify power cables or plugs. Consult a licensed electrician or your power company for site
modifications. Always follow your local or national wiring rules.
When connecting or disconnecting power to and from hot-pluggable power supplies, observe the following guidelines:
•Install the power supply before connecting the power cable to the power supply.
•Unplug the power cable before removing the power supply.
•If the system has multiple sources of power, disconnect power from the system by unplugging all power
cables from the power supplies.
•Move products with care and ensure that all casters and stabilizers are firmly connected to the system. Avoid
sudden stops and uneven surfaces.
•This equipment is only to be connected to PoE networks without routing to outside plants.
To help avoid damage to the system, be sure that the voltage selection switch, on the power supply, is set to match
the power available at the Switch’s location:
•115V/60Hz is used mostly in North and South America as well as Far Eastern countries like as South Korea
and Taiwan
•100V/50Hz is used mostly in Eastern Japan and 100V/60Hz in Western Japan
•230V/50Hz is used mostly in Europe, the Middle East, Africa and the Far East
CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries
According to the Instructions.
ATTENTION: Risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les piles
usagées selon les instructions.
警告：
如果更換不正確之電池型式會有爆炸的風險。請依製造商說明書處理用過之電池。
CAUTION: Shock hazard
This product is intended to be use with a UL Listed Optical Transceiver product, Rated DC3.3V,
Laser Class I.
ATTENTION: Risque d'électrocution
Ce produit est destiné à être utilisé avec un produit émetteur-récepteur optique répertorié UL, évalué
DC3.3V, classe laser I.
Consignes de sécurité
Veuillez prêter une attention particulière aux consignes de sécurité suivantes pour assurer votre sécurité personnelle
et protéger votre système des dommages potentiels.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
vi
Précautions de sécurité
Pour réduire considérablement les risques de blessure physique, de choc électrique, d'incendie et de détérioration du
matériel, observez les précautions suivantes.
Observez et respectez les marquages relatifs à l'entretien et/ou aux réparations.
•N'essayez pas de réparer un produit, sauf si cela est expliqué dans la documentation du système.
•L'ouverture ou le retrait des capots, signalés par un symbole de haute tension, peut exposer l'utilisateur à un
choc électrique.
•Seul un technicien de maintenance qualifié est habilité à réparer les composants à l'intérieur de ces
compartiments.
Si l'un des cas suivants se produit, débranchez l'appareil du secteur et remplacez la pièce concernée ou contactez
votre prestataire de services agréé.
•Endommagement du câble d'alimentation, du câble de rallonge ou de la fiche.
•Un objet est tombé dans le produit.
•Le produit a été exposé à l'eau.
•Le produit est tombé ou a été endommagé.
•Le produit ne fonctionne pas correctement lorsque les instructions d'utilisation sont correctement suivies.
Précautions générales de sécurité :
•Danger électrique : Seul le personnel qualifié doit effectuer les procédures d'installation.
•Avant de procéder à l'entretien, débranchez tous les cordons d'alimentation pour mettre le périphérique hors
tension.
•Eloignez le système des radiateurs et des sources de chaleur. Par ailleurs, n'obturez pas les fentes
d'aération.
•Ne versez pas de liquide sur les composants du système et n'introduisez pas de nourriture à l'intérieur. Ne
faites jamais fonctionner l'appareil dans un environnement humide. Si le système est mouillé, contactez votre
prestataire de services qualifié.
•N'insérez aucun objet dans les fentes de l'appareil. Vous risqueriez de provoquer un incendie ou un choc
electrique en court-circuitant les composants internes.
•Utilisez ce produit uniquement avec un équipement approuvé.
•Laissez l'appareil refroidir avant de déposer le capot ou de toucher les composants internes.
•Faites fonctionner le produit uniquement avec la source d'alimentation indiquée sur l'étiquette signalétique où
figurent les caractéristiques électriques nominales. Si vous ne savez pas avec certitude quel type de source
d'alimentation est requis, consultez votre prestataire de services ou votre compagnie d'électricité.
•Assurez-vous que les caractéristiques nominales des appareils branchés correspondant à la tension du
réseau électrique.
•Utilisez uniquement des câbles d'alimentation homologués. Si un câble d'alimentation n'est pas fourni pour le
système ou pour un composant/accessoire alimenté par CA destiné au système, procurez-vous un câble
d'alimentation homologué pour une utilisation dans votre pays. Le câble d'alimentation doit être adapté à
l'appareil et ses caractéristiques nominales doivent correspondre à celles figurant sur l'étiquette du produit. La
tension et le courant nominaux du câble doivent être supérieurs aux valeurs nominales indiquées sur
l'appareil.
•Pour éviter tout risque de choc électrique, branchez les câbles d'alimentation du système et des périphériques
à des prises électriques correctement mises à la masse. Ces câbles sont équipés de fiches à trois broches
pour garantir une mise à la masse appropriée. N'utilisez pas d'adaptateur de prise, et n'éliminez pas la broche
de mise à la masse du câble. Si un câble de rallonge est nécessaire, utilisez un câble à 3 fils avec des fiches
correctement mises à la terre.
•Respectez les caractéristiques nominales de la rallonge ou du bloc multiprise. Assurez-vous que l'intensité
nominale totale de tous les produits branchés à la rallonge ou au bloc multiprise ne dépasse pas 80 % de
l'intensité nominale limite de la rallonge ou du bloc multiprise.
•Pour protéger le système contre les pics et les chutes de tension transitoires et soudains, utilisez un
parasurtenseur, un filtre de secteur ou une alimentation sans interruption (ASI).
•Positionnez les câbles système et les câbles d'alimentation avec soin. Acheminez les câbles de manière à ce
qu'ils ne puissent pas être piétinés ou trébuchés. Veillez à ce que rien ne repose sur les câbles.
•Ne modifiez pas les câbles ou les fiches d'alimentation. Contactez un électricien qualifié ou la compagnie
d'électricité si des modifications sur site sont nécessaires. Respectez toujours la règlementation locale ou
nationale en matière de câblage.
Lors de la connexion ou de la déconnexion de l'alimentation vers et depuis des blocs d'alimentation enfichables à

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
vii
chaud, respectez les consignes suivantes :
•Installez l'alimentation avant d'y brancher le câble d'alimentation.
•Débranchez le câble d'alimentation avant de couper l'alimentation.
•Si le système possède plusieurs sources d'alimentation, mettez-le hors tension en débranchant tous les
câbles d'alimentation des prises.
•Déplacez les appareils avec précaution et assurez-vous que les roulettes et/ou que les pieds stabilisateurs
sont bien fixés au système. Évitez les arrêts brusques et les surfaces inégales.
Pour éviter d'endommager le système, assurez-vous que le commutateur de sélection de tension de l'alimentation est
réglé sur l'alimentation disponible à l'emplacement du commutateur :
•115 V/60 Hz est principalement utilisé en Amérique du Nord et du Sud, ainsi que dans des pays d'Extrême-
Orient tels que la Corée du Sud et Taïwan.
•100 V/50 Hz est utilisé principalement dans l'est du Japon et 100 V/ 60 Hz dans l'ouest du Japon.
•230 V/50 Hz est principalement utilisé en Europe, au Moyen-Orient, en Afrique et en Extrême-Orient.
General Precautions for Rack-Mountable Products
Please pay careful attention to the following precautions concerning rack stability and safety. Systems are considered
to be components in a rack. Thus, a component refers to any system, as well as to various peripherals or supporting
hardware:
CAUTION: Installing systems in a rack without the front and side stabilizers installed could cause the
rack to tip over, potentially resulting in bodily injury under certain circumstances. Therefore, always
install the stabilizers before installing components in the rack. After installing system/components in a
rack, never pull more than one component out of the rack on its slide assemblies at one time. The
weight of more than one extended component could cause the rack to tip over and may result in
serious injury.
ATTENTION: Le montage de systèmes sur un rack dépourvu de pieds stabilisateurs avant et
latéraux peut faire basculer le rack, pouvant causer des dommages corporels dans certains cas. Par
conséquent, installez toujours les pieds stabilisateurs avant de monter des composants sur le rack.
Après l'installation d'un système ou de composants dans un rack, ne sortez jamais plus d'un
composant à la fois hors du rack sur ses glissières. Le poids de plusieurs composants sur les
glissières en extension peut faire basculer le rack, pouvant causer de graves dommages corporels.
•Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and
that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front
stabilizers for joined multiple racks before working on the rack.
•Always load the rack from the bottom up, and load the heaviest item in the rack first.
•Make sure that the rack is level and stable before extending a component from the rack.
•Use caution when pressing the component rail release latches and sliding a component into or out of a rack;
the slide rails can pinch your fingers.
•After a component is inserted into the rack, carefully extend the rail into a locking position, and then slide the
component into the rack.
•Do not overload the AC supply branch circuit that provides power to the rack. The total rack load should not
exceed 80 percent of the branch circuit rating.
•Ensure that proper airflow is provided to components in the rack.
•Do not step on or stand on any component when servicing other components in a rack.
CAUTION: Never defeat the ground conductor or operate the equipment in the absence of a suitably
installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if
uncertain that suitable grounding is available.
ATTENTION: Ne neutralisez jamais le conducteur de masse et ne faites jamais fonctionner le
matériel en l'absence de conducteur de masse dûment installé. Contactez l'organisme de contrôle
en électricité approprié ou un électricien qualifié si vous n'êtes pas sûr qu'un système de mise à la
masse adéquat soit disponible.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
viii
CAUTION: The system chassis must be positively grounded to the rack cabinet frame. Do not
attempt to connect power to the system until grounding cables are connected. Completed power and
safety ground wiring must be inspected by a qualified electrical inspector. An energy hazard will exist
if the safety ground cable is omitted or disconnected.
ATTENTION: La carcasse du système doit être positivement reliée à la masse du cadre du rack.
N'essayez pas de mettre le système sous tension si les câbles de mise à la masse ne sont pas
raccordés. Le câblage de l'alimentation et de la mise à la masse de sécurité doit être inspecté par un
inspecteur qualifié en électricité. Un risque électrique existe si le câble de mise à la masse de
sécurité est omis ou débranché.
Protecting Against Electrostatic Discharge
Static electricity can harm delicate components inside the system. To prevent static damage, discharge static
electricity from your body before touching any of the electronic components, such as the microprocessor. This can be
done by periodically touching an unpainted metal surface on the chassis.
The following steps can also be taken to prevent damage from electrostatic discharge (ESD):
•When unpacking a static-sensitive component from its shipping carton, do not remove the component from
the antistatic packing material until ready to install the component in the system. Just before unwrapping the
antistatic packaging, be sure to discharge static electricity from your body.
•When transporting a sensitive component, first place it in an antistatic container or packaging.
•Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads, workbench pads
and an antistatic grounding strap.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
ix
Table of Contents
Intended Readers ........................................................................................................................................................ 3
Typographical Conventions ......................................................................................................................................... 3
Notes and Cautions ..................................................................................................................................................... 4
Safety/Sécurité............................................................................................................................................................. 4
Safety Instructions ....................................................................................................................................................... 4
Safety Cautions ...................................................................................................................................................... 4
Consignes de sécurité ................................................................................................................................................. 5
Précautions de sécurité ............................................................................................................................................... 6
General Precautions for Rack-Mountable Products .................................................................................................... 7
Protecting Against Electrostatic Discharge.................................................................................................................. 8
1. Introduction.............................................................................................................................................................11
Switch Description .....................................................................................................................................................11
Package Contents...................................................................................................................................................... 11
Features ..................................................................................................................................................................... 11
2. Hardware Components ..........................................................................................................................................14
DMS-3130-30TS Switch ............................................................................................................................................ 14
Front Panel Components......................................................................................................................................14
LED Indicators .................................................................................................................................................14
Rear Panel Components ...................................................................................................................................... 16
Side Panel Components ....................................................................................................................................... 16
DMS-3130-30PS Switch ............................................................................................................................................ 17
Front Panel Components......................................................................................................................................17
LED Indicators .................................................................................................................................................18
Rear Panel Components ...................................................................................................................................... 19
Side Panel Components ....................................................................................................................................... 20
3. Installation............................................................................................................................................................... 21
Installation Guidelines................................................................................................................................................21
Installing the Switch without a Rack .......................................................................................................................... 21
Installing the Switch in a Standard 19" Rack ............................................................................................................. 22
Installing Transceivers into the Transceiver Ports.....................................................................................................22
Power On (AC Power) ............................................................................................................................................... 23
Power Failure (AC Power) .................................................................................................................................... 23
Installing Power Cord Retainer............................................................................................................................. 23
Installing the Redundant Power Supply (RPS) .......................................................................................................... 25
DPS-500A Series Redundant Power Supply Unit ................................................................................................ 26
Installing the RPS into a Rack-mount Chassis ..........................................................................................................26
DPS-800 Rack-mount Chassis.............................................................................................................................26
4. Switch Connections ...............................................................................................................................................28
Switch to an End Node ..............................................................................................................................................28
Switch to Another Switch ........................................................................................................................................... 28
Switch Stacking..........................................................................................................................................................29
Switch to a Server......................................................................................................................................................34
5. Switch Management ............................................................................................................................................... 35
Management Options................................................................................................................................................. 35
Connecting to the Console Port ................................................................................................................................. 35
Connecting to the RJ45 Console Port .................................................................................................................. 35
Connecting to the Switch for the First Time..........................................................................................................36
Creating a User Account.......................................................................................................................................37
Configuring the IP Address...................................................................................................................................37

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
x
Connecting to the MGMT Port ...................................................................................................................................38
Connecting using SNMP............................................................................................................................................38
Traps.....................................................................................................................................................................39
Management Information Base (MIB)................................................................................................................... 39
Web-based Switch Configuration................................................................................................................................ 40
Introduction ................................................................................................................................................................40
Logging into the Web UI ............................................................................................................................................40
Web User Interface (Web UI).....................................................................................................................................41
Areas of the Web UI ............................................................................................................................................. 41
Web Pages ........................................................................................................................................................... 42
Appendix A - Technical Specifications....................................................................................................................... 43
General ...................................................................................................................................................................... 43
Physical and Environmental....................................................................................................................................... 43
Performance............................................................................................................................................................... 44
LED Indicators ........................................................................................................................................................... 44
Port Functions............................................................................................................................................................46
Appendix B - Cables and Connectors......................................................................................................................... 48
Ethernet Cable ........................................................................................................................................................... 48
Console Cable (RJ45 to RS-232) .............................................................................................................................. 49
Redundant Power Supply (RPS) Cable.....................................................................................................................50
CE RED Compliance Statement ................................................................................................................................51
Additional Notice ........................................................................................................................................................ 51
Technical Support......................................................................................................................................................... 52

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
11
1. Introduction
Switch Description
Package Contents
Features
Switch Description
The D-Link DMS-3130 Series is a high-performance member of the D-Link Layer 3 switch family. Designed to connect
end-users in a secure enterprise or metro Ethernet access network, the switch family has been future proof to provide
high-performance switching capability with advanced fault tolerance, port density and robust security to suit your
modern network environment.
The DMS-3130 Series has PoE and non-PoE models to support multi-speed Gigabit Ethernet and SFP network
connection options. The PoE model supports Perpetual POE which continues to supply power to connected devices
even during system booting process and it can be automatically disabled when power consumption exceeds the limit.
They provide an affordable solution for administrators to respond to the demand for high-speed Gigabit connections
ranging from 2.5BASE-T to 10GBASE-T to 25G fiber connectivity, which also makes the DMS-3130 Series suitable as
an access solution for large enterprises. The comprehensive security functions including advanced ACL and Storm
Control and IP-MAC-Port Binding (IMPB) with DHCP Snooping on the Switch to extend the network security coverage
from access to edge. The advanced robust features such as redundant power supply and 6 kV surge protection
increase overall reliability, serviceability, and availability.
This series of switches has 10 Gbps RJ45 ports and 25 Gbps SFP28 ports. The Small Form-factor Portable Pluggable
28 (SFP28 or optional SFP+) ports are used with fiber-optical transceiver cabling to uplink various other networking
devices for a 10 or 25 gigabit link that may span great distances. Furthermore, the SFP28 ports may be used to
physically stack the Switch with other switches in this series.
The D-Link DMS-3130 Series includes the following switches:
•DMS-3130-30TS supports twenty-four 2.5 Gigabit RJ45 ports (100 Megabit/1 Gigabit/2.5 Gigabit), two 10
Gigabit RJ45 ports (100 Megabit/1 Gigabit/2.5 Gigabit/5 Gigabit/10 Gigabit), and four SFP28 ports (10/25
Gigabit).
•DMS-3130-30PS supports sixteen 2.5 Gigabit PoE RJ45 ports (100 Megabit/1 Gigabit/2.5 Gigabit), eight 5
Gigabit PoE RJ45 ports (100 Megabit/1 Gigabit/2.5 Gigabit/5 Gigabit), two 10 Gigabit RJ45 ports (100
Megabit/1 Gigabit/2.5 Gigabit/5 Gigabit/10 Gigabit), and four SFP28 ports (10/25 Gigabit).
Package Contents
Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following
items:
•One DMS-3130 Series switch.
•One Quick Installation Guide.
•One AC power cord.
•One console cable (RJ45 to RS-232).
•One rack mounting kit (two brackets and screws for DMS-3130-30TS and four brackets and screws for DMS-
3130-30PS).
•Four rubber feet with adhesive backing (only available for DMS-3130-30TS).
•One power cord retainer set (only available for DMS-3130-30TS).
If any item is missing or damaged, please contact your local D-Link reseller for replacement.
Features
This switch is packed with an abundance of networking features that span inside and outside of the traditional Layer 3
framework. The list below highlights the significant protocols and features supported by this switch.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
12
Features that can be found on this switch are:
•Virtual Stacking. D-Link Single IP Management
(SIM)
•Physical Stacking, using the 10GBase-T
and/or SFP28 (SFP+) ports with 80G or 200G
(full-duplex) in Chain or Ring topology
•Jumbo Frames (9K Bytes)
•Spanning Tree Protocol (STP, RSTP, and
MSTP)
•Ethernet Ring Protection Switching (ERPS)
•Link Aggregation
•Mirroring (Port Mirroring, VLAN Mirroring,
Flow-based (ACL) Mirroring, and RSPAN)
•Loopback Detection (LBD)
•L2 Protocol Tunneling
•IGMP Snooping (Version 1, 2, and 3)
•MLD Snooping (Version 1 and 2)
•802.1Q VLAN, Port-based VLAN, 802.1v
Protocol-based VLAN , MAC-based VLAN,
Voice VLAN, Surveillance VLAN, Private
VLAN, Asymmetric VLAN, VLAN Trunking,
and GVRP
•Double VLAN (Q-in-Q), Selective Q-in-Q, and
VLAN Translation
•ISM VLAN (Multicast VLAN)
•Gratuitous ARP
•ARP Proxy
•IPv6 Neighbor Discovery (ND)
•Virtual Router Redundancy Protocol
(VRRPv2/VRRPv31)
•Equal-Cost Multi-Path Route (ECMP)
•Policy-based Route (PBR)
•Route Preference Setting
•Route Redistribution
•Routing Information Protocol (RIPv1/RIPv2),
and RIPng
•Class of Service (CoS)
•Two-rate Three-color Marker (trTCM)
•Policy Map (Remark 802.1p priority, Remark
ToS/DSCP, Rate Limiting, and Time-based
QoS)
•Queue Handling: Strict Priority Queue (SPQ),
Weighted Round Robin (WRR), and Weight
Deficit Round Robin (WDRR)
•Congestion Control: Weighted Random Early
Detection (WRED), Simple Random Early
Detection (SRED), Port-based Bandwidth
Control, Flow-based bandwidth Control, and
Queue-based Bandwidth Control
•Access Control List (ACL): IP Access List,
IPv6 Access List, Time-based ACL, and CPU
Interface Filtering
•Secure Shell (SSHv2) IPv4/IPv6
•Secure Sockets Layer for IPv4/IPv6
•Port Security
•Broadcast, Multicast, and Unicast Storm
Control
•Traffic Segmentation
•IP-MAC-Port Binding (IMPB)
•IP Source Guard (IPv4/IPv6)
•DHCP Snooping
•IPv6 Snooping
•Dynamic ARP Inspection (DAI)
•DHCPv6 Guard
•IPv6 Route Advertisement (RA) Guard
•IPv6 ND Inspection
•D-Link Safeguard Engine
•Layer 3 Control Packet Filtering
•NetBIOS/NetBEUI Filtering
•DHCP Server Screening (IPv4/IPv6)
•DHCP Client Filtering
•ARP Spoofing Prevention
•BPDU Attack Protection
•DoS Attack Prevention
•Authentication, Authorization, and Accounting
(AAA)
•RADIUS/TACACS+ Accounting (IPv4/IPv6)
•802.1X Network Access Control
•Web-based Access Control (WAC)
•MAC-based Access Control (MAC)
•Compound Authentication
•Guest VLAN
•Microsoft®NAP Support (IPv4/IPv6)
•Cable Diagnostics
•802.3ah Ethernet Link OAM
•802.1ag Connectivity Fault Management
(CFM)
•Y.1731 OAM
•Optical Transceiver Digital Diagnostic
Monitoring (DDM)
•D-Link Unidirectional Link Detection (DULD)

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
13
•Network Time Protocol (NTP) IPv4/IPv6
•Simple Network Time Protocol (SNTP)
IPv4/IPv6
•Link Layer Discovery Protocol (LLDP), and
LLDP-MED
•User Account Privilege for Management
Access
•Command Line Interface (CLI)
•Simple Network Management Protocol
(SNMPv1/SNMPv2c/SNMPv3) IPv4/IPv6
•Remote Network Monitoring
(RMONv1/RMONv2)
•SNMP Trap
•Web User Interface (Web UI)
•D-Link Discover Protocol (DDP)
•DHCP Server and Client, and DHCP Auto-
configuration (IPv4/IPv6)
•DHCP Relay (IPv4/IPv6)
•Telnet Server and Client
•TFTP Client (IPv4/IPv6)
•Secured FTP (SFTP) Server (IPv4/IPv6)
•System Log and Command Logging
•SMTP (IPv4/IPv6)
•Multiple Image and Configuration, and Flash
File System (FFS)
•Password Recovery and Encryption
•Debug Command
•CPU and Port Utilization Monitoring, and
Packets Counter
•Trap and Log Severity Control
•Traceroute and Ping (IPv4/IPv6)
•Microsoft®Network Load Balancing (NLB)
•sFlow (IPv4/IPv6)

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
14
2. Hardware Components
This chapter describes the front, rear, and side panel components of all switches in the series.
DMS-3130-30TS Switch
DMS-3130-30PS Switch
DMS-3130-30TS Switch
Front Panel Components
The front panel of DMS-3130-30TS features a variety of LED indicators and ports.
Figure 2-1 Front panel view of the DMS-3130-30TS
Ports that can be found on the front panel of this switch are listed in the table below.
Port Description
USB Inserting a flash drive into the USB 2.0 Type-A port provides an additional storage
space for portable firmware images and configuration files that can be copied to
and from the NVRAM of the Switch.
MGMT The RJ45 Management (MGMT) port is an IP-based, Out-Of-Band (OOB) port for
Telnet, web, or SNMP management that operates at 10/100/1000 Mbps wire-
speed. This port can be used to configure the Switch without being connected to
the network.
The MGMT port can also be used to supply the Switch with 90W DC power using
Power over Ethernet (PoE). This can be used as the main power source or as the
secondary power source to the Switch.
Console (RJ45) The RJ45 console port can be used to connect to the Command Line Interface
(CLI) of the Switch for configuration, management, and monitoring. This port uses
a special console cable (included in this package) with a RJ45-to-Serial interface
to connect the Switch and the serial port (COM) of the PC.
2.5GBASE-T RJ45 Ports The Switch is equipped with 24 RJ45 Ethernet ports. These ports can operate at
100 Mbps, 1 Gbps, or 2.5 Gbps wire-speed.
10GBASE-T RJ45 Ports The Switch is equipped with 2 RJ45 Ethernet ports. These ports can operate at 100
Mbps, 1 Gbps, 2.5 Gbps, 5 Gbps, or 10 Gbps wire-speed.
25 Gigabit SFP28 Ports The Switch is equipped with 4 SFP28 (or optional SFP+) ports. These ports can
operate at 10 Gbps or 25 Gbps wire-speed and support a wide collection of SFP+
or SFP28 transceivers.
For a complete list of SFP transceivers that are compatible with this switch, refer to the Port Functions sections in
Appendix A - Technical Specifications.
LED Indicators
Located on the front panel of this switch are LED indicators: Power, Console, RPS, Fan Err, USB, Link/Act indicators
for all the ports, and Stack ID.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
15
Figure 2-2 LED indicators for the DMS-3130-30TS
LED Description
This LED will light solid green after the Switch has been powered on successfully.
This LED will be off when the Switch is no longer receiving power (i.e. powered
off).
Console This LED will light solid green when the console port is active.
This LED will be off when the console port is not active.
MGMT The Left LED indicates the status of MGMT port.
This LED will light solid green (1000 Mbps) or amber (10/100Mbps) after a link to
the MGMT port was successfully established.
This LED will blink when activity on this port is taking place.
This LED will be off when MGMT port is not active.
The Right LED indicates the status of receiving power from a PSE.
The LED will light solid green when it is receiving power from a PSE.
The LED will light solid amber when power supply is in an error state.
The LED is off when there is no PSE connected to the port.
RPS This LED will light green when the Redundant Powers Supply is in use.
This LED will be off when the RPS is not in use.
Fan Error This LED will light solid red when the fan fails.
This LED will be off when the fan is operating normally.
USB This LED will light solid green if a USB flash drive is plugged in.
This LED will blink green when the Switch is reading or writing data to and from
the USB drive.
This LED will be off when no USB drive is plugged into the USB port.
Link/Act/Speed LEDs The Switch has LED indicators for Link and Activity.
2.5G RJ45 Ports (No.1~24):The LED at the left side indicates the Link/Act/Speed
status of 2.5G RJ45 ports. This LED will light solid green when there is a
connection (or link) to a 2.5 Gbps Ethernet device or solid amber when there is a
connection (or link) to a 100/1000 Mbps Ethernet device on any of the RJ45 ports.
The LED will blink green when a 2.5 Gbps port is active or blink amber when a
100/1000 Mbps port is active. The LED will be off when there is no link or activity.
The LED at the right side has no LED notification.
10G RJ45 Ports (No. 25~26):The left LED will light solid green when there is a
connection (or link) to a 2.5/5/10 Gbps Ethernet device; the right LED will light
solid amber when there is a connection (or link) to a 100/1000 Mbps Ethernet
device on any of the RJ45 ports. The left LED will blink green when a 2.5/5/10
Gbps port is active; the right LED will blink amber when a 100/1000 Mbps port is
active. The LED will be off when there is no link or activity.
SFP28 Ports (No. 27~30):The triangle LED indicates the Link/Act/Speed status
of 25G SFP28 ports. This LED will light solid green when there is a connection (or
link) to a 25 Gbps Ethernet device or solid amber when there is a connection (or
link) to a 10 Gbps Ethernet device on any of the SFP28 ports. The LED will blink

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
16
LED Description
green when a 25 Gbps port is active or blink amber when a 10 Gbps port is active.
The LED will be off when there is no link or activity.
Stack ID This 7-segment LED can display numbers from 1 to 9 and the following letters H,
h, E, and G. The stacking ID (1 to 9) can be assigned manually by the user or
automatically by the system.
The letter ‘H’ will be displayed if this switch is the master switch in the stack.
The letter ‘h’ will be displayed if this switch is the backup master switch in the
stack.
The letter ‘E’ will be displayed if there was an error in the system’s self-test.
The letter ‘G’ will be displayed when the Safeguard engine entered the
exhausted mode.
Please refer to the “LED Indicators” section in the Appendix A - Technical Specifications for more LED information.
Rear Panel Components
The rear panel of this switch features a security lock, a GND, an AC power connector, a power cord retainer hole, and
an outlet for an external redundant power supply.
Figure 2-3 Rear panel view of the DMS-3130-30TS
Components that can be found on the rear panel of this switch are listed in the table below.
Component Description
Security Lock Provide a Kensington-compatible security lock to be able to connect to a secure
immovable device. Insert the lock into the notch and turn the key to secure the
lock. The lock-and-cable apparatus should be purchased separately.
Switch GND Use an electrical grounding wire and connect one end of the wire to the Switch
GND and the other end of the wire to an electrical grounding point most commonly
found on the Switch mounting rack itself.
AC Power Connector The AC power cord with a three-pronged AC power connector can be plugged into
this receptacle to supply the Switch with 100-240 VAC power at 50-60 Hz.
Power Cord Retainer Hole The power cord retainer hole is used to insert the power cord retainer to secure
the AC power cord.
Redundant Power Supply An optional external RPS can be plugged into the RPS port found on the rear
panel. When the internal power fails, this optional external RPS will supply power
to the Switch immediately and automatically. The metal cover plate should be
mounted if there’s no RPS be plugged.
Side Panel Components
The side panels of this switch contain heat vents, fans, and rack-mounting screw holes. The heat vents are used to
dissipate internal heat and facilitate internal air circulation. Do not block these openings. Leave at least 4 inches of
space at the sides of the Switch for proper ventilation. Without proper heat dissipation and air circulation, system
components might overheat which could lead to system failure or even severely damaged components.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
17
Figure 2-4 Side panels of the DMS-3130-30TS
DMS-3130-30PS Switch
Front Panel Components
The front panel of DMS-3130-30PS features a variety of LED indicators and ports.
Figure 2-5 Front panel view of the DMS-3130-30PS
Ports that can be found on the front panel of this switch are listed in the table below.
Port Description
USB Inserting a flash drive into the USB 2.0 Type-A port provides an additional storage
space for portable firmware images and configuration files that can be copied to
and from the NVRAM of the Switch.
MGMT The RJ45 Management (MGMT) port is an IP-based, Out-Of-Band (OOB) port for
Telnet, web, or SNMP management that operates at 10/100/1000 Mbps wire-
speed. This port can be used to configure the Switch without being connected to
the network.
Console (RJ45) The RJ45 console port can be used to connect to the Command Line Interface
(CLI) of the Switch for configuration, management, and monitoring. This port uses
a special console cable (included in this package) with a RJ45-to-Serial interface
to connect the Switch and the serial port (COM) of a PC.
2.5GBASE-T RJ45 PoE
Ports
The Switch is equipped with 16 RJ45 Ethernet ports. These ports can operate at
100 Mbps, 1 Gbps, or 2.5 Gbps wire-speed. These PoE ports are compliant to
IEEE802.3af and IEEE802.3at.
5GBASE-T RJ45 PoE Ports The Switch is equipped with 8 RJ45 Ethernet ports. These ports can operate at 100
Mbps, 1 Gbps, 2.5 Gbps, or 5 Gbps wire-speed. These PoE ports are compliant to
IEEE802.3af, IEEE802.3at, and IEEE802.3bt.
10GBASE-T RJ45 Ports The Switch is equipped with 2 RJ45 Ethernet ports. These ports can operate at 100
Mbps, 1 Gbps, 2.5 Gbps, 5 Gbps, or 10 Gbps wire-speed.
25 Gigabit SFP28 Ports The Switch is equipped with 4 SFP28 (or optional SFP+) ports. These ports can
operate at 10 Gbps or 25 Gbps wire-speeds and support a wide collection of SFP+
or SFP28 transceivers.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
18
For a complete list of SFP transceivers that are compatible with this switch, refer to Port Functions in Appendix A -
Technical Specifications.
LED Indicators
Located on the front panel of this switch are LED indicators: Power, Console, RPS, Fan Err, USB, Link/Act indicators
for all the ports, and Stack ID.
Figure 2-6 LED indicators for the DMS-3130-30PS
LED Description
Power This LED will light solid green after the Switch has been powered on
successfully.
This LED will be off when the Switch is no longer receiving power (i.e.
powered off).
Console This LED will light solid green when the console port is active.
This LED will be off when the console port is not active.
MGMT The LED at the left side indicates the status of MGMT port.
This LED will light solid green (1000 Mbps) or amber (10/100Mbps) after a
link to the MGMT port was successfully established.
This LED will blink when activity on this port is taking place.
This LED will be off when MGMT port is not active.
The LED at the right side has no LED notification.
RPS This LED will light green when the Redundant Powers Supply is in use.
This LED will be off when the RPS is not in use.
Fan Error This LED will light solid red when the fan fails.
This LED will be off when the fan is operating normally.
USB This LED will light solid green if a USB flash drive is plugged in.
This LED will blink green when the Switch is reading or writing data to and
from the USB drive.
This LED will be off when no USB drive is plugged into the USB port.
Link/Act/Speed LEDs & PoE LEDs
The Switch has LED indicators for Link and Activity.
2.5G RJ45 Ports (No. 1~16):The left LED indicates the Link/Act/Speed
status of 2.5G RJ45 ports. This LED will light solid green when there is a
connection (or link) to a 2.5 Gbps Ethernet device or solid amber when
there is a connection (or link) to a 100/1000 Mbps Ethernet device on any
of the RJ45 ports. The LED will blink green when a 2.5 Gbps port is active
or blink amber when a 100/1000 Mbps port is active. The LED will be off
when there is no link or activity.
5G RJ45 Ports (No. 17~24):The left LED indicates the Link/Act/Speed
status of 5G RJ45 ports. This LED will light solid green when there is a
connection (or link) to a 2.5 or 5 Gbps Ethernet device or solid amber when
there is a connection (or link) to a 100/1000 Mbps Ethernet device on any
of the RJ45 ports. The LED will blink green when a 2.5/5 Gbps port is

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
19
LED Description
active or blink amber when a 100/1000 Mbps port is active. The LED will be
off when there is no link or activity.
PoE LED (No. 1~24): The right LEDs of the above ports indicate power
supply status. This LED will light solid green when there is a PoE device
connected to the port and is receiving power from the port. This LED will
light amber to indicate an error state in power supply. The LED is off when
there is no PD connected to the port.
10G RJ45 Ports (No. 25~26):The left LED will light solid green when there
is a connection (or link) to a 2.5/5/10 Gbps Ethernet device; the right LED
will light solid amber when there is a connection (or link) to a 100/1000
Mbps Ethernet device on any of the RJ45 ports. The left LED will blink
green when a 2.5/5/10 Gbps port is active; the right LED will blink amber
when a 100/1000 Mbps port is active. The LED will be off when there is no
link or activity.
SFP28 Ports (N0. 27~30):The triangle LED indicates the Link/Act/Speed
status of 25G SFP28 ports. This LED will light solid green when there is a
connection (or link) to a 25 Gbps Ethernet device or solid amber when
there is a connection (or link) to a 10 Gbps Ethernet device on any of the
SFP28 ports. The LED will blink green when a 25 Gbps port is active or
blink amber when a 10 Gbps port is active. The LED will be off when there
is no link or activity.
Stack ID This 7-segment LED can display numbers from 1 to 9 and the following
letters H, h, E, and G. The stacking ID (1 to 9) can be assigned manually by
the user or automatically by the system.
The letter ‘H’ will be displayed if this switch is the master switch in the
stack.
The letter ‘h’ will be displayed if this switch is the backup master switch in
the stack.
The letter ‘E’ will be displayed if there was an error in the system’s self-test.
The letter ‘G’ will be displayed when the Safeguard engine entered the
exhausted mode.
Please refer to the “LED Indicators” section in the Appendix A - Technical Specifications for more LED information.
Rear Panel Components
The rear panel of this switch features a GND and two hot-pluggable power supplies.
Figure 2-7 Rear panel view of the DMS-3130-30PS
Components that can be found on the rear panel of this switch are listed in the table below.

DMS-3130 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
20
Component Description
Switch GND Use an electrical grounding wire and connect one end of the wire to the Switch
GND and the other end of the wire to an electrical grounding point most commonly
found on the Switch mounting rack itself.
Redundant Power Supply A hot-pluggable RPS can be plugged into the RPS port found on the rear panel of
the Switch. When one of the two RPS units fails, the other one will supply power
to the Switch immediately and automatically.
RPS LED:
Thehot-pluggable RPS carries a LED which stays green or red. When it is solid
green, it shows that the power unit is working. When it is flashing green, it
indicates the power is at 12Vsb. When it is solid amber, it indicates that RPS
stops working due to lost power input. It can also indicate critical events such as
fan failure or over-current protection. When it is flashing amber, it shows that RPS
is still working but requires maintenance due to high temperature or high current
or fan in slow speed.
RPS LED
AC Power Connector AC Power Connector:
The AC power cord with a three-pronged AC power connector can be plugged into
this receptacle of the RPS to supply the Switch with 100-240 VAC power at 47-63
Hz.
Side Panel Components
The side panels of this switch contain heat vents, fans, and rack-mounting screw holes. The heat vents are used to
dissipate internal heat and facilitate internal air circulation. Do not block these openings. Leave at least 4 inches of
space at the sides of the Switch for proper ventilation. Without proper heat dissipation and air circulation, system
components might overheat which could lead to system failure or even severely damaged components.
Figure 2-8 Side panels of the DMS-3130-30PS
