INSTRUCTION BOOK FOR
Perm Wall Frame

2
Perm Wall Installation
The Perm Wall frame should be fastened to a wall. The frame is not designed for “lying” installations.
1. Assemble frame sections together by inserting plastic corner
brackets to tubes and securing the corners with #12 sheet
metal screws. If you have a larger jointed frame, insert steel
bracket on one section of frame into other section matching
the color code. Insert 1032 screw through tube and bracket
and fasten with wing nut.
NOTE: If the viewing surface is attached to the frame before
the frame is secured to the wall, the frame may bow.
2. Place bottom of frame at desired height on wall. Make sure
bottom is level. Drill through aluminum tubing every 18" to 24"
and fasten to wall with appropriate fastener (not supplied) for
type of wall construction.
NOTE: Use appropriate fastener for wall construction, i.e.
wood screws if wall behind frame is wood construction or
other appropriate fastener if dry wall or plaster or cement
block construction.
3. Make sure that sides are at 90 degrees or right angle to
bottom and fasten to wall in like manner. Next fasten top of
frame to wall in the same manner, making sure that the
center is the same distance from the bottom as it is at the
sides of frame. This is most important for proper surface it.
NOTE: If a center spreader is shipped with frame, insert
center spreader between the bottom and the top of frame as
a guide. This is most important to insure that the top and
bottom are equal distance apart across the entire top of
frame. Lack of care in this regard will result in poor it of
surface. Center spreader can be removed once top of frame
is fastened to the wall.
4. Carefully snap surface onto frame. This completes
the installation.

3
Cleaning
Da-Mat®, High Contrast Da-Mat®, Pearlescent, Cinema Vision,
High Contrast Cinema Vision, High Contrast Cinema Perf,
Audio Vision, High Contrast Audio Vision, Da-Tex® (Rear) and
Dual Vision surfaces can be cleaned as follows:
Using a white clean cloth (100% cotton preferred) that is
dampened with clear water, gently wipe the area in one direction.
Do not use a circular motion. Using a dry 100% cotton cloth,
wipe dry after each cleaning session. To clean a stubborn stain
or a sticky surface, use denatured alcohol (methanol or methyl
alcohol) following the same procedure as for water.
Corner Plastic Bracket
Frame
Tubing
#12 Sheet Metal
Screw
Detail View Of
Frame Corner
Color Coded
Bands To
Simplify
Assembly (For
Large Screens
With Width 96"
And Over)
Binding With
Snap Buttons
Precisely
Placed
Studs For
Snap
Buttons
Wing Nut Concealed
By Binding
Detail View Of
Frame Joint
Anodized
Aluminum Frame
Steel Bracket
Frame Tubing
Surface

LIMITED ONE YEAR WARRANTY ON DALITE PRESENTATION PRODUCTS
Milestone AV Technologies LLC warrants certain Da-Lite branded products to the original purchaser only, to be free from defects in
materials and workmanship for a period of one (1) year from the date of purchase by the original purchaser; provided they are properly
operated according to Da-Lite's instructions and are not damaged due to improper handling or treatment after shipment from the
factory.
This warranty does not apply to equipment showing evidence of misuse, abuse or accidental damage, or which has been tampered
with or repaired by a person other than authorized Da-Lite personnel.
Da-Lite’s sole obligation under this warranty shall be to repair or to replace (at Da-Lite’s option) the defective part of the merchandise.
Returns for service should be made to your Da-Lite dealer. If it is necessary for the dealer to return the screen or part to Da-Lite,
transportation expenses to and from Da-Lite are payable by the purchaser and Da-Lite is not responsible for damage in shipment.
To protect yourself against damage or loss in transit, insure the product and prepay all transportation expenses.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WARRANTIES AS TO FITNESS FOR USE AND MERCHANTABILITY. Any implied warranties of itness for use,
or merchantability, that may be mandated by statute or rule of law are limited to the one (1) year warranty period. This warranty gives
you speciic legal rights, and you may also have other rights, which vary from state-to-state. TO THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, NO LIABILITY IS ASSUMED FOR EXPENSES OR DAMAGES RESULTING FROM INTERRUPTION IN OPERATION
OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE.
In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137,
Warsaw, IN 465810137, (574) 2678101, (800) 6223737.
IMPORTANT: THIS WARRANTY SHALL NOT BE VALID AND DALITE BRANDED PRODUCTS SHALL NOT BE BOUND BY THIS
WARRANTY IF THE PRODUCT IS NOT OPERATED IN ACCORDANCE WITH THE DALITE WRITTEN INSTRUCTIONS.
Keep your sales receipt to prove the date of purchase and your original ownership.
