Instruction Book for
LARGE COSMOPOLITAN® ELECTROL®
The Da-Lite Difference.
DA-LITE SCREEN COMPANY LLC
3100 North Detroit Street
Post Office Box 137
Warsaw, IN 46581-0137 USA
P 800-622-3737 / 574-267-8101
F 877-325-4832 / 574-267-7804
www.da-lite.com
e-mail: [email protected]

1
Carefully unpack screen and remove outer wrapping from case.
Remove the black tape and rubber bands from the slat bar after the
case has been installed.
The Large Cosmopolitan®Electrol®comes with brackets to allow for
wall mount or ceiling mount installations. Procedures for each
method are as follows:
Wall Mount
1. The wall mount bracket should be fastened to wall studs or
some reinforcement within the wall. Concrete or brick walls
require special fasteners and anchors.
2. The wall bracket has holes spaced at 16" and 24" to align with
most wall studs.
3. The bracket must be level and plumb.
4. Keep in mind you will need at least 2-3/4" between the ceiling
and the top of the wall mount bracket to be able to position
the case on the bracket.
5. Mount the screen case on the wall bracket as shown in
figure 1. Be sure the case is fully seated on the bracket.
Tighten the stop screws against the wall bracket.
Ceiling Mount
1. Be sure the ceiling has adequate reinforcement to attach the
screen brackets.
2. Attach the ceiling brackets to the wall mount bracket using
the supplied 5/16" x 3/4" bolts, washers and nuts.
3. Position the ceiling bracket assembly on the ceiling and
attach with 5/16" bolts (not supplied). The bolts should be
long enough to pass through the drywall or ceiling tile and
penetrate at least 1-1/2" into the reinforcement in the ceiling.
4. Mount the screen on the wall bracket as shown in figure 2.
Be sure the case is fully seated on the bracket. Tighten the
stop screws against the wall bracket.
INSTALLATION
CASE HOOK
VIEWING SURFACE
(AUDIENCE SIDE)
FIGURE 2
FIGURE 1
2"
VIEWING SURFACE
(AUDIENCE SIDE)
CASE HOOK
WALL
MOUNT
BRACKET
STOP SCREW
CEILING
MOUNT
BRACKET
5/16x3/4" BOLT,
NUT AND
LOCK WASHER
WALL MOUNT
BRACKET
STOP SCREW
1-1/8"
IMPORTANT SAFETY INSTRUCTIONS
When using your video equipment, basic safety precautions should always be followed, including the following:
1. Read and understand all instructions before using.
2. To reduce the risk of electric shock, do not disassemble this appliance. Contact an authorized service dealer when
repair work is required. Incorrect reassembly can cause electric shock when the appliance is used subsequently.
3. The use of an accessory attachment not recommended by the manufacturer may cause a risk of fire, electric shock,
or injury to persons.
SAVE THESE INSTRUCTIONS

2
LARGE COSMOPOLITAN®ELECTROL®INSTALLATION FOR SCREENS WITHOUT A BUILT-IN LOW VOLTAGE
CONTROL
Internal wiring has been completed at the factory. Installer must route power to the wall switch and to the junction box
located on the left end of the screen case.
See wiring diagram below for wire connections.
NOTE: This screen can only be controlled by a single 120VAC or 240VAC wall switch. To use multiple switches, an optional low
voltage control must be used.
240 VOLT WIRING DIAGRAM FOR STANDARD WALL SWITCH:
Da-Lite offers two styles of 240 volt wall switches for standard operation.
Please see wiring diagram in wall switch boxes included with screen.
UP
OFF
DOWN
THIS SWITCH CAN NOT
BE USED WITH LVC.
120V WIRING DIAGRAM FOR
STANDARD WALL SWITCH
SPDT SWITCH WITH
CENTER OFF
AC (COMMON)
AC HOT 120VAC 60HZ 1 AMP
BLACK/YELLOW
BLACK
RED
WHITE RED (UP) BLACK (DOWN)
JUNCTION BOX
LOCATED IN
LEFT ENDCAP WHITE
RED
BLACK
GREEN
MOTOR
NOTE: A SINGLE SWITCH CANNOT BE
USED TO OPERATE MORE THAN
ONE SCREEN. CONTACT THE
FACTORY FOR FURTHER
INFORMATION.

3
SETTING THE UP LIMIT POSITION
CAUTION: Do not allow the slat bar to wrap over the top of the roller when the screen is rolling into the case. The screen could
be damaged.
SCREEN TRAVELS INTO CASE TOO FAR:
Turn the up limit switch screw clockwise to decrease the amount of travel. Run the screen up to test the stop
position. If the screen does not stop properly, lower the screen about one foot and turn the limit switch again.
Repeat until the desired position is set.
SCREEN DOES NOT TRAVEL FAR ENOUGH INTO CASE:
Turn the up limit switch screw counterclockwise to increase the amount of up travel. Run the screen up to test the
stop position. If more travel is desired, lower the screen about one foot and adjust the limit switch again. Repeat
until the desired position is set.
SCREEN AdjUSTMENT FOR SCREENS WITHOUT A BUILT-IN LOW VOLTAGE CONTROL
s
!
Screen travel is stopped automatically in the down and up positions by the limit switches that are preset at the factory.
No further adjustment is necessary.
If you need to make minor stop position adjustments see the appropriate step below.
SETTING THE DOWN LIMIT POSITION
NOTE: One turn of the limit screw equals approximately 2" of screen travel.
TO REDUCE SCREEN DROP:
Turn the down limit switch screw clockwise to decrease the
amount of screen drop. Run the screen down to test the stop
position. If the screen drops too far, raise the screen about one foot
and adjust the limit switch again. Repeat until the desired position
is set.
TO INCREASE SCREEN DROP:
Turn the down limit switch screw counterclockwise to increase the amount of screen drop. Run the screen down
to test the stop position. If the screen does not drop enough, raise the screen about one foot and adjust the limit
switch again. Repeat until the desired position is set. Do not adjust for more drop than what was ordered. At least
1-1/2 wraps of fabric must remain on the roller.
UP LIMIT SWITCH ACCESS
THROUGH CASE OPENING
FIGURE 3
DOWN LIMIT
SWITCH
ACCESS HOLE

4
LARGE COSMOPOLITAN®ELECTROL®INSTALLATION FOR 120V SCREENS WITH A BUILT-IN LOW VOLTAGE
CONTROL
FIGURE 4
120V WIRING DIAGRAM
WITH OPTIONAL BUILT-IN
LOW VOLTAGE CONTROL
GROUND–MUST BE
CONNECTED TO
BUILDING GROUND
RJ-14 PIN-OUTS
(TAB IS FACING UP)
IMPORTANT NOTE:
The wall switch is REQUIRED to make any limit switch
adjustments, EVEN if a third party control system is
used. Therefore, it is advised to wire the switch or
provide a 3-conductor connection that is accessible.
UP
STOP
DOWN
POWER INPUT 120VAC / 60HZ
GREEN (GROUND)
BLACK (HOT)
WHITE (COMMON)
POWER WIRE
DATA
CABLE
RJ-45 JACK
RJ-45
RECEPTACLE
RJ-22
OUTPUT
RJ-22
JACK
RJ-22
INPUTS
RJ-22
JACK
LED
UP LIMIT
TACTILE
BUTTON
DOWN LIMIT
TACTILE
BUTTON
FRONT OF
WALL SWITCH
BACK OF
WALL SWITCH
RJ-22 PIN-OUTS
(TAB IS FACING UP)
RJ-45 PIN-OUTS
(TAB IS FACING UP)
Standard RJ-22 can be used in place of RJ-14Supplied RJ-14 cable
BLUE
YELLOW
GREEN
RED
BLACK
WHITE
+12V
BUS (RP DATA)
RQ DATA
+5V
GND
RQ CLOCK
BUS (RP DATA)
RQ DATA
+5V
GND
WHITE
GREEN
RED
BLACK
BLUE
YELLOW
GREEN
RED
BLACK
ORANGE
BROWN
PURPLE
+12V
BUS (RP DATA)
RQ DATA
+5V
GND
RQ CLOCK
MANUAL 1
MANUAL 2
DRY CONTACTS
UP
DOWN
COMMON
BUS
5V BUS
BUS
COM
5V
BUS
3-conductor 20-24 gauge wire can be used in place of
the supplied RJ-14 cable to connect the wall switch.
Connect the BUS terminals on the wall switch to the
corresponding BUS terminals on the splitter board.
SCREEN AdjUSTMENT FOR 120v SCREENS WITH A BUILT-IN LOW VOLTAGE CONTROL
1. Locate the wall switch and remove the cover plate from the 3-button wall switch and remove the switch from the
junction box.
2. Locate the two tactile buttons on the back of the switch. They are square silver with black round buttons. See
Figure 4 (VPI) or Figure 5 (LVC) for diagram.
3. To adjust the down limit switch, press and hold the down tactile button until the LED on back of switch turns solid
red. This will put the motor in limit set mode. Turn the wall switch over and use the down button on front of
switch. Press and hold until the desired travel position is reached. If you travel to far down you can press the up to
move the screen upward. If you press and let go of either up or down button the motor will do a small jog in that
direction for finer adjustment of screen. Once desired position is reached turn switch over press and hold down
tactile button until the LED on back of switch blinks red twice. The down limit is now set.
4. To adjust the up limit switch, press and hold the up tactile button until the LED on back of switch turns solid green.
This will put the motor in limit set mode. Turn the wall switch over and use the up button on front of switch. Press
and hold until the desired travel position is reached. If you travel to far up you can press the down to move the
screen downward. If you press and let go of either up or down button the motor will do a small jog in that direction
for finer adjustment of screen. Once desired position is reached turn switch over press and hold up tactile button
until the LED on back of switch blinks green twice. The up limit is now set.
5. To test limit switch setting, press and release the up or down button on the wall switch to operate the screen.
6. Replace switch and cover plate on the wall.
NOTE: If the screen is in limit set mode and no buttons are pushed for 20 seconds, the LED on the back of the wall switch
will turn off, the motor will return to run mode and no changes will be saved. If this occurs, return to step 3 for
down limit adjustment or step 4 for up limit adjustment.
IMPORTANT NOTE: The wall switch is REQUIRED to make any limit switch adjustments, EVEN if a third party control
system is used. Therefore, it is advised to wire the switch or provide a 3-conductor connection that is
accessible.

55
SCREEN AdjUSTMENT FOR 240v SCREENS WITH A BUILT-IN LOW VOLTAGE CONTROL
1. Remove the cover plate from the 3-button wall switch and remove the switch from the junction box.
2. Locate small 3-position switch on back of wall switch. See Figure 4 for 120V screens or Figure 5 for 220/240V
screens.
3. To adjust the down limit switch, slide the 3-position switch to the down position. Press and hold the down button
to run the screen down to the desired stop position. Release the button to stop the screen. DO NOT PUSH THE
STOP BUTTON.
4. When the screen is in the desired down position, slide the 3-position switch to the off (center) position. The down
limit switch is now set.
5. To adjust the up limit switch, slide the 3-position switch to the up position. Press and hold the up button to run the
screen up to the desired stop position. Release the button to stop the screen. DO NOT PUSH THE STOP
BUTTON.
6. When the screen is in the desired up position, slide the 3-position switch to the off (center) position. The up limit
switch is now set.
7. To test limit switch setting, make sure the 3-position switch is in the off (center) position. Press and release the up
or down button on the wall switch to operate the screen.
8. Replace switch and cover plate on the wall.
NOTE: If stop button is pressed, the wall switch will reverse direction. To correct this, press the stop button again. This
will reset the switch. You will have to re-set both the up and the down settings.
IMPORTANT NOTE: The wall switch is REQUIRED to make any limit switch adjustments, EVEN if a third party control
system is used. Therefore, it is advised to wire the switch or provide a 4-conductor connection that is
accessible.
LARGE COSMOPOLITAN®ELECTROL®INSTALLATION FOR 240V SCREENS WITH A BUILT-IN LOW VOLTAGE
CONTROL
FIGURE 5
LOW-VOLTAGE WALL SWITCH
OPTIONAL IR AND RF
REMOTE CONTROL
MOTOR
BLUE (COMMON)
BROWN (HOT)
GREEN
GROUND TO CASE
240VAC 50HZ
240V WIRING DIAGRAM
WITH OPTIONAL BUILT-IN
LOW VOLTAGE CONTROL
RJ9
UP
STOP
DOWN
GROUND–MUST BE
CONNECTED TO
BUILDING GROUND
RJ9
GREEN
FRONT BACK
UP DN GND +5V
3-POSITION
SWITCH RJ9
ILT RJ9 PIN-OUTS
(TAB IS FACING UP)
IR or UP BLACK
GND COMMON RED
+5V GREEN
DN or DATA WHITE
DRY CONTACTS
SPLITTER
UP +5V COM DN
IMPORTANT NOTE: The wall switch is REQUIRED to make any limit
switch adjustments, EVEN if a third party control
system is used. Therefore, it is advised to wire
the switch or provide a 4-conductor connection
that is accessible.
CONNECT SUPPLIED
RJ9 CABLE TO
SPLITTER AND
SWITCH, OR USE 4
CABLE CONDUCTOR
TO CONNECT TO
SCREW TERMINALS.

6
TROUBLESHOOTING
SYMPTOM
1. Screen will not operate.
Motor does not hum.
2. Incorrect stopping position in
downward direction.
3. Incorrect stopping position in
upward direction.
4. Noise.
NOTE: Screen will operate with a
low pitched hum.
5. Coasting.
CAUSE
(a) Blown fuse.
(b) Tripped circuit breaker.
(c) No power to operating switch
or junction.
Power at junction box
(d) Thermal overload tripped.
(e) Broken wire in the “down” or “up”
position.
(f) Defective motor, limit switch or
capacitor.
(g) Capacitor burned out.
(a) Lost roller wrap.
(b) “Down” limit switch out of
adjustment
(a) Lost roller wrap.
(b) “Up” limit switch out of
adjustment
(a) Gear Noise.
(a) Defective brake.
RESTORING LOST ROLLER WRAP
1. Tape a strap to the bottom of the
screen surface.
2. Push strap over back of roller.
3. Feed fabric as you pull strap to
draw fabric over top of roller.
4. Remove tape and strap.
SOLUTION
(a) Replace fuse.
(b) Reset circuit breaker.
(c) Check above. Tighten all loose
wire connections. Correct any
improper connections.
“Down” Position
Check for power across black
and white leads.
“Up” Position
Check for power across red
and white leads.
(d) Let motor cool down for 15
minutes. Try again.
(e) Check for continuity. Cut off old
splice and reconnect.
(f) Replace motor assembly.
NOTE: Motor is a sealed assembly.
(g) Replace motor assembly.
(a) See instructions below.
(b) See installation instructions.
(a) See instructions below.
(b) Adjust “up” limit switch. See
installation instructions
(a) Replace motor assembly.
(a) Replace motor assembly.
Visit www.da-lite.com/products/product_videos.php to find installation and troubleshooting videos and
tutorials. You will also find a link to Live Chat for interactive support and you can contact us by email at
[email protected] or by phone at [phone] or [phone] with any troubleshooting questions.

LIMITED ONE YEAR WARRANTY
ON DA-LITE PRESENTATION PRODUCTS
Da-Lite Screen Company LLC warrants its products to the original purchaser only, to be free from
defects in materials and workmanship for a period of one (1) year from the date of purchase by
the original purchaser provided they are properly operated according to Da-Lite’s instructions and
are not damaged due to improper handling or treatment after shipment from the factory.
This warranty does not apply to equipment showing evidence of misuse, abuse or accidental
damage, or which has been tampered with or repaired by a person other than authorized Da-Lite
personnel.
Da-Lite’s sole obligation under this warranty shall be to repair or to replace (at Da-Lite’s option)
the defective part of the merchandise. Returns for service should be made to your Da-Lite dealer.
If it is necessary for the dealer to return the screen or part to Da-Lite, transportation expenses
to and from Da-Lite are payable by the purchaser and Da-Lite is not responsible for damage in
shipment. To protect yourself against damage or loss in transit, insure the product and prepay all
transportation expenses.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WARRANTIES AS TO FITNESS FOR USE AND MERCHANT ABILITY. Any implied
warranties of fitness for use, or merchantability, that may be mandated by statute or rule of law
are limited to the one (1) year warranty period. This warranty gives you specific legal rights, and
you may also have other rights, which vary from state-to-state. NO LIABILITY IS ASSUMED
FOR EXPENSES OR DAMAGES RESULTING FROM INTERRUPTION IN OPERATION OF
EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY
NATURE.
In the event that there is a defect in materials or workmanship of a Da-Lite product, you may
contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, [phone], [phone].
IMPORTANT: THIS WARRANTY SHALL NOT BE VALID AND DA-LITE SHALL NOT BE
BOUND BY THIS WARRANTY IF THE PRODUCT IS NOT OPERATED IN ACCORDANCE WITH
DA-LITE’S WRITTEN INSTRUCTIONS.
Keep your sales receipt to prove the date of purchase and your original ownership.
7
Printed in U.S.A. 96652 Rev. 3/12
