1. SAFETY MEASURES
Before starting the pump, read this instruction booklet carefully and keep it in a safe place for
future reference
For safety reasons, the pump must not be used by anyone who has not read these instructions.
The power cord must never be used to carry or move the pump. Always use the pump’s handle.
When handling the pump, while it is connected to the electric power supply, you should avoid
all contact with water.
Never remove the plug by pulling on the power cord.
Before taking any action on the pump, always remove the plug from the power socket.
If the power supply cord has been damaged, it must be replaced by the manufacturer or his
authorized customer support service
in order to avoid all risks.
Overload protection. The pump has a thermal overload safety device. In the event of any
overheating of the motor, this device automatically switches off the pump. The cooling time is
roughly 15 to 20 minutes, then the pump automatically comes on again. If the overload cut-out is
tripped, it is essential to identify and deal with the cause of the overheating. See
Troubleshooting.
2. USE OF THE VARIOUS TYPES OF PUMPS
2.1 Self priming multi-impeller surface pumps
Available with 1, 3, 4 or 5 impellers. The range of products includes pumps with stainless steel casings as
well as plastic casings.
xsuitable for domestic water supplies and for small and medium gardens.
xIdeal for emptying small tanks. The pumps are made of chlorine resistant materials (normal
concentration).
xSuitable for irrigation, drawing from water collection tanks
2.3 Boosters with integrated electronics
Characterised by their extremely silent running, and available with 3, 4 and 5 impellers.
xIncluding an electronic safety device to prevent the dry-running of the pump.
xIdeal for the irrigation of gardens and grounds, and domestic water supplies.
xCharacterised by the constant pressure and flow-rate.
2.2
The appliance is not intendend for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction con-
cerning use of the appliance by a person responsable for their safety. Children should be supervised to ensure
that they do not play with the appliance. (CEI EN 60335-1 : 08)
(MULTI INOX)
(BOOSTERSILENT)

7
GB
The temperature of the fluid being pumped must never exceed 35° C.
The pump must not be used to pump salt water, sewage, flammable, corrosive or explosive
liquids (e.g. petroleum oil, petrol, and thinners), grease, oils or foodstuffs.
Comply with the rules and regulations of the local water authority when using the pump for the
supply of domestic water.
3. STARTING THE PUMP
Given the different provisions applicable to the safety of electric systems in different countries,
make sure that the pump system, as concerns its intended use, is in accordance with current
legislation.
Before starting the pump, make sure that:
xthe voltage and frequency specified on the pump’s nameplate coincide with those of the
available power supply;
xthere are no signs of damage to the pump or its power cord;
xthe electric connection is made in a dry place, protected against any risk of flooding;
xthe electric system is complete with a residual current circuit-breaker (I ¨n30 mA) and an
efficient earthing connection;
xAny extension cords must comply with the requirements for electric safety.
Fill the pump casing and suction hose with clean water before starting the pump for the first
time. If the pump is installed above the water level, filling must be performed slowly until the
water overflows; wait a few seconds to make sure that all the air has escaped and top up until
the level has stabilised.
If the pump is installed below the water level (below head), bleed the air from the pump casing
by opening the filler cap. The pump will fill with water independently.
Plug the pump into the socket, start the pump and wait for the water to exit. If water has not
exited within 2-3 minutes from when the pump was switched on, turn the pump off and repeat
the filling operation again.
Attaching the suction hose
xFit the suction hose from the water source to the pump making sure that the pump is above the
water level. Do not position the suction hose above the level of the pump (to avoid air bubbles forming in
the suction hose).
xThe suction hose should be mounted in such a way that it does not create any mechanical stress on the
pump.
xThe foot valve should be placed at least 30 cm below the minimum water level.
xThe pump will draw water only when the suction hose is completely filled with water.
xThe suction hose and the pump’s suction inlet should be of the same diameter.
Attaching the delivery hose
xTo get the best performance from the pump, it is recommended that the diameter of the delivery hose
is at least 1”
xDuring the self-priming phase, all taps, valves, etc. on the delivery hose must be fully open in
order to allow the air inside the hose to escape.
Before plugging in and starting the pump for the first time, it is necessary that the suction hose and the pump
are completely filled with water in order for suction to take place. For use in wells or when the water level is
lower than the pump, a suction hose must be used that is equipped with the foot valve. This will allow the
suction hose to remain filled with water after the first time that it is filled and will prevent the emptying of the
hose when the pump shuts off automatically, avoiding any problems when restarting.

8
GB
fBooster with integrated electronics
Installation
The pump’s inlet pressure should not exceed 2 Bars.
The maximum suction depth should be less than 8m.
The device will not pump liquid if the tap is more than 15m the level of the pump.
Due to the non-return valve in this model, the suction hose cannot be filled through the filler cap
on the pump.
Using of the pump
Plug the electric cable into the socket. The pump will automatically begin to run.
If the suction phase is not activated within 120 seconds, the pump will shut-off automatically. The pump will
then try 2 more attempts to self prime for 120 seconds each.
The electric pump is equipped with an integrated electronic device that allows the unit to automatically
intervene in the following ways:
x Automatic operation of the pump
The pump automatically starts when a tap is opened and shuts-off approximately 10 seconds after it is
closed.
x Dry- Run Protection
If the pump senses that it is not drawing any water, it will automatically switch-off after approx. 45 seconds.
The red “Alarm” LED on the electronic display will begin to flash. After having restored the flow of water to the
pump, press the RESET pad to restart the pump.
If the alarm persists, or rather the user does not re-establish the flow of water and reset the pump, the
automatic reset will attempt to restart the pump after 1 hour, 5 hours and 20 hours, and then once every 24
hours. The electronic display continues to signal the lack of water from the first intervention of the dry run
protection up until the pump starts to operate correctly: flashing red LED with one flash and one pause. After
having re-established the flow of water, press the RESET button to restart the pump.
x Electronic display signals
Greed Led (Power) on.
The pump is connected to the main power and is ready to supply water (as soon as a tap is opened).
Yellow Led (Pump on) on.
The pump is supplying water.
Red Led (Alarm) with 1 flash cycles.
The pump is not functioning due to lack of water on the suction side: the dry running protection program is
activated.
4. RECOMMENDATIONS
To ensure the proper operation of the pump, it is important to comply with the following recommendations:
The pump should not operate with the delivery tap completely closed (except for electronically
controlled pumps).
The pump must never be allowed to run dry.
x The diameter of the suction and delivery hoses must not be less than the relative inlet or outlet (25 mm)
of the pump. A hose with a greater diameter should ideally be fitted to the suction inlet when the suction
height exceeds 4 meters. Do not use metal connectors on the pump’s threads.
x Connect the suction hose including a foot valve avoiding counterslopes, traps, goosenecks and kinks in
the hose.
x Place the pump in a level, stable and dry place, and away from inflammable or explosive substances.
Never expose the pump to the rain or direct jets of water.
x Make sure that the mains power connections are not subjectable to flooding, avoid that the pump is
exposed to direct jets of water and do not immerse the pump in water.

9
GB
MAINTENANCE AND CLEANING
It is absolutely essential to prevent any risk of the pump freezing. In the event of freezing temperatures,
remove the pump from the liquid, empty it and keep it in a place where it cannot freeze.
The pump must be disconnected from the mains before performing any cleaning operation.
The pump is maintenance free.
5. TROUBLESHOOTING
Before taking any troubleshooting action, disconnect the pump from the power supply.
If there is any damage to the power cord or pump, any necessary repairs or replacements must
be handled by the manufacturer or his authorized customer support service, or by an equally-
qualified party, in order to prevent all risks.
Multi-impeller self priming Surface pumps and Boosters with tank
Fault Cause Solution
The pump does not
turn on
1) no power.
2) shaft blocked
1) check if power is supplied to the
socket and that the plug is correctly
inserted.
2) remove the plug from the power
socket and insert a screwdriver into
the notch on the shaft (from the
cooling fan side) and unblock it by
turning the screwdriver.
The pump turns but
does not deliver
water
1) the air inside the pump has not been
completely bled. Pump casing without
water.
2) entry of air from the suction pipe.
3) - the suction valve is not submerged in
water
- suction valve blocked
- the maximum suction depth has been
exceeded
1) stop the pump, unscrew the
delivery pipe, shake the pump and
suction hose to remove any air
bubbles. Top up with water, connect
the hose ensuring it is correctly sealed
and start the pump again.
2) check that the joints of the suction
hose have been performed correctly.
Make sure there are no counterslopes,
traps, goosenecks or constriction on
the suction pipe and that the foot valve
is not blocked.
3) - place the suction valve in water
- clean the foot valve
- clean the suction basket
- check the suction depth.
The pump stops
due to overheating
caused by the
opening of the
overheating thermal
protection
1) The power supply does not conform to
that on the rating plate of the motor
(voltage too high or too low).
2) A solid object has blocked the impeller.
3) The pump has been operating with water
that is too hot.
4) The pump ran dry or ran with the delivery
tap closed for more than 10 minutes.
1)-4) remove the plug, remove the
cause of the overheating, wait for
the motor to cool and start it again.

10
GB
Booster with integrated electronics
Based on the combinations of LEDs, the cause of the pump malfunction can normally be identified.
Fault LED Cause Solution
No power
Check that the mains
power supply is sufficient.
Check the electrical line
and the connections.
Power is off
Pump on is off
Alarm is off
Faulty card Contact an authorised
service centre.
Power is on
Pump on is off
Alarm is off
The delivery hose is blocked
Incorrect installation (+ 15 m) Check the hydraulic system
Power is on
Pump on is on
Alarm is on
Faulty card Contact an authorised
service centre
Lack of suction water no more than 26
hours ago
Check that the suction
hose has been fitted
correctly
Power is on
Pump on is off
Alarm is flashing Impeller blocked (thermal cut-out tripped) Clean/free the pump
Lack of water for more than 26 hours
Check that the suction
hose has been fitted
correctly.
The pump
does not
work
Power is on
Pump on is off
Alarm is on Impeller blocked (thermal cut-out tripped) Clean the pump
Excessive suction depth Check the suction depth
Foot valve blocked Clean the foot valve
Insufficient
delivery Performance of the pump is reduced due
to foreign objects
Clean the pump
There are leaks in the system
The pump has sucked in foreign materials
The non-return valve is leaking
Clean the pump
The pump
continuousl
y stops and
starts. The water level drops rapidly below 8m
Position the foot valve
deeper
(not below 8 meters)

11
GB
6. DISPOSAL
This product or its parts must be disposed of in accordance with the laws regarding the environment;
Use the local, public or private, refuse collection services.
7. GUARANTEE
Any material or manufacturing defects will be corrected during the guarantee period established by current
law in the country where the product is purchased. It is up to the manufacturer to decide whether to repair or
replace any faulty parts.
The manufacturer’s guarantee covers all substantial defects attributable to manufacturing or material defects,
providing the product has been used correctly and in compliance with the instructions.
The guarantee becomes null and void in the event of the following:
y unauthorized attempts to repair the appliance;
y unauthorized technical changes to the appliance;
y use of non-original spare parts;
y manhandling;
y inappropriate use, e.g. for industrial purposes.
The guarantee does not cover:
y parts liable to rapid wear and tear.
For any action under guarantee, contact an authorized customer support service, presenting your receipt for
the purchase of the product.
The manufacturer accepts no liability for any inaccuracies in the present booklet due to printing or copying
errors. The manufacturer reserves the right to make any changes to the product he deems necessary or
useful, without affecting its essential features.

DAB PUMPS S.p.A.
Via M. Polo, 14 - 35035 Mestrino (PD) - Italy
Tel. [phone] - Fax [phone]
www.dabpumps.com
14 cod.
DAB PUMPS LTD.
Units 4 & 5, Stortford Hall Industrial Park,
Dunmow Road, Bishop’s Stortford, Herts
CM23 5GZ - UK
[email protected]
Tel.: [phone]
Fax: [phone]
DAB PUMPEN DEUTSCHLAND GmbH
Tackweg 11
D - 47918 Tönisvorst - Germany
[email protected]
Tel.: [phone]
Fax: [phone]
DAB UKRAINE Representative Office
Regus Horizon Park
4M. Hrinchenka St, suit 147
03680 Kiev. UKRAINE
Tel. [phone]
DAB PRODUCTION HUNGARY KFT.
H-8800
NAGYKANIZSA, Buda Ernó u.5
HUNGARY
Tel. [phone]
DAB PUMPS B.V.
Albert Einsteinweg, 4
5151 DL Drunen - Nederland
[email protected]
Tel.: [phone]
Fax: [phone]
DAB PUMPS B.V.
Brusselstraat 150
B-1702 Groot-Bijgaarden - Belgium
[email protected]
Tel.: [phone]
Fax: [phone]
DAB PUMPS IBERICA S.L.
Avenida de Castilla nr.1 Local 14
28830 - San Fernando De Henares - Madrid
Spain
[email protected]
Ph.: [phone]
Fax: [phone]
PUMPS AMERICA, INC. DAB PUMPS DIVISION
3226 Benchmark Drive
Ladson, SC 29456 USA
[email protected]
Ph. : 1-843-824-6332
Toll Free: 1-866-896-4DAB (4322)
Fax : [phone]
OOO DWT GROUP
100 bldg. 3 Dmitrovskoe highway,
127247 Moscow - Russia
[email protected]
Tel.: [phone]
Fax: [phone]
DAB PUMPS CHINA
No.40 Kaituo Road, Qingdao Economic &
Technological Development Zone
Qingdao City, Shandong Province, China
PC: 266500
[email protected]
Tel.: [phone]-6270
Fax: [phone]
DWT South Africa
Podium at Menlyn, 3rd Floor, Unit 3001b,
43 Ingersol Road, C/O Lois and Atterbury,
Menlyn, Pretoria, 0181 South-Africa
[email protected]
Tel [phone]
Fax [phone]
DAB PUMPS POLAND SP. Z.O.O.
Mokotow Marynarska
Ul. Postepu 15c - 3rd Floor
02-676 Warsaw - POLAND
Tel. [phone]
