Daewoo LXL-940 User manual

As an ENERGY STAR®Partner, Daewoo Lucoms co., Ltd has determined that this
product meets the Energy Star®guidelines for energy efficiency.
The product is also designed for IT power system with phase to phase voltage of 230V.
1. Read all of these instructions.
2. Save these instructions for later use.
3. Unplug this monitor from the
wall outlet before cleaning. Do not
use liquid cleaners or aerosol
cleaners. Use a damp cloth for
cleaning.
4. Do not use attachments not recommended by
the monitor manufacturer as they may cause
hazards.
5. Do not use this monitor near water, e.g., near a
bathtub, washbowl, kitchen sink, or laundry tub,
in a wet basement, or near a swimming pool, etc.
6. Do not place this monitor on an
unstable cart, stand, or table. The
monitor may fall, causing serious
injury to a child or adult, and
serious damage to the appliance.
7. Slots and openings in the
cabinet and the back or bottom are
provided for ventilation, to ensure
reliable operation of the monitor,
and to protect it from overheating.
These openings must not be blocked or covered.
The openings should never be blocked by
placing the monitor on a bed, sofa, rug, or other
similar surface. This monitor should never be
placed near or over a radiator or heat register.
This monitor should not be placed in a built-in
installation such as a bookcase unless proper
ventilation is provided.
8. This monitor should be operated
only from the type of power source
indicated on the marking label. If
you are not sure of the power
supplied to your home, consult
your monitor dealer or local power company.
9. This monitor is equipped with a
3-wire grounding-type plug, That
is, a plug having a third
(grounding) pin. This plug will
only fit into a grounding-type
power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet.
Do not defeat the purpose of the grounding-type
plug.
10. Do not allow anything to rest
on the power cord. Do not locate
this monitor where the cord will be
abused by people walking on it.
11. Follow all warnings and instructions marked
on the monitor.
IMPORTANT SAFEGUARDS
12. For added protection for this
monitor during a lightning storm,
or when it is left unattended and
unused for long periods of time,
unplug it from the wall outlet. This
will prevent damage to the monitor and/or the
computer due to lightning and power line surges.
13. Do not overload wall outlets and extension
cords as this can result in fire or electric shock.
14. Never push objects of any kind into this
monitor through cabinet slots, as they may touch
dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill
liquid of any kind on the monitor.
15. Do not attempt to service this
monitor yourself, as opening or
removing covers may expose you
to dangerous voltages or other
hazards. Refer all servicing to
qualified service personnel.
16. Unplug this monitor from the wall outlet and
refer servicing to qualified service personnel
under the following conditions:
a. When the power cord or plug is damaged or
frayed.
b. If liquid has been spilled into the monitor.
c. If the monitor has been exposed to rain or
water.
d. If the monitor does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore normal operation.
e. If the monitor has been dropped or the cabinet
has been damaged.
f. When the monitor exhibits a distinct change in
performance, this indicates a need for service.
17. When replacement parts are
required be sure the service
technician has used replacement
parts specified by the manufacturer
that have the same characteristics as
the original part. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.
18. Upon completion of any service or repairs to
this monitor, ask the service technician to
perform routine safety checks to determine that
the monitor is safe to operate.
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
NOTE : This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio or TV technician for help.
CAUTION :Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
CANADIAN NOTICE
AVIS CANADIEN
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la Class B respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.
European Union Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the
the Low Voltage Directive (73/23/EEC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the following European Norms (in
brackets are the equivalent international standards):
•EN55022 (CISPR 22) - Electromagnetic Interference
•EN55024 - Immunity Test for ITE Product
•EN60950 (IEC950) - Product Safety
•EN61000-3-2 (IEC555-2) - Power Line Harmonics

CONTENTS
Introduction ............................................................................. 1
Product Features ................................................................. 2
Setup ......................................................................................... 3
Connecting the 15 Pin Signal Cable and Power Cord..........3
Operation & Adjustment ...................................................... 5
Specifications ......................................................................... 13
Factory Preset Timings ......................................................... 14
Changing the Stand ............................................................... 15
Troubleshooting ..................................................................... 17
INTRODUCTION
This manual explains how to correctly install, operate and get the
best performance from your monitor. Please read this user’s guide
carefully before installing your monitor, then keep it near your
monitor for quick reference.
First, please check that the contents of the box corresponds with the
following checklist :
TFT LCD monitor
Power cord
15 pin signal cable
Video cable
Audio cable
S-Video cable
User’s guide
Warranty card
If any item is missing or damaged, please contact your dealer. Please
keep the box and packing materials so that you may properly store or
transport your monitor.
English - 1

AC POWER S-Video Video
AUDIO
RL
English - 3
PRODUCT FEATURES
The monitor is designed for use in a small work area or for
those who need more work space on the desk.
The convenient and user-friendly on-screen display allows for
easy and accurate adjustments of screen size, position and
screen color.
The monitor complies with the VESA Display Data Channel
(DDC) specification for Plug and Play compatibility.
Advanced microcircuitry makes setup and configuration fast
and effortless.
Embedded with VESA DPMS(Display Power Managenment
Signaling), function, it automatically turns into energy save
mode to reduce energy consumption when not used for a long
time.
Activate the higher refresh rates of the monitor to stabilize the
screen and eliminate the annoying flicker that contributes to
eye-strain and headaches.
With OSD(On Screen display), the monitor display conditions
are easily adjusted.
The internal stereo speakers make the end user enjoy audio
sound.
The monitor supports the optimal display performance with
1280x1024 at 75Hz.
With the POWER LIGHT function added,you can enjoy the
bright screen for movie or any other multimedia utilization.
The monitor can be connected to various types of video
devices with supporting video input signals like Composite
video(CVBS), Seperate video(S-Video).
!Plug the power cord into the AC receptacle located on the back of the
monitor.
@Connect the 15 pin signal cable to the output port of the video card in
your computer and monitor.
#Connect the audio cable to the output port of the sound card in your
computer.
CONNECTING THE 15 PIN SIGNAL CABLE AND POWER CORD
SETUP
15 pin signal
cable
Power Cord
English - 2
Audio
cable

English - 5
OPERATION & ADJUSTMENT
CONTROL PANEL
English - 4
CONNECTING THE OTHERS
1. Plug the connector to the S-Video port on the rear of the
monitor (ex : VCR, DVD , ---).
2. Plug the connector to the RCA port on the rear of the
monitor (ex : Camcorder, VCR, DVD, ---).
3. Plug the connector to AUDIO INPUT port on the rear of the
monitor (ex : Computer, CD Player, ---).
4. Plug the connector to AUDIO OUTPUT port on the rear of
the monitor (ex : Speaker, Headphone, ---).
1
2
3
4
2
1234
AC POWER S-Video Video
AUDIO
RL
1. Turn on monitor.
2. Choose “SVIDEO” or “VIDEO” connected to DVD player,
using buttons of remote controller or SOURCE button from
exterior adjustment buttons.
3. Put tape or DVD into VCR or DVD player and play.
How to watch DVD, VIDEO
Switches the monitor on and off.
POWER
1
7
6
BRIGHTNESS
While the OSD screen is off, you can
adjust the brightness directly.
Moves cursor to the right or low
window in the OSD window and
increases the value of any selected
function.
Moves cursor to the left or high window in
the OSD window and decreases value of
any selected function.
VOLUME
While the OSD screen is off, you can
adjust the volume directly.
MENU/EXIT
5
3
While the OSD screen is off, you can
adjust the screen brightness according
to each situation.
Turns the OSD window on.
EXIT
Turns the OSD (On-Screen Display)
window off and moves from sub
menu to top menu in the OSD
window.
*
( ) : Hot Key
( )
*
POWERLIGHT /VOLUME
AUTO
2
Launches the AUTO TRACKING
function directly.
*
( )
/
SOURCE/SELECT
4
Selects input signal in order.
SELECT
Moves from top menu to sub menu in the
OSD window and opens the function
window for the selected icon.
*
( )
( )
*
/
1765432

English - 7
English - 6
KEY PROCESS HOT KEY
When there is no OSD, if you press this
BRIGHTNESS button, you can adjust the
brightness directly.
: decreases brightness
: increases brightness
When there is no OSD, if you press this
AUTO button, you can use the best display
performance fit for a current mode.
AUTO TRACKING
AUTO
1024 X 768 75Hz
Brightness 100 - +
The screen will be brightened progressively by
10%. If you carry out general PC works such
as document edition on the Movie mode,you
may shorten the life span of LCD panel.
Thus,it is recommended to verify the selected
mode before use.
Signal Source
Mode Select PC Game Movie
Reset YES NO
1024 X 768 75Hz
POWER LIGHT
VOL.
When there is no OSD, you can adjust the
VOLUME directly.
BRIGHTNESS
SOURCE selects input signal in order.

English - 9
English - 8
ADJUSTMENT PROCEDURE
Adjust the CLOCK control.
Perform the AUTO
POSITION.
Is the H.Size
proper?
Is the
noise displayed on
the screen?
Perform the AUTO
TRACKING.
Is the
noise displayed on
the screen yet?
Is the
noise displayed on
the screen yet?
Adjust the CLOCK FINE
until the screen is cleared.
Yes
Yes
Yes
Yes
No
No
No
No End
OSD FUNCTIONS WITH USING PC
COLOR
FUNCTION
Choose different preset color temperatures or set your
own customized color parameters.
COLOR TEMP.
Adjust the position of the display horizontally (left or
right) and vertically (up or down).
H. POSITION &
V. POSITION
Remove any horizontal noise and clear or sharpen the
image of characters.
Adjust the width (horizontal size) of the screen
image.
PHASE
CLOCK
Adjust the display image quality (if the screen
proceed to scaling up).
SHARPNESS
Choose automatically the proper horizontal position
and vertical position & size of the screen image.
AUTO Adjust
Adjust the color.
COLOR
ADJUST
Adjust the contrast of image, the difference between
light and dark areas on the screen.
CONTRAST
Adjust the brightness of image.
BRIGHTNESS
Adjust the gamma correction.
GAMMA
(Unavailable in DVI MODE)
(Unavailable in DVI MODE)

English - 11
English - 10
OSD MENU
MISC.
Adjust the OSD. TransparencyTranlucent
Select language for OSD.
LANGUAGE
Adjust the OSD position horizontally (left or right)
and vertically (up or down).
OSD H &V
POS.
Adjust the display OSD Menu.
OSD TIMER
Select input signal source.
SIGNAL
SOURCE
Select powerlight mode(PC/Game/Movie)
POWER LIGHT
Reset the screen to the Factory Preset
Display Settings.
RESET
OSD
Adjust the display image quality (if the screen
proceed to scaling up).
SHARPNESS
Adjust the contrast of image.
CONTRAST
Adjust the brightness of image.
Adjust saturation of image.
BRIGHTNESS
SATURATION
Adjust the hues of image.
HUE
OSD FUNCTIONS WITH USING VIDEO and S-VIDEO
OSD MENU
MISC.
Adjust the OSD. Transparency
Tranlucent
Select language for OSD.
LANGUAGE
Adjust the OSD position horizontally (left or right)
and vertically (up or down).
OSD H &V
POS.
Adjust the display OSD Menu.
OSD TIMER
Select powerlight mode(PC/Game/Movie)
POWER LIGHT
Reset the screen to the Factory Preset
Display Settings.
RESET
SOUND
Turn the audio sound on or off.SOUND
Increase or decrease audio volume.VOLUME
OSD
Select input signal source.
SIGNAL
SOURCE

English - 13
English - 12
SELF DIAGNOSIS
SPECIFICATIONS
If there is no image, the Self Diagnosis screen will be displayed.
Self Diagnosis function checks if the status of the monitor screen is No
Signal, Out of range or None support .
No Signal screen is displayed when the D-
Sub signal connector is connected but the
status of the monitor is on DPMS mode.
Out of Range screen is displayed when the
applied frequency is under or over normal
range.
Normal range
(Non-interlaced mode only)
H : 30 - 80 KHz
V : 56 - 77 Hz
None support screen is displayed when the
applied frequency is under or over factory
preset timings.
Check cable screen is displayed when the
signal cable is disconnected.
Panel Size 19-inch diagonal
Pixel Pitch 0.098(H)mm x 0.294(V)mm
Viewing Angle 85°(Right/Left)
85°(up/down)
Contrast Ratio 500:1 contrast ratio (typ)
Brightness 250cd/m2brightness (typ)
Color Filter RGB vertical stripe
Synchronization Horizontal 30 - 80KHz
Vertical 56 - 77Hz
Video Bandwidth 135MHz
Max Resolution 1280 x 1024 75Hz
Colors 16M Colors
Display Area 376.32(H)mm x 301.056(V)mm
PC Input Signal Sync H/V separate (TTL)
Video 15 pin mini D-sub(Analog RGB)
AV Input Signal Video CVBS(RCA), S-Video(Mini-DIN)
Audio RCA Left+Right Input
Stereo Mini Jack Input & Output
Speaker Max. Output 2W(Left 1W+Right 1W)
Plug and Play VESA DDC Compatible
Power Source 100-240Vac, 50/60Hz (Free Voltage)
Power Consumption 40W
Dimension-W x H x D 418.5 x 435.4 x 263mm (with stand)
418.5 x 364.5 x 70.8mm (without stand)
Weight-net/gross 7.6/9.2Kg(16.7/20.3lbs)
Power Saving EPA, VESA DPMS, Nutek Compliant
Tilt Range 5° forward, 30° backward
Operating Temperature 10 ~ 40°C /50 ~ 104°F
a
The specification can be changed without any prior notice to improve the quality
of the product.
The LCD panel may have some defective pixels (e.g. slightly light or dark) due
to a characteristic of the LCD panel. But there is no defect in your LCD product
itself.
1
2
3
4

English - 15
FACTORY PRESET TIMINGS
English - 14
CHANGING THE STAND
VESA MODES
IBM MODES
MAC MODES
THE OTHERS
VGA 640
X 480 60Hz 31.5 60 Non-interlaced
VGA 640
X 480 72Hz 37.9 72 Non-interlaced
VGA 640
X 480 75Hz 37.5 75 Non-interlaced
SVGA 800
X 600 56Hz 35.2 56 Non-interlaced
SVGA 800
X 600 60Hz 37.9 60 Non-interlaced
SVGA 800
X 600 72Hz 48.1 72 Non-interlaced
SVGA 800
X 600 75Hz 46.9 75 Non-interlaced
XGA 1024
X 768 60Hz 48.4 60 Non-interlaced
XGA 1024
X 768 70Hz 56.5 70 Non-interlaced
XGA 1024
X 768 75Hz 60.0 75 Non-interlaced
SXGA 1280
X 1024 60Hz 64.0 60 Non-interlaced
SXGA 1280
X 1024 75Hz 80.0 75 Non-interlaced
SXGA 1152
X 864 75Hz 67.5 75 Non-interlaced
SXGA 1280
X 960 60Hz 60.0 60 Non-interlaced
EGA 640
X 350 70Hz 31.5 70 Non-interlaced
DOS 720
X 400 70Hz 31.3 70 Non-interlaced
VGA 640
X 480 67Hz 35.0 67 Non-interlaced
SVGA 832
X 624 75Hz 49.7 75 Non-interlaced
SXGA 1152
X 870 75Hz 68.7 75 Non-interlaced
SXGA 1280
X 1024 70Hz 74.4 70 Non-interlaced
Mode H.Freq(KHz) V.Freq(Hz) Remark
Resolution
(dots
X lines)
Mode H.Freq(KHz) V.Freq(Hz) Remark
Resolution
(dots
X lines)
Mode H.Freq(KHz) V.Freq(Hz) Remark
Resolution
(dots
X lines)
Mode H.Freq(KHz) V.Freq(Hz) Remark
Resolution
(dots
X lines)
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
The LCD Monitor has only Non-interlanced modes without flicker.
Removing Original Stand
1. Detach the rear cover of the stand with a screwdriver.
2. Remove the four screws connecting the stand and the body and the
stand is disassembled.
12
Turn off the monitor and pull out the power cable.
Place a cushion or a soft cloth on the floor and put the product on it with
the front of the monitor facing the floor.

English - 17
English - 16
TROBLESHOOTING
Attaching the monitor with the arm-stand(option)
Tighten up screws at the
locations indicated by
arrows.
Support
stand
This monitor’s installation surface is compatible with various kinds
of VESA standard stands.
Hole spacing : 100x100 mm
Screw Length : 8~12 mm
Adjust Clock to set the screen position and adjust
Clock fine until a noise isn’t displayed.
Check if power switch and computer power switch
are in the on position.
Check if the signal cable is correctly connected to
the video card.
Check if the pins of D subconnector are not bent.
Check if the computer is in the power- saving mode.
Check if power switch is in the on position.
Check if the power cord is correctly connected.
Check if the signal cable is suitable to the video card.
Adjust Clock or H&V Center to get the proper
image.
Keep the devices that may cause electrical
interference away from the monitor.
Adjust Contrast and Brightness.
Symptom
Picture is jitterd.
No picture.
POWER LED is not
lit.
Image is unstable.
Image is not
centered, too small
or too large.
Picture bounces or a
wave pattern is
present in the
picture.
Picture is blurred.
Check
Surface for
stand
installation

English - 18
Check the audio cable are correctly connected to the
computer.
Adjust the volume after checking the sound is muted.
Check the audio system in the computer.
Adjust the volume on the OSD Menu.
Adjust the volume of the sound card in the computer.
Check if the video cable is correctly connected to the
computer and set to the video mode.
Symptom
No sound.
Low sound.
No video.
Check

S/N:XL78600906
