NEO-V SVC MANUAL
RCP33**/36**
RCT33**/36**

NEO-V SVC MANUAL
1. Warmings and Precautions for Safety ------------------------
2. Product Specification -----------------------------------
3. Wiring Diagram ----------------------------------------
4. Product Size and Features --------------------------------
5. Cooling Cycle -----------------------------------------
6. Product Control Information -------------------------------
7. Disassembly / Assembly Guide of Each Part -------------------
8. Exploded View and SVC Parts List ---------------------------
Contents
2
3
5
14
19
20
40
47
1

NEO-V SVC MANUAL
1. Warmings and Precautions for Safety
2
Please observe the following safety precautions in order to use safely and correctly the
refrigerator and to prevent accident and danger during repair.
1) Be care of an electric shock. Disconnect power cord from wall outlet and wait for more
than three minutes before replacing PCB parts.
Shut off the power whenever replacing and repairing electric components.
2) When connecting power cord, please wait for more than five minutes after power cord
was disconnected from the wall outlet.
3) Please check if the power plug is pressed down by the refrigerator against the wall.
If the power plug was damaged, it may cause fire or electric shock.
4) If the wall outlet is over loaded, it may cause fire.
Please use its own individual electrical outlet for the refrigerator.
5) Please make sure the outlet is properly earthed, particularly in wet or damp area.
6) Use standard electrical components when replacing them.
7) Make sure the hook is correctly engaged.
Remove dust and foreign materials from the housing and connecting parts.
8) Do not fray, damage, machine, heavily bend, pull out or twist the power cord.
9) Please check the evidence of moisture intrusion in the electrical components.
Replace the parts or mask it with insulation tapes if moisture intrusion was confirmed.
10) Do not touch the icemaker with hands or tools to confirm the operation of geared motor.
11) Do not let the customers repair, disassemble and reconstruct the refrigerator for
themselves.
It may cause accident, electric shock, or fire.
12) Do not store flammable materials such as ether, benzene, alcohol, chemicals, gas,
or medicine in the refrigerator.
13) Do not put flower vase, cup, cosmetics, chemicals, etc., or container with full of water
on the top of the refrigerator.
14) Do not put glass bottles with full of water into the freezer.
The contents shall freeze and break the glass bottles.
15) When you scrap the refrigerator, please disconnect the door gasket first and scrap it
where children are not accessible.

NEO-V SVC MANUAL
2-1. Specification
ITEM SPEC
Model Name RCP33** RCP36** RCT33** RCT36**
Volume
Total 337L 362L 337L 362L
Freezer 92L
Refrigerator 245L 270L 245L 270L
External Dimension (mm)
(Width * Depth * Height)
(w/o Handle)
595 * 667 * 1897 595 * 667 * 2000 595 * 667 * 1897 595 * 667 * 2000
Voltage / Frequency 220~240V / 50Hz
Rated Input 95 W
Cooling Type In-direct Cooling
Refrigerant R-600a / 40g (A+), 38g (A++)
Climate Class SN ~ T
Weight 69Kg 72Kg 74.5Kg 78Kg
2-2. Electrical Inlet Specification
ITEM SPEC
Model Name RCP3*** / RCT3***
Cooling Components
Comp
Name TH1114Y1(A+), LR88CY1(A++)
Oil MINERAL OIL, 160ml(TH1114Y1) / 200ml(LR88CY1)
Evaporator Fin Type
Condenser Fan Cooling Type
Dryer MOLECULAR SIEVE XH-9
Capillary Tube IDΦ0.7 X 0.55t X L2,320
Refrigerant R-600a
O
L
P
Name B52-120/B(TH1114Y1) / BT60-105/V(LR88CY1)
Open Temp 120℃ ±5
Close Temp 61℃ ±9
Defrosting
Components
Defrost Heater AC230V / 160W
D-Sensor
(Name / Return Temp) PRE303F31GA-DWR06 / 13℃
Temp Fuse 250V / 10A / 77 (+0,-4)℃
2. Product Specification
3

NEO-V SVC MANUAL
ITEM SPEC
Model Name RCP3*** / RCT3***
Electric Components
Main Fuse AC250V /4A
Freezer Fan Motor D4612AAA41, DC12V / Φ110
Condenser Fan Motor D4612AAA39, DC12V / Φ130
Refrigerator Lamp LED ( DC12V / 0.6W )
Refrigerator Door Switch HC-050K4 (AC 250 V, 2.5A)
Power Code AC250V /16A
F/R Sensor REB303F31GA-DW / REB303F31GA
2-3. Refrigerator Control Temperature
4
REFRIGERATOR
STEP DISPLAY ON / OFF
Min LED “1 Section” lighting 8.1 / 1.5
Min-Mid LED “2 Section”lighting 5.8 / -0.6
Mid LED “3 Section” lighting 4.6 / -1.7
Mid-Max LED “4 Section” lighting 2.5 / -3.7
Max LED “5 Section” lighting 1.4 / -4.8

NEO-V SVC MANUAL
3-1. RCP3*** Model (Metal Door)
3. Wiring Diagram
5

NEO-V SVC MANUAL
6
3-2. RCT3*** Model (Glass Door)

NEO-V SVC MANUAL
3-3. Main PCB Circuit Diagram
7

NEO-V SVC MANUAL
8
3-3. Main PCB Circuit Diagram

NEO-V SVC MANUAL
9
3-3. Main PCB Circuit Diagram

NEO-V SVC MANUAL
10
3-3. Main PCB Circuit Diagram

NEO-V SVC MANUAL
11
3-3. Main PCB Circuit Diagram

NEO-V SVC MANUAL
12
3-3. Main PCB Circuit Diagram (RCP3*** Model)

NEO-V SVC MANUAL
13
3-3. Main PCB Circuit Diagram (RCT3*** Model)

NEO-V SVC MANUAL
14
4-1. Exterior Size (RCP3*** Model)
4. Product Size and Features

NEO-V SVC MANUAL
4-1. Exterior Size (RCT3*** Model)
15

NEO-V SVC MANUAL
4-2. Interior Features
Refrigerator Compartment Freezer Compartment
1. Shelves 10. Freezer Case
2. LED Lamp
3. Multi Duct Air Flow
4. Vegetable Plus (Option)
5. Vegetable Case
6. Dairy Pocket (Option)
7. Utility Pocket
8. Water Tank (Option)
9. Jumbo Pocket
16
1
2
3
4
5
10
7
8
6
9

NEO-V SVC MANUAL
4-3. Machine Room (A+ Model)
Machine Room
1. Running Capacitor 11. Hot Pipe
2. Power Code 12. Pipe Absorber
3. Cover Relay 13. Suction Pipe
4. Special Washer
5. Dryer
6. Connect Pipe
7. Absorber Comp
8. Pipe WiCon
9. Case Vapori
10. Drain Hose
17
1 Compressor
2
3 5 6 7 8
11
9
1213
4
10

NEO-V SVC MANUAL
18
1
Compressor
2
3 4 65
10
4-3. Machine Room (A++ Model)
Machine Room
1. Running Capacitor 11. Bell Mouth
2. Power Code 12. Hot Pipe
3. Cover Relay 13. Pipe Absorber
4. Special Washer 14. Suction Pipe
5. Dryer
6. Absorber Comp
7. Connect Pipe
8. Pipe WiCon
9. Case Vapori
10. Drain Hose
7 8 9
1113 1214

NEO-V SVC MANUAL
5. Cooling Cycle
19
