Dahua VTH1510A User manual

VTH15 Series User’s Manual
V1.1

Table of Contents
1General Introduction.....................................................................................4
1.1 Model List ...........................................................................................................4
1.2 Front Panel.........................................................................................................5
1.3 Rear Panel........................................................................................................10
2Installation..................................................................................................13
2.1 Install Device ....................................................................................................13
2.1.1 Embedded Box...........................................................................................13
2.1.2 Direct Installation........................................................................................15
2.2 Wiring ...............................................................................................................15
3Product Function........................................................................................16
3.1 Main Menu........................................................................................................16
3.1.1 Settings......................................................................................................16
3.1.2 Video Talk..................................................................................................24
3.1.3 Security Alarm............................................................................................26
3.1.4 Info Search.................................................................................................28
3.2 Monitor..............................................................................................................29
3.3 Unlock...............................................................................................................29
3.4 Screen Calibration ............................................................................................30
4Quick Configuration....................................................................................31
4.1 Process.............................................................................................................31
4.2 Result Verification.............................................................................................33
Appendix 1 Technical Specification .........................................................................34

Important Safeguards and Warnings
Please read the following safeguards and warnings carefully before using the product in order
to avoid damages and losses.
Note:
Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or
electric shock.
Do not install the device at position exposed to sunlight or in high temperature.
Temperature rise in device may cause fire.
Do not expose the device to humid environment. Otherwise it may cause fire.
The device must be installed on solid and flat surface in order to guarantee safety
under load and earthquake. Otherwise, it may cause device to fall off or turnover.
Do not place the device on carpet or quilt.
Do not block air vent of the device or ventilation around the device. Otherwise,
temperature in device will rise and may cause fire.
Do not place any object on the device.
Do not disassemble the device without professional instruction.
Warning:
Please use battery properly to avoid fire, explosion and other dangers.
Please replace used battery with battery of the same type.
Do not use power line other than the one specified. Please use it properly. Otherwise,
it may cause fire or electric shock.
Special Announcement
This manual is for reference only.
All the designs and software here are subject to change without prior written notice.
ered trademarks are the properties of their respective
owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.


1 General Introduction
1.1 Model List
This manual is for the following product models; please carefully check your model and
corresponding functions.
VTH15 Series
Model
Front Camera
Screen
SD Card
A
VTH1510A
Not support
Resistive
touch screen
Not support
VTH1520A
Not support
Resistive
touch screen
Support
AH
VTH1510AH
Not support
Resistive
touch screen
Not support
VTH1520AH
Not support
Resistive
touch screen
Support
AS
VTH1510AS
Not support
Resistive
touch screen
Not support
VTH1520AS
Not support
Resistive
touch screen
Support
AS-H
VTH1510AS-H
Not support
Resistive
touch screen
Not support
VTH1520AS-H
Not support
Resistive
touch screen
Support
B
VTH1550B
Not support
Capacitive
touch screen
Not support
VTH1560B(W)
Not support
Capacitive
touch screen
Support
CH
VTH1510CH
Not support
Resistive
touch screen
Not support
VTH1520CH
Support
Resistive
touch screen
Support
CS
VTH1560CS
Not support
Capacitive
touch screen
Support

1.2 Front Panel
Figure 1- 1 VTH15 Series A Model
Figure 1- 2 VTH15 Series AH Model

Figure 1- 3 VTH15 Series AS Model

Figure 1- 4 VTH15 Series AS-H Model

Figure 1- 5 VTH15 Series B(W) Model
Figure 1- 6 VTH15 Series CH Model

Figure 1- 7 VTH15 Series CS Model
Different models of VTH may have slightly different button locations, but same silk-screens still
correspond to the same function. See Figure 1- 8 and Figure 1- 9.
Figure 1- 8

Figure 1- 9
No.
Name
Note
1
SOS
Emergent call to center.
2
Arm/Menu
Press this button to return to main menu or arm.
3
Call
Under calling, status, press this button to answer call. During
a call, press this button to hang up.
4
Monitor
Monitor VTO video.
5
Unlock
During incoming call, calling, monitoring status, press this
button to unlock.
No.
Indicator
Name
Description
1
Power
Indicator turns on when power is normal.
2
Info
Indicator turns on when there is missed call, alarm, or
announcement. Otherwise, it remains off.
1.3 Rear Panel
Make VTH15 Series AH model and CH model as examples. Ports of VTH of different models
may have different locations, but corresponding ports’ functions stay the same.

Figure 1- 10 VTH15 Series AH Model
No.
Name
Note
1
Alarm port
8-ch alarm, may connect to external alarm extension
module, refer to label for details.
2
Debug port
For installation staff use only.
3
Network port
Plug in network cable.
4
Handset port
For model with handset only.
5
Power port
Connect to 2-pin plug 12V.

Figure 1- 11 VTH15 Series CH Model
No.
Name
Description
1
Alarm Port
8-ch alarm, please refer to tag.
2
Debug Port
Extension port, for RS485 communication port.
3
Network Port
Plug in network cable.
4
Alarm Output
Note:
Reserved port.
5
Power Port
Connect to 2-pin green 12V power supply.

2 Installation
2.1 Install Device
It introduces two installation methods as embedded box and direct installation.
Warning:
Avoid the indoor unit installed in adverse environments, such as condensation and high
temperature environment, oil and dust environment, chemically aggressive environments,
direct sunlight environment.
After power is found abnormal, should immediately unplug the network cable, turn off the
power. After troubleshooting before power again.
Project installation, debugging shall be performed by a professional team, in case of
equipment failure, do not disassemble repair yourself, please contact product sales
departments.
2.1.1 Embedded Box
Embedded box has 86-box and metal box, and their corresponding relationships are as
follows:
Embedded Box
Device
86 box
All devices.
Metal case
CH model ，including VTH1510CHand
VTH1520CH
2.1.1.1 86-Box
This installation is suitable for all models.
Screw
Component Name
Illustration
Quantity
M4×30 cross pan head
machine screw
2
Installation Step
Step 1. Embed 86-box into wall.
Step 2. Fix installation bracket on 86-box with screws.
Step 3. Fix device unit on installation bracket with buckle.
Note:
Distance from device center to ground is recommended to be 1400mm-1600mm.

Figure 2- 1
2.1.1.2 Metal Case
This installation method is for CH model only, including VTH1510CH and VTH1520CH.
Screw
Component Name
Illustration
Quantity
M4×30 cross pan head
machine screw
3
Installation Step
Step 1. Embed metal case into wall.
Step 2. Fix installation bracket on metal case with screws.
Step 3. Fix device unit on installation bracket with buckle.
Note:
Distance from device center to ground is recommended to be 1400mm-1600mm.

Figure 2- 2
2.1.2 Direct Installation
Direct installation is not to dig holes on wall, instead all wiring go from the side.
Installation Step
Step 1. Fix installation bracket on wall, with screw (M4×30 cross pan head machine screw).
Step 2. Fix the device unit on installation bracket with buckle.
Figure 2- 3
2.2 Wiring
Please refer to Ch 1.3.

3 Product Function
Digital VTH can unlock, alarm, talk, monitor, search message and set some system
performances.
3.1 Main Menu
The product main interface has four menus: Video Talk, Security, Message, and Settings. See
Figure 3- 1 VTH15 series.
Figure 3- 1 VTH15 series
Icon
Name
Note
Network
connection icon
It means network connection is normal.
VTO not
connected
It means device does not connect to any
VTO.
DND icon
It means device enable DND (do not
disturb) function.
3.1.1 Settings
System settings includes User, Project, Time, Product, and Info Initialization.
3.1.1.1 User
Click User Settings, to set password, ring, talk, DND, local IPC, touch cleaning and touch tone.
You also may restore system default settings.

Figure 3- 2
Set Password
Step 1. Click Password, and you can set password for user, unlock, arm/disarm and
anti-hijack.
Figure 3- 3
User password initial value is 123456
Unlock password initial value is null
Arm password initial value is 123456
Disarm password initial value is 123456
Anti-hijack password initial value is 654321.
Note:
Some models’ arm password is also its disarm password.
Step 2. After setup is complete, click OK.
Display Settings
Click Display Settings, you can click , to set screen brightness and screen saver
time.

Figure 3- 4
Ring Settings
Click Ring Settings, you can set phone ring, alarm ring, click and to
increase/decrease volume.
Figure 3- 5
Talk Settings
Step 1. Click Talk settings, you can set VTO and VTH’s ring time, call time, monitor time,
record time and message time.

Figure 3- 6
Step 1. Click to increase time, click to reduce time. Unit is second.
Step 2. Click OK.
DND Settings
Click DND Settings, you can set DND time (oh, 1h, 2h, 4h, 8h, 24h).
Local IPC
Step 1. Click Local IPC, you can set IPC name, IP address username, password, port and
protocol.
Figure 3- 7
Step 2. Click OK when finish.

Step 3. In homepage, click , you can view added IPC video window.
Clean
Click Clean, the screen will be locked for 10s and you can clean the screen during this time
period.
Default
Click Default to restore default settings.
Touch Ring
Slide , ON means touch ring is enabled and OFF means touch ring is disabled.
3.1.1.2 Project
This function is for professionals only, and the entrance password is 002236 by default.
Product Info
You can go to Project Settings>Product Info interface, to configure master VTH and
extension.
VTO “room no.” must match VTH short no. in VTH’s WEB interface.
Figure 3- 8
Net Set
You can go to Project Settings>Net Set interface, set master VTH’s IP, subnet mask,
gateway and MAC address.
