Daikin Altherma CHYHBH05AF User manual

Operation manual
Daikin Altherma R Hybrid English
Operation manual
Daikin Altherma R Hybrid
CHYHBH05AF
CHYHBH08AF

Table of contents
Operation manual
2
CHYHBH05+08AF
Daikin Altherma R Hybrid
4P471757-1C – 2020.10
Table of contents
1 About this document 2
2 About the system 2
2.1 Components in a typical system layout ..................................... 3
3 Operation 3
3.1 Overview: Operation.................................................................. 3
3.2 The user interface at a glance................................................... 3
3.2.1 Buttons........................................................................ 3
3.2.2 Status icons ................................................................ 3
3.3 Space heating control................................................................ 4
3.3.1 Room thermostat control - Using the room
temperature home pages............................................ 4
3.3.2 Room thermostat control - Using the leaving water
temperature home pages............................................ 5
3.4 Domestic hot water control........................................................ 5
3.4.1 Instant DHW (no tank installed) .................................. 5
3.4.2 Tank ............................................................................ 5
3.5 Schedules: Example.................................................................. 6
3.6 Menu structure: Overview user settings .................................... 7
3.7 Installer settings: Tables to be filled in by installer .................... 8
3.7.1 Quick wizard ............................................................... 8
3.7.2 Space heating control ................................................. 8
3.7.3 Domestic hot water control [A.4] ................................. 8
3.7.4 Contact/helpdesk number [6.3.2]................................ 8
3.8 Advanced usage........................................................................ 8
3.8.1 About changing the user permission level .................. 8
4 Setting the energy prices 8
4.1 To set the gas price................................................................... 8
4.2 To set the electricity price.......................................................... 9
4.3 To set the electricity price schedule timer ................................. 9
4.4 About energy prices in case of an incentive per kWh
renewable energy...................................................................... 9
4.4.1 To set the gas price in case of an incentive per kWh
renewable energy ....................................................... 9
4.4.2 To set the electricity price in case of an incentive per
kWh renewable energy ............................................... 9
4.4.3 Example ...................................................................... 9
5 Energy saving tips 9
6 Maintenance and service 10
6.1 Overview: Maintenance and service ......................................... 10
6.2 To find the contact/helpdesk number ........................................ 10
7 Troubleshooting 10
7.1 Symptom: You are feeling too cold (hot) in your living room..... 10
7.2 Symptom: The water at the tap is too cold ................................ 11
7.3 Symptom: Heat pump failure..................................................... 11
7.4 Symptom: The system is making gurgling noises after
commissioning........................................................................... 11
8 Disposal 11
9 Glossary 11
1 About this document
Thank you for purchasing this product. Please:
▪ Read the documentation carefully before operating the user
interface to ensure the best possible performance.
▪ Request the installer to inform you about the settings that he used
to configure your system. Check if he has filled in the installer
settings tables. If not, request him to do so.
▪ Keep the documentation for future reference.
Target audience
Endusers
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪General safety precautions:
▪ Safety instructions that you must read before operating your
system
▪ Format: Paper (in the box of the indoor unit)
▪Operation manual:
▪ Quick guide for basic usage
▪ Format: Paper (in the box of the indoor unit)
▪User reference guide:
▪ Detailed step-by-step instructions and background information
for basic and advanced usage
▪ Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
Available screens
Depending on your system layout and installer configuration, not all
screens in this document may be available on your user interface.
Breadcrumbs
1
20.0°C >
18.0°C >
7.4.1.1 Room temperature
Comfort (heating)
Eco (heating)
Select Scroll
Breadcrumbs help you to locate where you are in the menu structure
of the user interface. This document also mentions these
breadcrumbs.
Example: Go to [7.4.1.1]: > User settings > Preset values >
Room temperature > Comfort (heating)
2 About the system
Depending on the system layout, the system can:
▪ Heat up a space
▪ Produce domestic hot water
INFORMATION
The purpose of hybrid for multi indoor unit in combination
with multi outdoor unit is for heating only (space heating
and DHW (by boiler only)). The target use of the direct
expansion indoor unit (DX) in such a system is for cooling
only. A combination of hybrid and DX, both in heating
operation is NOT the main objective of such a system and
hence, the heating comfort or continuous operation of the
DX cannot be guaranteed over the complete operation
range.

3 Operation
Operation manual
3
CHYHBH05+08AF
Daikin Altherma R Hybrid
4P471757-1C – 2020.10
2.1 Components in a typical system
layout
d
a b c
e
f
gB
C
A
AMain zone. Example: Living room.
BAdditional zone. Example: Bedroom.
CTechnical room. Example: Garage.
aOutdoor unit heatpump
bIndoor unit heatpump
cInstant domestic hot water or domestic hot water (DHW) tank
dUser interface at the indoor unit
eUser interface in the living room, used as room thermostat
fRadiators
gDirect expansion indoor unit
3 Operation
3.1 Overview: Operation
You can operate the system via the user interface. This part
describes how to use the user interface:
Part Description
At a glance ▪ Buttons
▪ Status icons
Space heating control How to control space heating:
▪ Controlling the temperature
Domestic hot water
control
How to control domestic hot water:
▪ Reheat mode
▪ Scheduled mode
▪ Scheduled + reheat mode
Schedules How to select and program schedules
Menu structure Overview of menu structure
Installer settings table Overview of installer settings
3.2 The user interface at a glance
3.2.1 Buttons
a
ef
b
d
c
a HOME PAGES
▪ Switches between home pages (when you are on a home
page).
▪ Goes to the default home page (when you are in the menu
structure).
b MALFUNCTION INFORMATION
If a malfunction occurs, is displayed on the home pages.
Press to display more information about the malfunction.
c ON/OFF
Turns ON or OFF one of the controls (room temperature,
leaving water temperature, DHWtank temperature).
d MENU STRUCTURE/BACK
▪ Opens the menu structure (when you are on a home
page).
▪ Goes up a level (when you are navigating through the
menu structure).
▪ Goes back 1step (example: when you are programming a
schedule in the menu structure).
e   NAVIGATING/CHANGING SETTINGS
▪ Navigates the cursor on the display.
▪ Navigates through the menu structure.
▪ Changes settings.
▪ Selects a mode.
f OK
▪ Confirms a selection.
▪ Enters a submenu in the menu structure.
▪ Switches between displaying actual and desired values, or
between displaying actual and offset values (if applicable)
on the home pages.
▪ Goes to the next step (when you are programming a
schedule in the menu structure).
▪ Enables you to activate or deactivate button lock if pressed
for more than 5seconds on a home page.
▪ Enables you to activate or deactivate a function lock if
pressed for more than 5seconds in the main menu of the
menu structure.
INFORMATION
If you press or while changing settings, the changes
will NOT be applied.
3.2.2 Status icons
Icon Description
Space operation mode = Heating.
Not applicable.

3 Operation
Operation manual
4
CHYHBH05+08AF
Daikin Altherma R Hybrid
4P471757-1C – 2020.10
Icon Description
Heat pump (compressor) operation or boiler
operation. This symbol is related to the home page.
Desired room temperature = preset value (Comfort;
daytime).
Desired room temperature = preset value (Eco;
nighttime).
▪ On the room temperature home page: Desired
room temperature = according to the selected
schedule.
▪ On the DHW tank temperature home page:
DHWtank mode = Scheduled mode.
DHWtank mode = Reheat mode.
DHWtank mode = Scheduled + reheat mode.
Domestic hot water operation.
Actual temperature.
Desired temperature.
At the next scheduled action, the desired temperature
will increase.
At the next scheduled action, the desired temperature
will NOT change.
At the next scheduled action, the desired temperature
will decrease.
The preset value (Comfort or Eco) or scheduled value
is temporarily overruled.
The DHWtank booster mode is active or ready to be
activated.
Quiet mode is active.
Holiday mode is active or ready to be activated.
Button lock mode and/or function lock mode is active.
Boiler operation.
Heat pump (compressor) operation.
Boiler and heat pump (compressor) operation.
The disinfection mode is active.
A malfunction occurred. Press to display more
information about the malfunction.
Weather-dependent mode is active.
User permission level = Installer.
Defrost/oil return mode is active.
Not applicable.
Emergency operation is active.
INFORMATION
Boiler operation does NOT necessarily imply burner
operation. When a heating demand is sent to the boiler,
boiler operation ( ) is continuous, but the burner will ONLY
operate alternately.
INFORMATION
When operation symbol is blinking, then this means that
the outdoor unit is operation in cooling or dry operation. In
this case the gas boiler will take over to heat up the water
circuit if required.
3.3 Space heating control
NOTICE
Room frost protection. Even if you turn OFF the leaving
water temperature (main + additional) control via the home
pages (LWT main + LWT add), room frost protection –if
enabled– will remain active.
3.3.1 Room thermostat control - Using the room
temperature home pages
Typical room temperature home pages
Depending on the user profile, the user interface gives you either a
basic or a detailed home page. To set the user profile, refer to
Configuring user profile and home pages in the user reference
guide.
User profile = Basic User profile = Detailed
15:20
20.0°C
Mon
Room
Actual temperature
15:20
20.0°C
17:30
Actual temperature
Room
Scheduled
Mon
Tue
To read out the actual and desired room
temperature
1Go to the room temperature home page (Room).
Result: You can read out the actual temperature.
20.0°C
Actual temperature
2Press .
Result: You can read out the desired temperature.
22.0°C
Desired temperature
To temporarily overrule the room temperature
schedule
1Go to the room temperature home page (Room).
2In the detailed home page (user profile = Detailed), select the
scheduled room temperature mode ( ) by pressing or
.
Result: The room temperature follows the scheduled value.
3Use or to adjust the temperature.
Result: The room temperature follows the manually adjusted
value ( ), but will return to the scheduled value at the next
scheduled action.
To change the mode from scheduled to preset
value
Prerequisite: User profile = Detailed.
1Go to the room temperature home page (Room).
2Press or to select a preset value ( or ).
Result: The room temperature follows the preset value
(Comfort or Eco), but will return to the scheduled value after the
overrule period (= Temperature lock: 2/4/6/8 hours or
permanent).
3If necessary, you can overrule the preset value by using or
to adjust the temperature.
Result: The room temperature follows the manually adjusted
value ( ), but will return to the scheduled value after the
overrule period (= Temperature lock: 2/4/6/8 hours or
permanent).

3 Operation
Operation manual
5
CHYHBH05+08AF
Daikin Altherma R Hybrid
4P471757-1C – 2020.10
To set the overrule period
Prerequisite: You switched the permission level to Advanced end
user.
1Go to [7.2]: > User settings > Temperature lock.
2Select a value and press :
▪Permanent
▪hours (2, 4, 6, 8)
3.3.2 Room thermostat control - Using the
leaving water temperature home pages
INFORMATION
The leaving water is the water that is sent to the heat
emitters. The desired leaving water temperature is set by
your installer in accordance with the heat emitter type.
Example: Underfloor heating is designed for lower leaving
water temperature than radiators and heat pump
convectors and/or fan coil units. You only have to adjust
leaving water temperature settings in case of problems.
For more information about the leaving water temperature, see the
user reference guide.
3.4 Domestic hot water control
NOTICE
Disinfection mode. Even if you turn OFF domestic hot
water operation via the DHWtank temperature home page
(Tank), disinfection mode will remain active.
3.4.1 Instant DHW (no tank installed)
Not applicable for Switzerland
When there is a demand for hot water tapping, the boiler provides
DHW instantly.
Using the instant DHW home page
Not applicable for Switzerland
Depending on the user profile, the user interface gives you either a
basic or a detailed home page.
User profile = Basic User profile = Detailed
44°C
01:03
Tue
DHW
Desired temperature
01:03
44°C Tue
DHW
Desired temperature
To adjust the instant DHW temperature
1Go to the instant DHW home page.
2Press or to adjust the instant DHW temperature (DHW).
The instant DHW set point temperature may NOT be below 40°C.
3.4.2 Tank
The following modes are only applicable if a tank is installed and are
set by the installer.
Reheat mode
In reheat mode ( ),the DHW tank continuously heats up to the
temperature shown on the DHW tank temperature home page
(example: 50°C).
t
60°C
00:00 07:00
50°C
15°C
40°C
14:00 21:00
1
2
3
4
Tt
TtDomestic hot water tank temperature
tTime
INFORMATION
When the DHW tank mode is reheat, the risk for capacity
shortage and comfort problem is significant. In case of
frequent reheat operation, space heating function is
regularly interrupted.
Scheduled mode
In scheduled mode ( ), the DHW tank produces hot water
corresponding to a schedule. The best time to allow the tank to
produce hot water is at night, because the space heating demand is
lower.
Example:
t
60°C
00:00 07:00
50°C
15°C
40°C
14:00 21:00
1
2
34
5
Tt
TtDomestic hot water tank temperature
tTime
Scheduled + reheat mode
In scheduled + reheat mode (  ), the domestic hot water control is
the same as in scheduled mode. However, when the DHW tank
temperature drops below a preset value (=reheat tank temperature –
hysteresis value; example: 35°C), the DHW tank heats up until it
reaches the reheat set point (example: 45°C). This ensures that a
minimum amount of hot water is available at all times.
Example:
t
Tt
60°C
00:00 07:00
50°C
45°C
15°C
14:00 21:00
35°C
1
24
5
3
TtDHWtank temperature
tTime
60°C Storage comfort
50°C Storage eco
45°C Reheat
35°C Reheat tank temperature–hysteresis value
