Installer reference guide
Split system air conditioners
FTXP20M5V1B9
FTXP25M5V1B9
FTXP35M5V1B9

Table of contents
Installer reference guide
2
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
Table of contents
1 About the documentation 4
1.1 About this document ...................................................................................................................................................... 4
2 General safety precautions 5
2.1 For the installer............................................................................................................................................................... 5
2.1.1 General ........................................................................................................................................................... 5
2.1.2 Installation site ............................................................................................................................................... 6
2.1.3 Refrigerant — in case of R410A or R32.......................................................................................................... 8
2.1.4 Brine................................................................................................................................................................ 10
2.1.5 Water .............................................................................................................................................................. 10
2.1.6 Electrical ......................................................................................................................................................... 10
3 Specific installer safety instructions 13
4 About the box 15
4.1 Overview: About the box ................................................................................................................................................ 15
4.2 Indoor unit ...................................................................................................................................................................... 15
4.2.1 To unpack the indoor unit.............................................................................................................................. 15
4.2.2 To remove the accessories from the indoor unit .......................................................................................... 15
5 About the unit 17
5.1 System layout.................................................................................................................................................................. 17
5.2 Operation range.............................................................................................................................................................. 17
6 Unit installation 18
6.1 Preparing the installation site......................................................................................................................................... 18
6.1.1 Installation site requirements of the indoor unit .......................................................................................... 18
6.2 Opening the indoor unit ................................................................................................................................................. 19
6.2.1 To remove the front panel ............................................................................................................................. 19
6.2.2 To re-install the front panel ........................................................................................................................... 20
6.2.3 To remove the front grille .............................................................................................................................. 20
6.2.4 To re-install the front grille ............................................................................................................................ 22
6.2.5 To remove the electrical wiring box cover..................................................................................................... 22
6.2.6 To open the service cover .............................................................................................................................. 22
6.3 Installing the indoor unit ................................................................................................................................................ 23
6.3.1 Precautions when installing the indoor unit.................................................................................................. 23
6.3.2 To install the mounting plate ......................................................................................................................... 23
6.3.3 To drill a wall hole........................................................................................................................................... 23
6.3.4 To remove the pipe port cover ...................................................................................................................... 24
6.3.5 To provide drainage........................................................................................................................................ 24
7 Piping installation 28
7.1 Preparing refrigerant piping ........................................................................................................................................... 28
7.1.1 Refrigerant piping requirements.................................................................................................................... 28
7.1.2 Refrigerant piping insulation.......................................................................................................................... 29
7.2 Connecting the refrigerant piping .................................................................................................................................. 29
7.2.1 About connecting the refrigerant piping ....................................................................................................... 29
7.2.2 Precautions when connecting the refrigerant piping.................................................................................... 29
7.2.3 Guidelines when connecting the refrigerant piping...................................................................................... 30
7.2.4 Pipe bending guidelines ................................................................................................................................. 31
7.2.5 To flare the pipe end ...................................................................................................................................... 31
7.2.6 To connect the refrigerant piping to the indoor unit .................................................................................... 32
8 Electrical installation 33
8.1 Preparing electrical wiring .............................................................................................................................................. 33
8.1.1 About preparing electrical wiring................................................................................................................... 33
8.2 Connecting the electrical wiring..................................................................................................................................... 33
8.2.1 About connecting the electrical wiring.......................................................................................................... 33
8.2.2 Precautions when connecting the electrical wiring....................................................................................... 34
8.2.3 Guidelines when connecting the electrical wiring......................................................................................... 34
8.2.4 Specifications of standard wiring components.............................................................................................. 35
8.2.5 To connect the electrical wiring to the indoor unit....................................................................................... 35
8.2.6 To connect optional accessories (wired user interface, central user interface, wireless adapter, etc.)...... 37
9 Finishing the indoor unit installation 38
9.1 To insulate the drain piping, refrigerant piping and interconnection cable.................................................................. 38
9.2 To pass the pipes through the wall hole ........................................................................................................................ 38

Table of contents
Installer reference guide
3
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
9.3 To fix the unit on the mounting plate ............................................................................................................................ 39
10 Configuration 40
10.1 To set a different channel of the indoor unit infrared signal receiver .......................................................................... 40
11 Commissioning 42
11.1 Overview: Commissioning .............................................................................................................................................. 42
11.2 Checklist before commissioning ..................................................................................................................................... 42
11.3 To perform a test run...................................................................................................................................................... 43
11.3.1 To perform a test run in winter season ......................................................................................................... 43
12 Hand-over to the user 44
13 Disposal 45
14 Technical data 46
14.1 Wiring diagram................................................................................................................................................................ 46
14.1.1 Unified wiring diagram legend ....................................................................................................................... 46
15 Glossary 49

1 | About the documentation
Installer reference guide
4
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
1 About the documentation
1.1 About this document
INFORMATION
Make sure that the user has the printed documentation and ask him/her to keep it
for future reference.
Target audience
Authorised installers
INFORMATION
This appliance is intended to be used by expert or trained users in shops, in light
industry, and on farms, or for commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set consists of:
▪General safety precautions:
-Safety instructions that you MUST read before installing
-Format: Paper (in the box of the indoor unit)
▪Indoor unit installation manual:
-Installation instructions
-Format: Paper (in the box of the indoor unit)
▪Installer reference guide:
-Preparation of the installation, good practices, reference data,…
-Format: Digital files on http://www.daikineurope.com/support-and-manuals/
product-information/
Latest revisions of the supplied documentation may be available on the regional
Daikin website or via your dealer.
The original documentation is written in English. All other languages are
translations.
Technical engineering data
▪A subset of the latest technical data is available on the regional Daikin website
(publicly accessible).
▪The full set of latest technical data is available on the Daikin Business Portal
(authentication required).

2 | General safety precautions
Installer reference guide
5
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
2 General safety precautions
2.1 For the installer
2.1.1 General
If you are NOT sure how to install or operate the unit, contact your dealer.
DANGER: RISK OF BURNING/SCALDING
▪Do NOT touch the refrigerant piping, water piping or internal parts during and
immediately after operation. It could be too hot or too cold. Give it time to return
to normal temperature. If you MUST touch it, wear protective gloves.
▪Do NOT touch any accidental leaking refrigerant.
WARNING
Improper installation or attachment of equipment or accessories could result in
electrical shock, short-circuit, leaks, fire or other damage to the equipment. ONLY
use accessories, optional equipment and spare parts made or approved by Daikin.
WARNING
Make sure installation, testing and applied materials comply with applicable
legislation (on top of the instructions described in the Daikin documentation).
CAUTION
Wear adequate personal protective equipment (protective gloves, safety glasses,…)
when installing, maintaining or servicing the system.
WARNING
Tear apart and throw away plastic packaging bags so that nobody, especially
children, can play with them. Possible risk: suffocation.
WARNING
Provide adequate measures to prevent that the unit can be used as a shelter by small
animals. Small animals that make contact with electrical parts can cause
malfunctions, smoke or fire.
CAUTION
Do NOT touch the air inlet or aluminium fins of the unit.
CAUTION
▪Do NOT place any objects or equipment on top of the unit.
▪Do NOT sit, climb or stand on the unit.
In accordance with the applicable legislation, it might be necessary to provide a
logbook with the product containing at least: information on maintenance, repair
work, results of tests, stand-by periods,…
Also, at least, following information MUST be provided at an accessible place at the
product:

2 | General safety precautions
Installer reference guide
6
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
▪Instructions for shutting down the system in case of an emergency
▪Name and address of fire department, police and hospital
▪Name, address and day and night telephone numbers for obtaining service
In Europe, EN378 provides the necessary guidance for this logbook.
2.1.2 Installation site
▪Provide sufficient space around the unit for servicing and air circulation.
▪Make sure the installation site withstands the weight and vibration of the unit.
▪Make sure the area is well ventilated. Do NOT block any ventilation openings.
▪Make sure the unit is level.
Do NOT install the unit in the following places:
▪In potentially explosive atmospheres.
▪In places where there is machinery that emits electromagnetic waves.
Electromagnetic waves may disturb the control system, and cause malfunction of
the equipment.
▪In places where there is a risk of fire due to the leakage of flammable gases
(example: thinner or gasoline), carbon fibre, ignitable dust.
▪In places where corrosive gas (example: sulphurous acid gas) is produced.
Corrosion of copper pipes or soldered parts may cause the refrigerant to leak.
▪In bathrooms.
Instructions for equipment using R32 refrigerant
WARNING: FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
WARNING
▪Do NOT pierce or burn refrigerant cycle parts.
▪Do NOT use cleaning materials or means to accelerate the defrosting process
other than those recommended by the manufacturer.
▪Be aware that the refrigerant inside the system is odourless.
WARNING
The appliance shall be stored so as to prevent mechanical damage and in a well-
ventilated room without continuously operating ignition sources (example: open
flames, an operating gas appliance or an operating electric heater) and have a room
size as specified below.
WARNING
Make sure installation, servicing, maintenance and repair comply with instructions
from Daikin and with applicable legislation and are executed ONLY by authorised
persons.

2 | General safety precautions
Installer reference guide
7
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
WARNING
If one or more rooms are connected to the unit using a duct system, make sure:
▪there are no operating ignition sources (example: open flames, an operating gas
appliance or an operating electric heater) in case the floor area is less than the
minimum floor area A (m²).
▪no auxiliary devices, which may be a potential ignition source, are installed in the
duct work (example: hot surfaces with a temperature exceeding 700°C and
electric switching device);
▪only auxiliary devices approved by the manufacturer are used in the duct work;
▪air inlet AND outlet are connected directly to the same room by ducting. Do NOT
use spaces such as a false ceiling as a duct for the air inlet or outlet.
NOTICE
▪Precautions shall be taken to avoid excessive vibration or pulsation to
refrigeration piping.
▪Protection devices, piping and fittings shall be protected as far as possible against
adverse environmental effects.
▪Provision shall be made for expansion and contraction of long runs of piping.
▪Piping in refrigerating systems shall be designed and installed such as to minimise
the likelihood of hydraulic shock damaging the system.
▪The indoor equipment and pipes shall be securely mounted and guarded such
that accidental rupture of equipment or pipes cannot occur from events such as
moving furniture or reconstruction activities.
CAUTION
Do NOT use potential sources of ignition in searching for or detection of refrigerant
leaks.
NOTICE
▪Do NOT re-use joints and copper gaskets which have been used already.
▪Joints made in installation between parts of refrigerant system shall be accessible
for maintenance purposes.
Installation space requirements
WARNING
If appliances contain R32 refrigerant, the floor area of the room in which the
appliances are installed, operated and stored MUST be larger than the minimum
floor area defined in table below A (m2). This applies to:
▪Indoor units without a refrigerant leakage sensor; in case of indoor units with
refrigerant leakage sensor, consult the installation manual
▪Outdoor units installed or stored indoors (e.g. winter garden, garage, machinery
room)
NOTICE
▪Pipework shall be protected from physical damage.
▪Installation of pipework shall be kept to a minimum.
To determine the minimum floor area
1Determine the total refrigerant charge in the system (= factory refrigerant
charge + additional refrigerant amount charged).

2 | General safety precautions
Installer reference guide
8
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
Contains fluorinated greenhouse gases
2
11
1
2
2kg
tCO
2
eq
1000
GWP × kg
=
=
+
kg
=
kg
=
GWP: xxx
R32
2Determine which graph or table to use.
▪For indoor units: Is the unit ceiling-mounted, wall-mounted or floor-
standing?
▪For outdoor units installed or stored indoors, this depends on the installation
height:
If the installation height is… Then use the graph or table for…
<1.8m Floor-standing units
1.8≤x<2.2m Wall-mounted units
≥2.2m Ceiling-mounted units
mTotal refrigerant charge in the system
Amin Minimum floor area
(a) Ceiling-mounted unit (= Ceiling-mounted unit)
(b) Wall-mounted unit (= Wall-mounted unit)
(c) Floor-standing unit (= Floor-standing unit)
2.1.3 Refrigerant — in case of R410A or R32
If applicable. See the installation manual or installer reference guide of your
application for more information.
NOTICE
Make sure refrigerant piping installation complies with applicable legislation. In
Europe, EN378 is the applicable standard.
NOTICE
Make sure the field piping and connections are NOT subjected to stress.
WARNING
During tests, NEVER pressurise the product with a pressure higher than the
maximum allowable pressure (as indicated on the nameplate of the unit).
WARNING
Take sufficient precautions in case of refrigerant leakage. If refrigerant gas leaks,
ventilate the area immediately. Possible risks:
▪Excessive refrigerant concentrations in a closed room can lead to oxygen
deficiency.
▪Toxic gas might be produced if refrigerant gas comes into contact with fire.

2 | General safety precautions
Installer reference guide
9
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
DANGER: RISK OF EXPLOSION
Pump down – Refrigerant leakage. If you want to pump down the system, and there
is a leak in the refrigerant circuit:
▪Do NOT use the unit's automatic pump down function, with which you can collect
all refrigerant from the system into the outdoor unit. Possible consequence: Self-
combustion and explosion of the compressor because of air going into the
operating compressor.
▪Use a separate recovery system so that the unit's compressor does NOT have to
operate.
WARNING
ALWAYS recover the refrigerant. Do NOT release them directly into the environment.
Use a vacuum pump to evacuate the installation.
NOTICE
After all the piping has been connected, make sure there is no gas leak. Use nitrogen
to perform a gas leak detection.
NOTICE
▪To avoid compressor breakdown, do NOT charge more than the specified amount
of refrigerant.
▪When the refrigerant system is to be opened, refrigerant MUST be treated
according to the applicable legislation.
WARNING
Make sure there is no oxygen in the system. Refrigerant may ONLY be charged after
performing the leak test and the vacuum drying.
Possible consequence: Self-combustion and explosion of the compressor because of
oxygen going into the operating compressor.
▪In case recharge is required, see the nameplate of the unit. It states the type of
refrigerant and necessary amount.
▪The unit is factory charged with refrigerant and depending on pipe sizes and pipe
lengths some systems require additional charging of refrigerant.
▪ONLY use tools exclusively for the refrigerant type used in the system, this to
ensure pressure resistance and prevent foreign materials from entering into the
system.
▪Charge the liquid refrigerant as follows:
If Then
A siphon tube is present
(i.e., the cylinder is marked with "Liquid
filling siphon attached")
Charge with the cylinder upright.
A siphon tube is NOT present Charge with the cylinder upside down.
▪Open refrigerant cylinders slowly.

2 | General safety precautions
Installer reference guide
10
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
▪Charge the refrigerant in liquid form. Adding it in gas form may prevent normal
operation.
CAUTION
When the refrigerant charging procedure is done or when pausing, close the valve of
the refrigerant tank immediately. If the valve is NOT closed immediately, remaining
pressure might charge additional refrigerant. Possible consequence: Incorrect
refrigerant amount.
2.1.4 Brine
If applicable. See the installation manual or installer reference guide of your
application for more information.
WARNING
The selection of the brine MUST be in accordance with the applicable legislation.
WARNING
Take sufficient precautions in case of brine leakage. If brine leaks, ventilate the area
immediately and contact your local dealer.
WARNING
The ambient temperature inside the unit can get much higher than that of the room,
e.g. 70°C. In case of a brine leak, hot parts inside the unit can create a hazardous
situation.
WARNING
The use and installation of the application MUST comply with the safety and
environmental precautions specified in the applicable legislation.
2.1.5 Water
If applicable. See the installation manual or installer reference guide of your
application for more information.
NOTICE
Make sure water quality complies with EU directive 2020/2184.
2.1.6 Electrical
DANGER: RISK OF ELECTROCUTION
▪Turn OFF all power supply before removing the switch box cover, connecting
electrical wiring or touching electrical parts.
▪Disconnect the power supply for more than 10minutes, and measure the voltage
at the terminals of main circuit capacitors or electrical components before
servicing. The voltage MUST be less than 50VDC before you can touch electrical
components. For the location of the terminals, see the wiring diagram.
▪Do NOT touch electrical components with wet hands.
▪Do NOT leave the unit unattended when the service cover is removed.

2 | General safety precautions
Installer reference guide
11
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
WARNING
If NOT factory installed, a main switch or other means for disconnection, having a
contact separation in all poles providing full disconnection under overvoltage
categoryIII condition, MUST be installed in the fixed wiring.
WARNING
▪ONLY use copper wires.
▪Make sure the field wiring complies with the applicable legislation.
▪All field wiring MUST be performed in accordance with the wiring diagram
supplied with the product.
▪NEVER squeeze bundled cables and make sure they do NOT come in contact with
the piping and sharp edges. Make sure no external pressure is applied to the
terminal connections.
▪Make sure to install earth wiring. Do NOT earth the unit to a utility pipe, surge
absorber, or telephone earth. Incomplete earth may cause electrical shock.
▪Make sure to use a dedicated power circuit. NEVER use a power supply shared by
another appliance.
▪Make sure to install the required fuses or circuit breakers.
▪Make sure to install an earth leakage protector. Failure to do so may cause
electrical shock or fire.
▪When installing the earth leakage protector, make sure it is compatible with the
inverter (resistant to high frequency electric noise) to avoid unnecessary opening
of the earth leakage protector.
CAUTION
▪When connecting the power supply: connect the earth cable first, before making
the current-carrying connections.
▪When disconnecting the power supply: disconnect the current-carrying cables
first, before separating the earth connection.
▪The length of the conductors between the power supply stress relief and the
terminal block itself MUST be as such that the current-carrying wires are
tautened before the earth wire is in case the power supply is pulled loose from
the stress relief.
NOTICE
Precautions when laying power wiring:
▪Do NOT connect wiring of different thicknesses to the power terminal block (slack
in the power wiring may cause abnormal heat).
▪When connecting wiring which is the same thickness, do as shown in the figure
above.
▪For wiring, use the designated power wire and connect firmly, then secure to
prevent outside pressure being exerted on the terminal board.
▪Use an appropriate screwdriver for tightening the terminal screws. A screwdriver
with a small head will damage the head and make proper tightening impossible.
▪Over-tightening the terminal screws may break them.

2 | General safety precautions
Installer reference guide
12
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
WARNING
▪After finishing the electrical work, confirm that each electrical component and
terminal inside the electrical components box is connected securely.
▪Make sure all covers are closed before starting up the unit.
NOTICE
ONLY applicable if the power supply is three‑phase, and the compressor has an ON/
OFF starting method.
If there exists the possibility of reversed phase after a momentary black out and the
power goes ON and OFF while the product is operating, attach a reversed phase
protection circuit locally. Running the product in reversed phase can break the
compressor and other parts.

3 | Specific installer safety instructions
Installer reference guide
13
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
3 Specific installer safety instructions
Always observe the following safety instructions and regulations.
Unit installation (see "6Unit installation"[ 4
18])
WARNING
Installation shall be done by an installer, the choice of materials and installation shall
comply with the applicable legislation. In Europe, EN378 is the applicable standard.
WARNING
The appliance shall be stored so as to prevent mechanical damage and in a well-
ventilated room without continuously operating ignition sources (e.g. open flames,
an operating gas appliance, or an operating electric heater). The room size shall be as
specified in the General safety precaution.
CAUTION
For walls containing a metal frame or a metal board, use a wall embedded pipe and
wall cover in the feed-through hole to prevent possible heat, electrical shock, or fire.
Piping installation (see "7Piping installation"[ 4
28])
CAUTION
Piping and joints of a split system shall be made with permanent joints when inside
an occupied space except joints directly connecting the piping to the indoor units.
DANGER: RISK OF BURNING/SCALDING
NOTICE
▪Use the flare nut fixed to the unit.
▪To prevent gas leakage, apply refrigeration oil ONLY to the inside of the flare. Use
refrigeration oil for R32 (FW68DA).
▪Do NOT reuse joints.
NOTICE
▪Do NOT use mineral oil on flared part.
▪NEVER install a drier to this R32 unit to guarantee its lifetime. The drying material
may dissolve and damage the system.
NOTICE
▪Incomplete flaring may cause refrigerant gas leakage.
▪Do NOT re-use flares. Use new flares to prevent refrigerant gas leakage.
▪Use flare nuts that are included with the unit. Using different flare nuts may
cause refrigerant gas leakage.
Electrical installation (see "8Electrical installation"[ 4
33])
DANGER: RISK OF ELECTROCUTION

3 | Specific installer safety instructions
Installer reference guide
14
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
WARNING
ALWAYS use multicore cable for power supply cables.
WARNING
▪All wiring MUST be performed by an authorised electrician and MUST comply
with the applicable legislation.
▪Make electrical connections to the fixed wiring.
▪All components procured on-site and all electrical construction MUST comply
with the applicable legislation.
WARNING
▪If the power supply has a missing or wrong N-phase, equipment might break
down.
▪Establish proper earthing. Do NOT earth the unit to a utility pipe, surge absorber,
or telephone earth. Incomplete earthing may cause electrical shock.
▪Install the required fuses or circuit breakers.
▪Secure the electrical wiring with cable ties so that the cables do NOT come in
contact with sharp edges or piping, particularly on the high-pressure side.
▪Do NOT use taped wires, stranded conductor wires, extension cords, or
connections from a star system. They can cause overheating, electrical shock or
fire.
▪Do NOT install a phase advancing capacitor, because this unit is equipped with an
inverter. A phase advancing capacitor will reduce performance and may cause
accidents.
WARNING
Use an all-pole disconnection type breaker with at least 3mm between the contact
point gaps that provide full disconnection under overvoltage category III.
WARNING
If the supply cord is damaged, it MUST be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
WARNING
Do NOT connect the power supply to the indoor unit. This could result in electrical
shock or fire.
WARNING
▪Do NOT use locally purchased electrical parts inside the product.
▪Do NOT branch the power supply for the drain pump, etc. from the terminal
block. This could result in electrical shock or fire.
WARNING
Keep the interconnection wiring away from copper pipes without thermal insulation
as such pipes will be very hot.

4 | About the box
Installer reference guide
15
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
4 About the box
4.1 Overview: About the box
This chapter describes what you have to do after the box with the indoor unit is
delivered on-site.
It contains information about:
▪Unpacking and handling the unit
▪Removing the accessories from the unit
Keep the following in mind:
▪At delivery, the unit MUST be checked for damage. Any damage MUST be
reported immediately to the claims agent of the carrier.
▪Bring the packed unit as close as possible to its final installation position to
prevent damage during transport.
▪When handling the unit, take into account the following:
Fragile, handle the unit with care.
Keep the unit upright in order to avoid damage.
▪Prepare the path along which you want to bring the unit inside in advance.
4.2 Indoor unit
INFORMATION
The following figures are just examples and may NOT completely match your system
layout.
4.2.1 To unpack the indoor unit
4.2.2 To remove the accessories from the indoor unit
1Remove:
▪the accessory bag located at the bottom of the package,
▪the mounting plate attached to the back of the indoor unit.

4 | About the box
Installer reference guide
16
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
2× 2× 2×1× 1× 1×1× 1× 1×
edba c f g h i
aInstallation manual
bOperation manual
cGeneral safety precautions
dTitanium apatite deodorising and silver particle filter (only for FTXP)
eIndoor unit fixing screw (M4×12L). Refer to "9.3To fix the unit on the mounting
plate"[439].
fDry battery AAA.LR03 (alkaline) for user interface
gUser interface holder
hUser interface
iMounting plate

5 | About the unit
Installer reference guide
17
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
5 About the unit
WARNING: FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
5.1 System layout
NOTICE
Design of the system must not be done at temperatures below –15°C.
a
f
c
e
d
b
aIndoor unit
bService lid
cAir filter
dTitanium apatite deodorising and silver particle filter (only for FTXP)
eRefrigerant piping, drain hose and interconnection cable
fInsulation tape
5.2 Operation range
Use the system in the following temperature and humidity ranges for safe and
effective operation.
Operation mode Operation range
Cooling(a)(b) ▪Outdoor temperature: –10~48°C DB
▪Indoor temperature: 18~32°C DB
▪Indoor humidity: ≤80%
Heating(a) ▪Outdoor temperature: –15~24°C DB
▪Indoor temperature: 10~30°C DB
Drying(a) ▪Outdoor temperature: –10~48°C DB
▪Indoor temperature: 18~32°C DB
▪Indoor humidity: ≤80%
(a) A safety device might stop the operation of the system if the unit runs outside its
operation range.
(b) Condensation and water dripping might occur if the unit runs outside its operation range.

6 | Unit installation
Installer reference guide
18
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
6 Unit installation
In this chapter
6.1 Preparing the installation site ................................................................................................................................................ 18
6.1.1 Installation site requirements of the indoor unit .................................................................................................. 18
6.2 Opening the indoor unit ......................................................................................................................................................... 19
6.2.1 To remove the front panel..................................................................................................................................... 19
6.2.2 To re-install the front panel ................................................................................................................................... 20
6.2.3 To remove the front grille...................................................................................................................................... 20
6.2.4 To re-install the front grille .................................................................................................................................... 22
6.2.5 To remove the electrical wiring box cover ............................................................................................................ 22
6.2.6 To open the service cover...................................................................................................................................... 22
6.3 Installing the indoor unit ........................................................................................................................................................ 23
6.3.1 Precautions when installing the indoor unit.......................................................................................................... 23
6.3.2 To install the mounting plate................................................................................................................................. 23
6.3.3 To drill a wall hole .................................................................................................................................................. 23
6.3.4 To remove the pipe port cover.............................................................................................................................. 24
6.3.5 To provide drainage ............................................................................................................................................... 24
6.1 Preparing the installation site
Choose an installation location with sufficient space for carrying the unit in and out
of the site.
Do NOT install the unit in places often used as work place. In case of construction
works (e.g. grinding works) where a lot of dust is created, the unit MUST be
covered.
WARNING
The appliance shall be stored in a room without continuously operating ignition
sources (example: open flames, an operating gas appliance or an operating electric
heater).
6.1.1 Installation site requirements of the indoor unit
INFORMATION
Also read the precautions and requirements in the "2 General safety
precautions"[45].
INFORMATION
The sound pressure level is less than 70dBA.
▪Air flow. Make sure nothing blocks the air flow.
▪Drainage. Make sure condensation water can be evacuated properly.
▪Wall insulation. When conditions in the wall exceed 30°C and a relative humidity
of 80%, or when fresh air is inducted into the wall, then additional insulation is
required (minimum 10mm thickness, polyethylene foam).
▪Wall strength. Check whether the wall or the floor is strong enough to support
the weight of the unit. If there is a risk, reinforce the wall or the floor before
installing the unit.

6 | Unit installation
Installer reference guide
19
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
Install power cables at least 1 metre away from televisions or radios to prevent
interference. Depending on the radio waves, a distance of 3metres may NOT be
sufficient.
▪Choose a location where the operation noise or the hot/cold air discharged from
the unit will not disturb anyone.
▪Fluorescent lights. When installing a wireless remote control (user interface) in a
room with fluorescent lights, mind the following to avoid interference:
-Install the wireless remote control (user interface) as close as possible to the
indoor unit.
-Install the indoor unit as far as possible from the fluorescent lights.
It is NOT recommended to install the unit in the following places because it may
shorten the life of the unit:
▪Where the voltage fluctuates a lot
▪In vehicles or vessels
▪Where acidic or alkaline vapour is present
▪In places where a mineral oil mist, spray or vapour may be present in the
atmosphere. Plastic parts may deteriorate and fall off or cause water leakage.
▪In places where the unit would be in the path of direct sunlight.
▪In bathrooms.
▪Sound sensitive areas (e.g. near a bedroom), so that the operation noise will
cause no trouble.
NOTICE
Do NOT place objects below the indoor and/or outdoor unit that may get wet.
Otherwise condensation on the unit or refrigerant pipes, air filter dirt or drain
blockage may cause dripping, and objects under the unit may get dirty or damaged.
WARNING
Do NOT place objects below the indoor and/or outdoor unit that may get wet.
Otherwise condensation on the unit or refrigerant pipes, air filter dirt or drain
blockage may cause dripping, and objects under the unit may get dirty or damaged.
▪Spacing. Install the unit at least 1.8 m from the floor and keep the following
requirements in mind for distances from the walls and the ceiling:
≥50 ≥50
≥30
(mm)
6.2 Opening the indoor unit
6.2.1 To remove the front panel
1Hold the front panel by the panel tabs on both sides and open it.

6 | Unit installation
Installer reference guide
20
FTXP20~35M5V1B9
Split system air conditioners
4P519439-7S – 2021.12
a
aPanel tabs
a
aPanel tabs
2Remove the front panel by sliding it to the left or the right and pulling it
toward you.
Result: The front panel shaft on 1 side will be disconnected.
3Disconnect the front panel shaft on the other side in the same manner.
a
aFront panel shaft
6.2.2 To re-install the front panel
1Attach the front panel. Align the shafts with the slots and push them all the
way in.
2Close the front panel slowly; press at both sides and at the centre.
6.2.3 To remove the front grille
CAUTION
Wear adequate personal protective equipment (protective gloves, safety glasses,…)
when installing, maintaining or servicing the system.
1Remove the front panel to remove the air filter.
2Remove 2 screws (class 20~35) or 3 screws (class 50~71) from the front grille.
3Push down the 3 upper hooks marked with a symbol with 3 circles.
