Daikin FTKS L Series Dimension Guide

FTK(X)S-L Series
- Cooling Only / Heat Pump -
ED041204

ED041204
Split Type Air Conditioners FTK(X)S-L Series 1
Split Type
Air Conditioners
FTK(X)S-L Series
1. Power Supply ..........................................................................................3
2. Functions.................................................................................................4
2.1 Cooling Only.............................................................................................4
2.2 Heat Pump ...............................................................................................5
3. Specifications ..........................................................................................6
3.1 Cooling Only.............................................................................................6
3.2 Heat Pump .............................................................................................10
4. Dimensions ..........................................................................................15
4.1 Indoor Unit..............................................................................................15
4.2 Outdoor Unit ...........................................................................................20
5. Wiring Diagrams....................................................................................23
5.1 Indoor Unit..............................................................................................23
5.2 Outdoor Unit ...........................................................................................24
6. Piping Diagrams....................................................................................26
6.1 Indoor Unit..............................................................................................26
6.2 Outdoor Unit ...........................................................................................28
7. Capacity Tables ....................................................................................33
7.1 Cooling Only...........................................................................................33
7.2 Heat Pump .............................................................................................37
Cooling Only
FTKS20LVMA
FTKS25LVMA
FTKS35LVMA
FTKS46LVMA
FTKS50LVMA
FTKS60LVMA
FTKS71LVMA
RKS20LVMA
RKS25LVMA
RKS35LVMA
RKS46LVMA
RKS50LVMA
RKS60LVMA
RKS71LVMA
Heat Pump
FTXS20LVMA
FTXS25LVMA
FTXS35LVMA
FTXS46LVMA
FTXS50LVMA
FTXS60LVMA
FTXS71LVMA
FTXS85LVMA
FTXS95LVMA
RXS20LVMA
RXS25LVMA
RXS35LVMA
RXS46LVMA
RXS50LVMA
RXS60LVMA
RXS71LVMA
RXS85LVMA
RXS95LVMA

ED041204
2Split Type Air Conditioners FTK(X)S-L Series
7.3 Capacity correction factor by the length of refrigerant piping
(Reference) ............................................................................................46
8. Operation Limit......................................................................................48
8.1 Cooling Only...........................................................................................48
8.2 Heat Pump .............................................................................................49
9. Sound Level ..........................................................................................50
9.1 Measuring Location ................................................................................50
9.2 Indoor Unit..............................................................................................51
9.3 Outdoor Unit ...........................................................................................55
10.Electric Characteristics..........................................................................59
11.Installation Manual ................................................................................60
11.1 Indoor Unit..............................................................................................60
11.2 Outdoor Unit ...........................................................................................82
12.Operation Manual................................................................................111
12.1 Safety Precautions ...............................................................................111
12.2 20/25/35/46 Class ................................................................................113
12.3 50/60/71 Class .....................................................................................147
12.4 85/95 Class ..........................................................................................181
13.Optional Accessories ..........................................................................215
13.1 Option List ............................................................................................215
13.2 <BRC944B2> Wired Remote Controller...............................................216
13.3 <KRP413AB1S> Wiring Adaptor for Timer Clock /
Remote Controller ................................................................................230
13.4 <KRP928BB2S> Interface Adaptor for DIII-NET
(Residential Air Conditioner) ................................................................234
13.5 <KPW937A4> Air Direction Adjustment Grille......................................237
13.6 <KPW945A4> Air Direction Adjustment Grille......................................238
13.7 <KPW5E112> Air Direction Adjustment Grille......................................239
13.8 <KKP945A4> Drain Plug......................................................................241

ED041204 Power Supply
Split Type Air Conditioners FTK(X)S-L Series 3
1. Power Supply
Note: Power Supply Intake; Outdoor Unit
Indoor Unit Outdoor Unit Power Supply
FTKS20LVMA RKS20LVMA
1 φ, 220 ~ 240 V, 50 Hz
1 φ, 220 ~ 230 V, 60 Hz
FTKS25LVMA RKS25LVMA
FTKS35LVMA RKS35LVMA
FTKS46LVMA RKS46LVMA
FTKS50LVMA RKS50LVMA
FTKS60LVMA RKS60LVMA
FTKS71LVMA RKS71LVMA
FTXS20LVMA RXS20LVMA
FTXS25LVMA RXS25LVMA
FTXS35LVMA RXS35LVMA
FTXS46LVMA RXS46LVMA
FTXS50LVMA RXS50LVMA
FTXS60LVMA RXS60LVMA
FTXS71LVMA RXS71LVMA
FTXS85LVMA RXS85LVMA
FTXS95LVMA RXS95LVMA

Functions ED041204
4Split Type Air Conditioners FTK(X)S-L Series
2. Functions
2.1 Cooling Only
Category Functions
FTKS20/25/35/50/60/71LVMA RKS20/25/35/50/60/71LVMA FTKS46LVMA RKS46LVMA
Category Functions
FTKS20/25/35/50/60/71LVMA RKS20/25/35/50/60/71LVMA FTKS46LVMA RKS46LVMA
Basic Function Inverter (with Inverter Power Control) zzHealth & Clean Air-Purifying Filter — —
Operation Limit for Cooling (°CDB) 10
~ 46
10
~ 46
Photocatalytic Deodorising Filter — —
Air-Purifying Filter with Photocatalytic
Deodorising Function —— Operation Limit for Heating (°CWB) — —
PAM Control zz Titanium Apatite Photocatalytic
Air-Purifying Filter zz
Standby Electricity Saving zz Air Filter (Prefilter) zz
Compressor Oval Scroll Compressor — — Wipe-Clean Flat Panel zz
Swing Compressor zz Washable Grille — —
Rotary Compressor — — MOULD PROOF Operation — —
Reluctance DC Motor zz Heating Dry Operation — —
Comfortable
Airflow
Power-Airflow Flap — — Good-Sleep Cooling Operation — —
Power-Airflow Dual Flaps zzTimer WEEKLY TIMER Operation zz
Power-Airflow Diffuser — — 24-Hour ON/OFF TIMER zz
Wide-Angle Louvres zz NIGHT SET Mode zz
Vertical Auto-Swing (Up and Down) zzWorry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) zz
Horizontal Auto-Swing (Right and Left) zz Self-Diagnosis (Digital, LED) Display zz
3-D Airflow zz Wiring Error Check Function — —
COMFORT AIRFLOW Operation zz Anti-Corrosion Treatment of Outdoor
Heat Exchanger zz
Comfort
Control
Auto Fan Speed zz
Indoor Unit Quiet Operation zz
Flexibility Multi-Split / Split Type Compatible
Indoor Unit z—
NIGHT QUIET Mode (Automatic) — — Flexible Power Supply
Correspondence zz
OUTDOOR UNIT QUIET Operation
(Manual) zz High Ceiling Application — —
INTELLIGENT EYE Operation zz Chargeless 10 m 10 m
Quick Warming Function
(Preheating Operation) — — Either Side Drain (Right or Left) zz
Hot-Start Function — — Power Selection — —
Automatic Defrosting — — Remote
Control
5-Room Centralised Controller
(Option) zz
Operation Automatic Operation — — Remote Control Adaptor
(Normal Open Pulse Contact) (Option) zz
Programme Dry Operation zz
Fan Only zz
Remote Control Adaptor
(Normal Open Contact) (Option) zz
Lifestyle
Convenience
New POWERFUL Operation (Non-
Inverter) ——
Inverter POWERFUL Operation zz DIII-NET Compatible (Adaptor)
(Option) zz
Priority-Room Setting — — Remote
Controller
Wireless zz
COOL / HEAT Mode Lock — — Wired (Option) zz
HOME LEAVE Operation — —
ECONO Operation zz
Indoor Unit ON/OFF Button zz
Signal Receiving Sign zz
R/C with Back Light zz
Temperature Display — —
Note: z: Holding Functions
— : No Functions

ED041204 Functions
Split Type Air Conditioners FTK(X)S-L Series 5
2.2 Heat Pump
Category Functions
FTXS20/25/35/50/60/71LVMA RXS20/25/35/50/60/71LVMA FTXS46/85/95LVMA RXS46/85/95LVMA
Category Functions
FTXS20/25/35/50/60/71LVMA RXS20/25/35/50/60/71LVMA FTXS46/85/95LVMA RXS46/85/95LVMA
Basic Function Inverter (with Inverter Power Control) zzHealth & Clean Air-Purifying Filter — —
Operation Limit for Cooling (°CDB) 10
~ 46
10
~ 46 Photocatalytic Deodorising Filter — —
Operation Limit for Heating (°CWB) –15
~ 18
–15
~ 18
Air-Purifying Filter with Photocatalytic
Deodorising Function ——
PAM Control zz Titanium Apatite Photocatalytic
Air-Purifying Filter zz
Standby Electricity Saving zz
Compressor Oval Scroll Compressor — — Air Filter (Prefilter) zz
Swing Compressor zz Wipe-Clean Flat Panel zz
Rotary Compressor — — Washable Grille — —
Reluctance DC Motor zz MOULD PROOF Operation — —
Comfortable
Airflow
Power-Airflow Flap — — Heating Dry Operation — —
Power-Airflow Dual Flaps zz Good-Sleep Cooling Operation — —
Power-Airflow Diffuser — — Timer WEEKLY TIMER Operation zz
Wide-Angle Louvres zz 24-Hour ON/OFF TIMER zz
Vertical Auto-Swing (Up and Down) zz NIGHT SET Mode zz
Horizontal Auto-Swing (Right and Left) zzWorry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) zz
3-D Airflow zz Self-Diagnosis (Digital, LED) Display zz
COMFORT AIRFLOW Operation zz Wiring Error Check Function — —
Comfort
Control
Auto Fan Speed zz Anti-Corrosion Treatment of Outdoor
Heat Exchanger zz
Indoor Unit Quiet Operation zz
NIGHT QUIET Mode (Automatic) — — Flexibility Multi-Split / Split Type Compatible
Indoor Unit z—
OUTDOOR UNIT QUIET Operation
(Manual) zz
INTELLIGENT EYE Operation zz Flexible Power Supply
Correspondence zz
Quick Warming Function
(Preheating Operation) zz High Ceiling Application — —
Hot-Start Function zz Chargeless 10 m 10 m
Automatic Defrosting zz Either Side Drain (Right or Left) zz
Operation Automatic Operation zz Power Selection — —
Programme Dry Operation zzRemote
Control 5-Room Centralised Controller
(Option) zz
Fan Only zz
Lifestyle
Convenience
New POWERFUL Operation
(Non-Inverter) —— Remote Control Adaptor (Normal Open Pulse Contact) (Option) zz
Inverter POWERFUL Operation zz Remote Control Adaptor
(Normal Open Contact) (Option) zz
Priority-Room Setting — —
DIII-NET Compatible (Adaptor)
(Option)
zz
COOL / HEAT Mode Lock — — Remote
Controller
Wireless zz
HOME LEAVE Operation — — Wired (Option) zz
ECONO Operation zz
Indoor Unit ON/OFF Button zz
Signal Receiving Sign zz
R/C with Back Light zz
Temperature Display — —
Note: z: Holding Functions
— : No Functions

Specifications ED041204
6Split Type Air Conditioners FTK(X)S-L Series
3. Specifications
3.1 Cooling Only
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model Indoor Unit FTKS20LVMA FTKS25LVMA
Outdoor Unit RKS20LVMA RKS25LVMA
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.5 (1.3 ~ 3.2)
Btu/h 6,800 (4,400 ~ 9,600) 8,500 (4,400 ~ 10,900)
kcal/h 1,720 (1,120 ~ 2,410) 2,150 (1,120 ~ 2,750)
Moisture Removal L/h 0.9 1.2
Running Current (Rated) A 2.6 - 2.5 - 2.4 / 2.6 - 2.5 3.1 - 3.0 - 2.9 / 3.1 - 3.0
Power Consumption
Rated (Min. ~ Max.) W 450 (320 ~ 910) 540 (320 ~ 770)
Power Factor % 78.7 - 78.3 - 78.1 / 78.7 - 78.3 79.2 - 78.3 - 77.6 / 79.2 - 78.3
EER (Cooling)
Rated (Min. ~ Max.) W/W 4.44 (4.06 ~ 3.08) 4.63 (4.06 ~ 4.16)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTKS20LVMA FTKS25LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
9.7 (343) 10.6 (374)
M 7.7 (272) 8.1 (286)
L 5.6 (198) 5.7 (201)
SL 4.1 (145) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 / 0.09 - 0.08 0.10 - 0.09 - 0.09 / 0.10 - 0.09
Power Consumption (Rated) W 18 - 18 - 18 / 18 - 18 20 - 20 - 20 / 20 - 20
Power Factor % 90.9 - 97.8 - 93.8 / 90.9 - 97.8 90.9 - 96.6 - 92.6 / 90.9 - 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 9 10
Gross Weight (Gross Mass) kg 13 13
Sound Pressure
Level H / M / L / SL dB(A) 38 / 32 / 25 / 22 40 / 32 / 25 / 22
Sound Power
Level HdB 54 56
Outdoor Unit RKS20LVMA RKS25LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 600 600
Refrigerant Oil Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant Type R-410A R-410A
Charge kg 0.8 1.2
Airflow Rate Hm³/min
(cfm)
36.2 (1,278) 33.5 (1,183)
SL 32.7 (1,155) 30.1 (1,063)
Fan Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.5 - 2.4 - 2.3 / 2.5 - 2.4 3.0 - 2.9 - 2.8 / 3.0 - 2.9
Power Consumption (Rated) W 432 - 432 - 432 / 432 - 432 520 - 520 - 520 / 520 - 520
Power Factor % 78.5 - 78.3 - 78.3 / 78.5 - 78.3 78.8 - 78.0 - 77.4 / 78.8 - 78.0
Starting Current A 2.6 3.1
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 589 × 882 × 363 589 × 882 × 363
Weight (Mass) kg 31 34
Gross Weight (Gross Mass) kg 35 38
Sound Pressure
Level H / SL dB(A) 46 / 43 47 / 43
Sound Power
Level HdB 60 61
Drawing No. 3D075852 3D075853
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB 7.5 m

ED041204 Specifications
Split Type Air Conditioners FTK(X)S-L Series 7
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model Indoor Unit FTKS35LVMA FTKS46LVMA
Outdoor Unit RKS35LVMA RKS46LVMA
Capacity
Rated (Min. ~ Max.)
kW 3.5 (1.4 ~ 4.0) 4.6 (1.7 ~ 5.3)
Btu/h 11,900 (4,800 ~ 13,600) 15,700 (5,800 ~ 18,100)
kcal/h 3,010 (1,200 ~ 3,440) 3,960 (1,460 ~ 4,560)
Moisture Removal L/h 1.9 2.9
Running Current (Rated) A 4.4 - 4.2 - 4.0 / 4.4 - 4.2 5.8 - 5.5 - 5.3 / 5.8 - 5.5
Power Consumption
Rated (Min. ~ Max.) W 910 (350 ~ 1,160) 1,250 (440 ~ 1,760)
Power Factor % 94.0 - 94.2 - 94.8 / 94.0 - 94.2 98.0 - 98.8 - 98.3 / 98.0 - 98.8
EER (Cooling)
Rated (Min. ~ Max.) W/W 3.85 (4.00 ~ 3.45) 3.68 (3.86 ~ 3.01)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 12.7
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20 30
Max. lnterunit Height Difference m 15 20
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTKS35LVMA FTKS46LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
11.3 (399) 12.2 (431)
M 8.6 (304) 10.6 (374)
L 5.9 (208) 9.0 (318)
SL 4.6 (162) 7.9 (279)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 / 0.12 - 0.12 0.15 - 0.14 - 0.14 / 0.15 - 0.14
Power Consumption (Rated) W 26 - 26 - 26 / 26 - 26 32 - 32 - 32 / 32 - 32
Power Factor % 98.5 - 94.2 - 98.5 / 98.5 - 94.2 97.0 - 99.4 - 95.2 / 97.0 - 99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 10 10
Gross Weight (Gross Mass) kg 13 13
Sound Pressure
Level H / M / L / SL dB(A) 42 / 34 / 26 / 23 44 / 40 / 35 / 32
Sound Power
Level HdB 58 60
Outdoor Unit RKS35LVMA RKS46LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 2YC36BXD
Motor Output W 600 1,100
Refrigerant Oil Type FVC50K FVC50K
Charge L 0.375 0.650
Refrigerant Type R-410A R-410A
Charge kg 1.2 1.7
Airflow Rate Hm³/min
(cfm)
36.0 (1,271) 48.5 (1,713)
SL 30.1 (1,063) 41.6 (1,469)
Fan Type Propeller Propeller
Motor Output W 33 53
Running Current (Rated) A 4.3 - 4.1 - 3.9 / 4.3 - 4.1 5.6 - 5.4 - 5.2 / 5.6 - 5.4
Power Consumption (Rated) W 884 - 884 - 884 / 884 - 884 1,218 - 1,218 - 1,218 / 1,218 - 1,218
Power Factor % 93.4 - 93.7 - 94.4 / 93.4 - 93.7 98.9 - 98.1 - 97.6 / 98.9 - 98.1
Starting Current A 4.4 5.8
Dimensions (H × W × D) mm 550 × 765 × 285 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 589 × 882 × 363 792 × 960 × 390
Weight (Mass) kg 34 46
Gross Weight (Gross Mass) kg 38 52
Sound Pressure
Level H / SL dB(A) 49 / 44 47 / 44
Sound Power
Level HdB 63 61
Drawing No. 3D075854 3D075855
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB 7.5 m

Specifications ED041204
8Split Type Air Conditioners FTK(X)S-L Series
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model Indoor Unit FTKS50LVMA FTKS60LVMA
Outdoor Unit RKS50LVMA RKS60LVMA
Capacity
Rated (Min. ~ Max.)
kW 5.0 (1.7 ~ 6.0) 6.0 (1.7 ~ 6.7)
Btu/h 17,100 (5,800 ~ 20,500) 20,500 (5,800 ~ 22,900)
kcal/h 4,300 (1,460 ~ 5,160) 5,160 (1,460 ~ 5,760)
Moisture Removal L/h 2.9 3.9
Running Current (Rated) A 6.1 - 5.8 - 5.6 / 6.1 - 5.8 7.8 - 7.4 - 7.1 / 7.8 - 7.4
Power Consumption
Rated (Min. ~ Max.) W 1,320 (440 ~ 1,920) 1,690 (440 ~ 2,230)
Power Factor % 98.4 - 99.0 - 98.2 / 98.4 - 99.0 98.5 - 99.3 - 99.2 / 98.5 - 99.3
EER (Cooling)
Rated (Min. ~ Max.) W/W 3.79 (3.86 ~ 3.13) 3.55 (3.86 ~ 3.00)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 12.7 φ 12.7
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 30 30
Max. lnterunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTKS50LVMA FTKS60LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
18.3 (646) 19.2 (678)
M 14.9 (526) 15.5 (547)
L 11.6 (410) 11.9 (420)
SL 10.8 (381) 10.7 (378)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.30 - 0.29 - 0.28 / 0.30 - 0.29 0.48 - 0.46 - 0.45 / 0.48 - 0.46
Power Consumption (Rated) W 38 - 38 - 38 / 38 - 38 60 - 60 - 60 / 60 - 60
Power Factor % 57.6 - 57.0 - 56.5 / 57.6 - 57.0 56.8 - 56.7 - 55.6 / 56.8 - 56.7
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 248 340 × 1,050 × 248
Packaged Dimensions (H × W × D) mm 331 × 1,160 × 429 331 × 1,160 × 429
Weight (Mass) kg 14 14
Gross Weight (Gross Mass) kg 20 21
Sound Pressure
Level H / M / L / SL dB(A) 46 / 40 / 35 / 32 48 / 42 / 36 / 33
Sound Power
Level HdB 62 64
Outdoor Unit RKS50LVMA RKS60LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant Oil Type FVC50K FVC50K
Charge L 0.650 0.650
Refrigerant Type R-410A R-410A
Charge kg 1.8 1.8
Airflow Rate Hm³/min
(cfm)
48.5 (1,713) 50.4 (1,780)
SL 41.6 (1,469) 42.3 (1,494)
Fan Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 5.9 - 5.6 - 5.4 / 5.9 - 5.6 7.5 - 7.1 - 6.8 / 7.5 - 7.1
Power Consumption (Rated) W 1,282 - 1,282 - 1,282 / 1,282 - 1,282 1,630 - 1,630 - 1,630 / 1,630 - 1,630
Power Factor % 98.8 - 99.5 - 98.9 / 98.8 - 99.5 98.8 - 99.8 - 99.9 / 98.8 - 99.8
Starting Current A 6.1 10
Dimensions (H × W × D) mm 735 × 825 × 300 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 792 × 960 × 390 792 × 960 × 390
Weight (Mass) kg 46 46
Gross Weight (Gross Mass) kg 52 52
Sound Pressure
Level H / SL dB(A) 47 / 44 49 / 46
Sound Power
Level HdB 61 63
Drawing No. 3D075828A 3D075829
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB 7.5 m

ED041204 Specifications
Split Type Air Conditioners FTK(X)S-L Series 9
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model Indoor Unit FTKS71LVMA
Outdoor Unit RKS71LVMA
Capacity
Rated (Min. ~ Max.)
kW 7.1 (2.3 ~ 8.5)
Btu/h 24,200 (7,800 ~ 29,000)
kcal/h 6,110 (1,980 ~ 7,310)
Moisture Removal L/h 4.5
Running Current (Rated) A 9.7 - 9.3 - 8.9 / 9.7 - 9.3
Power Consumption
Rated (Min. ~ Max.) W 2,080 (570 ~ 3,060)
Power Factor % 97.5 - 97.2 - 97.4 / 97.5 - 97.2
EER (Cooling)
Rated (Min. ~ Max.) W/W 3.41 (4.04 ~ 2.78)
Piping
Connections
Liquid mm φ 9.5
Gas mm φ 15.9
Drain mm φ 16.0
Heat Insulation Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 30
Max. lnterunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of Refrigerant g/m 50
Indoor Unit FTKS71LVMA
Front Panel Colour White
Airflow Rate
H
m³/min
(cfm)
21.1 (745)
M16.9 (597)
L12.7 (448)
SL 11.5 (406)
Fan
Type Cross Flow Fan
Motor Output W 48
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.68 - 0.65 - 0.62 / 0.68 - 0.65
Power Consumption (Rated) W 82 - 82 - 82 / 82 - 82
Power Factor % 54.8 - 54.8 - 55.1 / 54.8 - 54.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 248
Packaged Dimensions (H × W × D) mm 331 × 1,160 × 429
Weight (Mass) kg 14
Gross Weight (Gross Mass) kg 21
Sound Pressure
Level H / M / L / SL dB(A) 51 / 44 / 37 / 34
Sound Power
Level HdB 67
Outdoor Unit RKS71LVMA
Casing Colour Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63BXD
Motor Output W 1,920
Refrigerant Oil Type FVC50K
Charge L 0.750
Refrigerant Type R-410A
Charge kg 2.3
Airflow Rate Hm³/min
(cfm)
55.8 (1,970)
SL 46.0 (1,624)
Fan Type Propeller
Motor Output W 66
Running Current (Rated) A 9.3 - 8.9 - 8.5 / 9.3 - 8.9
Power Consumption (Rated) W 1,998 - 1,998 - 1,998 / 1,998 - 1,998
Power Factor % 97.7 - 97.6 - 97.9 / 97.7 - 97.6
Starting Current A 9.7
Dimensions (H × W × D) mm 770 × 900 × 320
Packaged Dimensions (H × W × D) mm 900 × 925 × 390
Weight (Mass) kg 71
Gross Weight (Gross Mass) kg 79
Sound Pressure
Level H / SL dB(A) 52 / 49
Sound Power
Level HdB 66
Drawing No. 3D075830
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB 7.5 m

Specifications ED041204
10 Split Type Air Conditioners FTK(X)S-L Series
3.2 Heat Pump
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS20LVMA FTXS25LVMA
Outdoor Unit RXS20LVMA RXS25LVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.7 (1.3 ~ 4.3) 2.5 (1.3 ~ 3.2) 3.4 (1.3 ~ 4.7)
Btu/h 6,800 (4,400 ~ 9,600) 9,200 (4,400 ~ 14,700) 8,500 (4,400 ~ 10,900) 11,600 (4,400 ~ 16,000)
kcal/h 1,720 (1,120 ~ 2,410) 2,320 (1,120 ~ 3,700) 2,150 (1,120 ~ 2,750) 2,920 (1,120 ~ 4,040)
Moisture Removal L/h 0.9 — 1.2 —
Running Current (Rated) A 2.6 - 2.5 - 2.4 / 2.6 - 2.5 3.5 - 3.4 - 3.2 / 3.5 - 3.4 3.1 - 3.0 - 2.9 / 3.1 - 3.0 4.0 - 3.8 - 3.7 / 4.0 - 3.8
Power Consumption
Rated (Min. ~ Max.) W 450 (320 ~ 910) 610 (310 ~ 1,360) 540 (320 ~ 770) 700 (310 ~ 1,170)
Power Factor % 78.7 - 78.3 - 78.1 /
78.7 - 78.3 79.2 - 78.0 - 79.4 / 79.2 - 78.0 79.2 - 78.3 - 77.6 / 79.2 - 78.3 79.5 - 80.1 - 78.8 / 79.5 - 80.1
EER (Cooling) / COP (Heating)
Rated (Min. ~ Max.) W/W 4.44 (4.06 ~ 3.08) 4.43 (4.19 ~ 3.16) 4.63 (4.06 ~ 4.16) 4.86 (4.19 ~ 4.02)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTXS20LVMA FTXS25LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
9.7 (343) 10.5 (371) 10.6 (374) 11.5 (406)
M 7.7 (272) 8.5 (300) 8.1 (286) 9.3 (328)
L 5.6 (198) 6.7 (237) 5.7 (201) 7.2 (254)
SL 4.1 (145) 5.6 (198) 4.4 (155) 6.4 (226)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 /
0.09 - 0.08 0.10 - 0.10 - 0.09 / 0.10 - 0.10 0.10 - 0.09 - 0.09 / 0.10 - 0.09 0.13 - 0.13 - 0.12 / 0.13 - 0.13
Power Consumption (Rated) W 18 - 18 - 18 / 18 - 18 21 - 21 - 21 / 21 - 21 20 - 20 - 20 / 20 - 20 28 - 28 - 28 / 28 - 28
Power Factor % 90.9 - 97.8 - 93.8 /
90.9 - 97.8 95.5 - 91.3 - 97.2 / 95.5 - 91.3 90.9 - 96.6 - 92.6 / 90.9 - 96.6 97.9 - 93.6 - 97.2 / 97.9 - 93.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 9 10
Gross Weight (Gross Mass) kg 13 13
Sound Pressure
Level H / M / L / SL dB(A) 38 / 32 / 25 / 22 39 / 34 / 28 / 25 40 / 32 / 25 / 22 40 / 34 / 28 / 25
Sound Power
Level HdB54555656
Outdoor Unit RXS20LVMA RXS25LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 600 600
Refrigerant Oil Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant Type R-410A R-410A
Charge kg 0.8 1.2
Airflow Rate Hm³/min
(cfm)
36.2 (1,278) 32.6 (1,151) 33.5 (1,183) 30.2 (1,066)
SL 32.7 (1,155) 27.8 (982) 30.1 (1,063) 25.6 (904)
Fan Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.5 - 2.4 - 2.3 / 2.5 - 2.4 3.4 - 3.3 - 3.1 / 3.4 - 3.3 3.0 - 2.9 - 2.8 / 3.0 - 2.9 3.8 - 3.6 - 3.6 / 3.8 - 3.6
Power Consumption (Rated) W 432 - 432 - 432 / 432 - 432 589 - 589 - 589 / 589 - 589 520 - 520 - 520 / 520 - 520 672 - 672 - 672 / 672 - 672
Power Factor % 78.5 - 78.3 - 78.3 /
78.5 - 78.3 78.7 - 77.6 - 79.2 / 78.7 - 77.6 78.8 - 78.0 - 77.4 / 78.8 - 78.0 80.4 - 81.2 - 77.8 / 80.4 - 81.2
Starting Current A 3.5 4.0
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 589 × 882 × 363 589 × 882 × 363
Weight (Mass) kg 31 34
Gross Weight (Gross Mass) kg 35 38
Sound Pressure
Level H / SL dB(A) 46 / 43 47 / 44 47 / 43 48 / 44
Sound Power
Level HdB60616162
Drawing No. 3D075848 3D075849A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 7.5 m

ED041204 Specifications
Split Type Air Conditioners FTK(X)S-L Series 11
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS35LVMA FTXS46LVMA
Outdoor Unit RXS35LVMA RXS46LVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 3.5 (1.4 ~ 4.0) 4.0 (1.4 ~ 5.2) 4.6 (1.7 ~ 5.3) 5.1 (1.7 ~ 6.8)
Btu/h 11,900 (4,800 ~ 13,600) 13,600 (4,800 ~ 17,700) 15,700 (5,800 ~ 18,100) 17,400 (5,800 ~ 23,200)
kcal/h 3,010 (1,200 ~ 3,440) 3,440 (1,200 ~ 4,470) 3,960 (1,460 ~ 4,560) 4,390 (1,460 ~ 5,850)
Moisture Removal L/h 1.9 — 2.9 —
Running Current (Rated) A 4.4 - 4.2 - 4.0 / 4.4 - 4.2 4.1 - 4.0 - 3.8 / 4.1 - 4.0 5.8 - 5.5 - 5.3 / 5.8 - 5.5 6.3 - 6.0 - 5.8 / 6.3 - 6.0
Power Consumption
Rated (Min. ~ Max.) W 910 (350 ~ 1,160) 880 (340 ~ 1,320) 1,250 (440 ~ 1,760) 1,370 (400 ~ 2,160)
Power Factor % 94.0 - 94.2 - 94.8 /
94.0 - 94.2 97.6 - 95.7 - 96.5 / 97.6 - 95.7 98.0 - 98.8 - 98.3 / 98.0 - 98.8 98.8 - 99.3 - 98.4 / 98.8 - 99.3
EER (Cooling) / COP (Heating)
Rated (Min. ~ Max.) W/W 3.85 (4.00 ~ 3.45) 4.55 (4.12 ~ 3.94) 3.68 (3.86 ~ 3.01) 3.72 (4.25 ~ 3.15)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ12.7
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 30
Max. Interunit Height Difference m 15 20
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTXS35LVMA FTXS46LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
11.3 (399) 12.0 (424) 12.2 (431) 12.9 (455)
M 8.6 (304) 9.8 (346) 10.6 (374) 10.8 (381)
L 5.9 (208) 7.7 (272) 9.0 (318) 8.7 (307)
SL 4.6 (162) 6.6 (233) 7.9 (279) 7.7 (272)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 /
0.12 - 0.12 0.14 - 0.14 - 0.13 / 0.14 - 0.14 0.15 - 0.14 - 0.14 / 0.15 - 0.14 0.16 - 0.16 - 0.15 / 0.16 - 0.16
Power Consumption (Rated) W 26 - 26 - 26 / 26 - 26 30 - 30 - 30 / 30 - 30 32 - 32 - 32 / 32 - 32 35 - 35 - 35 / 35 - 35
Power Factor % 98.5 - 94.2 - 98.5 /
98.5 - 94.2 97.4 - 93.2 - 96.2 / 97.4 - 93.2 97.0 - 99.4 - 95.2 / 97.0 - 99.4 99.4 - 95.1 - 97.2 / 99.4 - 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 10 10
Gross Weight (Gross Mass) kg 13 13
Sound Pressure
Level H / M / L / SL dB(A) 42 / 34 / 26 / 23 42 / 36 / 29 / 26 44 / 40 / 35 / 32 42 / 38 / 33 / 30
Sound Power
Level HdB58586058
Outdoor Unit RXS35LVMA RXS46LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 2YC36BXD
Motor Output W 600 1,100
Refrigerant Oil Type FVC50K FVC50K
Charge L 0.375 0.650
Refrigerant Type R-410A R-410A
Charge kg 1.2 1.7
Airflow Rate Hm³/min
(cfm)
36.0 (1,271) 30.2 (1,066) 48.5 (1,713) 39.8 (1,405)
SL 30.1 (1,063) 25.6 (904) 41.6 (1,469) 37.0 (1,306)
Fan Type Propeller Propeller
Motor Output W 33 53
Running Current (Rated) A 4.3 - 4.1 - 3.9 /
4.3 - 4.1 4.0 - 3.9 - 3.7 / 4.0 - 3.9 5.6 - 5.4 - 5.2 / 5.6 - 5.4 6.1 - 5.9 - 5.7 / 6.1 - 5.9
Power Consumption (Rated) W 884 - 884 - 884 /
884 - 884 850 - 850 - 850 / 850 - 850 1,218 - 1,218 - 1,218 / 1,218 - 1,218 1,335 - 1,335 - 1,335 / 1,335 - 1,335
Power Factor % 93.4 - 93.7 - 94.4 /
93.4 - 93.7 96.6 - 94.8 - 95.7 / 96.6 - 94.8 98.9 - 98.1 - 97.6 / 98.9 - 98.1 99.5 - 98.4 - 97.6 / 99.5 - 98.4
Starting Current A 4.4 6.3
Dimensions (H × W × D) mm 550 × 765 × 285 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 589 × 882 × 363 792 × 960 × 390
Weight (Mass) kg 34 46
Gross Weight (Gross Mass) kg 38 52
Sound Pressure
Level H / SL dB(A) 49 / 44 49 / 45 47 / 44 48 / 45
Sound Power
Level HdB63636162
Drawing No. 3D075850A 3D075851
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 7.5 m

Specifications ED041204
12 Split Type Air Conditioners FTK(X)S-L Series
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS50LVMA FTXS60LVMA
Outdoor Unit RXS50LVMA RXS60LVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 5.0 (1.7 ~ 6.0) 6.0 (1.7 ~ 7.7) 6.0 (1.7 ~ 6.7) 7.0 (1.7 ~ 8.0)
Btu/h 17,100 (5,800 ~ 20,500) 20,500 (5,800 ~ 26,300) 20,500 (5,800 ~ 22,900) 23,900 (5,800 ~ 27,300)
kcal/h 4,300 (1,460 ~ 5,160) 5,160 (1,460 ~ 6,620) 5,160 (1,460 ~ 5,760) 6,020 (1,460 ~ 6,880)
Moisture Removal L/h 2.9 — 3.9 —
Running Current (Rated) A 6.1 - 5.8 - 5.6 / 6.1 - 5.8 6.8 - 6.5 - 6.2 / 6.8 - 6.5 7.8 - 7.4 - 7.1 / 7.8 - 7.4 7.9 - 7.6 - 7.3 / 7.9 - 7.6
Power Consumption
Rated (Min. ~ Max.) W 1,320 (440 ~ 1,920) 1,470 (400 ~ 2,150) 1,690 (440 ~ 2,230) 1,730 (400 ~ 2,360)
Power Factor % 98.4 - 99.0 - 98.2 /
98.4 - 99.0 98.3 - 98.3 - 98.8 / 98.3 - 98.3 98.5 - 99.3 - 99.2 / 98.5 - 99.3 99.5 - 99.0 - 98.7 / 99.5 - 99.0
EER (Cooling) / COP (Heating)
Rated (Min. ~ Max.) W/W 3.79 (3.86 ~ 3.13) 4.08 (4.25 ~ 3.58) 3.55 (3.86 ~ 3.00) 4.05 (4.25 ~ 3.39)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 12.7 φ 12.7
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTXS50LVMA FTXS60LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
18.3 (646) 19.4 (685) 19.2 (678) 21.2 (749)
M 14.9 (526) 16.1 (568) 15.5 (547) 16.7 (590)
L 11.6 (410) 12.7 (448) 11.9 (420) 12.4 (438)
SL 10.8 (381) 11.7 (413) 10.7 (378) 11.2 (395)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.30 - 0.29 - 0.28 /
0.30 - 0.29 0.32 - 0.31 - 0.30 / 0.32 - 0.31 0.48 - 0.46 - 0.45 / 0.48 - 0.46 0.55 - 0.53 - 0.51 / 0.55 - 0.53
Power Consumption (Rated) W 38 - 38 - 38 / 38 - 38 40 - 40 - 40 / 40 - 40 60 - 60 - 60 / 60 - 60 68 - 68 - 68 / 68 - 68
Power Factor % 57.6 - 57.0 - 56.5 /
57.6 - 57.0 56.8 - 56.1 - 55.6 / 56.8 - 56.1 56.8 - 56.7 - 55.6 / 56.8 - 56.7 56.2 - 55.8 - 55.6 / 56.2 - 55.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 248 340 × 1,050 × 248
Packaged Dimensions (H × W × D) mm 331 × 1,160 × 429 331 × 1,160 × 429
Weight (Mass) kg 14 14
Gross Weight (Gross Mass) kg 20 21
Sound Pressure
Level H / M / L / SL dB(A) 46 / 40 / 35 / 32 45 / 39 / 33 / 30 48 / 42 / 36 / 33 48 / 41 / 33 / 30
Sound Power
Level HdB62616464
Outdoor Unit RXS50LVMA RXS60LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant Oil Type FVC50K FVC50K
Charge L 0.650 0.650
Refrigerant Type R-410A R-410A
Charge kg 1.8 1.8
Airflow Rate Hm³/min
(cfm)
48.5 (1,713) 39.8 (1,405) 50.4 (1,780) 40.9 (1,444)
SL 41.6 (1,469) 37.0 (1,306) 42.3 (1,494) 37.6 (1,328)
Fan Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 5.9 - 5.6 - 5.4 /
5.9 - 5.6 6.6 - 6.3 - 6.0 / 6.6 - 6.3 7.5 - 7.1 - 6.8 / 7.5 - 7.1 7.6 - 7.3 - 7.0 / 7.6 - 7.3
Power Consumption (Rated) W 1,282 - 1,282 - 1,282 /
1,282 - 1,282 1,430 - 1,430 - 1,430 / 1,430 - 1,430 1,630 - 1,630 - 1,630 / 1,630 - 1,630 1,662 - 1,662 - 1,662 / 1,662 - 1,662
Power Factor % 98.8 - 99.5 - 98.9 /
98.8 - 99.5 98.5 - 98.7 - 99.3 / 98.5 - 98.7 98.8 - 99.8 - 99.9 / 98.8 - 99.8 99.4 - 99.0 - 98.9 / 99.4 - 99.0
Starting Current A 6.8 7.9
Dimensions (H × W × D) mm 735 × 825 × 300 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 792 × 960 × 390 792 × 960 × 390
Weight (Mass) kg 46 46
Gross Weight (Gross Mass) kg 52 52
Sound Pressure
Level H / SL dB(A) 47 / 44 48 / 45 49 / 46 49 / 46
Sound Power
Level HdB61626363
Drawing No. 3D075821 3D075822
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 7.5 m

ED041204 Specifications
Split Type Air Conditioners FTK(X)S-L Series 13
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS71LVMA FTXS85LVMA
Outdoor Unit RXS71LVMA RXS85LVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 7.1 (2.3 ~ 8.5) 8.0 (2.3 ~ 10.0) 8.5 (3.0 ~ 10.5) 9.0 (3.0 ~ 11.2)
Btu/h 24,200 (7,800 ~ 29,000) 27,300 (7,800 ~ 34,100) 29,000 (10,200 ~ 35,800) 30,700 (10,200 ~ 38,200)
kcal/h 6,110 (1,980 ~ 7,310) 6,880 (1,980 ~ 8,600) 7,310 (2,580 ~ 9,030) 7,740 (2,580 ~ 9,630)
Moisture Removal L/h 4.5 — 5.6 —
Running Current (Rated) A 9.7 - 9.3 - 8.9 /
9.7 - 9.3 10.1 - 9.7 - 9.3 / 10.1 - 9.7 11.9 - 11.4 - 10.9 / 11.9 - 11.4 11.6 - 11.1 - 10.6 / 11.6 - 11.1
Power Consumption
Rated (Min. ~ Max.) W 2,080 (570 ~ 3,060) 2,180 (520 ~ 3,400) 2,580 (620 ~ 4,100) 2,510 (620 ~ 4,030)
Power Factor % 97.5 - 97.2 - 97.4 /
97.5 - 97.2 98.1 - 97.7 - 97.7 / 98.1 - 97.7 98.5 - 98.4 - 98.6 / 98.5 - 98.4 98.4 - 98.3 - 98.7 / 98.4 - 98.3
EER (Cooling) / COP (Heating)
Rated (Min. ~ Max.) W/W 3.41 (4.04 ~ 2.78) 3.67 (4.42 ~ 2.94) 3.29 (4.84 ~ 2.56) 3.59 (4.84 ~ 2.78)
Piping
Connections
Liquid mm φ9.5 φ 9.5
Gas mm φ 15.9 φ15.9
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 50 50
Indoor Unit FTXS71LVMA FTXS85LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
21.1 (745) 21.6 (763) 23.8 (840) 24.1 (851)
M 16.9 (597) 17.2 (607) 20.6 (727) 20.5 (724)
L 12.7 (448) 13.1 (463) 17.5 (618) 17.0 (600)
SL 11.5 (406) 11.9 (420) 15.8 (558) 15.5 (547)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 48 64
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.68 - 0.65 - 0.62 /
0.68 - 0.65 0.58 - 0.56 - 0.54 / 0.58 - 0.56 0.54 - 0.52 - 0.51 / 0.54 - 0.52 0.54 - 0.52 - 0.51 / 0.54 - 0.52
Power Consumption (Rated) W 82 - 82 - 82 / 82 - 82 71 - 71 - 71 / 71 - 71 66 - 66 - 66 / 66 - 66 66 - 66 - 66 / 66 - 66
Power Factor % 54.8 - 54.8 - 55.1 /
54.8 - 54.8 55.6 - 55.1 - 54.8 / 55.6 - 55.1 55.6 - 55.2 - 53.9 / 55.6 - 53.2 55.6 - 55.2 - 53.9 / 55.6 - 53.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 248 340 × 1,200 × 240
Packaged Dimensions (H × W × D) mm 331 × 1,160 × 429 325 × 1,310 × 429
Weight (Mass) kg 14 17
Gross Weight (Gross Mass) kg 21 23
Sound Pressure
Level H / M / L / SL dB(A) 51 / 44 / 37 / 34 49 / 43 / 35 / 32 49 / 45 / 40 / 37 49 / 44 / 38 / 35
Sound Power
Level HdB67656565
Outdoor Unit RXS71LVMA RXS85LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC63BXD 2YC63FXD
Motor Output W 1,920 2,030
Refrigerant Oil Type FVC50K FVC50K
Charge L 0.750 0.750
Refrigerant Type R-410A R-410A
Charge kg 2.3 2.8
Airflow Rate Hm³/min
(cfm)
55.8 (1,970) 55.9 (1,974) 77.3 (2,729) 74.4 (2,627)
SL 46.0 (1,624) 45.5 (1,607) 65.6 (2,316) 65.6 (2,316)
Fan Type Propeller Propeller
Motor Output W 66 200
Running Current (Rated) A 9.3 - 8.9 - 8.5 /
9.3 - 8.9 9.8 - 9.4 - 9.0 / 9.8 - 9.4 11.6 - 11.1 - 10.6 / 11.6 - 11.1 11.3 - 10.8 - 10.3 / 11.3 - 10.8
Power Consumption (Rated) W 1,998 - 1,998 - 1,998 /
1,998 - 1,998 2,109 - 2,109 - 2,109 / 2,109 - 2,109 2,514 - 2,514 - 2,514 / 2,514 - 2,514 2,444 - 2,444 - 2,444 / 2,444 - 2,444
Power Factor (Rated) % 97.7 - 97.6 - 97.9 /
97.7 - 97.6 97.8 - 97.5 - 97.6 / 97.8 - 97.5 98.5 - 98.5 - 98.8 / 98.5 - 98.5 98.3 - 98.4 - 98.9 / 98.3 - 98.4
Starting Current A 10.1 11.9
Dimensions (H × W × D) mm 770 × 900 × 320 990 × 940 × 320
Packaged Dimensions (H × W × D) mm 900 × 925 × 390 1,114 × 1,003 × 425
Weight (Mass) kg 71 80
Gross Weight (Gross Mass) kg 79 93
Sound Pressure
Level H / SL dB(A) 52 / 49 53 / 49 54 / 51 55 / 51
Sound Power
Level HdB66676869
Drawing No. 3D075823 3D075824
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 7.5 m

Specifications ED041204
14 Split Type Air Conditioners FTK(X)S-L Series
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS95LVMA
Outdoor Unit RXS95LVMA
Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 9.4 (3.0 ~ 11.2) 10.5 (3.0 ~ 11.7)
Btu/h 32,000 (10,200 ~ 38,200) 35,800 (10,200 ~ 39,900)
kcal/h 8,080 (2,580 ~ 9,630) 9,030 (2,580 ~ 10,060)
Moisture Removal L/h 6.3 —
Running Current (Rated) A 13.3 - 12.7 - 12.2 / 13.3 - 12.7 14.8 - 14.1 - 13.5 / 14.8 - 14.1
Power Consumption
Rated (Min. ~ Max.) W 2,880 (620 ~ 4,320) 3,220 (620 ~ 4,360)
Power Factor % 98.4 - 98.6 - 98.4 / 98.4 - 98.6 98.9 - 99.3 - 99.4 / 98.9 - 99.3
EER (Cooling) / COP (Heating)
Rated (Min. ~ Max.) W/W 3.26 (4.84 ~ 2.59) 3.26 (4.84 ~ 2.68)
Piping
Connections
Liquid mm φ 9.5
Gas mm φ 15.9
Drain mm φ 16.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of Refrigerant g/m 50
Indoor Unit FTXS95LVMA
Front Panel Colour White
Airflow Rate
H
m³/min
(cfm)
22.7 (802) 24.9 (879)
M 19.0 (671) 20.1 (710)
L 15.5 (547) 15.7 (554)
SL 13.2 (466) 14.1 (498)
Fan
Type Cross Flow Fan
Motor Output W 64
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.57 - 0.55 - 0.53 / 0.57 - 0.55 0.55 - 0.53 - 0.51 / 0.55 - 0.53
Power Consumption (Rated) W 71 - 71 - 71 / 71 - 71 68 - 68 - 68 / 68 - 68
Power Factor % 56.6 - 56.1 - 55.8 / 56.6 - 56.1 56.2 - 55.8 - 55.6 / 56.2 - 55.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,200 × 240
Packaged Dimensions (H × W × D) mm 325 × 1,310 × 429
Weight (Mass) kg 18
Gross Weight (Gross Mass) kg 25
Sound Pressure
Level H / M / L / SL dB(A) 51 / 47 / 42 / 38 50 / 44 / 38 / 35
Sound Power
Level HdB 67 66
Outdoor Unit RXS95LVMA
Casing Colour Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63FXD
Motor Output W 2,030
Refrigerant Oil Type FVC50K
Charge L 0.750
Refrigerant Type R-410A
Charge kg 3.2
Airflow Rate Hm³/min
(cfm)
79.4 (2,804) 73.6 (2,599)
SL 64.8 (2,288) 64.8 (2,288)
Fan Type Propeller
Motor Output W 200
Running Current (Rated) A 13.0 - 12.4 - 11.9 / 13.0 - 12.4 14.5 - 13.8 - 13.2 / 14.5 - 13.8
Power Consumption (Rated) W 2,809 - 2,809 - 2,809 / 2,809 - 2,809 3,152 - 3,152 - 3,152 / 3,152 - 3,152
Power Factor (Rated) % 98.2 - 98.5 - 98.4 / 98.2 - 98.5 98.8 - 99.3 - 99.5 / 98.8 - 99.3
Starting Current A 14.8
Dimensions (H × W × D) mm 990 × 940 × 320
Packaged Dimensions (H × W × D) mm 1,114 × 1,003 × 425
Weight (Mass) kg 82
Gross Weight (Gross Mass) kg 94
Sound Pressure
Level H / SL dB(A) 54 / 50 55 / 51
Sound Power
Level HdB 68 69
Drawing No. 3D075825A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 7.5 m

ED041204 Dimensions
Split Type Air Conditioners FTK(X)S-L Series 15
4. Dimensions
4.1 Indoor Unit
4.1.1 Cooling Only
FTKS20/25/35LVMA
FTKS46LVMA
THE MARK (→) SHOWS PIPING DIRECTION AIRFLOW (INDOOR)
800
REAR
INCLUDING
RIGHTLEFT MOUNTING PLATE )(
30MIN
(SPACE FOR
217
PERFORMANCE)
50MIN
50MIN
215
(SPACE FOR (SPACE FOR
MAINTENANCE)MAINTENANCE)
REQUIRED SPACE
NAME PLATE
FRONT GRILLE
FIXED SCREWS
TERMINAL BLOCK
(INSIDE)
295
WITH EARTH
TERMINAL
BOTTOM INTELLIGENT EYE SENSOR
FLAPS SIGNAL RECEIVER
OPERATION LAMP GAS PIPE φ9.5 CuT DRAIN HOSE
(THE LENGTH OF PIPE OUTSIDE
TIMER LAMP (CONNECTING PART
THE UNIT: ABOUT 350)
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF SWITCH LIQUID PIPE φ6.4 CuT
O.D. φ16
THE HOSE LENGTH OF OUTSIDE
(THE LENGTH OF PIPE OUTSIDE
ROOM TEMP. THERMISTOR(INSIDE)THE UNIT IS APPROX. 465)
THE UNIT: ABOUT 400)
MODEL NAME PLATE 800
SIGNAL TRANSMITTER BLADE ANGLES 586 145.5
UP/DOWN
14.5
1858 (AUTOMATIC)
FANCOOLING, DRY
5˚
295
15˚
187
44.5
35˚ 30˚
55˚
45˚ 65˚
44.5
80˚ 60 59.5
WALL HOLE FOR EMBEDDED PIPING
φ65 HOLE
RIGHT/LEFT WALL HOLE
(AUTOMATIC)STANDARD LOCATIONS OF WALL HOLES φ65 HOLE
WIRELESS REMOTE CONTROLLER
45˚
45˚
(ARC452A13)3D069095B
FRONT GRILLE
FIXED SCREWS
(INSIDE)
FLAPS
WIRELESS REMOTE CONTROLLER
(ARC452A13)
PERFORMANCE) (SPACE FOR
(SPACE FOR (SPACE FOR
MAINTENANCE) MAINTENANCE)
INTELLIGENT EYE SENSOR
SIGNAL RECEIVER
OPERATION LAMP
TIMER LAMP
INTELLIGENT EYE LAMP
SIGNAL TRANSMITTER
STANDARD LOCATIONS OF WALL HOLES
AIRFLOW (INDOOR)
INCLUDING
MOUNTING PLATE
REQUIRED SPACE
NAME PLATE
TERMINAL BLOCK
WITH EARTH
TERMINAL
INDOOR UNIT ON/OFF SWITCH
ROOM TEMP. THERMISTOR (INSIDE)
MODEL NAME PLATE
BLADE ANGLES
UP/DOWN
(AUTOMATIC)
FAN
COOLING, DRY
5°
15°
35°30°
55°
45°65°
80°
WALL HOLE FOR EMBEDDED PIPING
φ65 HOLE
RIGHT/LEFT WALL HOLE
(AUTOMATIC) φ65 HOLE
800
REAR
RIGHT
LEFT
30MIN
217
50MIN
50MIN
215
295
BOTTOM
800
586 145.5
14.5
58 18
295
187
44.5
44.5
60 59.5
45°
45°
3D074612
THE MARK (→) SHOWS PIPING DIRECTION
()
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 350)
GAS PIPE φ12.7 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 400)
LIQUID PIPE φ6.4 CuT
DRAIN HOSE
(CONNECTING PART
O.D. φ16
THE HOSE LENGTH OF OUTSIDE
THE UNIT IS APPROX. 465)

Dimensions ED041204
16 Split Type Air Conditioners FTK(X)S-L Series
FTKS50/60LVMA
FTKS71LVMA
DRAIN HOSE
(CONNECTING PART
O.D. φ16
THE HOSE LENGTH OF OUTSIDE
THE UNIT: ABOUT 465)
SIGNAL
TRANSMITTER
1858 UP/DOWN
(AUTOMATIC)
FAN
COOLING,DRY
15°15°
187
25°25°
75°
50°60°
70°
WIRELESS REMOTE CONTROLLER
(ARC452A13)
1050
250
248
MIN.50 MIN.50
340
1050
14.5
35.5947
16
210
340
45
45
65 89
45°
45°
THE MARK ( →) SHOWS PIPING DIRECTION
AIR FLOW (INDOOR)
REAR
LEFT RIGHT
INCLUDING
INSTALLATION PLATE
(SPACE FOR
MAINTENANCE)
(SPACE FOR
MAINTENANCE)
REQUIRED SPACE
NAME PLATE
INTELLIGENT EYE SENSOR
BOTTOM
SIGNAL RECEIVER
FLAPS OPERATION LAMP
TIMER LAMP
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF
SWITCH
MODEL NAME PLATE
BLADE ANGLES
RIGHT/LEFT (AUTOMATIC) φ80 HOLE
MIN.30
(SPACE FOR
PERFORMANCE)
FRONT
GRILLE
FIXING
SCREWS
(INSIDE)
TERMINAL BLOCK WITH
EARTH TERMINAL
(INSIDE)
GAS PIPE φ12.7 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 400)
LIQUID PIPE φ6.4 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 460)
ROOM TEMP. THERMISTOR
(INSIDE)
WALL HOLE
φ80 HOLE
WALL HOLE FOR EMBEDDED PIPING
STANDARD LOCATIONS OF WALL HOLES
( )
3D073964A
DRAIN HOSE
(CONNECTING PART
O.D. φ16
THE HOSE LENGTH OF OUTSIDE
THE UNIT: ABOUT 465)
SIGNAL
TRANSMITTER
58 18 UP/DOWN
(AUTOMATIC)
FAN
COOLING, DRY
15°
15°
187
25°25°
75°
50°60°
70°
WIRELESS REMOTE CONTROLLER
(ARC452A13)
1050
250
248
MIN.50 MIN.50
340
1050
14.5
947 35.5
16
210
340
45 45
8965
45°
45°
THE MARK ( →) SHOWS PIPING DIRECTION
AIR FLOW (INDOOR)
REAR
LEFT RIGHT
INCLUDING
INSTALLATION PLATE
(SPACE FOR
MAINTENANCE)
(SPACE FOR
MAINTENANCE)
REQUIRED SPACE
NAME PLATE
INTELLIGENT EYE SENSOR
BOTTOM
SIGNAL RECEIVER
FLAPS OPERATION LAMP
TIMER LAMP
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF
SWITCH
MODEL NAME PLATE
BLADE ANGLES
RIGHT/LEFT (AUTOMATIC) φ80 HOLE
MIN.30
(SPACE FOR
PERFORMANCE)
FRONT
GRILLE
FIXING
SCREWS
(INSIDE)
TERMINAL BLOCK WITH
EARTH TERMINAL
(INSIDE)
GAS PIPE φ15.9 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 400)
LIQUID PIPE φ9.5 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 460)
ROOM TEMP. THERMISTOR
(INSIDE)
WALL HOLE
φ80 HOLE
WALL HOLE FOR EMBEDDED PIPING
STANDARD LOCATIONS OF WALL HOLES
( )
3D073965A

ED041204 Dimensions
Split Type Air Conditioners FTK(X)S-L Series 17
4.1.2 Heat Pump
FTXS20/25/35LVMA
FTXS46LVMA
THE MARK (→) SHOWS PIPING DIRECTION
AIRFLOW (INDOOR)
800
REAR
INCLUDING
MOUNTING PLATE
RIGHTLEFT
30MIN
(SPACE FOR PERFORMANCE)
217
50MIN
50MIN
215
(SPACE FOR
MAINTENANCE)
(SPACE FOR
MAINTENANCE)
REQUIRED SPACE
NAME PLATE
FRONT GRILLE
FIXED SCREWS
(INSIDE) TERMINAL BLOCK
WITH EARTH
TERMINAL
295
BOTTOM INTELLIGENT EYE SENSOR
FLAPS SIGNAL RECEIVER
OPERATION LAMP GAS PIPE φ9.5 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 350)
DRAIN HOSE
(CONNECTING PART
O.D. φ16
THE HOSE LENGTH OF OUTSIDE
THE UNIT IS APPROX. 465)
TIMER LAMP
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF SWITCH LIQUID PIPE φ6.4 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 400)
ROOM TEMP. THERMISTOR(INSIDE)
MODEL NAME PLATE 800
SIGNAL TRANSMITTER BLADE ANGLES 145.5586
UP/DOWN
(AUTOMATIC)
14.5
58 18
FANCOOLING, DRY HEATING
5˚
295
15˚ 30˚
187
44.5
35˚ 30˚
30˚
55˚
45˚ 65˚ 65˚
44.5
70˚ 80˚ 60 59.5
WALL HOLE FOR EMBEDDED PIPING
φ65 HOLE
RIGHT/LEFT
(AUTOMATIC) WALL HOLE
STANDARD LOCATIONS OF WALL HOLES φ65 HOLE
WIRELESS REMOTE CONTROLLER
45˚
45˚
(ARC452A4) 3D069143B
THE MARK (→) SHOWS PIPING DIRECTION AIRFLOW (INDOOR)
800
REAR
INCLUDING
MOUNTING PLATE
RIGHTLEFT
30MIN (SPACE FOR PERFORMANCE)
217
50MIN
50MIN
215
(SPACE FOR
MAINTENANCE)
(SPACE FOR
MAINTENANCE)
REQUIRED SPACE
NAME PLATE
FRONT GRILLE
FIXED SCREWS
(INSIDE) TERMINAL BLOCK
WITH EARTH
TERMINAL
295
BOTTOM INTELLIGENT EYE SENSOR
FLAPS SIGNAL RECEIVER
OPERATION LAMP GAS PIPE φ12.7CuT DRAIN HOSE
(CONNECTING PART
(THE LENGTH OF PIPE OUTSIDE
TIMER LAMP
THE UNIT: ABOUT 350)
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF SWITCH LIQUID PIPE φ6.4CuT
O.D. φ16
THE HOSE LENGTH OF OUTSIDE
(THE LENGTH OF PIPE OUTSIDE
ROOM TEMP. THERMISTOR (INSIDE) THE UNIT IS APPROX. 465)
THE UNIT: ABOUT 400)
MODEL NAME PLATE 800
SIGNAL TRANSMITTER BLADE ANGLES 145.5586
UP/DOWN
14.5
1858 (AUTOMATIC)
FANCOOLING, DRY HEATING
5˚
295
15˚ 30˚
187
44.5
35˚ 30˚
30˚
55˚
45˚ 65˚ 65˚
44.5
70˚ 80˚ 60 59.5
WALL HOLE FOR EMBEDDED PIPING
φ65 HOLE
RIGHT/LEFT
(AUTOMATIC) WALL HOLE
φ65 HOLE
STANDARD LOCATIONS OF WALL HOLES
WIRELESS REMOTE CONTROLLER
45˚
45˚
(ARC452A4)
()
3D069094A

Dimensions ED041204
18 Split Type Air Conditioners FTK(X)S-L Series
FTXS50/60LVMA
FTXS71LVMA
DRAIN HOSE
(CONNECTING PART
O.D. φ16
THE HOSE LENGTH OF OUTSIDE
THE UNIT: ABOUT 465)
SIGNAL
TRANSMITTER
58 18 UP/DOWN
(AUTOMATIC)
FAN
COOLING, DRY HEATING
15°15°
187
25°30°25°
40°75°
50°60°75°70°
70°
WIRELESS REMOTE CONTROLLER
(ARC452A4)
1050
250
248
MIN.50 MIN.50
340
1050
14.5
35.5947
16
210
340
45
45
8965
45°
AIRFLOW (INDOOR)
REAR
LEFT RIGHT
INCLUDING
INSTALLATION PLATE
(SPACE FOR
MAINTENANCE)
(SPACE FOR
MAINTENANCE)
REQUIRED SPACE
NAME PLATE
INTELLIGENT EYE SENSOR
BOTTOM
SIGNAL RECEIVER
FLAPS OPERATION LAMP
TIMER LAMP
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF
SWITCH
MODEL NAME PLATE
BLADE ANGLES
RIGHT/LEFT (AUTOMATIC)
φ80 HOLE
MIN.30
(SPACE FOR
PERFORMANCE)
FRONT
GRILLE
FIXING
SCREWS
(INSIDE)
TERMINAL BLOCK
WITH
EARTH TERMINAL
(INSIDE)
GAS PIPE φ12.7 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 400)
LIQUID PIPE φ6.4 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 460)
ROOM TEMP. THERMISTOR
(INSIDE)
WALL HOLE
φ80 HOLE
WALL HOLE FOR EMBEDDED
PIPING
STANDARD LOCATIONS OF WALL HOLES
45°
THE MARK ( → ) SHOWS PIPING DIRECTION
( )
3D073961A
DRAIN HOSE
(CONNECTING PART
O.D. φ16
THE HOSE LENGTH OUTSIDE
THE UNIT: ABOUT 465)
SIGNAL
TRANSMITTER
1858 UP/DOWN
(AUTOMATIC)
FAN
COOLING, DRY HEATING
15°15°
187
25°30°25°
40°75°
50°60°75°70°
70°
WIRELESS REMOTE CONTROLLER
(ARC452A4)
1050
250
248
MIN.50 MIN.50
340
1050
14.5
947 35.5
16
210
340
45 45
8965
45°
45°
THE MARK ( →) SHOWS PIPING DIRECTION
AIRFLOW (INDOOR)
REAR
LEFT RIGHT
INCLUDING
INSTALLATION PLATE
(SPACE FOR
MAINTENANCE)
(SPACE FOR
MAINTENANCE)
REQUIRED SPACE
NAME PLATE
INTELLIGENT EYE SENSOR
BOTTOM
SIGNAL RECEIVER
FLAPS OPERATION LAMP
TIMER LAMP
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF
SWITCH
MODEL NAME PLATE
BLADE ANGLES
RIGHT/LEFT (AUTOMATIC)
φ80 HOLE
MIN.30
(SPACE FOR
PERFORMANCE)
FRONT
GRILLE
FIXING
SCREWS
(INSIDE)
TERMINAL BLOCK
WITH
EARTH TERMINAL
(INSIDE)
GAS PIPE φ15.9 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 400)
LIQUID PIPE φ9.5 CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 460)
ROOM TEMP. THERMISTOR
(INSIDE)
WALL HOLE
φ80 HOLE
WALL HOLE FOR EMBEDDED
PIPING
STANDARD LOCATIONS OF WALL HOLES
( )
3D073963A
