Daikin FTKS50BVMA User manual

Inverter Pair
Wall Mounted Type B-Series
[Applied Models]
z
zz
zInverter Pair : Cooling Only
z
zz
zInverter Pair : Heat Pump
z
zz
zNon-Inverter Pair : Cooling Only
z
zz
zNon-Inverter Pair : Heat Pump
Si04-306
Service
Manual

Si04-306
Table of Contents i
Inverter Pair
Inverter PairInverter Pair
Inverter Pair
B-Series
B-SeriesB-Series
B-Series
zCooling Only
Indoor Unit
<R410A>
FTKS50BVMA FTKS50BVMB FTS50BVMB
FTKS60BVMA FTKS60BVMB FTS60BVMB
FTKS71BVMA FTKS71BVMB
<R22>
FTKD50BVM FTKD50BVMA FTKD50BVMT FTKD18BVMS
FTKD60BVM FTKD60BVMA FTKD60BVMT FTKD24BVMS
FTKD71BVM FTKD71BVMA FTKD71BVMT FTKD28BVMS
Outdoor Unit
<R410A>
RKS50BVMA RKS50BVMB RS50BVMB
RKS60BVMA RKS60BVMB RS60BVMB
RKS71BVMA RKS71BVMB
<R22>
RKD50BVM RKD50BVMA RKD50BVMT RKD18BVMS
RKD60BVM RKD60BVMA RKD60BVMT RKD24BVMS
RKD71BVM RKD71BVMA RKD71BVMT RKD28BVMS
zHeat Pump
Indoor Unit
<R410A>
FTXS50BVMA FTXS50BVMB FTYS50BVMB
FTXS60BVMA FTXS60BVMB FTYS60BVMB
FTXS71BVMA FTXS71BVMB
<R22>
FTXD50BVMA FTXD50BVMT
FTXD60BVMA FTXD60BVMT
FTXD71BVMA FTXD71BVMT
Outdoor Unit
<R410A>
RXS50BVMA RXS50BVMB RYS50BVMB
RXS60BVMA RXS60BVMB RYS60BVMB
RXS71BVMA RXS71BVMB
<R22>
RXD50BVMA RXD50BVMT
RXD60BVMA RXD60BVMT
RXD71BVMA RXD71BVMT

Si04-306
ii Table of Contents
1. Introduction .............................................................................................v
1.1 Safety Cautions ........................................................................................v
Part 1 List of Functions ................................................................ 1
1. List of Functions ......................................................................................2
1.1 R410A Series ...........................................................................................2
1.2 R22 Series................................................................................................5
Part 2 Specifications .................................................................... 9
1. Specifications ........................................................................................10
1.1 Cooling Only - R410A Series .................................................................10
1.2 Cooling Only - R22 Series......................................................................13
1.3 Heat Pump - R410A Series ....................................................................17
1.4 Heat Pump - R22 Series ........................................................................22
Part 3 Printed Circuit Board
Connector Wiring Diagram ............................................... 27
1. Printed Circuit Board Connector Wiring Diagram..................................28
1.1 Indoor Unit..............................................................................................28
1.2 Outdoor Unit ...........................................................................................30
Part 4 Function and Control........................................................33
1. Main Functions......................................................................................34
1.1 Frequency Principle................................................................................34
1.2 Power-Airflow Dual Flaps, Wide Angle Louvers and Auto-Swing ..........36
1.3 Fan Speed Control for Indoor Units........................................................37
1.4 Programme Dry Function .......................................................................38
1.5 Automatic Operation...............................................................................39
1.6 Night Set Mode.......................................................................................40
1.7 Intelligent Eye.........................................................................................41
1.8 Home Leave Operation ..........................................................................43
1.9 Inverter Powerful Operation ...................................................................44
1.10 Other Functions......................................................................................45
2. Function of Main Structural Parts..........................................................46
2.1 Function of Thermistor ...........................................................................46
3. Control Specification .............................................................................48
3.1 Mode Hierarchy ......................................................................................48
3.2 Frequency Control..................................................................................49
3.3 Controls at Mode Changing / Start-up....................................................51
3.4 Discharge Pipe Temperature Control.....................................................52
3.5 Input Current Control..............................................................................52
3.6 Freeze-up Protection Control .................................................................53
3.7 Heating Peak-cut Control .......................................................................53
3.8 Fan Control.............................................................................................54
3.9 Moisture Protection Function 2...............................................................54
3.10 Low Hz High Pressure Limit ...................................................................55
3.11 Defrost Control .......................................................................................55
3.12 Electronic Expansion Valve Control .......................................................56

Si04-306
Table of Contents iii
3.13 Malfunctions ...........................................................................................59
3.14 Forced Operation Mode .........................................................................60
3.15 Additional Function.................................................................................60
Part 5 System Configuration....................................................... 61
1. System Configuration............................................................................62
2. Instruction..............................................................................................63
2.1 Safety Precautions .................................................................................63
2.2 Names of Parts.......................................................................................65
2.3 Preparation before Operation.................................................................68
2.4 AUTO · DRY · COOL · HEAT · FAN Operation ......................................71
2.5 Adjusting the Air Flow Direction .............................................................73
2.6 POWERFUL Operation ..........................................................................75
2.7 OUTDOOR UNIT SILENT Operation .....................................................76
2.8 HOME LEAVE Operation .......................................................................77
2.9 INTELLIGENT EYE Operation ...............................................................79
2.10 TIMER Operation ...................................................................................81
2.11 Care and Cleaning .................................................................................83
2.12 Troubleshooting......................................................................................86
Part 6 Service Diagnosis............................................................. 89
1. Caution for Diagnosis............................................................................90
2. Problem Symptoms and Measures .......................................................91
3. Service Check Function ........................................................................92
4. Troubleshooting ....................................................................................93
4.1 Error Codes and Description ..................................................................93
4.2 Indoor Unit PCB Abnormality .................................................................94
4.3 Freeze-up Protection Control or High Pressure Control.........................95
4.4 Fan Motor (DC Motor) or Related Abnormality.......................................97
4.5 Thermistor or Related Abnormality (Indoor Unit)....................................99
4.6 Signal Transmission Error (between Indoor and Outdoor Units)..........100
4.7 OL Activation (Compressor Overload) .................................................101
4.8 Compressor Lock .................................................................................102
4.9 DC Fan Lock ........................................................................................103
4.10 Input Over Current Detection ...............................................................104
4.11 Four Way Valve Abnormality................................................................106
4.12 Discharge Pipe Temperature Control...................................................108
4.13 Position Sensor Abnormality ................................................................109
4.14 CT or Related Abnormality ...................................................................110
4.15 Thermistor or Related Abnormality (Outdoor Unit)...............................112
4.16 Electrical Box Temperature Rise..........................................................114
4.17 Radiation Fin Temperature Rise ..........................................................116
4.18 Output Over Current Detection.............................................................118
4.19 Insufficient Gas.....................................................................................120
4.20 Low-voltage Detection..........................................................................122
4.21 High Pressure Control in Cooling .........................................................123
5. Check ..................................................................................................125
5.1 How to Check .......................................................................................125

Si04-306
iv Table of Contents
Part 7 Removal Procedure ........................................................ 135
1. Indoor Unit...........................................................................................136
1.1 Removal of the Air Filter / Front Panel .................................................136
1.2 Removal of the Front Grille ..................................................................139
1.3 Removal of the Horizontal Blades / Vertical Blades .............................141
1.4 Removal of the Electrical Box / PCB / Swing Motor .............................143
1.5 Removal of the Heat Exchanger ..........................................................149
1.6 Removal of the Fan Rotor / Fan Motor.................................................152
2. Outdoor Unit........................................................................................154
2.1 Removal of the Panels and Plates .......................................................154
2.2 Removal of the Fan Motor / Propeller Fan ...........................................158
2.3 Removal of the PCB / Electrical Box ....................................................162
2.4 Removal of the Reactor........................................................................170
2.5 Removal of the Sound Blanket.............................................................172
2.6 Removal of the Four Way Valve...........................................................174
2.7 Removal of the Electronic Expansion Valve.........................................175
2.8 Removal of the Compressor.................................................................176
Part 8 Others ............................................................................. 179
1. Others .................................................................................................180
1.1 Test Run from the Remote Controller ..................................................180
1.2 Jumper Settings ...................................................................................181
Part 9 Appendix......................................................................... 183
1. Piping Diagrams..................................................................................184
1.1 Indoor Units ..........................................................................................184
1.2 Outdoor Units .......................................................................................186
2. Wiring Diagrams..................................................................................190
2.1 Indoor Units ..........................................................................................190
2.2 Outdoor Units .......................................................................................193
Index ............................................................................................. i
Drawings & Flow Charts ................................................................V

Si04-306 Introduction
v
1. Introduction
1.1 Safety Cautions
Cautions and
Warnings
Be sure to read the following safety cautions before conducting repair work.
The caution items are classified into “ Warning” and “ Caution”. The “ Warning”
items are especially important since they can lead to death or serious injury if they are not
followed closely. The “ Caution” items can also lead to serious accidents under some
conditions if they are not followed. Therefore, be sure to observe all the safety caution items
described below.
About the pictograms
This symbol indicates an item for which caution must be exercised.
The pictogram shows the item to which attention must be paid.
This symbol indicates a prohibited action.
The prohibited item or action is shown inside or near the symbol.
This symbol indicates an action that must be taken, or an instruction.
The instruction is shown inside or near the symbol.
After the repair work is complete, be sure to conduct a test operation to ensure that the
equipment operates normally, and explain the cautions for operating the product to the
customer.
1.1.1 Caution in Repair
Warning
Be sure to disconnect the power cable plug from the plug socket before
disassembling the equipment for a repair.
Working on the equipment that is connected to a power supply can cause an
electrical shook.
If it is necessary to supply power to the equipment to conduct the repair or
inspecting the circuits, do not touch any electrically charged sections of the
equipment.
If the refrigerant gas discharges during the repair work, do not touch the
discharging refrigerant gas.
The refrigerant gas can cause frostbite.
When disconnecting the suction or discharge pipe of the compressor at the
welded section, release the refrigerant gas completely at a well-ventilated
place first.
If there is a gas remaining inside the compressor, the refrigerant gas or
refrigerating machine oil discharges when the pipe is disconnected, and it can
cause injury.
If the refrigerant gas leaks during the repair work, ventilate the area. The
refrigerant gas can generate toxic gases when it contacts flames.
The step-up capacitor supplies high-voltage electricity to the electrical
components of the outdoor unit.
Be sure to discharge the capacitor completely before conducting repair work.
A charged capacitor can cause an electrical shock.
Do not start or stop the air conditioner operation by plugging or unplugging the
power cable plug.
Plugging or unplugging the power cable plug to operate the equipment can
cause an electrical shock or fire.

Introduction Si04-306
vi
1.1.2 Cautions Regarding Products after Repair
Caution
Do not repair the electrical components with wet hands.
Working on the equipment with wet hands can cause an electrical shock.
Do not clean the air conditioner by splashing water.
Washing the unit with water can cause an electrical shock.
Be sure to provide the grounding when repairing the equipment in a humid or
wet place, to avoid electrical shocks.
Be sure to turn off the power switch and unplug the power cable when cleaning
the equipment.
The internal fan rotates at a high speed, and cause injury.
Do not tilt the unit when removing it.
The water inside the unit can spill and wet the furniture and floor.
Be sure to check that the refrigerating cycle section has cooled down
sufficiently before conducting repair work.
Working on the unit when the refrigerating cycle section is hot can cause burns.
Use the welder in a well-ventilated place.
Using the welder in an enclosed room can cause oxygen deficiency.
Warning
Be sure to use parts listed in the service parts list of the applicable model and
appropriate tools to conduct repair work. Never attempt to modify the
equipment.
The use of inappropriate parts or tools can cause an electrical shock,
excessive heat generation or fire.
When relocating the equipment, make sure that the new installation site has
sufficient strength to withstand the weight of the equipment.
If the installation site does not have sufficient strength and if the installation
work is not conducted securely, the equipment can fall and cause injury.
Be sure to install the product correctly by using the provided standard
installation frame.
Incorrect use of the installation frame and improper installation can cause the
equipment to fall, resulting in injury.
For integral units
only
Be sure to install the product securely in the installation frame mounted on a
window frame.
If the unit is not securely mounted, it can fall and cause injury.
For integral units
only

Si04-306 Introduction
vii
1.1.3 Inspection after Repair
Be sure to use an exclusive power circuit for the equipment, and follow the
technical standards related to the electrical equipment, the internal wiring
regulations and the instruction manual for installation when conducting
electrical work.
Insufficient power circuit capacity and improper electrical work can cause an
electrical shock or fire.
Be sure to use the specified cable to connect between the indoor and outdoor
units. Make the connections securely and route the cable properly so that there
is no force pulling the cable at the connection terminals.
Improper connections can cause excessive heat generation or fire.
When connecting the cable between the indoor and outdoor units, make sure
that the terminal cover does not lift off or dismount because of the cable.
If the cover is not mounted properly, the terminal connection section can cause
an electrical shock, excessive heat generation or fire.
Do not damage or modify the power cable.
Damaged or modified power cable can cause an electrical shock or fire.
Placing heavy items on the power cable, and heating or pulling the power cable
can damage the cable.
Do not mix air or gas other than the specified refrigerant (R410A / R22) in the
refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
If the refrigerant gas leaks, be sure to locate the leak and repair it before
charging the refrigerant. After charging refrigerant, make sure that there is no
refrigerant leak.
If the leak cannot be located and the repair work must be stopped, be sure to
perform pump-down and close the service valve, to prevent the refrigerant gas
from leaking into the room. The refrigerant gas itself is harmless, but it can
generate toxic gases when it contacts flames, such as fan and other heaters,
stoves and ranges.
When replacing the coin battery in the remote controller, be sure to disposed
of the old battery to prevent children from swallowing it.
If a child swallows the coin battery, see a doctor immediately.
Warning
Caution
Installation of a leakage breaker is necessary in some cases depending on the
conditions of the installation site, to prevent electrical shocks.
Do not install the equipment in a place where there is a possibility of
combustible gas leaks.
If a combustible gas leaks and remains around the unit, it can cause a fire.
Be sure to install the packing and seal on the installation frame properly.
If the packing and seal are not installed properly, water can enter the room and
wet the furniture and floor.
For integral units
only
Warning
Check to make sure that the power cable plug is not dirty or loose, then insert
the plug into a power outlet all the way.
If the plug has dust or loose connection, it can cause an electrical shock or fire.
If the power cable and lead wires have scratches or deteriorated, be sure to
replace them.
Damaged cable and wires can cause an electrical shock, excessive heat
generation or fire.

Introduction Si04-306
viii
1.1.4 Using Icons
Icons are used to attract the attention of the reader to specific information. The meaning of each
icon is described in the table below:
1.1.5 Using Icons List
Do not use a joined power cable or extension cable, or share the same power
outlet with other electrical appliances, since it can cause an electrical shock,
excessive heat generation or fire.
Warning
Caution
Check to see if the parts and wires are mounted and connected properly, and
if the connections at the soldered or crimped terminals are secure.
Improper installation and connections can cause excessive heat generation,
fire or an electrical shock.
If the installation platform or frame has corroded, replace it.
Corroded installation platform or frame can cause the unit to fall, resulting in
injury.
Check the grounding, and repair it if the equipment is not properly grounded.
Improper grounding can cause an electrical shock.
Be sure to measure the insulation resistance after the repair, and make sure
that the resistance is 1 Mohm or higher.
Faulty insulation can cause an electrical shock.
Be sure to check the drainage of the indoor unit after the repair.
Faulty drainage can cause the water to enter the room and wet the furniture
and floor.
Icon Type of
Information
Description
Note:
Note A “note” provides information that is not indispensable, but may
nevertheless be valuable to the reader, such as tips and tricks.
Caution
Caution A “caution” is used when there is danger that the reader, through
incorrect manipulation, may damage equipment, loose data, get
an unexpected result or has to restart (part of) a procedure.
Warning
Warning A “warning” is used when there is danger of personal injury.
Reference A “reference” guides the reader to other places in this binder or
in this manual, where he/she will find additional information on a
specific topic.

Si04-306
List of Functions 1
Part 1
Part 1Part 1
Part 1
List of Functions
List of FunctionsList of Functions
List of Functions
1. List of Functions ......................................................................................2
1.1 R410A Series ...........................................................................................2
1.2 R22 Series................................................................................................5

List of Functions Si04-306
2List of Functions
1. List of Functions
1.1 R410A Series
Category Functions
FTKS50·60·71BVMA RKS50·60·71BVMA FTXS50·60·71BVMA RXS50·60·71BVMA
Category Functions
FTKS50·60·71BVMA RKS50·60·71BVMA FTXS50·60·71BVMA RXS50·60·71BVMA
Basic
Function
Inverter (with Inverter Power Control) {{
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions ——
Operation Limit for Cooling (°CDB) –5
~46
–5
~46
Operation Limit for Heating (°CWB) — –15
~18 Photocatalytic Deodorizing Filter — —
PAM Control {{ Air Purifying Filter with Photocatalytic
Deodorizing Function {{
Compressor
Oval Scroll Compressor — — Longlife Filter — —
Swing Compressor {{ Ultra-Longlife Filter (Option) — —
Rotary Compressor — — Mold Proof Air Filter {{
Reluctance DC Motor {{ Wipe-clean Flat Panel {{
Comfortable
Airflow
Power-Airflow Flap — — Washable Grille — —
Power-Airflow Dual Flaps {{ Filter Cleaning Indicator — —
Power-Airflow Diffuser — — Good-Sleep Cooling Operation — —
Wide-Angle Louvers {{
Timer 24-Hour On/Off Timer {{
Vertical Auto-Swing (Up and Down) {{ Night Set Mode {{
Horizontal Auto-Swing (Right and Left) {{
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
3-D Airflow {{ Self-Diagnosis (Digital, LED) Display {{
3-Step Airflow (H/P Only) — — Wiring Error Check — —
Comfort
Control
Auto Fan Speed {{ Anticorrosion Treatment of Outdoor
Heat Exchanger {{
Indoor Unit Silent Operation {{
Night Quiet Mode (Automatic) — —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit {{
Outdoor Unit Silent Operation (Manual) {{
Intelligent Eye {{ Flexible Voltage Correspondence {{
Quick Warming Function — {High Ceiling Application — —
Hot-Start Function — {Chargeless 10m 10m
Automatic Defrosting — {Power Selection — —
Operation
Automatic Operation — {
Remote
Control
5-Rooms Centralized Controller
(Option) {{
Programme Dry Function {{ Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) {{
Fan Only {{
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) — — Remote Control Adaptor
(Normal Open Contact)(Option) {{
Inverter Powerful Operation {{
Priority-Room Setting — — DIII-NET Compatible (Adaptor)(Option) {{
Cooling / Heating Mode Lock — — Remote
Controller
Wireless {{
Home Leave Operation {{ Wired — —
Indoor Unit On/Off Switch {{
Signal Reception Indicator {{
Temperature Display — —
Another Room Operation — —
Note: {: Holding Functions
— : No Functions

Si04-306 List of Functions
List of Functions 3
Category Functions
FTKS50·60·71BVMB RKS50·60·71BVMB FTXS50·60·71BVMB RXS50·60·71BVM\B
Category Functions
FTKS50·60·71BVMB RKS50·60·71BVMB FTXS50·60·71BVMB RXS50·60·71BVMB
Basic
Function
Inverter (with Inverter Power Control) {{
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions ——
Operation Limit for Cooling (°CDB) –10
~46
–10
~46
Operation Limit for Heating (°CWB) — –15
~18 Photocatalytic Deodorizing Filter — —
PAM Control {{ Air Purifying Filter with Photocatalytic
Deodorizing Function {{
Compressor
Oval Scroll Compressor — — Longlife Filter — —
Swing Compressor {{ Ultra-Longlife Filter (Option) — —
Rotary Compressor — — Mold Proof Air Filter {{
Reluctance DC Motor {{ Wipe-clean Flat Panel {{
Comfortable
Airflow
Power-Airflow Flap — — Washable Grille — —
Power-Airflow Dual Flaps {{ Filter Cleaning Indicator — —
Power-Airflow Diffuser — — Good-Sleep Cooling Operation — —
Wide-Angle Louvers {{
Timer 24-Hour On/Off Timer {{
Vertical Auto-Swing (Up and Down) {{ Night Set Mode {{
Horizontal Auto-Swing (Right and Left) {{
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
3-D Airflow {{ Self-Diagnosis (Digital, LED) Display {{
3-Step Airflow (H/P Only) — — Wiring Error Check — —
Comfort
Control
Auto Fan Speed {{ Anticorrosion Treatment of Outdoor
Heat Exchanger {{
Indoor Unit Silent Operation {{
Night Quiet Mode (Automatic) — —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit {{
Outdoor Unit Silent Operation (Manual) {{
Intelligent Eye {{ Flexible Voltage Correspondence {{
Quick Warming Function — {High Ceiling Application — —
Hot-Start Function — {Chargeless 10m 10m
Automatic Defrosting — {Power Selection — —
Operation
Automatic Operation — {
Remote
Control
5-Rooms Centralized Controller
(Option) {{
Programme Dry Function {{ Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) {{
Fan Only {{
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) — — Remote Control Adaptor
(Normal Open Contact)(Option) {{
Inverter Powerful Operation {{
Priority-Room Setting — — DIII-NET Compatible (Adaptor)(Option) {{
Cooling / Heating Mode Lock — — Remote
Controller
Wireless {{
Home Leave Operation {{ Wired — —
Indoor Unit On/Off Switch {{
Signal Reception Indicator {{
Temperature Display — —
Another Room Operation — —
Note: {: Holding Functions
— : No Functions

List of Functions Si04-306
4List of Functions
Category Functions
FTS50·60BVMB RS50·60BVMB FTYS50·60BVMB RYS50·60BVMB
Category Functions
FTS50·60BVMB RS50·60BVMB FTYS50·60BVMB RYS50·60BVMB
Basic
Function
Inverter (with Inverter Power Control) — —
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions ——
Operation Limit for Cooling (°CDB) –10
~46
–10
~46
Operation Limit for Heating (°CWB) — –15
~18 Photocatalytic Deodorizing Filter — —
PAM Control — — Air Purifying Filter with Photocatalytic
Deodorizing Function {{
Compressor
Oval Scroll Compressor — — Longlife Filter — —
Swing Compressor {{ Ultra-Longlife Filter (Option) — —
Rotary Compressor — — Mold Proof Air Filter {{
Reluctance DC Motor {{ Wipe-clean Flat Panel — —
Comfortable
Airflow
Power-Airflow Flap — — Washable Grille {{
Power-Airflow Dual Flaps {{ Filter Cleaning Indicator — —
Power-Airflow Diffuser — — Good-Sleep Cooling Operation — —
Wide-Angle Louvers {{
Timer 24-Hour On/Off Timer {{
Vertical Auto-Swing (Up and Down) {{ Night Set Mode {{
Horizontal Auto-Swing (Right and Left) — —
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
3-D Airflow — — Self-Diagnosis (Digital, LED) Display {{
3-Step Airflow (H/P Only) — — Wiring Error Check — —
Comfort
Control
Auto Fan Speed {{ Anticorrosion Treatment of Outdoor
Heat Exchanger {{
Indoor Unit Silent Operation — —
Night Quiet Mode (Automatic) — —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit ——
Outdoor Unit Silent Operation (Manual) — —
Intelligent Eye — — Flexible Voltage Correspondence {{
Quick Warming Function — {High Ceiling Application — —
Hot-Start Function — {Chargeless 10m 10m
Automatic Defrosting — {Power Selection — —
Operation
Automatic Operation — {
Remote
Control
5-Rooms Centralized Controller
(Option) {{
Programme Dry Function {{ Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) {{
Fan Only {{
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) {{ Remote Control Adaptor
(Normal Open Contact)(Option) {{
Inverter Powerful Operation — —
Priority-Room Setting — — DIII-NET Compatible (Adaptor)(Option) — —
Cooling / Heating Mode Lock — — Remote
Controller
Wireless {{
Home Leave Operation — — Wired — —
Indoor Unit On/Off Switch {{
Signal Reception Indicator {{
Temperature Display — —
Another Room Operation — —
Note: {: Holding Functions
— : No Functions

Si04-306 List of Functions
List of Functions 5
1.2 R22 Series
Category Functions
FTKD50·60·71BVM(A) RKD50·60·71BVM(A) FTXD50·60·71BVMA RXD50·60·71BVMA
Category Functions
FTKD50·60·71BVM(A) RKD50·60·71BVM(A) FTXD50·60·71BVMA RXD50·60·71BVMA
Basic
Function
Inverter (with Inverter Power Control) {{
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions ——
Operation Limit for Cooling (°CDB) –5
~46
–5
~46
Operation Limit for Heating (°CWB) — –15
~18 Photocatalytic Deodorizing Filter — —
PAM Control {{ Air Purifying Filter with Photocatalytic
Deodorizing Function {{
Compressor
Oval Scroll Compressor — — Longlife Filter — —
Swing Compressor {{ Ultra-Longlife Filter (Option) — —
Rotary Compressor — — Mold Proof Air Filter {{
Reluctance DC Motor {{ Wipe-clean Flat Panel {{
Comfortable
Airflow
Power-Airflow Flap — — Washable Grille — —
Power-Airflow Dual Flaps {{ Filter Cleaning Indicator — —
Power-Airflow Diffuser — — Good-Sleep Cooling Operation — —
Wide-Angle Louvers {{
Timer 24-Hour On/Off Timer {{
Vertical Auto-Swing (Up and Down) {{ Night Set Mode {{
Horizontal Auto-Swing (Right and Left) {{
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
3-D Airflow {{ Self-Diagnosis (Digital, LED) Display {{
3-Step Airflow (H/P Only) — — Wiring Error Check — —
Comfort
Control
Auto Fan Speed {{ Anticorrosion Treatment of Outdoor
Heat Exchanger {{
Indoor Unit Silent Operation {{
Night Quiet Mode (Automatic) — —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit {{
Outdoor Unit Silent Operation (Manual) {{
Intelligent Eye {{ Flexible Voltage Correspondence {{
Quick Warming Function — {High Ceiling Application — —
Hot-Start Function — {Chargeless 10m 10m
Automatic Defrosting — {Power Selection — —
Operation
Automatic Operation — {
Remote
Control
5-Rooms Centralized Controller
(Option) {{
Programme Dry Function {{ Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) {{
Fan Only {{
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) — — Remote Control Adaptor
(Normal Open Contact)(Option) {{
Inverter Powerful Operation {{
Priority-Room Setting — — DIII-NET Compatible (Adaptor)(Option) {{
Cooling / Heating Mode Lock — — Remote
Controller
Wireless {{
Home Leave Operation {{ Wired — —
Indoor Unit On/Off Switch {{
Signal Reception Indicator {{
Temperature Display — —
Another Room Operation — —
Note: {: Holding Functions
— : No Functions

List of Functions Si04-306
6List of Functions
Category Functions
FTKD50·60·71BVMT RKD50·60·71BVMT FTXD50·60·71BVMT RXD50·60·71BVMT
Category Functions
FTKD50·60·71BVMT RKD50·60·71BVMT FTXD50·60·71BVMT RXD50·60·71BVMT
Basic
Function
Inverter (with Inverter Power Control) {{
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions ——
Operation Limit for Cooling (°CDB) –5
~46
–5
~46
Operation Limit for Heating (°CWB) — –15
~18 Photocatalytic Deodorizing Filter — —
PAM Control {{ Air Purifying Filter with Photocatalytic
Deodorizing Function {{
Compressor
Oval Scroll Compressor — — Longlife Filter — —
Swing Compressor {{ Ultra-Longlife Filter (Option) — —
Rotary Compressor — — Mold Proof Air Filter {{
Reluctance DC Motor {{ Wipe-clean Flat Panel {{
Comfortable
Airflow
Power-Airflow Flap — — Washable Grille — —
Power-Airflow Dual Flaps {{ Filter Cleaning Indicator — —
Power-Airflow Diffuser — — Good-Sleep Cooling Operation — —
Wide-Angle Louvers {{
Timer 24-Hour On/Off Timer {{
Vertical Auto-Swing (Up and Down) {{ Night Set Mode {{
Horizontal Auto-Swing (Right and Left) {{
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
3-D Airflow {{ Self-Diagnosis (Digital, LED) Display {{
3-Step Airflow (H/P Only) — — Wiring Error Check — —
Comfort
Control
Auto Fan Speed {{ Anticorrosion Treatment of Outdoor
Heat Exchanger {{
Indoor Unit Silent Operation {{
Night Quiet Mode (Automatic) — —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit {{
Outdoor Unit Silent Operation (Manual) {{
Intelligent Eye {{ Flexible Voltage Correspondence {{
Quick Warming Function — {High Ceiling Application — —
Hot-Start Function — {Chargeless 10m 10m
Automatic Defrosting — {Power Selection — —
Operation
Automatic Operation — {
Remote
Control
5-Rooms Centralized Controller
(Option) {{
Programme Dry Function {{ Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) {{
Fan Only {{
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) — — Remote Control Adaptor
(Normal Open Contact)(Option) {{
Inverter Powerful Operation {{
Priority-Room Setting — — DIII-NET Compatible (Adaptor)(Option) {{
Cooling / Heating Mode Lock — — Remote
Controller
Wireless {{
Home Leave Operation {{ Wired — —
Indoor Unit On/Off Switch {{
Signal Reception Indicator {{
Temperature Display — —
Another Room Operation — —
Note: {: Holding Functions
— : No Functions

Si04-306 List of Functions
List of Functions 7
Category Functions
FTKD18·24·28BVMS RKD18·24·28BVMS
Category Functions
FTKD18·24·28BVMS RKD18·24·28BVMS
Basic
Function
Inverter (with Inverter Power Control) {
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions —
Operation Limit for Cooling (°CDB) 10~46
Operation Limit for Heating (°CWB) — Photocatalytic Deodorizing Filter —
PAM Control {Air Purifying Filter with Photocatalytic
Deodorizing Function {
Compressor
Oval Scroll Compressor — Longlife Filter —
Swing Compressor {Ultra-Longlife Filter (Option) —
Rotary Compressor — Mold Proof Air Filter {
Reluctance DC Motor {Wipe-clean Flat Panel {
Comfortable
Airflow
Power-Airflow Flap — Washable Grille —
Power-Airflow Dual Flaps {Filter Cleaning Indicator —
Power-Airflow Diffuser — Good-Sleep Cooling Operation —
Wide-Angle Louvers {
Timer 24-Hour On/Off Timer {
Vertical Auto-Swing (Up and Down) {Night Set Mode {
Horizontal Auto-Swing (Right and Left) {
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {
3-D Airflow {Self-Diagnosis (Digital, LED) Display {
3-Step Airflow (H/P Only) — Wiring Error Check —
Comfort
Control
Auto Fan Speed {Anticorrosion Treatment of Outdoor
Heat Exchanger {
Indoor Unit Silent Operation {
Night Quiet Mode (Automatic) —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit —
Outdoor Unit Silent Operation (Manual) {
Intelligent Eye {Flexible Voltage Correspondence {
Quick Warming Function — High Ceiling Application —
Hot-Start Function — Chargeless 10m
Automatic Defrosting — Power Selection —
Operation
Automatic Operation —
Remote
Control
5-Rooms Centralized Controller
(Option) {
Programme Dry Function {Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) {
Fan Only {
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) — Remote Control Adaptor
(Normal Open Contact)(Option) {
Inverter Powerful Operation {
Priority-Room Setting — DIII-NET Compatible (Adaptor)(Option) {
Cooling / Heating Mode Lock — Remote
Controller
Wireless {
Home Leave Operation {Wired —
Indoor Unit On/Off Switch {
Signal Reception Indicator {
Temperature Display —
Another Room Operation —
Note: {: Holding Functions
— : No Functions

List of Functions Si04-306
8List of Functions

Si04-306
Specifications 9
Part 2
Part 2Part 2
Part 2
Specifications
SpecificationsSpecifications
Specifications
1. Specifications ........................................................................................10
1.1 Cooling Only - R410A Series .................................................................10
1.2 Cooling Only - R22 Series......................................................................13
1.3 Heat Pump - R410A Series ....................................................................17
1.4 Heat Pump - R22 Series ........................................................................22

Specifications Si04-306
10 Specifications
1. Specifications
1.1 Cooling Only - R410A Series
240V, 50Hz
Notes: MAX. interunit piping length: 30m
MIN. interunit piping length: 1.5m
MAX. interunit height difference: 20m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Model Indoor Units FTKS50BVMA FTKS60BVMA FTKS71BVMA
Outdoor Units RKS50BVMA RKS60BVMA RKS71BVMA
Capacity
Rated (Min.~Max.)
kW 5.0 (0.9~5.8) 6.0 (0.9~6.7) 7.1 (0.9~8.0)
Btu/h 17,070 (3,070~19,800) 20,480 (3,070~22,870) 24,240 (3,070~27,310)
kcal/h 4,300 (770~4,990) 5,160 (770~5,760) 6,110 (770~6,880)
Moisture Removal L/h 2.9 3.9 4.5
Running Current (Rated) A 7.0 8.9 10.6
Power Consumption
Rated (Min.~Max.) W 1,660 (450~2,300) 2,120 (450~2,450) 2,530 (450~3,070)
Power Factor % 98.8 99.3 99.4
COP W/W 3.01 2.83 2.81
Piping
Connections
Liquid mm φ 6.4 φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7 φ15.9
Drain mm φ18.0 φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTKS50BVMA FTKS60BVMA FTKS71BVMA
Front Panel Color White White White
Air Flow Rate m³/min
(cfm)
H 11.4 (402) 16.2 (572) 16.8 (593)
M 9.8 (346) 13.9 (491) 14.2 (501)
L 8.7 (307) 11.9 (420) 11.9 (420)
SL 7.7 (272) 10.7 (378) 11.2 (395)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 40 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current (Rated) A 0.17 0.19 0.21
Power Consumption (Rated) W 40 45 50
Power Factor % 98.0 98.7 99.2
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×795×238 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 280×840×338 337×1,147×366 337×1,147×366
Weight kg 9 12 12
Gross Weight kg 13 17 17
Operation
Sound H/M/L/SL dBA 44/40/35/32 45/41/36/33 46/42/37/34
Sound Power H dBA 63 63 63
Outdoor Unit RKS50BVMA RKS60BVMA RKS71BVMA
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32HXD 2YC32HXD 2YC45BXD
Motor Output W 1,500 1,500 1,900
Refrigerant Oil Type FVC50K FVC50K FVC50K
Charge L 0.65 0.65 0.75
Refrigerant Type R410A R410A R410A
Charge kg 1.20 1.70 1.70
Air Flow Rate m³/min (cfm) H 47.7(1,684) 47.6 (1,680) 51.5 (1,818)
L 44.1(1,557) 44.1 (1,557) 41.5 (1,465)
Fan Type Propeller Propeller Propeller
Motor Output W 53 53 53
Running Current (Rated) A 6.83 8.71 10.39
Power Consumption (Rated) W 1,620 2,075 2,480
Power Factor % 98.8 99.3 99.5
Starting Current A 7 8.9 10.6
Dimensions (H×W×D) mm 735×825×300 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390 784×960×390
Weight kg 48 52 54
Gross Weight kg 53 57 59
Operation
Sound H/L dBA 47/44 49/46 52/49
Sound Power H dBA 63 64 66
Drawing No. 3D040801 3D040802 3D040803
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB 7.5m

Si04-306 Specifications
Specifications 11
230V, 50Hz
Notes: MAX. interunit piping length: 30m
MIN. interunit piping length: 1.5m
MAX. interunit height difference: 20m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Model Indoor Units FTKS50BVMB FTKS60BVMB FTKS71BVMB
Outdoor Units RKS50BVMB RKS60BVMB RKS71BVMB
Capacity
Rated (Min.~Max.)
kW 5.0 (0.9~5.8) 6.0 (0.9~6.7) 7.1 (0.9~8.0)
Btu/h 17,070 (3,070~19,800) 20,480 (3,070~22,870) 24,240 (3,070~27,310)
kcal/h 4,300 (770~4,990) 5,160 (770~5,760) 6,110 (770~6,880)
Moisture Removal L/h 2.9 3.9 4.5
Running Current (Rated) A 7.3 9.3 11.1
Power Consumption
Rated (Min.~Max.) W 1,660 (450~2,300) 2,120 (450~2,450) 2,530 (450~3,070)
Power Factor % 98.9 99.1 99.1
COP W/W 3.01 2.83 2.81
Piping
Connections
Liquid mm φ 6.4 φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7 φ15.9
Drain mm φ18.0 φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTKS50BVMB FTKS60BVMB FTKS71BVMB
Front Panel Color White White White
Air Flow Rate m³/min
(cfm)
H 11.4 (402) 16.2 (572) 16.7 (590)
M 9.7 (342) 13.6 (480) 14.2 (501)
L 8.0 (282) 11.4 (402) 11.6 (409)
SL 7.1 (251) 10.2 (360) 10.6 (374)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 40 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current (Rated) A 0.18 0.18 0.20
Power Consumption (Rated) W 40 40 45
Power Factor % 96.6 96.6 96.4
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×795×238 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 280×840×338 337×1,147×366 337×1,147×366
Weight kg 9 12 12
Gross Weight kg 13 17 17
Operation
Sound H/M/L/SL dBA 44/40/35/32 45/41/36/33 46/42/37/34
Sound Power H dBA 63 63 63
Outdoor Unit RKS50BVMB RKS60BVMB RKS71BVMB
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32HXD 2YC32HXD 2YC45BXD
Motor Output W 1,500 1,500 1,900
Refrigerant Oil Type FVC50K FVC50K FVC50K
Charge L 0.65 0.65 0.75
Refrigerant Type R410A R410A R410A
Charge kg 1.20 1.70 1.70
Air Flow Rate m³/min (cfm) H 47.7(1,684) 47.6 (1,680) 51.5 (1,818)
L 44.1(1,557) 44.1 (1,557) 41.5 (1,465)
Fan Type Propeller Propeller Propeller
Motor Output W 53 53 53
Running Current (Rated) A 6.82 9.12 10.90
Power Consumption (Rated) W 1,620 2,080 2,485
Power Factor % 99.0 99.2 99.1
Starting Current A 7.3 9.3 11.1
Dimensions (H×W×D) mm 735×825×300 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390 784×960×390
Weight kg 49 52 55
Gross Weight kg 53 57 59
Operation
Sound H dBA 47 49 52
Sound Power H dBA 63 64 66
Drawing No. 3D040781A 3D040782A 3D040783A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB 7.5m
