TECHNICAL MANUAL
Inverter Single Split Air Conditioner
Wall Mounted A Series
FTXS-A Series
— Heatpump [50Hz] —
R410A
TM-5WMZR-SI-ARA1

Table of Contents
i
Table of Contents
Nomenclature......................................................................................................................1
Indoor ............................................................................................................................1
Outdoor..........................................................................................................................1
Product Line-Up.............................................................................................................2
Application Information .....................................................................................................4
Operating Range ...........................................................................................................4
Refrigerant Circuit Diagrams .........................................................................................6
Installation Guideline .....................................................................................................7
Sound Data........................................................................................................................10
Sound Pressure Level ................................................................................................10
NC Curve..................................................................................................................... 11
Engineering & Physical Data...........................................................................................13
Performance Data.............................................................................................................14
Calculation Steps.........................................................................................................14
Performance Tables.....................................................................................................16
Outline & Dimension ........................................................................................................20
Wiring Diagram .................................................................................................................24
Service & Maintenance ....................................................................................................26
Troubleshooting ...............................................................................................................30

ii

Nomenclature
1
Nomenclature
Indoor
FT 25 A X V1 GX S
Power Supply
V1 : 220-240V/1Ph/50Hz
Manufacturer
X : Malaysia
Product Series
A : A Series
Capacity
25 : 2500 Watt*
35 : 3500 Watt*
50 : 5000 Watt*
60 : 6000 Watt*
Refrigerant & Mode
X : R410A, Inverter Heatpump
Outdoor
R 25 F X V1 GXN
Power Supply
V1 : 220-240V/1Ph/50Hz
Manufacturer
X : Malaysia
Product Series
F : F Series
C : C Series
Capacity
25 : 2500 Watt*
35 : 3500 Watt*
50 : 5000 Watt*
60 : 6000 Watt*
Refrigerant & Mode
XN : R410A, Inverter Heatpump
Market
G : Argentina
Market
G : Argentina
Remark:
* : Capacity value under Nomenclature is an indication.
Please refer to Engineering and Physical Data for exact capacity value.
Model
FT : Wall Mounted
Model
R : Single Split Condensing Unit
Classication
S : Premium Model

Nomenclature
2
Product Line-Up
Indoor Unit
FTXS
Nomenclature
Classication
Handset PCB Fin Air Purication
BRC52B61 W203EM WMY10J/JR VZ+ W203EM WMY15J/JR VZ+ W204B WMY20J/JR VZ+ W204B WMY25J/JR VZ+ Hydrophilic (Blue) Saranet Filter Titanium Apatite Filter
HEATPUMP
FTXS25AXV1G X X X X X
FTXS35AXV1G X X X X X
FTXS50AXV1G X X X X X
FTXS60AXV1G X X X X X

Nomenclature
3
Outdoor Unit
RXN
Nomenclature
Classication
Refrigerant Control PCB Fin Compressor
EXV 5SLY10FR 5SLY15FR 5SLY20CR 5SLY25CR Hydrophilic (Blue) Swing
HEATPUMP
RXN25FXV1G X X X X
RXN35FXV1G X X X X
RXN50CXV1G X X X X
RXN60CXV1G X X X X

4
Application Information
Application Information
Operating Range
Ensure the operating temperature is in allowable range.
Cooling
Model : FTXS25/35A - RXN25/35F
The use of your air conditioner
outside the range of working
temperature and humidity can
result in serious failure.
32 5214 15 19 2010
50
46
43
40
30
20
10
0
INDOOR TEMP (°CWB)
OUTDOOR TEMP (°CDB)
Model : FTXS50/60A - RXN50/60C
The use of your air conditioner
outside the range of working
temperature and humidity can
result in serious failure.
50
46
43
40
30
20
10
10 14 15 19 20 23 25
-10
-20
0
INDOOR TEMP (°CWB)
OUTDOOR TEMP (°CDB)

5
Application Information
Heating
Model : FTXS25/35/50/60A - RXN25/35F / RXN50/60C
The use of your air conditioner
outside the range of working
temperature and humidity can
result in serious failure.
20 25 27 301510
20
18
10
0
-10
-15
-20
OUTDOOR TEMP (°CWB)
INDOOR TEMP (°CDB)

6
Application Information
Refrigerant Circuit Diagrams
Model: FTXS25/35A – RXN25/35F
3 WAY VALVE MUFFLER
MUFFLER
4 WAY VALVE
Cooling operation
Heating operation
PIPING
LIQUID
ELECTRONIC EXPANSION
VALVE
RETURN AIR SENSOR
HEAT EXCHANGER
(OUTDOOR UNIT)
PIPE TEMPERATURE SENSOR
DISCHARGE PIPE
SENSOR
PIPE TEMPERATURE SENSOR
RETURN AIR SENSOR
HEAT EXCHANGER
(OUTDOOR UNIT)
COMPRESSOR
ACCUMULATOR
STRAINER
STRAINER
OUTDOOR UNIT
INDOOR UNIT
2 WAY VALVE
PIPING
GAS
Model: FTXS50/60A – RXN50/60C
3 WAY VALVE
MUFFLER
4 WAY VALVE
Cooling operation
Heating operation
PIPING
LIQUID
ELECTRONIC EXPANSION
VALVE
RETURN AIR SENSOR
HEAT EXCHANGER
(OUTDOOR UNIT)
PIPE TEMPERATURE SENSOR
DISCHARGE PIPE
SENSOR
PIPE TEMPERATURE SENSOR
RETURN AIR SENSOR
HEAT EXCHANGER
(OUTDOOR UNIT)
COMPRESSOR
ACCUMULATOR
STRAINER
STRAINER
OUTDOOR UNIT
INDOOR UNIT
2 WAY VALVE
PIPING
GAS

7
Application Information
Installation Guideline
Sharp edges and coil surfaces are potential injury hazard. Avoid from contact with them.
Installation Diagram
Indoor Unit
Air lter
M4 x 12L
Front panel
75mm or more from ceiling
Outdoor Unit
50mm or more from walls
(on both sides)
Caulk pipe
hole gap
with putty. Cut thermal insulation pipe to an
appropriate length and wrap it with
tape, making sure that no gap is left
in the insulation pipe’s cut line.
Wrap the insulation pipe
with the nishing tape
from bottom to top.
Service lid
500mm from wall
nOpening service lid
Service lid is opening/closing
type.
nOpening method
1) Remove the service lid
screws.
2) Pull out the service lid
diagonally down in the
direction of the arrow.
3) Pull down.

8
Application Information
Outdoor Clearance
If the condensing unit is operated in an atmosphere containing oils (including machine
oils), salt (coastal area), sulphide gas (near hot spring, oil renery plant), such as
substances may lead to failure of the unit.
• Where a wall or order obstacle is in the path of outdoor unit’s intake or exhaust airow, follow the
installation guidelines below.
• For any of the below installation patterns, the wall height on the exhaust side should be 1200mm or less.
Model: RXN25/35F
Wall facing one side Wall facing two side
More than 50
Side View Top View
Top View
Unit : mm
More than 50
More than 150
More than 50 More than 300
More than 50
More than 100
More
than 100
1200 or
less
More than 150
Wall facing three side
Model: RXN50/60C
ALL MODELS
Minimum Distance
A
300 mm
B
1000 mm
C
300 mm
D
500 mm
Return air
Discharge air
A
Obstacle
Obstacle
B
H/2
H
Return air
Service access
CD
Obstacle
Obstacle

9
Application Information
Cable Size
Model Unit FTXS25A FTXS35A FTXS50A FTXS60A
RXN25F RXN35F RXN50C RXN60C
Power supply cable size
Number of wire
mm21.5
3
2.5
3
Interconnection cable size
Number of wire
mm21.5
4
2.5
4
Recommended fuse A 16 20
Refrigerant Piping
Piping Length and Elevation
When the pipe length becomes too long, both the capacity and reliability drop.As the number of bends increases,
system piping resistance to the refrigerant ow increases, thus lowering the cooling capacity, and as the result
the compressor may become defective. Always choose the shortest path and follow the recommendation as
tabulated below:
Indoor Unit
Outdoor Unit
L E
Model FTXS25A FTXS35A FTXS50A FTXS60A
RXN25F RXN35F RXN50C RXN60C
Min. Allowable Length (L), m 3 3
Max. Allowable Length (L), m 20 30
Max. Allowable Elevation (E), m 10 10
Gas Pipe Size, mm/(in) 9.52 (3/8") 12.70 (1/2") 15.88 (5/8")
Liquid Pipe Size, mm/(in) 6.35 (1/4") 6.35 (1/4")
Additional Charge
• The refrigerant gas is charged in the outdoor unit and, if the piping length is 7.5m, additional charge of the
refrigerant after vacuuming is not necessary.
• When the piping length is more than 7.5m, additional refrigerant charge (g) per additional 1m length as
tabulated:
Model FTXS25A FTXS35A FTXS50A FTXS60A
RXN25F RXN35F RXN50C RXN60C
Additional charge [g/m] 20
Example:
FTXS25 & RXN25 with 12m piping length, additional piping length is 4.5m.
Thus, Additional charge = 4.5[m] x 20[g/m]
= 90.0[g]

10
Sound Data
Sound Data
Sound Pressure Level
Model Speed 1/1 Octave A-weighted Sound Pressure Level (dB, ref 20µPa) Overall
(dBA)
Noise
Criteria
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz
FTXS25A
High 42 38 37 36 32 24 12 40 35
Med 37 33 32 30 25 17 13 34 29
Low 32 29 28 24 19 14 13 29 22
Quiet 21 22 20 15 10 7 8 21 -
FTXS35A
High 40 38 38 37 34 27 14 41 36
Med 36 32 32 30 26 18 11 34 29
Low 33 29 29 25 21 15 11 30 23
Quiet 24 22 21 17 11 7 7 22 -
FTXS50A
High 35 37 37 36 32 25 12 40 35
Med 34 36 36 34 29 22 11 38 33
Low 30 34 33 31 26 18 10 35 30
Quiet 28 32 30 28 22 14 10 32 26
FTXS60A
High 39 41 40 38 36 31 16 43 37
Med 37 39 38 37 33 28 13 41 36
Low 33 36 35 33 28 22 11 37 32
Quiet 28 33 32 28 23 17 9 33 26
Model Measuring Location
FTXS25A
FTXS35A
FTXS50A
FTXS60A
Microphone
1.0m
0.8m
Standard : JIS C 9612

11
Sound Data
NC Curve
0
10
20
30
40
50
60
70
80
125 250 500 1000 2000 4000 8000
Sound pressure level (dB, ref 20µPa)
Octave-band frequency (Hz)
FTXS25A
NC-20
NC-30
NC-25
NC-35
NC-40
NC-45
NC-50
NC-55
NC-65
NC-60
NC-70
Q
0
10
20
30
40
50
60
70
80
125 250 500 1000 2000 4000 8000
Sound pressure level (dB, ref 20µPa)
Octave-band frequency (Hz)
FTXS35A
NC-20
NC-30
NC-25
NC-35
NC-40
NC-45
NC-50
NC-55
NC-65
NC-60
NC-70
Q

12
Sound Data
0
10
20
30
40
50
60
70
80
125 250 500 1000 2000 4000 8000
Sound pressure level (dB, ref 20µPa)
Octave-band frequency (Hz)
FTXS50A
NC-20
NC-30
NC-25
NC-35
NC-40
NC-45
NC-50
NC-55
NC-65
NC-60
NC-70
Q
0
10
20
30
40
50
60
70
80
125 250 500 1000 2000 4000 8000
Sound pressure level (dB, ref 20µPa)
Octave-band frequency (Hz)
FTXS60A
NC-20
NC-30
NC-25
NC-35
NC-40
NC-45
NC-50
NC-55
NC-65
NC-60
NC-70
Q

13
Engineering & Physical Data
Engineering & Physical Data
Engineering Data - R410A MODEL (Heatpump)
MODEL INDOOR UNIT FTXS25A FTXS35A FTXS50A FTXS60A
OUTDOOR UNIT RXN25F RXN35F RXN50C RXN60C
NOMINAL COOLING CAPACITY (MIN - MAX) Btu/h 8700 (4400 - 10200) 11600 (4400 - 13000) 19100 (4300 - 21200) 21500 (6000 - 22700)
kW 2.56 (1.30 - 3.00) 3.41 (1.30 - 3.80) 5.60 (1.26 - 6.20) 6.30 (1.75 - 6.65)
NOMINAL HEATING CAPACITY (MIN- MAX) Btu/h 8600 (4400 - 13600) 11800 (4400 - 16200) 19200 (4000 - 22500) 21800 (4100 - 27300)
kW 2.53 (1.30 - 4.00) 3.46 (1.30 - 4.75) 5.62 (1.17 - 6.60) 6.40 (1.20 - 8.00)
NOMINAL TOTAL INPUT POWER (COOLING) W 693 1060 1650 1880
NOMINAL TOTAL INPUT POWER (HEATING) W 700 950 1550 1680
NOMINAL RUNNING CURRENT (COOLING) A 3.82 5.73 7.28 8.29
NOMINAL RUNNING CURRENT (HEATING) A 3.83 5.19 6.86 7.46
EER W/W 3.69 3.22 3.39 3.35
COP W/W 3.61 3.64 3.63 3.81
REFRIGERANT CHARGE kg 0.74 1.00 1.25 1.45
POWER SOURCE V/Ph/Hz 220-240/1/50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL AIR DISCHARGE AUTO LOUVER (UP & DOWN) & MANUAL GRILLE (LEFT & RIGHT)
OPERATION WIRELESS REMOTE CONTROL
AIR FLOW
TURBO CFM 378 392 578 703
HIGH CFM 345 358 529 654
MEDIUM CFM 272 282 471 585
LOW CFM 215 232 418 507
QUIET CFM 165 165 374 437
SOUND PRESSURE LEVEL (T/H/M/L/Q) dBA 41/40/34/29/21 42/41/34/30/22 44/40/38/35/32 46/43/41/37/33
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 297 X 890 X 210 297 X 890 X 210 320 X 1172 X 242 320 X 1172 X 242
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 367 X 970 X 303 367 X 970 X 303 400 X 1252 X 333 400 X 1252 X 333
UNIT WEIGHT kg 9 9 14 14
CONDENSATE DRAIN SIZE mm 19.05
FAN TYPE CROSS FLOW
DRIVE DIRECT
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR MOTOR DIRECT CURRENT MOTOR
INDEX OF PROTECTION (IP) IP44 IP20
INSULATION GRADE CLASS E CLASS E CLASS E CLASS E
RATED INPUT POWER W 37 42 37 63
RATED RUNNING CURRENT A 0.19 0.21 0.32 0.56
MOTOR OUTPUT W 18 18 40 40
POLES 4 4 8 8
COIL
TUBE MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m20.18 0.29
ROW 2
AIR QUALITY FILTER TYPE SARANET + TITANIUM APATITE
QUANTITY pc 2
CASING COLOUR WHITE
OUTDOOR UNIT
AIR FLOW CFM 850 730 1796 1796
SOUND PRESSURE LEVEL dBA 45 46 51 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 550 X 658 X 273 550 X 658 X 273 651 X 855 X 328 753 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 580 X 775 X 355 580 X 775 X 355 693 X 990 X 415 793 X 990 X 415
UNIT WEIGHT kg 24 26 37 44
PIPE
CONNECTION SIZE LIQUID mm 6.35 6.35 6.35 6.35
GAS mm 9.52 9.52 12.70 15.88
PIPE LENGTH PRE-CHARGED m 7.5 7.5 7.5 7.5
MAXIMUM m 20 20 30 30
FAN TYPE PROPELLER PROPELLER PROPELLER PROPELLER
DRIVE DIRECT DIRECT DIRECT DIRECT
FAN MOTOR
TYPE DIRECT CURRENT
MOTOR
DIRECT CURRENT
MOTOR
DIRECT CURRENT
MOTOR
DIRECT CURRENT
MOTOR
INDEX OF PROTECTION (IP) IP24 IP24 IP23 IP23
INSULATION GRADE CLASS E CLASS E CLASS E CLASS E
RATED INPUT POWER W 25 24 86 80
RATED RUNNING CURRENT A 0.36 0.34 0.90 0.77
MOTOR OUTPUT W 41 41 61 61
POLES 8
COMPRESSOR
TYPE HERMETIC SWING
OIL TYPE DAPHNE FVC50K (Ether Oil)
OIL AMOUNT cm3375 650
COIL
TUBE MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m20.33 0.32 0.50 0.62
ROW 1 2 2 2
CASING COLOUR IVORY WHITE
OPERATING RANGE COOLING °C DB 10 ~ 46
HEATING °C WB -15 ~ 18
1) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB OUTDOOR: 8°C DB / 6°C WB

14
Performance Data
Performance Data
Calculation Steps
Interpolation method can be used to get the total
cooling capacity, TC and sensible cooling capacity,
SC and power input, PI at those temperatures which
are not stated out in the table. Extrapolation method
is not allowed to be used.
Example:
Indoor Condition: 25°C DB, 17°C WB
Outdoor Condition: 37°C DB
Fan Speed: High
Solution:
Based on the Performance Table,
1. Refer to the Indoor DB column,
- 25°C is located between 24°C & 27°C
for 16°C WB.
- 25°C is located between 24°C & 27°C
for 19°C WB.
- Thus, Interpolation needs to be applied.
2. Refer to the Indoor WB column,
- 17°C is located between 16°C & 19°C
for 25°C DB.
- Thus, Interpolation needs to be applied.
3. Refer to the Outdoor DB column,
- 37°C is located between 35°C & 40°C.
- Thus, Interpolation needs to be applied.
1st Step
Interpolation of Indoor WB
Find TC, SC & PI
(a) Indoor: 25°C DB, 16°C WB
Outdoor: 35°C DB
(b) Indoor: 25°C DB, 19°C WB
Outdoor: 35°C DB
(c) Indoor: 25°C DB, 16°C WB
Outdoor: 40°C DB
(d) Indoor: 25°C DB, 19°C WB
Outdoor: 40°C DB
2nd Step
Interpolation of Indoor DB
Find TC, SC & PI
(a) Indoor: 25°C DB, 17°C WB
Outdoor: 35°C DB
(b) Indoor: 25°C DB, 17°C WB
Outdoor: 40°C DB
3rd Step
Interpolation of Outdoor DB
Find TC, SC & PI
(a) Indoor: 25°C DB, 17°C WB
Outdoor: 37°C DB
Details of Calculation:
1st Step:
To obtain the TC, SC & PI for
(a) Indoor Condition: 25°C DB, 16°C WB
Outdoor Condition: 35°C DB
EWB EDB
Outdoor temperature
35°C
TC SC PI
16
24 2.33 2.32 0.68
25 x1y1z1
27 2.40 2.40 0.68
By Interpolation Method
⇒25°C – 24°C =x1– 2.33 kW
27°C – 24°C 2.40 kW – 2.33 kW
⇒x1= 2.35 kW
Similarly,
y1= 2.35 kW
z1= 0.68 kW

15
Performance Data
(b) Indoor Condition: 25°C DB, 19°C WB
Outdoor Condition: 35°C DB
EWB EDB
Outdoor temperature
35°C
TC SC PI
19
24 2.55 1.82 0.69
25 x2y2z2
27 2.56 2.12 0.69
By Interpolation Method
⇒25°C – 24°C =y2– 1.82 kW
27°C – 24°C 2.12 kW – 1.82 kW
⇒y2= 1.92 kW
Similarly,
x2= 2.55 kW
z2= 0.69 kW
Repeat the same process for (c) & (d) in 1st Step
(c) x3= 2.17 kW; y3= 2.17 kW; z3= 0.69 kW (d) x4= 2.34 W; y4= 1.80 kW; z4= 0.75 kW
2nd Step:
To obtain the TC, SC & PI for
(a) Indoor Condition: 25°C DB, 17°C WB
Outdoor Condition: 35°C DB
EWB EDB
Outdoor temperature
35°C
TC SC PI
16
25
2.35 2.35 0.68
17 x5y5z5
19 2.55 1.92 0.69
By Interpolation Method
⇒17°C – 16°C =x5– 2.35 kW
19°C – 16°C 2.55 kW – 2.35 kW
⇒x5= 2.42 kW
Similarly,
y5= 2.21 kW
z5= 0.68 kW
Repeat the same process for (b) in 2nd Step
(c) x6= 2.22 kW; y6= 2.05 kW; z6= 0.71 kW
3rd Step:
To obtain the TC, SC & PI for
(a) Indoor Condition: 25°C DB, 17°C WB
Outdoor Condition: 37°C DB
EWB EDB
Outdoor temperature
35°C 37°C 40°C
TC SC PI TC SC PI TC SC PI
25 17 2.42 2.21 0.68 x y z 2.22 2.05 0.71
By Interpolation Method
⇒37°C – 35°C =x – 2.42 kW
40°C – 35°C 2.22 kW – 2.42 kW
⇒x = 2.34 kW
Similarly,
y = 2.15 kW
z = 0.69 kW

16
Performance Data
Performance Tables
R410A Heatpump
Model: FTXS25A - RXN25F
Cooling Mode
AFR
(CFM) EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
215
16°C
21°C 2.41 1.77 0.53 2.33 1.73 0.57 2.24 1.68 0.62 2.15 1.63 0.67 1.98 1.52 0.73 1.82 1.43 0.80
24°C 2.42 2.13 0.53 2.33 2.08 0.57 2.24 2.03 0.62 2.15 1.98 0.67 1.98 1.85 0.73 1.83 1.74 0.80
27°C 2.44 2.41 0.53 2.35 2.35 0.57 2.27 2.30 0.62 2.19 2.24 0.67 2.02 2.08 0.73 1.88 1.96 0.80
30°C 2.51 2.51 0.53 2.44 2.44 0.57 2.36 2.36 0.62 2.29 2.29 0.68 2.12 2.12 0.73 1.98 1.98 0.81
19°C
24°C 2.66 1.66 0.53 2.57 1.61 0.58 2.47 1.57 0.63 2.38 1.53 0.68 2.18 1.42 0.74 2.02 1.34 0.81
27°C 2.66 1.90 0.53 2.57 1.85 0.58 2.48 1.81 0.63 2.38 1.77 0.68 2.19 1.65 0.74 2.02 1.57 0.81
30°C 2.67 2.34 0.54 2.58 2.29 0.58 2.48 2.24 0.63 2.39 2.18 0.68 2.20 2.04 0.74 2.04 1.93 0.81
33°C 2.70 2.70 0.54 2.61 2.61 0.58 2.53 2.53 0.63 2.44 2.44 0.68 2.26 2.26 0.74 2.11 2.11 0.82
22°C
27°C 2.93 1.62 0.54 2.83 1.58 0.59 2.72 1.54 0.64 2.62 1.50 0.69 2.41 1.40 0.75 2.23 1.32 0.83
30°C 2.93 1.98 0.54 2.83 1.93 0.59 2.72 1.89 0.64 2.62 1.85 0.69 2.41 1.73 0.75 2.23 1.64 0.83
33°C 2.93 2.31 0.54 2.83 2.26 0.59 2.73 2.22 0.64 2.62 2.17 0.69 2.41 2.04 0.75 2.23 1.94 0.83
36°C 2.94 2.62 0.55 2.84 2.56 0.59 2.74 2.51 0.64 2.64 2.46 0.70 2.44 2.30 0.75 2.27 2.18 0.83
272
16°C
21°C 2.51 1.85 0.53 2.42 1.80 0.57 2.33 1.76 0.62 2.23 1.71 0.67 2.05 1.59 0.73 1.89 1.50 0.81
24°C 2.52 2.25 0.53 2.43 2.20 0.57 2.34 2.14 0.62 2.24 2.09 0.68 2.06 1.95 0.73 1.90 1.84 0.81
27°C 2.55 2.55 0.53 2.46 2.49 0.58 2.38 2.43 0.62 2.29 2.36 0.68 2.12 2.19 0.74 1.97 2.05 0.81
30°C 2.66 2.66 0.54 2.58 2.58 0.58 2.50 2.50 0.63 2.42 2.42 0.68 2.24 2.24 0.74 2.09 2.09 0.82
19°C
24°C 2.77 1.75 0.54 2.67 1.71 0.58 2.57 1.66 0.63 2.46 1.62 0.69 2.26 1.51 0.74 2.09 1.42 0.82
27°C 2.77 2.02 0.54 2.67 1.97 0.58 2.57 1.93 0.63 2.47 1.88 0.69 2.27 1.76 0.75 2.10 1.67 0.82
30°C 2.78 2.49 0.54 2.69 2.44 0.59 2.59 2.38 0.63 2.49 2.32 0.69 2.29 2.17 0.75 2.13 2.05 0.82
33°C 2.83 2.83 0.54 2.74 2.74 0.59 2.66 2.66 0.64 2.57 2.57 0.69 2.38 2.38 0.75 2.22 2.22 0.83
22°C
27°C 3.04 1.72 0.55 2.93 1.68 0.60 2.82 1.63 0.65 2.71 1.59 0.70 2.49 1.48 0.76 2.30 1.40 0.84
30°C 3.04 2.10 0.55 2.94 2.06 0.60 2.83 2.02 0.65 2.71 1.97 0.70 2.49 1.84 0.76 2.31 1.75 0.84
33°C 3.05 2.47 0.55 2.94 2.42 0.60 2.83 2.37 0.65 2.72 2.32 0.70 2.51 2.18 0.76 2.32 2.07 0.84
36°C 3.07 2.79 0.55 2.97 2.74 0.60 2.86 2.68 0.65 2.76 2.62 0.70 2.55 2.45 0.76 2.37 2.31 0.84
345
16°C
21°C 2.60 1.93 0.54 2.51 1.88 0.58 2.41 1.83 0.63 2.31 1.78 0.68 2.12 1.66 0.74 1.96 1.56 0.81
24°C 2.62 2.35 0.54 2.52 2.29 0.58 2.43 2.24 0.63 2.33 2.18 0.68 2.14 2.03 0.74 1.98 1.92 0.81
27°C 2.66 2.69 0.54 2.57 2.62 0.58 2.49 2.55 0.63 2.40 2.47 0.68 2.22 2.29 0.74 2.06 2.14 0.82
30°C 2.79 2.79 0.54 2.71 2.71 0.59 2.63 2.63 0.64 2.54 2.54 0.69 2.35 2.35 0.75 2.20 2.20 0.83
19°C
24°C 2.87 1.85 0.54 2.76 1.81 0.59 2.66 1.76 0.64 2.55 1.71 0.69 2.34 1.60 0.75 2.16 1.51 0.83
27°C 2.88 2.15 0.54 2.77 2.10 0.59 2.67 2.05 0.64 2.56 2.00 0.69 2.35 1.87 0.75 2.17 1.77 0.83
30°C 2.90 2.64 0.55 2.80 2.58 0.59 2.70 2.52 0.64 2.59 2.46 0.69 2.39 2.30 0.75 2.22 2.17 0.83
33°C 2.96 2.96 0.55 2.87 2.87 0.59 2.79 2.79 0.65 2.69 2.69 0.70 2.50 2.50 0.76 2.33 2.33 0.84
22°C
27°C 3.15 1.81 0.55 3.03 1.77 0.60 2.92 1.73 0.65 2.80 1.68 0.71 2.57 1.57 0.77 2.38 1.48 0.84
30°C 3.15 2.24 0.55 3.04 2.19 0.60 2.93 2.15 0.65 2.81 2.10 0.71 2.58 1.96 0.77 2.39 1.86 0.84
33°C 3.16 2.62 0.56 3.05 2.57 0.60 2.94 2.52 0.65 2.83 2.46 0.71 2.60 2.31 0.77 2.41 2.19 0.85
36°C 3.19 2.96 0.56 3.09 2.90 0.60 2.98 2.84 0.65 2.88 2.77 0.71 2.66 2.58 0.77 2.48 2.43 0.85
Remark:
AFR: Air ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 10°C to 46°C without pressure trip.
Heating Mode
Outdoor WB°C
Indoor -15 -10 -5 0 6 10
DB°C TC PI TC PI TC PI TC PI TC PI TC PI
16 1.27 0.50 1.57 0.54 1.88 0.57 2.19 0.61 2.56 0.65 2.80 0.68
18 1.26 0.53 1.56 0.56 1.87 0.60 2.18 0.63 2.54 0.68 2.79 0.70
20 1.24 0.55 1.55 0.59 1.86 0.62 2.16 0.66 2.53 0.70 2.77 0.73
21 1.24 0.56 1.54 0.60 1.85 0.63 2.15 0.67 2.53 0.71 2.77 0.74
22 1.23 0.58 1.54 0.61 1.85 0.65 2.15 0.68 2.52 0.72 2.76 0.75
24 1.22 0.61 1.53 0.64 1.83 0.68 2.14 0.71 2.50 0.75 2.75 0.78
Remark:
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 10°C to 46°C without pressure trip.
