1 About the documentation
1.1 About this document
Thank you for purchasing this product. Please:
▪ Keep the documentation for future reference.
Target audience
Endusers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪General safety precautions:
▪ Safety instructions that you must read before operating your
system
▪ Format: Paper (in the box of the indoor unit)
▪Operation manual:
▪ Quick guide for basic usage
▪ Format: Paper (in the box of the indoor unit)
▪User reference guide:
▪ Detailed step-by-step instructions and background information
for basic and advanced usage
▪ Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
2 About the system
WARNING: FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
NOTICE
Do NOT use the system for other purposes. In order to
avoid any quality deterioration, do NOT use the unit for
cooling precision instruments, food, plants, animals, or
works of art.
2.1 Indoor unit
CAUTION
Do NOT insert fingers, rods or other objects into the air
inlet or outlet. When the fan is rotating at high speed, it will
cause injury.
INFORMATION
The sound pressure level is less than 70dBA.
WARNING
▪ Do not modify, disassemble, remove, reinstall or repair
the unit yourself as incorrect dismantling or installation
may cause an electric shock or fire. Contact your
dealer.
▪ In case of accidental refrigerant leaks, make sure there
are no naked flames. The refrigerant itself is entirely
safe, non-toxic and mildly flammable, but it will
generate toxic gas when it accidentally leaks into a
room where combustible air from fan heaters, gas
cookers, etc. is present. Always have qualified service
personnel confirm that the point of leakage has been
repaired or corrected before resuming operation.
INFORMATION
The following figures are just examples and may NOT
completely match your system layout.

2 About the system
Operation manual
3
ATXF50~71A2V1B
Daikin room air conditioner
3P511999-5G – 2019.12
a
cd
ON/OFF
f
g
l
h
i
k
j
e
b
aAir inlet
bAir outlet
cFlap (horizontal blade)
dLouvers (vertical blades)
eFront panel
fModel name plate
gRoom temperature sensor
hSignal receiver
iOperation indicator (green)
jTimer lamp (orange)
kIndoor unit ON/OFF switch
lAir filter
ON/OFF button
If the user interface is missing, you can use the ON/OFF button on
the indoor unit to start/stop operation. When operation is started
using this button, the following settings are used:
▪ Operation mode = Automatic
▪ Temperature setting = 25°C
▪ Airflow rate = Automatic
2.2 About the user interface
▪Direct sunlight. Do NOT expose the user interface to direct
sunlight.
▪Dust. Dust on the signal transmitter or receiver will reduce
sensitivity. Wipe off dust with a soft cloth.
▪Fluorescent lights. Signal communication might be disabled if
fluorescent lamps are in the room. In that case, contact your
installer.
▪Other appliances. If the user interface signals operate other
appliances, move the other appliances, or contact your installer.
▪Curtains. Make sure that the signal between the unit and the user
interface is NOT blocked by curtains or other objects.
NOTICE
▪ Do NOT drop the user interface.
▪ Do NOT let the user interface get wet.
2.2.1 Components: User interface
b
d
c
f
h
e
m
l
k
i
j
a
g
aSignal transmitter
bLCD display
cON/OFF button
dFan setting button
eTemperature adjustment button
fSwing button
gTimer cancel button
hON timer button
iOFF timer button
jComfort airflow button
kEcono button
lMode selector button
mPowerful button
2.2.2 To operate the user interface
a
aSignal receiver
1Aim the signal transmitter at the signal receiver on the indoor
unit (maximum distance for communication is 7m).
Result: When the indoor unit receives a signal from the user
interface, you will hear a sound:
Sound Description
Beep-beep Operation starts.
Beep Setting changes.
Long beep Operation stops.

3 Before operation
Operation manual
4
ATXF50~71A2V1B
Daikin room air conditioner
3P511999-5G – 2019.12
3 Before operation
3.1 To fix the user interface to the wall
2×
b ca
aUser interface
bScrews (field supply)
cUser interface holder
1Choose a place where the signals reach the unit.
2Attach the holder with screws to the wall or a similar location.
3Hang the user interface on the user interface holder.
3.2 To insert the batteries
The batteries will last for about 1 year.
1Remove the back cover.
2Insert both batteries at once.
3Put the cover back.
2
3
1
AAA.LR03
3.3 To turn on the power supply
1Turn the circuit breaker on.
Result: The flap of the indoor unit will open and close to set the
reference position.
4 Operation
4.1 Operation range
Operation mode Operation range
Cooling(a)(b) ▪ Outdoor temperature: –10~46°C DB
▪ Indoor temperature: 18~32°C DB
▪ Indoor humidity: ≤80%
Heating(a) ▪ Outdoor temperature: –15~24°C DB
▪ Indoor temperature: 10~30°C DB
Drying(a) ▪ Outdoor temperature: –10~46°C DB
▪ Indoor temperature: 18~32°C DB
▪ Indoor humidity: ≤80%
(a) A safety device might stop the operation of the system if
the unit runs outside its operation range.
(b) Condensation and water dripping might occur if the unit
runs outside its operation range.
4.2 Operation mode and temperature
setpoint
When. Adjust the system operation mode and set the temperature
when you want to:
▪ Heat up or cool down a room
▪ Blow air in a room without heating or cooling
▪ Decrease the humidity in a room
What. The system operates differently, depending on the user
selection.
Setting Description
Automatic The system cools down or heats up a
room to the temperature setpoint. It
automatically switches between cooling
and heating if necessary.
Drying The system decreases the humidity in a
room without changing the temperature.
Heating The system heats up a room to the
temperature setpoint.
Cooling The system cools down a room to the
temperature setpoint.
Fan The system only controls the airflow
(airflow rate and airflow direction).
The system does NOT control the
temperature.
Additional info:
▪Outside temperature. The system's cooling or heating effect
decreases when the outside temperature is too high or too low.
▪Defrost operation. During heating operation, frost might occur on
the outdoor unit and decrease the heating capacity. In that case,
the system automatically switches to defrosting operation to
remove the frost. During defrosting operation, hot air is NOT
blown from the indoor unit.
4.2.1 To start/stop operation mode and to set
the temperature
: Unit is operating.
: Operation mode = Automatic
: Operation mode = Drying
: Operation mode = Heating
: Operation mode = Cooling
: Operation mode = Fan only
: Shows the set temperature.
1Press one or more times to select the operation mode.
Result: The mode will be set in the following sequence:
2Press to start operation.
Result: is displayed on the LCD.

4 Operation
Operation manual
5
ATXF50~71A2V1B
Daikin room air conditioner
3P511999-5G – 2019.12
Result: The operation lamp lights up.
3Press or on the button one or more times to lower or
raise the temperature.
Note: When using drying or fan only mode, you cannot adjust the
temperature.
4Press to stop operation.
Result: disappears from the LCD.
Result: The operation lamp goes off.
4.3 Airflow rate
1Press to choose:
5 airflow rate levels, from " " to " "
Automatic operation
Indoor unit quiet operation. When the airflow is set to
" ", the noise from the unit will be reduced.
INFORMATION
▪ If the unit reach the temperature setpoint in cooling,
heating or automatic mode. Fan will stop operating.
▪ When using drying operation mode, you CANNOT
adjust the airflow rate setting.
4.3.1 To adjust the airflow rate
1Press to change the airflow setting as follows:
4.4 Airflow direction
When. Adjust the airflow direction as desired.
What. The system directs the airflow differently, depending on the
user selection (swinging or fixed position). It does so by moving the
vertical blades.
Setting Airflow direction
Vertical auto swing Moves up and down.
[—] Stays in a fixed position.
CAUTION
▪ ALWAYS use a user interface to adjust the angle of the
flap. When the flap is swinging and you move it forcibly
by hand, the mechanism will break.
▪ Be careful when adjusting the louvers. Inside the air
outlet, a fan is rotating at high speed.
Note: The movable range of the flap varies according to the
operation mode. The flap will stop at the upper position when the
airflow rate is changed to low during the up and down swing setting.
a
b
c
aFlap range in cooling or drying operation
bFlap range in hating operation
cFlap range in fan only operation
4.4.1 To adjust the airflow direction
1To use auto swing, press .
Result: will appear on the LCD.
Result: The flap (horizontal blade) will begin to swing.
2To use fixed position, press when the flap reaches the
desired position.
Result: disappears from the LCD.
4.4.2 To adjust the louvers (vertical blades)
1Hold 1 or both knobs and move the louvers.
aa
aKnobs
INFORMATION
When the unit is installed in a corner of a room, the
direction of the louvers should be facing away from the
wall. Efficiency will drop if a wall blocks the air.
4.5 Comfort airflow operation
This operation can be used in heating or cooling operation mode. It
will provide a comfortable wind that will NOT come in direct contact
with people. The system automatically sets the fixed airflow position
upward in Cooling and downward in Heating operation mode.
Cooling operation mode Heating operation mode
INFORMATION
Powerful and Comfort airflow operation CANNOT be used
at the same time. The last selected function takes priority.
If the vertical automatic swing is selected, Comfort airflow
operation will be cancelled.
4.5.1 To start/stop Comfort airflow operation
1Press to start.

4 Operation
Operation manual
6
ATXF50~71A2V1B
Daikin room air conditioner
3P511999-5G – 2019.12
Result: The flap position will change, is displayed on the
LCD, and the airflow rate is set to automatic.
Mode Position of flap…
Cooling/Drying Up
Heating Down
2Press to stop.
Result: The flap will return to the position from before the Comfort
airflow mode; disappears from the LCD.
4.6 Powerful operation
This operation quickly maximizes the cooling/heating effect in any
operation mode. You can get the maximum capacity.
INFORMATION
Powerful operation CANNOT be used together with Econo
and Comfort airflow operation. The last selected function
takes priority.
Powerful operation will NOT increase the capacity of the
unit if it already operates at maximum capacity.
4.6.1 To start/stop Powerful operation
1Press to start.
Result: is displayed on the LCD. Powerful operation runs
for 20minutes; after that, operation returns to the previously set
mode.
2Press to stop.
Result: disappears from the LCD.
Note: Powerful operation can be set only when the unit is running. If
you press , operation will be cancelled; disappears
from the LCD.
4.7 Econo operation
This is a function which enables efficient operation by limiting the
maximum power consumption value. This function is useful for cases
in which attention should be paid to ensure a circuit breaker will not
trip when the product runs alongside other appliances.
INFORMATION
▪ Powerful and Econo operation CANNOT be used at the
same time. The last selected function takes priority.
▪ Econo operation reduces power consumption of the
outdoor unit by limiting the rotation speed of the
compressor. If power consumption is already low,
Econo operation will NOT further reduce power
consumption.
4.7.1 To start/stop Econo operation
1Press to start.
Result: is displayed on the LCD.
2Press to stop.
Result: disappears from the LCD.
4.8 OFF/ON timer operation
Timer functions are useful for automatically switching the air
conditioner on/off at night or in the morning. You can also use OFF
timer and ON timer in combination.
INFORMATION
Program the timer again in case of:
▪ A breaker has turned the unit off.
▪ A power failure.
▪ After replacing batteries in the user interface.
4.8.1 To start/stop ON timer operation
1Press to start.
Result: is displayed on the LCD and the timer lamp lights
up.
INFORMATION
Each time is pressed, the time setting advances by
1 hour. The timer can be set between 1 to 12 hours.
2Press to stop.
Result: disappears from the LCD and the timer lamp
goes off.
4.8.2 To start/stop OFF timer operation
1Press to start.
Result: is displayed on the LCD and the timer lamp lights
up.
INFORMATION
Each time is pressed, the time setting advances by
1 hour. The timer can be set between 1 to 9 hours.
2Press to stop.
Result: disappears from the LCD and the timer lamp
goes off.
INFORMATION
When you set the ON/OFF timer, the time setting is stored
in the memory. The memory will be reset when the user
interface batteries are replaced.
Use of night set mode in combination with OFF timer
The air conditioner automatically adjusts the temperature
setting (0.5°C up in cooling, 2.0°C down in heating) to
prevent excessive cooling/heating and ensure a
comfortable sleeping temperature.
4.8.3 To combine OFF timer and ON timer
1To set the timers, refer to "4.8.2 To start/stop OFF timer
operation" [4 6] and "4.8.1 To start/stop ON timer
operation"[46].
Result: and are displayed on the LCD.
2Example of what is displayed on the LCD if you combine the 2
timers:

5 Energy saving and optimum operation
Operation manual
7
ATXF50~71A2V1B
Daikin room air conditioner
3P511999-5G – 2019.12
5 Energy saving and optimum
operation
INFORMATION
▪ Even if the unit is turned OFF, it consumes electricity.
▪ When the power turns back on after a power break, the
previously selected mode will be resumed.
CAUTION
NEVER expose little children, plants or animals directly to
the airflow.
WARNING
Do NOT place objects below the indoor and/or outdoor unit
that may get wet. Otherwise condensation on the unit or
refrigerant pipes, air filter dirt or drain blockage may cause
dripping, and objects under the unit may get dirty or
damaged.
WARNING
Do NOT place a flammable spray bottle near the air
conditioner and do NOT use sprays near the unit. Doing so
may result in a fire.
CAUTION
Do NOT operate the system when using a room
fumigation-type insecticide. Chemicals could collect in the
unit, and endanger the health of people who are
hypersensitive to chemicals.
Observe the following precautions to ensure the system operates
properly.
▪ Prevent direct sunlight from entering a room during cooling
operation by using curtains or blinds.
▪ Make sure the area is well ventilated. Do NOT block any
ventilation openings.
▪ Ventilate often. Extended use requires special attention to
ventilation.
▪ Keep doors and windows closed. If the doors and windows remain
open, air will flow out of your room causing a decrease in the
cooling or heating effect.
▪ Be careful NOT to cool or heat too much. To save energy, keep
the temperature setting at a moderate level.
▪ NEVER place objects near the air inlet or the air outlet of the unit.
Doing so may cause a reduced heating/cooling effect or stop
operation.
▪ Turn the breaker off when the unit is NOT used for longer periods
of time. If the breaker is on, the unit consumes electricity. Before
restarting the unit, turn the breaker on 6 hours before operation to
ensure smooth running.
▪ Condensation may form if the humidity is above 80% or if the
drain outlet gets blocked.
▪ Adjust the room temperature properly for a comfortable
environment. Avoid excessive heating or cooling. Notice that it
may take some time for the room temperature to reach the set
temperature. Consider using the timer setting options.
▪ Adjust the air flow direction to avoid cool air from gathering on the
floor or warm air against the ceiling. (Up during cooling or dry
operation to the ceiling and down during heating operation.)
▪ Avoid direct air flow to room inhabitants.
▪ Operate the system within the recommended temperature range
(26~28°C for cooling and 20~24°C for heating) to save energy.
6 Maintenance and service
6.1 Overview: Maintenance and
service
The installer has to perform a yearly maintenance.
About the refrigerant
This product contains fluorinated greenhouse gases. Do NOT vent
gases into the atmosphere.
Refrigerant type: R32
Global warming potential (GWP) value: 675
NOTICE
Applicable legislation on fluorinated greenhouse gases
requires that the refrigerant charge of the unit is indicated
both in weight and CO2 equivalent.
Formula to calculate the quantity in CO2 equivalent
tonnes: GWP value of the refrigerant × total refrigerant
charge [in kg] / 1000
Please contact your installer for more information.
WARNING
The refrigerant inside the unit is mildly flammable, but
normally does NOT leak. If the refrigerant leaks in the
room and comes in contact with fire from a burner, a
heater, or a cooker, this may result in fire, or the formation
of a harmful gas.
Turn off any combustible heating devices, ventilate the
room, and contact the dealer where you purchased the
unit.
Do NOT use the unit until a service person confirms that
the part from which the refrigerant leaked has been
repaired.
WARNING
▪ Do NOT pierce or burn refrigerant cycle parts.
▪ Do NOT use cleaning materials or means to accelerate
the defrosting process other than those recommended
by the manufacturer.
▪ Be aware that the refrigerant inside the system is
odourless.
WARNING
The appliance shall be stored in a room without
continuously operating ignition sources (example: open
flames, an operating gas appliance or an operating electric
heater).
NOTICE
Maintenance MUST be done by an authorized installer or
service agent.
We recommend performing maintenance at least once a
year. However, applicable legislation might require shorter
maintenance intervals.
DANGER: RISK OF ELECTROCUTION
To clean the air conditioner or air filter, be sure to stop
operation and turn all power supplies off. Otherwise, an
electric shock and injury may result.

6 Maintenance and service
Operation manual
8
ATXF50~71A2V1B
Daikin room air conditioner
3P511999-5G – 2019.12
WARNING
To prevent electric shocks or fire:
▪ Do NOT rinse the unit.
▪ Do NOT operate the unit with wet hands.
▪ Do NOT place any objects containing water on the unit.
CAUTION
After a long use, check the unit stand and fitting for
damage. If damaged, the unit may fall and result in injury.
CAUTION
Do NOT touch the heat exchanger fins. These fins are
sharp and could result in cutting injuries.
WARNING
Be careful with ladders when working in high places.
6.2 To clean the indoor unit and user
interface
NOTICE
▪ Do NOT use gasoline, benzene, thinner polishing
powder or liquid insecticide. Possible consequence:
Discoloration and deformation.
▪ Do NOT use water or air of 40°C or higher. Possible
consequence: Discoloration and deformation.
▪ Do NOT use polishing compounds.
▪ Do NOT use a scrubbing brush. Possible
consequence: The surface finishing peels off.
DANGER: RISK OF ELECTROCUTION
Before cleaning, be sure to stop the operation, turn the
breaker off or pull out the supply cord. Otherwise, an
electric shock and injury may result.
1Clean with a soft cloth. If it is difficult to remove stains, use
water or a neutral detergent.
6.3 To clean the front panel
1Clean the front panel with a soft cloth. If it is difficult to remove
stains, use water or a neutral detergent.
6.4 About the air filters
Operating the unit with dirty filters means that the filter:
▪ CANNOT deodorize the air,
▪ CANNOT clean the air,
▪ poor heating/cooling,
▪ causes odour.
6.5 To clean the air filters
1Push the tab at the centre of each air filter, then pull it down.
2Pull out the air filters.
2
1
3Wash the air filters with water or clean them with a vacuum
cleaner.
4Soak in lukewarm water for about 10 to 15 minutes.
5Install all filters back in their original positions.
INFORMATION
▪ If the dust does NOT come off easily, wash them with a
neutral detergent diluted in lukewarm water. Dry the air
filters in the shade.
▪ It is recommended to clean the air filters every 2
weeks.
6.6 To take following items into
account before a long idle period
Operate the unit in fan only mode for several hours to dry the inside
of the unit.
1Press and select fan only operation.
2Press to start operation.
3After operation stops, turn the breaker off.
4Clean the air filters and replace them in their original position.
5Remove the batteries from the user interface.
INFORMATION
It is recommended to have periodical maintenance
performed by a specialist. For specialist maintenance,
contact your dealer. Maintenance costs shall be borne by
the customer.
In certain operating conditions the inside of the unit may
get dirty after several seasons of use. This results in poor
performance.

7 Troubleshooting
Operation manual
9
ATXF50~71A2V1B
Daikin room air conditioner
3P511999-5G – 2019.12
7 Troubleshooting
If one of the following malfunctions occur, take the measures shown
below and contact your dealer.
WARNING
Stop operation and shut off the power if anything
unusual occurs (burning smells etc.).
Leaving the unit running under such circumstances may
cause breakage, electric shock or fire. Contact your dealer.
The system MUST be repaired by a qualified service person.
Malfunction Measure
If a safety device such as a fuse, a
breaker or an earth leakage breaker
frequently actuates or the ON/OFF
switch does NOT properly work.
Turn OFF the main power
switch.
If water leaks from the unit. Stop the operation.
The operation switch does NOT work
well.
Turn OFF the power
supply.
If the user interface display indicates the
unit number, the operation lamp flashes
and the malfunction code appears.
Notify your installer and
report the malfunction
code.
If the system does NOT operate properly except for the above
mentioned cases and none of the above mentioned malfunctions is
evident, investigate the system according to the following
procedures.
INFORMATION
Refer to the user reference guide located on http://
www.daikineurope.com/support-and-manuals/product-
information/ for more troubleshooting tips.
If after checking all above items, it is impossible to fix the problem
yourself, contact your installer and state the symptoms, the complete
model name of the unit (with manufacturing number if possible) and
the installation date (possibly listed on the warranty card).
8 Disposal
NOTICE
Do NOT try to dismantle the system yourself: dismantling
of the system, treatment of the refrigerant, oil and other
parts MUST comply with applicable legislation. Units
MUST be treated at a specialised treatment facility for
reuse, recycling and recovery.

3P511999-5G 2019.12
Copyright 2019 Daikin
Verantwortung für Energie und Umwelt
