Daikin FXAQ-MAVE9 Series Instruction manual

Wall Mounted Unit
FXAQ-MAVE9
air conditioning systems
technical data

•VRV
®Systems • Indoor Units 1
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
TABLE OF CONTENTS
FXAQ-MAVE9
®
1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Electrical Specifications (50Hz) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Specifications (60Hz) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Safety device settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Control systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cooling capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Heating capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Dimensional drawing & centre of gravity . . . . . . . . . . . . . . . . . . . . . . . . 9
Dimensional drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7 Piping diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9 Sound data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sound level data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sound pressure spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Drainage instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Service space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
2
1 Specifications
3
1
VRV
®
Systems IndoorUnit FXAQ-MAVE9 WallMounte
1-1 TECHNICAL SPECIFICATIONS FXAQ20MAVE9 FXAQ25MAVE9 FXAQ32MAVE9 FXAQ40MAVE9 FXAQ50MAVE9 FXAQ63MAVE9
Capacity Cooling kW 2.2 2.8 3.6 4.5 5.6 7.1
Heating kW 2.5 3.2 4.0 5.0 6.3 8.0
Power Input (50Hz) Cooling kW 0.016 0.022 0.027 0.020 0.027 0.050
Heating kW 0.024 0.027 0.032 0.020 0.032 0.060
Power Input (60Hz) Cooling kW 0.016 0.022 0.027 0.020 0.027 0.050
Heating kW 0.024 0.027 0.032 0.020 0.032 0.060
Casing Colour white (3.0Y8.5/0.5)
Dimensions Unit Height mm 290
Width mm 795 795 795 1,050 1,050 1,050
Depth mm 230
Weight Unit kg 11 11 11 14 14 14
Heat Exchanger Dimensions Nr of Rows 2
Fin Pitch mm 1.40
Face Area m² 0.161 0.161 0.161 0.213 0.213 0.213
Nr of Stages 14
Fan Type Cross flow fan
Quantity 1
Cooling High m³/min 7.5 8 9 12 15 19
Low m³/min 4.5 5 5.5 9 12 14
Fan Motor Quantity 1
Model QCL9661M QCL9661M QCL9661M QCL9686M QCL9686M QCL9686M
Output(high)W404040434343
Drive Direct drive
Refrigerant Name R-410A
Cooling Sound Pressure High dBA 35.0 36.0 37.0 39.0 42.0 46.0
Low dBA 29.0 29.0 29.0 34.0 36.0 39.0
Piping connections Liquid (OD) Type Flare connection
Diameter mm 6.35 6.35 6.35 6.35 6.35 9.52
Gas Type Flare connection
Diameter mm 12.7 12.7 12.7 12.7 12.7 15.9
Drain Diameter mm VP13 (I.D. 13/O.D. 18)
Heat Insulation Foamed polystyrene/foamed polyethylene
Air Filter Washable resin net
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse
Standard Accessories Installation and operation manual
Installation panel
Paper pattern for installation
Insulation tape
Clamps
Screws
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature
: 35°CDB, equivalent refrigerant piping : 5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB,
6°CWB, equivalent refrigerant piping : 5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.

•VRV
®Systems • Indoor Units 3
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
1 Specifications
3
1
1-2 ELECTRICAL SPECIFICATIONS (50HZ) FXAQ20MAVE9 FXAQ25MAVE9 FXAQ32MAVE9 FXAQ40MAVE9 FXAQ50MAVE9 FXAQ63MAVE9
Power Supply Name VE
Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps (MCA) A 0.3 0.4 0.4 0.4 0.4 0.6
Maximum fuse amps (MFA) A 15
Full load amps (FLA) A 0.2 0.3 0.3 0.3 0.3 0.5
Voltage range Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals
is not below or above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA is smaller than or equal to 4 x FLA
Next lower standard fuse rating minimum 15A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
1-3 ELECTRICAL SPECIFICATIONS (60HZ) FXAQ20MAVE9 FXAQ25MAVE9 FXAQ32MAVE9 FXAQ40MAVE9 FXAQ50MAVE9 FXAQ63MAVE9
Power Supply Name VE
Phase 1~
Frequency Hz 60
Voltage V 220
Current Minimum circuit amps (MCA) A 0.3 0.3 0.4 0.4 0.4 0.6
Maximum fuse amps (MFA) A 15
Full load amps (FLA) A 0.2 0.2 0.3 0.3 0.3 0.5
Voltage range Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals
is not below or above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA is smaller than or equal to 4 x FLA
Next lower standard fuse rating minimum 15A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
4
2 Safety device settings
3
2
3 Options
4 Control systems
FXAQ20MV FXAQ25MV FXAQ32MV FXAQ40MV FXAQ50MV FXAQ63MV
PC BOARD FUSE 250V 3A
4D034906F
FXAQ20MV FXAQ25MV FXAQ32MV FXAQ40MV FXAQ50MV FXAQ63MV
DRAIN PUMP KIT K-KDU572CVE
ED39-226B
Individual control systems
Centralised control systems
Others
3D023974L
NOTES
1 Installation box is necessary for each adapter marked with #
2 Up to 2 adapters can be fixed per installation box.
3 Only 1 installation box can be installed per indoor unit.
FXAQ20MV FXAQ25MV FXAQ32MV FXAQ40MV FXAQ50MV FXAQ63MV
Wired remote control BRC1D52
Infrared remote control Heat pump BRC7E618
Cooling only BRC7E619
FXAQ20MV FXAQ25MV FXAQ32MV FXAQ40MV FXAQ50MV FXAQ63MV
Remote control DCS302C51
Unified on/off control DCS301B51
Schedule timer DST301B51
FXAQ20MV FXAQ25MV FXAQ32MV FXAQ40MV FXAQ50MV FXAQ63MV
Wiring adapter for electrical appendices (1) KRP2A51#
Wiring adapter for electrical appendices (2) KRP4A51#
Installation box for adapter PCB (2) (3) KRP4A93
Remote sensor KRCS01-1
Electrical box with earth terminal (3 blocks) KJB311A
Electrical box with earth terminal (2 blocks) KJB212A
Noise filter (for electromagnetic interface use only) KEK26-1
External control adapter for outdoor units (installation on indoor unit) DTA104A61#
Adapter for multi tenant DTA114A61

•VRV
®Systems • Indoor Units 5
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
5 Capacity tables
5 - 1 Cooling capacity tables
3
5
FXAQ-MV
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit size Nominal
capacity
Outdoor
air temp.
Indoor air temperature
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDBTCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
20 2.2 10.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.9 1.9
12.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.9 1.9
14.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.8 1.9
16.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.8 1.9
18.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.7 1.9
20.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.7 1.9
21.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.7 1.9
23.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 1.9 2.6 1.9
25.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 1.9 2.6 1.9
27.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.5 1.9 2.6 1.8
29.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.5 1.9 2.5 1.8
31.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.4 1.9 2.5 1.8
33.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.4 1.9 2.5 1.8
35.0 1.5 1.5 1.8 1.8 2.1 1.9 2.21.92.31.92.41.92.41.8
37.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.3 1.8 2.4 1.7
39.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.2 1.9 2.3 1.8 2.3 1.7
25 2.8 10.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.7 2.3
12.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.6 2.2
14.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.6 2.3
16.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.5 2.2
18.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.5 2.2
20.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.4 2.2
21.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.4 2.2
23.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.3 2.3 3.4 2.2
25.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.3 2.2 3.3 2.2
27.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.2 2.2 3.3 2.1
29.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.2 2.2 3.2 2.1
31.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.1 2.2 3.2 2.1
33.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.1 2.2 3.1 2.1
35.0 1.9 1.8 2.3 2.0 2.6 2.2 2.82.23.02.23.02.23.12.1
37.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 2.9 2.2 3.0 2.1 3.0 2.0
39.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 2.9 2.2 2.9 2.1 3.0 2.0
32 3.6 10.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.7 2.8
12.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.7 2.8
14.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.6 2.8
16.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.6 2.8
18.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.5 2.7
20.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.4 2.7
21.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.4 2.7
23.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.2 2.8 4.3 2.7
25.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.2 2.8 4.3 2.6
27.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.1 2.7 4.2 2.6
29.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.1 2.7 4.2 2.6
31.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.0 2.7 4.1 2.6
33.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 3.9 2.6 4.0 2.5
35.0 2.4 2.2 2.9 2.4 3.4 2.6 3.62.73.82.73.92.64.02.5
37.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.7 2.6 3.8 2.6 3.9 2.5
39.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.7 2.6 3.8 2.6 3.8 2.5
40 4.5 10.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.9 3.6
12.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.8 3.5
14.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.8 3.5
16.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.7 3.5
18.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.6 3.4
20.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.5 3.4
21.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.5 3.4
23.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.3 3.6 5.4 3.3
25.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.2 3.6 5.3 3.3
27.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.2 3.5 5.3 3.3
29.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.1 3.5 5.2 3.2
31.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.0 3.4 5.1 3.2
33.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 4.9 3.4 5.0 3.1
35.0 3.0 2.9 3.6 3.3 4.2 3.7 4.53.54.73.64.93.45.03.1
37.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.7 3.5 4.8 3.3 4.9 3.1
39.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.6 3.5 4.7 3.3 4.8 3.0

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
6
5 Capacity tables
5 - 1 Cooling capacity tables
3
5
FXAQ-MV
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit size Nominal
capacity
Outdoor
air temp.
Indoor air temperature
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDBTCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
50 5.6 10.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.4 4.4
12.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.3 4.3
14.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.2 4.3
16.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.1 4.3
18.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.0 4.2
20.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 6.9 4.2
21.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 6.8 4.2
23.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.6 4.4 6.7 4.1
25.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.5 4.3 6.6 4.1
27.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.4 4.3 6.6 4.0
29.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.3 4.2 6.5 4.0
31.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.2 4.2 6.4 3.9
33.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.1 4.2 6.3 3.9
35.0 3.8 3.2 4.5 3.7 5.2 4.1 5.64.25.94.36.04.16.23.8
37.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 5.8 4.3 5.9 4.1 6.1 3.8
39.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 5.7 4.2 5.8 4.0 6.0 3.8
63 7.1 10.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.3 5.3
12.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.2 5.3
14.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.1 5.2
16.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.0 5.2
18.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 8.8 5.2
20.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 8.7 5.1
21.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 8.7 5.1
23.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.4 5.5 8.5 5.0
25.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.3 5.5 8.4 5.0
27.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.1 5.4 8.3 4.9
29.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.0 5.4 8.2 4.9
31.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 7.9 5.3 8.1 4.8
33.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 7.8 5.2 7.9 4.8
35.0 4.8 4.1 5.7 4.6 6.6 5.1 7.15.37.55.47.75.27.84.7
37.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.4 5.3 7.5 5.1 7.7 4.7
39.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.2 5.3 7.4 5.1 7.6 4.6

•VRV
®Systems • Indoor Units 7
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
5 Capacity tables
5 - 2 Heating capacity tables
3
5
FXAQ-MV
Unit Size Nominal capacity Outdoor
air temperature
Indoor air temperature °CDB
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWBkWkWkWkWkWkW
20 2.5 -19.8 -20.0 1.5 1.5 1.5 1.5 1.5 1.5
-18.8 -19.0 1.5 1.5 1.5 1.5 1.5 1.5
-16.7 -17.0 1.6 1.6 1.6 1.6 1.6 1.6
-14.7 -15.0 1.7 1.7 1.7 1.7 1.7 1.7
-12.6 -13.0 1.8 1.8 1.8 1.8 1.8 1.8
-10.5 -11.0 1.9 1.9 1.9 1.9 1.9 1.9
-9.5 -10.0 1.9 1.9 1.9 1.9 1.9 1.9
-8.5 -9.1 2.0 2.0 1.9 1.9 1.9 1.9
-7.0 -7.6 2.0 2.0 2.0 2.0 2.0 2.0
-5.0 -5.6 2.1 2.1 2.1 2.1 2.1 2.1
-3.0 -3.7 2.2 2.2 2.2 2.2 2.2 2.2
0.0 -0.7 2.3 2.3 2.3 2.3 2.3 2.2
3.0 2.2 2.5 2.5 2.4 2.4 2.3 2.2
5.0 4.1 2.5 2.5 2.5 2.4 2.3 2.2
7.0 6.0 2.6 2.6 2.5 2.4 2.3 2.2
9.0 7.9 2.7 2.7 2.5 2.4 2.3 2.2
11.0 9.8 2.8 2.7 2.5 2.4 2.3 2.2
13.0 11.8 2.8 2.7 2.5 2.4 2.3 2.2
15.0 13.7 2.8 2.7 2.5 2.4 2.3 2.2
25 3.2 -19.8 -20.0 1.9 1.9 1.9 1.9 1.9 1.9
-18.8 -19.0 1.9 1.9 1.9 1.9 1.9 1.9
-16.7 -17.0 2.1 2.1 2.0 2.0 2.0 2.0
-14.7 -15.0 2.2 2.2 2.2 2.2 2.2 2.1
-12.6 -13.0 2.3 2.3 2.3 2.3 2.3 2.3
-10.5 -11.0 2.4 2.4 2.4 2.4 2.4 2.4
-9.5 -10.0 2.5 2.4 2.4 2.4 2.4 2.4
-8.5 -9.1 2.5 2.5 2.5 2.5 2.5 2.5
-7.0 -7.6 2.6 2.6 2.6 2.6 2.6 2.6
-5.0 -5.6 2.7 2.7 2.7 2.7 2.7 2.7
-3.0 -3.7 2.8 2.8 2.8 2.8 2.8 2.8
0.0 -0.7 3.0 3.0 3.0 3.0 3.0 2.8
3.0 2.2 3.1 3.1 3.1 3.1 3.0 2.8
5.0 4.1 3.3 3.2 3.2 3.1 3.0 2.8
7.0 6.0 3.4 3.4 3.2 3.1 3.0 2.8
9.0 7.9 3.5 3.4 3.2 3.1 3.0 2.8
11.0 9.8 3.6 3.4 3.2 3.1 3.0 2.8
13.0 11.8 3.6 3.4 3.2 3.1 3.0 2.8
15.0 13.7 3.6 3.4 3.2 3.1 3.0 2.8
32 4.0 -19.8 -20.0 2.4 2.4 2.3 2.3 2.3 2.3
-18.8 -19.0 2.4 2.4 2.4 2.4 2.4 2.4
-16.7 -17.0 2.6 2.6 2.6 2.6 2.6 2.5
-14.7 -15.0 2.7 2.7 2.7 2.7 2.7 2.7
-12.6 -13.0 2.9 2.8 2.8 2.8 2.8 2.8
-10.5 -11.0 3.0 3.0 3.0 3.0 3.0 3.0
-9.5 -10.0 3.1 3.1 3.1 3.1 3.0 3.0
-8.5 -9.1 3.1 3.1 3.1 3.1 3.1 3.1
-7.0 -7.6 3.2 3.2 3.2 3.2 3.2 3.2
-5.0 -5.6 3.4 3.4 3.4 3.4 3.4 3.4
-3.0 -3.7 3.5 3.5 3.5 3.5 3.5 3.5
0.0 -0.7 3.7 3.7 3.7 3.7 3.7 3.5
3.0 2.2 3.9 3.9 3.9 3.9 3.7 3.5
5.0 4.1 4.1 4.1 4.0 3.9 3.7 3.5
7.0 6.0 4.2 4.2 4.0 3.9 3.7 3.5
9.0 7.9 4.3 4.3 4.0 3.9 3.7 3.5
11.0 9.8 4.5 4.3 4.0 3.9 3.7 3.5
13.0 11.8 4.5 4.3 4.0 3.9 3.7 3.5
15.0 13.7 4.5 4.3 4.0 3.9 3.7 3.5
40 5.0 -19.8 -20.0 3.0 2.9 2.9 2.9 2.9 2.9
-18.8 -19.0 3.0 3.0 3.0 3.0 3.0 3.0
-16.7 -17.0 3.2 3.2 3.2 3.2 3.2 3.2
-14.7 -15.0 3.4 3.4 3.4 3.4 3.4 3.4
-12.6 -13.0 3.6 3.6 3.6 3.5 3.5 3.5
-10.5 -11.0 3.7 3.7 3.7 3.7 3.7 3.7
-9.5 -10.0 3.8 3.8 3.8 3.8 3.8 3.8
-8.5 -9.1 3.9 3.9 3.9 3.9 3.9 3.9
-7.0 -7.6 4.0 4.0 4.0 4.0 4.0 4.0
-5.0 -5.6 4.2 4.2 4.2 4.2 4.2 4.2
-3.0 -3.7 4.4 4.4 4.4 4.4 4.4 4.4
0.0 -0.7 4.7 4.6 4.6 4.6 4.6 4.4
3.0 2.2 4.9 4.9 4.9 4.8 4.7 4.4
5.0 4.1 5.1 5.1 5.0 4.8 4.7 4.4
7.0 6.0 5.2 5.2 5.0 4.8 4.7 4.4
9.0 7.9 5.4 5.3 5.0 4.8 4.7 4.4
11.0 9.8 5.6 5.3 5.0 4.8 4.7 4.4
13.0 11.8 5.6 5.3 5.0 4.8 4.7 4.4
15.0 13.7 5.6 5.3 5.0 4.8 4.7 4.4

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
8
5 Capacity tables
5 - 2 Heating capacity tables
3
5
FXAQ-MV
Unit Size Nominal capacity Outdoor
air temperature
Indoor air temperature °CDB
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWBkWkWkWkWkWkW
50 6.3 -19.8 -20.0 3.7 3.7 3.7 3.7 3.7 3.7
-18.8 -19.0 3.8 3.8 3.8 3.8 3.8 3.8
-16.7 -17.0 4.1 4.0 4.0 4.0 4.0 4.0
-14.7 -15.0 4.3 4.3 4.3 4.2 4.2 4.2
-12.6 -13.0 4.5 4.5 4.5 4.5 4.5 4.5
-10.5 -11.0 4.7 4.7 4.7 4.7 4.7 4.7
-9.5 -10.0 4.8 4.8 4.8 4.8 4.8 4.8
-8.5 -9.1 4.9 4.9 4.9 4.9 4.9 4.9
-7.0 -7.6 5.1 5.1 5.1 5.1 5.1 5.1
-5.0 -5.6 5.3 5.3 5.3 5.3 5.3 5.3
-3.0 -3.7 5.5 5.5 5.5 5.5 5.5 5.5
0.0 -0.7 5.9 5.9 5.8 5.8 5.8 5.5
3.0 2.2 6.2 6.2 6.2 6.1 5.9 5.5
5.0 4.1 6.4 6.4 6.3 6.1 5.9 5.5
7.0 6.0 6.6 6.6 6.3 6.1 5.9 5.5
9.0 7.9 6.8 6.7 6.3 6.1 5.9 5.5
11.0 9.8 7.0 6.7 6.3 6.1 5.9 5.5
13.0 11.8 7.1 6.7 6.3 6.1 5.9 5.5
15.0 13.7 7.1 6.7 6.3 6.1 5.9 5.5
63 8.0 -19.8 -20.0 4.7 4.7 4.7 4.7 4.7 4.7
-18.8 -19.0 4.9 4.9 4.8 4.8 4.8 4.8
-16.7 -17.0 5.1 5.1 5.1 5.1 5.1 5.1
-14.7 -15.0 5.4 5.4 5.4 5.4 5.4 5.4
-12.6 -13.0 5.7 5.7 5.7 5.7 5.7 5.7
-10.5 -11.0 6.0 6.0 6.0 6.0 6.0 5.9
-9.5 -10.0 6.1 6.1 6.1 6.1 6.1 6.1
-8.5 -9.1 6.3 6.3 6.2 6.2 6.2 6.2
-7.0 -7.6 6.5 6.5 6.4 6.4 6.4 6.4
-5.0 -5.6 6.8 6.7 6.7 6.7 6.7 6.7
-3.0 -3.7 7.0 7.0 7.0 7.0 7.0 7.0
0.0 -0.7 7.5 7.4 7.4 7.4 7.4 7.0
3.0 2.2 7.9 7.8 7.8 7.7 7.5 7.0
5.0 4.1 8.1 8.1 8.0 7.7 7.5 7.0
7.0 6.0 8.4 8.4 8.0 7.7 7.5 7.0
9.0 7.9 8.7 8.5 8.0 7.7 7.5 7.0
11.0 9.8 8.9 8.5 8.0 7.7 7.5 7.0
13.0 11.8 9.0 8.5 8.0 7.7 7.5 7.0
15.0 13.7 9.0 8.5 8.0 7.7 7.5 7.0

•VRV
®Systems • Indoor Units 9
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
6 Dimensional drawing & centre of gravity
6 - 1 Dimensional drawing
3
6
FXAQ20,25,32MV
3D034903C
Approx. 400
232
230
290
50 or more
(Required space)
Dimensions for
full open front panel
Piping direction
Piping direction
626
795
155
125
Outside line
ø 80 hole ø 80 hole
107
60
14.5
44
105
44
62
98
Piping direction
50 or more
(Required space)
120 or less
30 or more (required space) 90 or more
(required space)
2500 or more
For installation
in high places
(Filter part)
(Filter part) (Flexible tube part)
Name plate Note 2
Approx. 475
Approx. 460
Approx. 415
Approx. 290
(Piping and wiring intake)
Mounting location
NOTES
1 Name plate location: right side surface of casing
2 In case of using an infrared remote control, this position will be
a signal receiver. Refer to the drawing of an infrared remote
control in detail.
Nr Part name Description
1 Front panel
2 Front grill
3Airoutlet
4 Gas pipe ø 12.7 Flare connection
5 Liquid pipe ø 6.4 Flare connection
6 Drain hose VP13 (External dia. ø18)
7 Grounding terminal M4
8 Right side pipe connection hole
9 Left side pipe connection hole
FXAQ40,50MV
3D038539B
Approx. 400
232
230
290
50 or more
(Required space)
Dimensions for
full open front panel
Piping direction
Piping direction
894
1,050
155
125
Outside line
ø 80 hole ø 80 hole
104
60
14.5
44
105
44
52
98
Piping direction 50 or more
(Required space)
120 or less
30 or more (required space) 90 or more
(required space)
2,500 or more
For installation
in high places
(Filter part)
(Filter part) (Flexible tube part)
Name plate Note 2
Approx. 475
Approx. 460
Approx. 415
Approx. 290
(Piping and wiring intake)
Mounting location
NOTES
1 Name plate location: right side surface of casing.
2 In case of using an infrared remote control, this position will be
a signal receiver. Refer to the drawing of the infrared remote
control in detail.
Nr Part name Description
1 Front panel
2 Front grill
3Airoutlet
4 Gas pipe ø 12.7 Flare connection
5 Liquid pipe ø 6.4 Flare connection
6 Drain hose VP13 (External dia. ø 18)
7 Grounding terminal M4
8 Right side pipe connection hole
9 Left side pipe connection hole

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
10
6 Dimensional drawing & centre of gravity
6 - 1 Dimensional drawing
3
6
FXAQ63MV
3D038541B
Approx. 400
232
230
50 or more
(Required space)
Dimensions for
full open front
panel
Piping direction
Piping direction
894
1,050
155
125
Outside line
ø 80 hole ø 80 hole
104
60
14.5
44
105
44
52
98
Piping direction
50 or more
(Required space)
120 or less
30 or more (required space) 90 or more
(required space)
2,500 or more
For installation
in high places
(Filter part)
(Filter part)
Name plate Note 2
Approx. 475
Approx. 460
Approx. 415
(Piping and wiring intake)
Mounting location
NOTES
1 Name plate location: right side surface of casing.
2 In case of using an infrared remote control, this position will be
a signal receiver. Refer to the drawing of the infrared remote
control in detail.
Nr Part name Description
1 Front panel
2 Front grill
3Airoutlet
4 Gas pipe ø 15.9 Flare connection
5 Liquid pipe ø 9.5 Flare connection
6Drainhose VP13
7 Grounding terminal M4
8 Right side pipe connection hole
9 Left side pipe connection hole

•VRV
®Systems • Indoor Units 11
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
7 Piping diagram
3
7
FXAQ-MV
DU220-602J
Liquid pipe connection port
Filter Filter
Electronic
expansion valve
Fan
Gas pipe connection port
Refrigerant flow
Cooling
Heating
Heat exchanger
Piping connection diameters
Model Gas Liquid
FXAQ20,25,32,40,50MV ø12.7 ø6.4
FXAQ63MV ø15.9 ø9.5

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
12
8 Wiring diagram
8 - 1 Wiring diagram
3
8
FXAQ-MV
3D060858A
NOTES
1 In case of using central remote control, connect it to the unit in accordance with the attached instruction manual.
2 When connecting the input wires from outside, forced off or on/off control operation can be selected by remote control.
In details, refer to the installation manual attached to the unit.
3 Remote control model varies according to the combination system confirm enineering materials and catalogs, etc. before connecting.
4 Confirm the method of setting the selector switch (SS1, SS2) of wired remote control and ingrared rempte control by installation manual and
engineering data, etc.
5 X24A is connected when the infrared remote control kit is being used.
Indoor unit Y1E Electronic expansion valve Wired remote control
A1P Printed circuit board PC Power Circuit R1T Thermistor (Air)
F1U Fuse (훾, 3A, 250V) Receiver / display unit (attached to infrared remote control) SS1 Selector switch (main/sub)
HAP Light emitting diode
(service monitor-green)
A2P Printed circuit board Connector for optional parts
A3P Printed circuit board R1T Thermistor (Air)
M1F Motor (indoor fan) BS1 Push button (On/Off) SS1 Selector switch (main/sub)
M1S Motor (swing flap) H1P Light emitting diode (On-red) Connector for optional parts
R1T Thermistor (air) H2P Light emitting diode (timer-green) X15A Connector (float switch)
R2T Thermistor (coil liquid pipe) H3P Light emitting diode (filter sign-red) X35A Connector (group control adapter)
R3T Thermistor (coil gas pipe) H4P Light emitting diode (defrost-orange) X38A Connector (adapter for multi tenant)
X1M Terminal block SS1 Selector switch (Wireless adress set)
X2M Terminal block
: Terminal Colors: RED: Red PRP: Purple ORG: Orange
: Connector BLK: Black GRN: Green
: Connector WHT: White BLU: Blue
: Field wiring YLW: Yellow PNK: Pink
POWER SUPPLY
Control box
(indoor unit)
Input from outside note 3
Transmission wiring
Central remote control note 1
Note: 5 Receiver/Display unit
(Infrared remote control)
Wired remote control
Side
Front
Note: 5
,

•VRV
®Systems • Indoor Units 13
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
9 Sound data
9 - 1 Sound level data
3
9
FXAQ-MV
NOTES
1 Reference acoustic pressure 0 dB = 20 Pa.
2 Measuring place: anechoic chamber.
3 Operating noise differs with operation and ambient conditions.
*Data were not available at the time of publication
Model Sound pressure level Sound power level
H L Measuring location
FXAQ20MV 35 29 *
FXAQ25MV 36 29 *
FXAQ32MV 37 29 *
FXAQ40MV 39 34 *
FXAQ50MV 42 36 *
FXAQ63MV 46 39 *
Microphone

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
14
9 Sound data
9 - 2 Sound pressure spectrum
3
9
NOTES
1Overall(dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB; Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB; Outdoor temperature: 7°C DB, 6°C WB
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operating noise differs with operation and ambient conditions.
FXAQ20MV 4D037087D
Ocatve band center frequency (Hz)
HI
LOW
Approximate
treshold hearing for
continuous noise
Ocatve band sound pressure level dB (0dB=0.0002μ bar)
Scale Mode
Hi Low
A35.029.0
C39.534.5
Mike
1m
1m
NOTES
1Overall(dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB; Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB; Outdoor temperature: 7°C DB, 6°C WB
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operating noise differs with operation and ambient conditions.
FXAQ25MV 4D037088D
Ocatve band center frequency (Hz)
HI
LOW
Approximate
treshold hearing for
continuous noise
Ocatve band sound pressure level dB (0dB=0.0002μ bar)
Scale Mode
Hi Low
A36.029.0
C40.534.0
Mike
1m
1m
NOTES
1Overall(dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB; Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB; Outdoor temperature: 7°C DB, 6°C WB
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operating noise differs with operation and ambient conditions.
FXAQ32MV 4D037089D
Ocatve band center frequency (Hz)
HI
LOW
Approximate
treshold hearing for
continuous noise
Ocatve band sound pressure level dB (0dB=0.0002μ bar)
Scale Mode
Hi Low
A37.029.0
C41.534.5
Mike
1m
1m
NOTES
1Overall(dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB; Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB; Outdoor temperature: 7°C DB, 6°C WB
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operating noise differs with operation and ambient conditions.
FXAQ40MV 4D038513A
Ocatve band center frequency (Hz)
HI
LOW
Approximate
treshold hearing for
continuous noise
Ocatve band sound pressure level dB (0dB=0.0002μ bar)
Scale Mode
Hi Low
A39.034.0
C41.039.0
Mike
1m
1m

•VRV
®Systems • Indoor Units 15
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
9 Sound data
9 - 2 Sound pressure spectrum
3
9
NOTES
1Overall(dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB; Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB; Outdoor temperature: 7°C DB, 6°C WB
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operating noise differs with operation and ambient conditions.
FXAQ50MV 4D038514A
Ocatve band center frequency (Hz)
HI
LOW
Approximate
treshold hearing for
continuous noise
Ocatve band sound pressure level dB (0dB=0.0002μ bar)
Scale Mode
Hi Low
A42.036.0
C44.039.0
Mike
1m
1m
NOTES
1Overall(dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB; Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB; Outdoor temperature: 7°C DB, 6°C WB
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operating noise differs with operation and ambient conditions.
FXAQ63MV 4D038515A
Ocatve band center frequency (Hz)
HI
LOW
Approximate
treshold hearing for
continuous noise
Ocatve band sound pressure level dB (0dB=0.0002μ bar)
Scale Mode
Hi Low
A46.039.0
C48.042.0
Mike
1m
1m

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
16
10 Installation
10 - 1 Drainage instructions
3
10
Install the drain piping
• The drain pipe should be short with a downward slope and should prevent the formation of air pockets.
• When extending the drain hose, use a commercially available drain extension hose, and be sure to insulate the extended section of the drain hose which is indoors.
• Make sure the diameter of the piping is the same as the piping (hard vinyl chloride, nominal diameter 13mm) or bigger.
• When directly connecting a hard vinyl chloride pipe joint (nominal diameter 13mm) to the drain hose connected to the indoor unit (i.e. for embedded piping,
etc.), use a commercially available hard vinyl chloride pipe joint (nominal diameter 13mm).
Make sure the drain hose is at a
downward slope.
Make sure the tip does not go
underwater even when water is added.
Drain hose
(Downward slope)
Drain hose
Insulating tape (accessory)
Insulating tube (locally procured)
Indoor unit drain hose
Extension drain piping (locally procured)
Drain hose connected to the indoor unit Commercially available hard vinyl chloride pipe joint
(nominal diameter 13mm)
Commercially available hard vinyl chloride pipe (nominal
diameter 13mm)

•VRV
®Systems • Indoor Units 17
• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
10 Installation
10 - 2 Service space
3
10
1 Select an installation site where the following conditions are fulfilled and that meets with your customer’s approval.
• In the upper space (including the back of the ceiling) of the indoor unit where there is no possible dripping of water from the refrigerant pipe, drain pipe,
water pipe, etc.
• Where the wall is strong enough to bear the indoor unit weight.
• Where sufficient clearance for installation and maintenance can be ensured.
• Where optimum air distribution can be ensured.
• Where nothing blocks the air passage.
• Where condensation can be properly drained.
• Where the wall is not significantly tilted.
• Where not exposed to combustible gases.
• Where piping between indoor and outdoor units is possible within the allowable limit. (Refer to the installation manual of the outdoor unit.)
• Keep the indoor and outdoor units, power cable and transmission wiring, at least 1 m from TVs and radios, to prevent distorted pictures and static.
(Depending on the type and source of the electrical waves, static may be heard even when more than 1 m away.)
• Install the indoor unit no less than 2.5 m above the floor. Where unavoidably lower, take what measures are necessary to keep hands out of the air inlet.
2 Consider whether the location where the unit will be installed can support the full weight of the unit, and reinforce it with
boards and beams, etc. if needed before proceeding with the installation. Also, reinforce the location to prevent vibration
and noise before installing.
3 The indoor unit may not be directly installed on the wall. Use the attached installation panel before installing the unit.
≥50 ≥50
≤120
Space required for installation (mm)
≥90
≥30
Floor
Obstruction
≥2500 (from floor)
for installation
in high place.

• Indoor Units • Wall Mounted Unit • FXAQ-MAVE9
•VRV
®Systems • Indoor Units
18
10 Installation
10 - 2 Service space
3
10

Daikin Europe N.V. is approved by LRQA for its Quality
Management System in accordance with the ISO9001
standard. ISO9001 pertains to quality assurance regarding
design, development, manufacturing as well as to services
related to the product.
Daikin units comply with the European regulations that
guarantee the safety of the product.
Prepared in Belgium by Lannoo (www.lannooprint.be), a company whose concern for the environmont is set in the EMAS and ISO 14001 systems. Responsible Editor: Daikin Europe N.V., Zandvoordestraat 300, B- 8400 Oostende
The present publication is drawn up by way of information only and does not
constitute an offer binding upon Daikin Europe N.V.. Daikin Europe N.V. has
compiled the content of this publication to the best of its knowledge. No
express or implied warranty is given for the completeness, accuracy,
reliability or fitness for particular purpose of its content and the products and
services presented therein. Specifications are subject to change without
prior notice. Daikin Europe N.V. explicitly rejects any liability for any direct or
indirect damage, in the broadest sense, arising from or related to the use
and/or interpretation of this publication. All content is copyrighted by Daikin
Europe N.V..
VRV®products are not within the scope of the Eurovent
certification programme.
Naamloze Vennootschap
Zandvoordestraat 300
B-8400 Oostende, Belgium
www.daikin.eu
BTW: BE 0412 120 336
RPR Oostende
Daikin’s unique position as a manufacturer of air
conditioning equipment, compressors and
refrigerants has led to its close involvement in
environmental issues. For several years Daikin has
had the intension to become a leader in the provision
of products that have limited impact on the
environment. This challenge demands the eco design
and development of a wide range of products and an
energy management system, resulting in energy
conservation and a reduction of waste.
ISO14001 assures an effective environmental
management system in order to help protect human health
and the environment from the potential impact of our
activities, products and services and to assist in
maintaining and improving the quality of the environment.
