Daikin J Series User manual

Service
Manual
Inverter Pair
Wall Mounted Type J-Series
SiBE041101
[Applied Models]
zInverter Pair : Cooling Only
zInverter Pair : Heat Pump

SiBE041101
iTable of Contents
Inverter Pair
Wall Mounted Type
J-Series
zCooling Only
Indoor Unit
FTXS20J2V1B
FTXS25J2V1B
FTXS35J2V1B
FTXS42J2V1B
FTXS50J2V1B
Outdoor Unit
RKS20J2V1B
RKS25J2V1B
RKS35J2V1B
RKS42J2V1B
RKS50J2V1B
zHeat Pump
Indoor Unit
FTXS20J2V1B
FTXS25J2V1B
FTXS35J2V1B
FTXS42J2V1B
FTXS50J2V1B
Outdoor Unit
RXS20J2V1B
RXS25J2V1B
RXS35J2V1B
RXS42J2V1B
RXS50J2V1B

SiBE041101
Table of Contents ii
1. Introduction ............................................................................................ vi
1.1 Safety Cautions ....................................................................................... vi
1.2 Used Icons ...............................................................................................x
Part 1 List of Functions ................................................................ 1
1. Functions.................................................................................................2
1.1 Cooling Only.............................................................................................2
1.2 Heat Pump ...............................................................................................3
Part 2 Specifications .................................................................... 4
1. Specifications ..........................................................................................5
1.1 Cooling Only.............................................................................................5
1.2 Heat Pump ...............................................................................................7
Part 3 Printed Circuit Board Connector Wiring Diagram ........... 10
1. Indoor Unit.............................................................................................11
2. Outdoor Unit..........................................................................................14
2.1 RK(X)S20/25/35J2V1B...........................................................................14
2.2 RK(X)S42J2V1B.....................................................................................16
2.3 RK(X)S50J2V1B.....................................................................................18
Part 4 Function and Control........................................................20
1. Main Functions......................................................................................21
1.1 Temperature Control ..............................................................................21
1.2 Frequency Principle................................................................................21
1.3 Airflow Direction Control.........................................................................23
1.4 Fan Speed Control for Indoor Units........................................................24
1.5 Program Dry Operation ..........................................................................25
1.6 Automatic Operation...............................................................................26
1.7 Thermostat Control.................................................................................27
1.8 NIGHT SET Mode ..................................................................................28
1.9 ECONO Operation .................................................................................29
1.10 2-Area INTELLIGENT EYE Operation ...................................................30
1.11 Inverter POWERFUL Operation .............................................................32
1.12 Other Functions......................................................................................33
2. Function of Thermistor ..........................................................................34
3. Control Specification .............................................................................35
3.1 Mode Hierarchy ......................................................................................35
3.2 Frequency Control..................................................................................36
3.3 Controls at Mode Changing / Start-up....................................................38
3.4 Discharge Pipe Temperature Control.....................................................40
3.5 Input Current Control..............................................................................41
3.6 Freeze-up Protection Control .................................................................42
3.7 Heating Peak-cut Control .......................................................................42
3.8 Outdoor Fan Control...............................................................................43
3.9 Liquid Compression Protection Function................................................43
3.10 Defrost Control .......................................................................................44
3.11 Electronic Expansion Valve Control .......................................................45
3.12 Malfunctions ...........................................................................................48

SiBE041101
iii Table of Contents
Part 5 Operation Manual ............................................................. 49
1. System Configuration............................................................................50
2. Operation Manual..................................................................................51
2.1 Remote Controller ..................................................................................51
2.2 AUTO · DRY · COOL · HEAT · FAN Operation ......................................52
2.3 Adjusting the Airflow Direction................................................................54
2.4 COMFORT AIRFLOW and INTELLIGENT EYE Operation....................56
2.5 POWERFUL Operation ..........................................................................60
2.6 OUTDOOR UNIT QUIET Operation.......................................................61
2.7 ECONO Operation .................................................................................62
2.8 OFF TIMER Operation ...........................................................................63
2.9 ON TIMER Operation .............................................................................64
2.10 WEEKLY TIMER Operation ...................................................................65
Part 6 Service Diagnosis............................................................. 73
1. Troubleshooting with LED .....................................................................75
1.1 Indoor Unit..............................................................................................75
1.2 Outdoor Unit ...........................................................................................75
2. Problem Symptoms and Measures .......................................................76
3. Service Check Function ........................................................................77
3.1 ARC452 Series.......................................................................................77
4. Troubleshooting ....................................................................................80
4.1 Error Codes and Description ..................................................................80
4.2 Indoor Unit PCB Abnormality .................................................................81
4.3 Freeze-up Protection Control or Heating Peak-cut Control....................82
4.4 Fan Motor (DC Motor) or Related Abnormality.......................................84
4.5 Thermistor or Related Abnormality (Indoor Unit)....................................86
4.6 Signal Transmission Error (between Indoor Unit and Outdoor Unit) ......87
4.7 Unspecified Voltage (between Indoor Unit and Outdoor Unit) ...............88
4.8 Outdoor Unit PCB Abnormality...............................................................89
4.9 OL Activation (Compressor Overload) ...................................................92
4.10 Compressor Lock ...................................................................................93
4.11 DC Fan Lock ..........................................................................................94
4.12 Input Overcurrent Detection ...................................................................95
4.13 Four Way Valve Abnormality..................................................................96
4.14 Discharge Pipe Temperature Control.....................................................98
4.15 High Pressure Control in Cooling .........................................................100
4.16 Compressor System Sensor Abnormality ............................................101
4.17 Position Sensor Abnormality ................................................................103
4.18 DC Voltage / Current Sensor Abnormality (20/25/35/42 Class) ...........106
4.19 CT or Related Abnormality (50 Class)..................................................107
4.20 Thermistor or Related Abnormality (Outdoor Unit)...............................109
4.21 Electrical Box Temperature Rise..........................................................111
4.22 Radiation Fin Temperature Rise ..........................................................113
4.23 Output Overcurrent Detection ..............................................................115
4.24 Refrigerant Shortage ............................................................................117
4.25 Low-voltage Detection or Over-voltage Detection................................120
4.26 Signal Transmission Error on Outdoor Unit PCB (50 Class Only) .......122
5. Check ..................................................................................................123
5.1 Fan Motor Connector Output Check ....................................................123

SiBE041101
Table of Contents iv
5.2 Electronic Expansion Valve Check.......................................................123
5.3 Four Way Valve Performance Check ...................................................124
5.4 Thermistor Resistance Check ..............................................................125
5.5 Installation Condition Check.................................................................126
5.6 Discharge Pressure Check...................................................................126
5.7 Outdoor Fan System Check .................................................................127
5.8 Power Supply Waveforms Check.........................................................127
5.9 Inverter Units Refrigerant System Check .............................................127
5.10 Capacitor Voltage Check......................................................................128
5.11 Power Module Check ...........................................................................128
5.12 “Inverter Checker” Check .....................................................................129
5.13 Rotation Pulse Check on the Outdoor Unit PCB ..................................131
5.14 Main Circuit Short Check......................................................................132
Part 7 Removal Procedure ........................................................ 133
1. Indoor Unit...........................................................................................134
1.1 Removal of Air Filters ...........................................................................134
1.2 Removal of Front Panel........................................................................136
1.3 Removal of Front Grille ........................................................................138
1.4 Removal of Horizontal Blades / Vertical Blades ...................................141
1.5 Removal of Electrical Box ....................................................................144
1.6 Removal of PCBs .................................................................................147
1.7 Removal of Indoor Heat Exchanger .....................................................152
1.8 Removal of Swing Motors ....................................................................155
1.9 Removal of Fan Motor..........................................................................159
2. Outdoor Unit - RK(X)S20/25/35J2V1B................................................162
2.1 Removal of Outer Panels / Fan Motor..................................................162
2.2 Removal of Electrical Box ....................................................................171
2.3 Removal of PCBs .................................................................................174
2.4 Removal of Reactor / Partition Plate ....................................................182
2.5 Removal of Sound Blankets .................................................................184
2.6 Removal of Four Way Valve.................................................................186
2.7 Removal of Compressor.......................................................................189
3. Outdoor Unit - RK(X)S42J2V1B..........................................................191
3.1 Removal of Outer Panels .....................................................................191
3.2 Removal of Electrical Box ....................................................................193
3.3 Removal of PCB...................................................................................198
3.4 Removal of Sound Blankets .................................................................203
3.5 Removal of Outdoor Fan / Fan Motor...................................................205
3.6 Removal of Thermistors .......................................................................208
3.7 Removal of Four Way Valve / Electronic Expansion Valve ..................209
3.8 Removal of Compressor.......................................................................212
4. Outdoor Unit - RK(X)S50J2V1B..........................................................215
4.1 Removal of Outer Panels .....................................................................215
4.2 Removal of Outdoor Fan / Fan Motor...................................................219
4.3 Removal of Electrical Box ....................................................................223
4.4 Removal of PCB...................................................................................228
4.5 Removal of Sound Blankets / Thermistors ...........................................231
4.6 Removal of Four Way Valve.................................................................233
4.7 Removal of Electronic Expansion Valve...............................................234
4.8 Removal of Compressor.......................................................................235

SiBE041101
vTable of Contents
Part 8 Trial Operation and Field Settings................................. 238
1. Pump Down Operation........................................................................239
2. Forced Cooling Operation ...................................................................240
3. Trial Operation ....................................................................................242
4. Field Settings ......................................................................................243
4.1 Model Type Setting ..............................................................................243
4.2 When 2 Units are Installed in 1 Room..................................................243
4.3 Standby Electricity Saving....................................................................244
4.4 Facility Setting Jumper and Switch
(cooling at low outdoor temperature)....................................................245
4.5 Jumper and Switch Settings.................................................................246
5. Application of Silicon Grease to a Power Transistor and
a Diode Bridge ....................................................................................247
Part 9 Appendix......................................................................... 248
1. Piping Diagrams..................................................................................249
1.1 Indoor Unit............................................................................................249
1.2 Outdoor Unit .........................................................................................250
2. Wiring Diagrams..................................................................................254
2.1 Indoor Unit............................................................................................254
2.2 Outdoor Unit .........................................................................................254

SiBE041101 Introduction
vi
1. Introduction
1.1 Safety Cautions
Cautions and
Warnings
Be sure to read the following safety cautions before conducting repair work.
The caution items are classified into “ Warning” and “ Caution”. The “ Warning”
items are especially important since they can lead to death or serious injury if they are not
followed closely. The “ Caution” items can also lead to serious accidents under some
conditions if they are not followed. Therefore, be sure to observe all the safety caution items
described below.
About the pictograms
This symbol indicates the item for which caution must be exercised.
The pictogram shows the item to which attention must be paid.
This symbol indicates the prohibited action.
The prohibited item or action is shown in the illustration or near the symbol.
This symbol indicates the action that must be taken, or the instruction.
The instruction is shown in the illustration or near the symbol.
After the repair work is complete, be sure to conduct a test operation to ensure that the
equipment operates normally, and explain the cautions for operating the product to the
customer.
1.1.1 Cautions Regarding Safety of Workers
Warning
Be sure to disconnect the power cable plug from the plug socket before
disassembling the equipment for repair.
Working on the equipment that is connected to the power supply may cause an
electrical shock.
If it is necessary to supply power to the equipment to conduct the repair or
inspecting the circuits, do not touch any electrically charged sections of the
equipment.
If the refrigerant gas is discharged during the repair work, do not touch the
discharged refrigerant gas.
The refrigerant gas may cause frostbite.
When disconnecting the suction or discharge pipe of the compressor at the
welded section, evacuate the refrigerant gas completely at a well-ventilated
place first.
If there is a gas remaining inside the compressor, the refrigerant gas or
refrigerating machine oil discharges when the pipe is disconnected, and it may
cause injury.
If the refrigerant gas leaks during the repair work, ventilate the area. The
refrigerant gas may generate toxic gases when it contacts flames.
The step-up capacitor supplies high-voltage electricity to the electrical
components of the outdoor unit.
Be sure to discharge the capacitor completely before conducting repair work.
A charged capacitor may cause an electrical shock.
Do not start or stop the air conditioner operation by plugging or unplugging the
power cable plug.
Plugging or unplugging the power cable plug to operate the equipment may
cause an electrical shock or fire.

Introduction SiBE041101
vii
Be sure to wear a safety helmet, gloves, and a safety belt when working at a
high place (more than 2 m). Insufficient safety measures may cause a fall
accident.
In case of R-410A refrigerant models, be sure to use pipes, flare nuts and tools
for the exclusive use of the R-410A refrigerant.
The use of materials for R-22 refrigerant models may cause a serious accident
such as a damage of refrigerant cycle as well as an equipment failure.
Warning
Caution
Do not repair the electrical components with wet hands.
Working on the equipment with wet hands may cause an electrical shock.
Do not clean the air conditioner by splashing water.
Washing the unit with water may cause an electrical shock.
Be sure to provide the grounding when repairing the equipment in a humid or
wet place, to avoid electrical shocks.
Be sure to turn off the power switch and unplug the power cable when cleaning
the equipment.
The internal fan rotates at a high speed, and cause injury.
Be sure to conduct repair work with appropriate tools.
The use of inappropriate tools may cause injury.
Be sure to check that the refrigerating cycle section has cooled down enough
before conducting repair work.
Working on the unit when the refrigerating cycle section is hot may cause
burns.
Use the welder in a well-ventilated place.
Using the welder in an enclosed room may cause oxygen deficiency.

SiBE041101 Introduction
viii
1.1.2 Cautions Regarding Safety of Users
Warning
Be sure to use parts listed in the service parts list of the applicable model and
appropriate tools to conduct repair work. Never attempt to modify the
equipment.
The use of inappropriate parts or tools may cause an electrical shock,
excessive heat generation or fire.
If the power cable and lead wires have scratches or deteriorated, be sure to
replace them.
Damaged cable and wires may cause an electrical shock, excessive heat
generation or fire.
Do not use a joined power cable or extension cable, or share the same power
outlet with other electrical appliances, since it may cause an electrical shock,
excessive heat generation or fire.
Be sure to use an exclusive power circuit for the equipment, and follow the local
technical standards related to the electrical equipment, the internal wiring
regulations, and the instruction manual for installation when conducting
electrical work.
Insufficient power circuit capacity and improper electrical work may cause an
electrical shock or fire.
Be sure to use the specified cable for wiring between the indoor and outdoor
units. Make the connections securely and route the cable properly so that there
is no force pulling the cable at the connection terminals.
Improper connections may cause excessive heat generation or fire.
When wiring between the indoor and outdoor units, make sure that the terminal
cover does not lift off or dismount because of the cable.
If the cover is not mounted properly, the terminal connection section may cause
an electrical shock, excessive heat generation or fire.
Do not damage or modify the power cable.
Damaged or modified power cable may cause an electrical shock or fire.
Placing heavy items on the power cable, and heating or pulling the power cable
may damage the cable.
Do not mix air or gas other than the specified refrigerant (R-410A / R-22) in the
refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
If the refrigerant gas leaks, be sure to locate the leaking point and repair it
before charging the refrigerant. After charging refrigerant, make sure that there
is no refrigerant leak.
If the leaking point cannot be located and the repair work must be stopped, be
sure to perform pump-down and close the service valve, to prevent the
refrigerant gas from leaking into the room. The refrigerant gas itself is
harmless, but it may generate toxic gases when it contacts flames, such as fan
and other heaters, stoves and ranges.
When relocating the equipment, make sure that the new installation site has
sufficient strength to withstand the weight of the equipment.
If the installation site does not have sufficient strength and if the installation
work is not conducted securely, the equipment may fall and cause injury.

Introduction SiBE041101
ix
Check to make sure that the power cable plug is not dirty or loose, then insert
the plug into a power outlet securely.
If the plug has dust or loose connection, it may cause an electrical shock or fire.
Be sure to install the product correctly by using the provided standard
installation frame.
Incorrect use of the installation frame and improper installation may cause the
equipment to fall, resulting in injury.
For unitary type
only
Be sure to install the product securely in the installation frame mounted on the
window frame.
If the unit is not securely mounted, it may fall and cause injury.
For unitary type
only
When replacing the coin battery in the remote controller, be sure to disposed
of the old battery to prevent children from swallowing it.
If a child swallows the coin battery, see a doctor immediately.
Warning
Caution
Installation of a leakage breaker is necessary in some cases depending on the
conditions of the installation site, to prevent electrical shocks.
Do not install the equipment in a place where there is a possibility of
combustible gas leaks.
If the combustible gas leaks and remains around the unit, it may cause a fire.
Check to see if the parts and wires are mounted and connected properly, and
if the connections at the soldered or crimped terminals are secure.
Improper installation and connections may cause excessive heat generation,
fire or an electrical shock.
If the installation platform or frame has corroded, replace it.
Corroded installation platform or frame may cause the unit to fall, resulting in
injury.
Check the grounding, and repair it if the equipment is not properly grounded.
Improper grounding may cause an electrical shock.

SiBE041101 Introduction
x
1.2 Used Icons
Icons are used to attract the attention of the reader to specific information. The meaning of each
icon is described in the table below:
Be sure to measure the insulation resistance after the repair, and make sure
that the resistance is 1 MΩor higher.
Faulty insulation may cause an electrical shock.
Be sure to check the drainage of the indoor unit after the repair.
Faulty drainage may cause the water to enter the room and wet the furniture
and floor.
Do not tilt the unit when removing it.
The water inside the unit may spill and wet the furniture and floor.
Be sure to install the packing and seal on the installation frame properly.
If the packing and seal are not installed properly, water may enter the room and
wet the furniture and floor.
For unitary type
only
Caution
Icon Type of
Information
Description
Note:
Note A “note” provides information that is not indispensable, but may
nevertheless be valuable to the reader, such as tips and tricks.
Caution
Caution A “caution” is used when there is danger that the reader, through
incorrect manipulation, may damage equipment, loose data, get
an unexpected result or has to restart (part of) a procedure.
Warning
Warning A “warning” is used when there is danger of personal injury.
Reference A “reference” guides the reader to other places in this binder or
in this manual, where he/she will find additional information on a
specific topic.

SiBE041101
1List of Functions
Part 1
List of Functions
1. Functions.................................................................................................2
1.1 Cooling Only.............................................................................................2
1.2 Heat Pump ...............................................................................................3

SiBE041101 Functions
List of Functions 2
1. Functions
1.1 Cooling Only
Category Functions
FTXS20/25/35/42J2V1B RKS20/25/35/42J2V1B FTXS50J2V1B RKS50J2V1B
Category Functions
FTXS20/25/35/42J2V1B RKS20/25/35/42J2V1B FTXS50J2V1B RKS50J2V1B
Basic
Function
Inverter (with Inverter Power Control) {{ Health &
Clean
Air-Purifying Filter — —
Operation Limit for Cooling (°CDB)
–10
~46
★
–10
~46
★
Photocatalytic Deodorizing Filter — —
Operation Limit for Heating (°CWB) — — Air-Purifying Filter with Photocatalytic
Deodorizing Function ——
PAM Control {{
Standby Electricity Saving {—Titanium Apatite Photocatalytic
Air-Purifying Filter {{
Compressor Oval Scroll Compressor — —
Swing Compressor {{ Air Filter (Prefilter) {{
Rotary Compressor — — Wipe-Clean Flat Panel {{
Reluctance DC Motor {{ Washable Grille — —
Comfortable
Airflow
Power-Airflow Flap — — MOLD PROOF Operation — —
Power-Airflow Dual Flaps {{ Good-Sleep Cooling Operation — —
Power-Airflow Diffuser — — Timer WEEKLY TIMER Operation {{
Wide-Angle Louvers {{ 24-Hour ON/OFF TIMER {{
Vertical Auto-Swing (Up and Down) {{ NIGHT SET Mode {{
Horizontal Auto-Swing (Right and Left) {{ Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
3-D Airflow {{ Self-Diagnosis (Digital, LED) Display {{
COMFORT AIRFLOW Operation {{ Wiring Error Check Function — —
Comfort
Control Auto Fan Speed {{ Anti-Corrosion Treatment of Outdoor
Heat Exchanger {{
Indoor Unit Quiet Operation {{
Flexibility Multi-Split / Split Type Compatible
Indoor Unit {{
NIGHT QUIET Mode (Automatic) — — H/P, C/O Compatible Indoor Unit {{
OUTDOOR UNIT QUIET Operation
(Manual) {{ Flexible Power Supply Correspondence — —
2-Area INTELLIGENT EYE Operation {{
Chargeless 10
m
10
m
INTELLIGENT EYE Operation — —
Quick Warming Function (Preheating
Operation) — — Either Side Drain (Right or Left) {{
Hot-Start Function — — Power Selection — —
Automatic Defrosting — — Remote
Control
5-Rooms Centralized Controller (Option) {{
Operation Automatic Operation — — Remote Control Adaptor
(Normal Open Pulse Contact) (Option) {{
Program Dry Operation {{
Fan Only {{ Remote Control Adaptor
(Normal Open Contact) (Option) {{
Lifestyle
Convenience
New POWERFUL Operation
(Non-Inverter) — — DIII-NET Compatible (Adaptor) (Option) {{
Inverter POWERFUL Operation {{ Remote
Controller
Wireless {{
Priority-Room Setting — — Wired (Option) {{
COOL / HEAT Mode Lock — —
HOME LEAVE Operation — —
ECONO Operation {{
Indoor Unit ON/OFF Button {{
Signal Receiving Sign {{
R/C with Back Light — —
Temperature Display — —
Note: {: Holding Functions
— : No Functions
★: Lower limit can be extended to –15°C by cutting
jumper (20-42 class) or turning switch (50 class).
(facility use only)

Functions SiBE041101
3List of Functions
1.2 Heat Pump
Category Functions
FTXS20/25/35/42J2V1B RXS20/25/35/42J2V1B FTXS50J2V1B RXS50J2V1B
Category Functions
FTXS20/25/35/42J2V1B RXS20/25/35/42J2V1B FTXS50J2V1B RXS50J2V1B
Basic
Function
Inverter (with Inverter Power Control) {{ Health &
Clean
Air-Purifying Filter — —
Operation Limit for Cooling (°CDB) –10
~46
–10
~46 Photocatalytic Deodorizing Filter — —
Operation Limit for Heating (°CWB) –15
~18
–15
~18
Air-Purifying Filter with Photocatalytic
Deodorizing Function ——
PAM Control {{ Titanium Apatite Photocatalytic
Air-Purifying Filter {{
Standby Electricity Saving {—
Compressor Oval Scroll Compressor — — Air Filter (Prefilter) {{
Swing Compressor {{ Wipe-Clean Flat Panel {{
Rotary Compressor — — Washable Grille — —
Reluctance DC Motor {{ MOLD PROOF Operation — —
Comfortable
Airflow
Power-Airflow Flap — — Good-Sleep Cooling Operation — —
Power-Airflow Dual Flaps {{
Timer WEEKLY TIMER Operation {{
Power-Airflow Diffuser — — 24-Hour ON/OFF TIMER {{
Wide-Angle Louvers {{ NIGHT SET Mode {{
Vertical Auto-Swing (Up and Down) {{ Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
Horizontal Auto-Swing (Right and Left) {{ Self-Diagnosis (Digital, LED) Display {{
3-D Airflow {{ Wiring Error Check Function — —
COMFORT AIRFLOW Operation {{ Anti-Corrosion Treatment of Outdoor
Heat Exchanger {{
Comfort
Control Auto Fan Speed {{
Flexibility Multi-Split / Split Type Compatible
Indoor Unit {{
Indoor Unit Quiet Operation {{ H/P, C/O Compatible Indoor Unit {{
NIGHT QUIET Mode (Automatic) — — Flexible Power Supply Correspondence — —
OUTDOOR UNIT QUIET Operation
(Manual) {{ Chargeless 10
m
10
m
2-Area INTELLIGENT EYE Operation {{ Either Side Drain (Right or Left) {{
INTELLIGENT EYE Operation — — Power Selection — —
Quick Warming Function (Preheating
Operation) {{
Remote
Control
5-Room Centralized Controller (Option) {{
Remote Control Adaptor
(Normal Open Pulse Contact) (Option) {{
Hot-Start Function {{
Automatic Defrosting {{ Remote Control Adaptor
(Normal Open Contact) (Option) {{
Operation Automatic Operation {{
Program Dry Operation {{ DIII-NET Compatible (Adaptor) (Option) {{
Fan Only {{
Remote
Controller
Wireless {{
Lifestyle
Convenience
New POWERFUL Operation
(Non-Inverter) — — Wired (Option) {{
Inverter POWERFUL Operation {{
Priority-Room Setting — —
COOL / HEAT Mode Lock — —
HOME LEAVE Operation — —
ECONO Operation {{
Indoor Unit ON/OFF Button {{
Signal Receiving Sign {{
R/C with Back Light — —
Temperature Display — —
Note: {: Holding Functions
— : No Functions

SiBE041101
Specifications 4
Part 2
Specifications
1. Specifications ..........................................................................................5
1.1 Cooling Only.............................................................................................5
1.2 Heat Pump ...............................................................................................7

Specifications SiBE041101
5Specifications
1. Specifications
1.1 Cooling Only
50 Hz, 220 - 230 - 240 V
Note: The data are based on the conditions shown in the table below.
Model Indoor Unit FTXS20J2V1B FTXS25J2V1B FTXS35J2V1B
Outdoor Unit RKS20J2V1B RKS25J2V1B RKS35J2V1B
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.5 (1.3 ~ 3.2) 3.5 (1.4 ~ 4.0)
Btu/h 6,800 (4,400 ~ 9,600) 8,500 (4,400 ~ 10,900) 11,900 (4,800 ~ 13,600)
kcal/h 1,720 (1,120 ~ 2,410) 2,150 (1,120 ~ 2,750) 3,010 (1,200 ~ 3,440)
Moisture Removal L/h 0.9 1.2 1.9
Running Current (Rated) A 2.6 - 2.5 - 2.4 3.1 - 2.9 - 2.8 4.4 - 4.2 - 4.0
Power Consumption
Rated (Min. ~ Max.) W 450 (320 ~ 810) 535 (320 ~ 810) 860 (350 ~ 1,190)
Power Factor % 78.7 - 78.3 - 78.1 78.4 - 80.2 - 79.6 88.8 - 89.0 - 89.6
COP (Rated) W/W 4.44 (4.06 ~ 3.95) 4.67 (4.06 ~ 3.95) 4.07 (4.00 ~ 3.36)
Piping
Connections
Liquid mm φ 6.4 φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5 φ 9.5
Drain mm φ 18.0 φ 18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20 20 20
Max. lnterunit Height Difference m 15 15 15
Chargelessm101010
Amount of Additional Charge of
Refrigerant g/m202020
Indoor Unit FTXS20J2V1B FTXS25J2V1B FTXS35J2V1B
Front Panel Color White White White
Airflow Rate
H
m³/min
(cfm)
9.4 (332) 10.8 (381) 11.4 (403)
M 7.4 (261) 7.9 (279) 8.7 (307)
L 5.5 (194) 5.2 (184) 5.8 (205)
SL 4.1 (145) 3.7 (131) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
MotorOutputW232323
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.09 - 0.08 - 0.08 0.12 - 0.12 - 0.11
Power Consumption (Rated) W 18 - 18 - 18 18 - 18 - 18 26 - 26 - 26
Power Factor % 90.9 - 97.8 - 93.8 90.9 - 97.8 - 93.8 98.5 - 94.2 - 98.5
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366 289 × 870 × 366
Weight kg 9 9 10
Gross Weight kg 13 13 14
Operation
Sound H / M / L / SL dB(A) 38 / 32 / 25 / 22 41 / 33 / 25 / 22 45 / 37 / 29 / 23
Sound Power dB(A) 54 57 61
Outdoor Unit RKS20J2V1B RKS25J2V1B RKS35J2V1B
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD 1YC23AEXD
Motor Output W 600 600 600
Refrigerant
Oil
Type FVC50K FVC50K FVC50K
Charge L 0.375 0.375 0.375
Refrigerant Type R-410A R-410A R-410A
Charge kg 0.80 1.00 1.20
Airflow Rate Hm³/min
(cfm)
36.2 (1,278) 33.5 (1,183) 36.0 (1,271)
SL 32.7 (1,155) 30.1 (1,063) 30.1 (1,063)
Fan Type Propeller Propeller Propeller
MotorOutputW232323
Running Current (Rated) A 2.5- 2.4 - 2.3 3.0 - 2.8 - 2.7 4.3 - 4.1 - 3.9
Power Consumption (Rated) W 432 - 432 - 432 517 - 517 - 517 834 - 834 - 834
Power Factor % 78.5 - 78.3 - 78.3 78.3 - 80.3 - 79.8 88.2 - 88.4 - 89.1
Starting Current A 2.6 3.1 4.4
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364 612 × 906 × 364
Weight kg 32 34 34
Gross Weight kg 35 38 38
Operation
Sound H / SL dB(A) 46 / 43 46 / 43 48 / 44
Sound Power H dB(A) 61 61 63
Drawing No. 3D070569A 3D070570A 3D070571A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB 5 m

SiBE041101 Specifications
Specifications 6
50 Hz, 220 - 230 - 240 V
Note: The data are based on the conditions shown in the table below.
Model Indoor Unit FTXS42J2V1B FTXS50J2V1B
Outdoor Unit RKS42J2V1B RKS50J2V1B
Capacity
Rated (Min. ~ Max.)
kW 4.2 (1.7 ~ 5.0) 5.0 (1.7 ~ 5.3)
Btu/h 14,300 (5,800 ~ 17,100) 17,100 (5,800 ~ 18,100)
kcal/h 3,010 (1,460 ~ 4,300) 4,300 (1,460 ~ 4,560)
Moisture Removal L/h 2.3 2.8
Running Current (Rated) A 6.1 - 5.8 - 5.6 6.8 - 6.5 - 6.2
Power Consumption
Rated (Min. ~ Max.) W 1,210 (440 ~ 2,330) 1,460 (440 ~ 1,810)
Power Factor % 90.2 - 90.7 - 90.0 97.6 - 97.7 - 98.1
COP (Rated) W/W 3.47 (3.86 ~ 2.24) 3.42 (3.86 ~ 2.24)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 12.7
Drain mm φ 18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 30
Max. Interunit Height Difference m 15 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant g/m 20 20
Indoor Unit FTXS42J2V1B FTXS50J2V1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
11.3 (399) 11.6 (410)
M 9.0 (318) 9.2 (325)
L 6.8 (240) 7.0 (247)
SL 5.9 (208) 6.0 (212)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.11 - 0.11 - 0.11 0.12 - 0.12 - 0.11
Power Consumption (Rated) W 24 - 24 - 24 26 - 26 - 26
Power Factor % 99.2 - 94.9 - 90.9 98.5 - 94.2 - 98.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight kg 10 10
Gross Weight kg 14 14
Operation
Sound H / M / L / SL dB(A) 45 / 39 / 33 / 30 46 / 40 / 34 / 31
Sound Power dB(A) 61 62
Outdoor Unit RKS42J2V1B RKS50J2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant Type R-410A R-410A
Charge kg 1.30 1.70
Airflow Rate Hm³/min
(cfm)
37.3 (1,317) 50.9 (1,797)
SL 30.6 (1,080) 48.9 (1,727)
Fan Type Propeller Propeller
Motor Output W 50 53
Running Current (Rated) A 6.0 - 5.7 - 5.5 6.7 - 6.4 - 6.1
Power Consumption (Rated) W 1,186 - 1,186 - 1,186 1,434 - 1,434 - 1,434
Power Factor % 89.8 - 90.5 - 89.8 97.3 - 97.4 - 98.0
Starting Current A 6.1 6.8
Dimensions (H × W × D) mm 550 × 765 × 285 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 797 × 960 × 390
Weight kg 39 47
Gross Weight kg 45 52
Operation
Sound H / SL dB(A) 48 / 44 48 / 44
Sound Power H dB(A) 63 63
Drawing No. 3D070572A 3D070573A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB 5 m

Specifications SiBE041101
7Specifications
1.2 Heat Pump
50 Hz, 220 - 230 - 240 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS20J2V1B
Outdoor Unit RXS20J2V1B
Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.7 (1.3 ~ 4.3)
Btu/h 6,800 (4,400 ~ 9,600) 9,200 (4,400 ~ 14,700)
kcal/h 1,720 (1,120 ~ 2,410) 2,320 (1,120 ~ 3,700)
Moisture Removal L/h 0.9 —
Running Current (Rated) A 2.6 - 2.5 - 2.4 3.5 - 3.4 - 3.2
Power Consumption
Rated (Min. ~ Max.) W 450 (320 ~ 810) 610 (310 ~ 1,290)
Power Factor % 78.7 - 78.3 - 78.1 79.2 - 78.0 - 79.4
COP (Rated) W/W 4.44 (4.06 ~ 3.95) 4.43 (4.19 ~ 3.64)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 9.5
Drain mm φ 18.0
Heat Insulation Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20
Max. lnterunit Height Difference m 15
Chargeless m 10
Amount of Additional Charge of
Refrigerant g/m 20
Indoor Unit FTXS20J2V1B
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
9.4 (332) 9.9 (350)
M 7.4 (261) 8.2 (290)
L 5.5 (194) 6.6 (233)
SL 4.1 (145) 6.2 (219)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21
Power Factor % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366
Weight kg 9
Gross Weight kg 13
Operation
Sound H / M / L / SL dB(A) 38 / 32 / 25 / 22 38 / 33 / 28 / 25
Sound Power dB(A) 54 54
Outdoor Unit RXS20J2V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23AEXD
Motor Output W 600
Refrigerant
Oil
Type FVC50K
Charge L 0.375
Refrigerant Type R-410A
Charge kg 0.80
Airflow Rate Hm³/min
(cfm)
36.2 (1,278) 30.6 (1,080)
SL 32.7 (1,155) 28.5 (1,006)
Fan Type Propeller
Motor Output W 23
Running Current (Rated) A 2.5 - 2.4 - 2.3 3.4 - 3.3 - 3.1
Power Consumption (Rated) W 432 - 432 - 432 589 - 589 - 589
Power Factor % 78.5 - 78.3 - 78.3 78.7 - 77.6 - 79.2
Starting Current A 3.5
Dimensions (H × W × D) mm 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364
Weight kg 32
Gross Weight kg 35
Operation
Sound H / SL dB(A) 46 / 43 47 / 44
Sound Power H dB(A) 61 62
Drawing No. 3D070564A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m

SiBE041101 Specifications
Specifications 8
50 Hz, 220 - 230 - 240 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS25J2V1B FTXS35J2V1B
Outdoor Unit RXS25J2V1B RXS35J2V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.5 (1.3 ~ 3.2) 3.3 (1.3 ~ 4.7) 3.5 (1.4 ~ 4.0) 4.0 (1.4 ~ 5.2)
Btu/h 8,500 (4,400 ~ 10,900) 11,600 (4,400 ~ 16,000) 11,900 (4,800 ~ 13,600) 13,600 (4,800 ~ 17,700)
kcal/h 2,150 (1,120 ~ 2,750) 2,840 (1,120 ~ 4,040) 3,010 (1,200 ~ 3,440) 3,440 (1,200 ~ 4,470)
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 3.1 - 2.9 - 2.8 4.0 - 3.9 - 3.7 4.4 - 4.2 - 4.0 4.8 - 4.6 - 4.4
Power Consumption
Rated (Min. ~ Max.) W 535 (320 ~ 810) 710 (310 ~ 1,290) 860 (350 ~ 1,190) 950 (340 ~ 1,460)
Power Factor % 78.4 - 80.2 - 79.6 80.7 - 79.2 - 80.0 88.8 - 89.0 - 89.6 90.0 - 89.8 - 90.0
COP (Rated) W/W 4.67 (4.06 ~ 3.95) 4.65 (4.19 ~ 3.64) 4.07 (4.00 ~ 3.36) 4.21 (4.12 ~ 3.56)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ9.5 φ9.5
Drain mm φ 18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20 20
Max. lnterunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant g/m 20 20
Indoor Unit FTXS25J2V1B FTXS35J2V1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
10.8 (381) 11.9 (420) 11.4 (403) 12.4 (438)
M 7.9 (279) 9.1 (321) 8.7 (307) 9.5 (335)
L 5.2 (184) 6.4 (226) 5.8 (205) 6.8 (240)
SL 3.7 (131) 5.9 (208) 4.4 (155) 6.0 (212)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21 26 - 26 - 26 28 - 28 - 28
Power Factor % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight kg 9 10
Gross Weight kg 13 14
Operation
Sound H / M / L / SL dB(A) 41 / 33 / 25 / 22 42 / 35 / 28 / 25 45 / 37 / 29 / 23 45 / 39 / 29 / 26
Sound Power dB(A) 57 58 61 61
Outdoor Unit RXS25J2V1B RXS35J2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant Type R-410A R-410A
Charge kg 1.00 1.20
Airflow Rate Hm³/min
(cfm)
33.5 (1,183) 28.3 (999) 36.0 (1,271) 28.3 (999)
SL 30.1 (1,063) 25.6 (904) 30.1 (1,063) 25.6 (904)
Fan Type Propeller Propeller
Motor Output W 23 23
Running Current (Rated) A 3.0 - 2.8 - 2.7 3.9 - 3.8 - 3.6 4.3 - 4.1 - 3.9 4.7 - 4.5 - 4.3
Power Consumption (Rated) W 517 - 517 - 517 689 - 689 - 689 834 - 834 - 834 922 - 922 - 922
Power Factor % 78.3 - 80.3 - 79.8 80.3 - 78.8 - 79.7 88.2 - 88.4 - 89.1 89.2 - 89.1 - 89.3
Starting Current A 4.0 4.8
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight kg 34 34
Gross Weight kg 38 38
Operation
Sound H / SL dB(A) 46 / 43 47 / 44 48 / 44 48 / 45
Sound Power H dB(A) 61 62 63 63
Drawing No. 3D070565A 3D070566A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m

Specifications SiBE041101
9Specifications
50 Hz, 220 - 230 - 240 V
Note: The data are based on the conditions shown in the table below.
Mode
Indoor Unit FTXS42J2V1B FTXS50J2V1B
Outdoor Unit RXS42J2V1B RXS50J2V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 4.2 (1.7 ~ 5.0) 5.4 (1.7 ~ 6.0) 5.0 (1.7 ~ 5.3) 5.8 (1.7 ~ 6.5)
Btu/h 14,300 (5,800 ~ 17,100) 18,400 (5,800 ~ 20,500) 17,100 (5,800 ~ 18,100) 19,800 (5,800 ~ 22,200)
kcal/h 3,010 (1,460 ~ 4,300) 3,440 (1,460 ~ 5,160) 4,300 (1,460 ~ 4,560) 4,990 (1,460 ~ 5,590)
Moisture Removal L/h 2.3 — 2.8 —
Running Current
Rated A 6.1 - 5.8 - 5.6 7.2 - 6.9 - 6.6 6.8 - 6.5 - 6.2 7.1 - 6.8 - 6.5
Power Consumption
Rated (Min. ~ Max.) W 1,210 (440 ~ 2,230) 1,450 (400 ~ 1,980) 1,460 (440 ~ 1,810) 1,530 (400 ~ 2,000)
Power Factor % 90.2 - 90.7 - 90.0 91.5 - 91.4 - 91.5 97.6 - 97.7 - 98.1 98.0 - 97.8 - 98.1
COP
Rated (Min. ~ Max.) W/W 3.47 (3.86 ~ 2.24) 3.72 (4.25 ~ 3.03) 3.42 (3.86 ~ 2.24) 3.79 (4.25 ~ 3.03)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 12.7
Drain mm φ 18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 30
Max. Interunit Height Difference m 15 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant g/m 20 20
Indoor Unit FTXS42J2V1B FTXS50J2V1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
11.3 (399) 12.2 (431) 11.6 (410) 12.1 (427)
M 9.0 (318) 9.7 (343) 9.2 (325) 9.8 (346)
L 6.8 (240) 7.3 (258) 7.0 (247) 7.6 (268)
SL 5.9 (208) 6.4 (228) 6.0 (212) 6.7 (237)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.11 - 0.11 - 0.11 0.14 - 0.14 - 0.13 0.12 - 0.12 - 0.11 0.15 - 0.14 - 0.14
Power Consumption (Rated) W 24 - 24 - 24 30 - 30 - 30 26 - 26 - 26 32 - 32 - 32
Power Factor % 99.2 - 94.9 - 90.9 97.4 - 93.2 - 96.2 98.5 - 94.2 - 98.5 97.0 - 99.4 - 95.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight kg 10 10
Gross Weight kg 14 14
Operation
Sound H / M / L / SL dB(A) 45 / 39 / 33 / 30 45 / 39 / 33 / 30 46 / 40 / 34 / 31 47 / 41 / 34 / 31
Sound Power dB(A) 61 61 62 63
Outdoor Unit RXS42J2V1B RXS50J2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant Model R-410A R-410A
Charge kg 1.30 1.70
Airflow Rate Hm³/min
(cfm)
37.3 (1,317) 31.3 (1,105) 50.9 (1,797) 45.0 (1,589)
SL 30.6 (1,080) 27.2 (960) 48.9 (1,727) 43.1 (1,522)
Fan Type Propeller Propeller
Motor Output W 50 53
Running Current (Rated) A 6.0 - 5.7 - 5.5 7.1 - 6.8 - 6.5 6.7 - 6.4 - 6.1 7.0 - 6.7 - 6.4
Power Consumption (Rated) W 1,186 - 1,186 - 1,186 1,420 - 1,420 - 1,420 1,434 - 1,434 - 1,434 1,498 - 1,498 - 1,498
Power Factor (Rated) % 89.8 - 90.5 - 89.8 90.9 - 90.8 - 91.0 97.3 - 97.4 - 98.0 97.3 - 97.2 - 97.5
Starting Current A 7.2 7.1
Dimensions (H × W × D) mm 550 × 765 × 285 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 797 × 960 × 390
Weight kg 39 48
Gross Weight kg 45 53
Operation
Sound H / SL dB(A) 48 / 44 48 / 45 48 / 44 48 / 45
Sound Power H dB(A) 63 63 63 63
Drawing No. 3D070567A 3D070568A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m
